2006 PONTIAC GRAND PRIX Owners Manual

{CAUTION:
Storing the tire inator kit or other equipment
in the passenger compartment of the vehicle
could cause injury. In a sudden stop or
collision, loose equipment could strike
someone. Store the tire inator kit in the
proper place.
11. Disconnect the compressor inator hose and wrap
the hose in the bottom of the inator kit.
12. Place the equipment in the original location in the
trunk of your vehicle.
Removal and Installation of the
Sealant Canister
To remove the sealant canister, do the following:
1. Unlock the air compressor inator hose from the
sealant canister by pulling the lever up.
2. Disconnect the air compressor inator hose from
the sealant canister.
3. Unwrap the sealant lling hose from the
compressor.
5-87

4. Turn the sealant canister so the inator lling hose
is aligned with the slot in the compressor.
5. Lift the sealant canister from the air compressor
and replace with a new sealant canister. See
your GM dealer for more information.To install a new sealant canister, do the following:
1. Align the sealant lling hose with the slot in the air
compressor.
2. Push the sealant canister down and rotate it
clockwise.
3. Wrap the sealant lling hose around the air
compressor channel to stow it in its original location.
4. Push the air compressor inator hose onto the
sealant canister inlet and push the lever down.
Changing a Flat Tire
If a tire goes at, avoid further tire and wheel damage
by driving slowly to a level place. Turn on your vehicle’s
hazard warning ashers. SeeHazard Warning Flashers
on page 3-6for more information.
5-88

{CAUTION:
Changing a tire can be dangerous. The vehicle
can slip off the jack and roll over or fall on you
or other people. You and they could be badly
injured or even killed. Find a level place to
change your tire. To help prevent the vehicle
from moving:
1. Set the parking brake rmly.
2. Put the shift lever in PARK (P).
3. Turn off the engine and do not restart
while the vehicle is raised.
4. Do not allow passengers to remain in
the vehicle.
To be even more certain the vehicle will not
move, you should put blocks at the front and
rear of the tire farthest away from the one
being changed. That would be the tire, on the
other side, at the opposite end of the vehicle.When your vehicle has a at tire, use the following
example as a guide to assist you in the placement of
wheel blocks.
The following information will tell you next how to use
the jack and change a tire.
5-89

Removing the Spare Tire and Tools
The equipment needed to change a tire is located in
the trunk.
1. Open the trunk. SeeTrunk on page 2-13for more
information.
2. Remove the convenience net, if equipped, by
removing the net hook attachments.
3. Lift up the carpet.
4. Turn the center nut on
the compact spare tire
cover counterclockwise
to remove it.
5. Remove the cover.
6. Remove the compact spare tire. SeeCompact
Spare Tire on page 5-99for more information.7. Turn the nut holding the jack counterclockwise and
remove it. Then remove the jack and wrench.
5-90

8. The tools you will be using include the jack (A),
extension and protector/guide (B) and the wheel
wrench (C).
Removing the Flat Tire and
Installing the Spare Tire
Your vehicle may have aluminum wheels. If so, you will
see exposed stainless steel wheel nuts. Use the
wheel wrench to loosen all the wheel nuts. Do not
remove them yet.
Or, your vehicle may have steel wheel covers.
To remove the steel wheel covers and wheel nut caps,
loosen the plastic nut caps with the wheel wrench in
a counterclockwise direction. If needed, you can nish
loosening them with your ngers. The plastic nut
caps will not come off.
5-91

Use the at end of the wheel wrench and pry along the
edge of the cover until it comes off. The edge of the
wheel cover could be sharp, so do not try to remove it
with your bare hands. Do not drop the cover or lay
it face down, as it could become scratched or damaged.
Once you have removed the wheel cover, use the
following procedure to remove the at tire and install the
spare tire.
1. Turn the wheel wrench
once on each wheel nut
to loosen them. Do not
remove them yet.
2. Find the jacking location using the diagram. For
jacking at the vehicle’s front location, put the jack
lift head (C) about 6 inches (15 cm) from the
rear edge of the front wheel opening (B). Line up
the jack with the arrow (A) as shown.
5-92

For jacking at the vehicle’s rear location, put the
jack lift head (B) about 9 inches (23 cm) from
the front edge of the rear wheel opening (C). Line
up the jack with the arrow (A) as shown.
3. Put the compact spare tire near you.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
5-93

{CAUTION:
Lifting a vehicle and getting under it to do
maintenance or repairs is dangerous without
the appropriate safety equipment and training.
The jack provided with your vehicle is
designed only for changing a at tire. If it is
used for anything else, you or others could be
badly injured or killed if the vehicle slips off
the jack. Use the jack provided with your
vehicle only for changing a at tire.
4. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground for the compact spare tire to t underneath
the wheel well of the vehicle.
5. Remove all wheel nuts and take off the at tire.
5-94
