FRONT FOG LAMPPFP:26150
Component Parts and Harness Connector LocationEKS00HX5
System DescriptionEKS00HX6
The front fog lamps are controlled by lighting switch inputs to the BCM (body control module). The lighting
switch must be in the 1ST or 2ND position with the high beams OFF before the BCM will request the IPDM E/
R (intelligent power distribution module engine room) to turn the front fog lamps on. The BCM requests the
front fog lamps over the CAN communication lines to the IPDM E/R. The CPU (central processing unit) of the
IPDM E/R controls the front fog lamp relay coil ground. When energized, the relay directs power to the front
fog lamps.
OUTLINE
Power is supplied at all times:

to front fog lamp relay (located in IPDM E/R),

to ignition relay (located in IPDM E/R),

through 15A fuse (No. 52, located in IPDM E/R) and

through 20A fuse (No. 53, located in IPDM E/R)

to CPU located in IPDM E/R,

through 40A fusible link (letter g , located in the fuse and fusible link box)

to BCM terminal 70,

through 10A fuse [No. 8, located in fuse block (J/B)]

to BCM terminal 57,

through 10A fuse [No. 13, located in fuse block (J/B)]

to combination meter terminal 27.
With the ignition switch in the ON or START position, power is supplied:

to ignition relay (located in IPDM E/R),

through 10A fuse [No. 6, located in fuse block (J/B)]

to BCM terminal 38.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 20, located in fuse block (J/B)]

to BCM terminal 11.
Ground is supplied

to BCM terminal 67

through grounds M57 and M61,

to IPDM E/R terminals 39 and 59

through grounds E15 and E24.
1. IPDM E/R E46, E47 and E48 2. BCM M18 and M20 (viewed with
glove box removed)3. Combination switch (lighting switch)
M28
WKIA5554E

LT-42
FRONT FOG LAMP
Revision: June 20062007 Versa
FOG LAMP OPERATION
The front fog lamp switch is built into the lighting switch. The lighting switch must be in 1ST position or 2ND
position and front fog lamp switch must be ON position for front fog lamp operation. The fog lamp will not oper-
ate with the high beam headlamps ON.
When the front fog lamp switch is in the ON position, the BCM sends a request, via the CAN communication
lines, to the CPU of the IPDM E/R to ground the coil side of the front fog lamp relay. The front fog lamp relay
then directs power

through 15A fuse (No. 56, located in IPDM E/R)

through IPDM E/R terminal 50

to front fog lamp LH terminal 1, and

through IPDM E/R terminal 51

to front fog lamp RH terminal 1.
Ground is supplied

to front fog lamp terminal 2,

through grounds E15 and E24.
With power and grounds supplied, front fog lamps illuminate.
COMBINATION SWITCH READING FUNCTION
Refer to BCS-3, "COMBINATION SWITCH READING FUNCTION" .
EXTERIOR LAMP BATTERY SAVER CONTROL
Refer to LT- 7 6 , "EXTERIOR LAMP BATTERY SAVER CONTROL" .
CAN Communication System DescriptionEKS00HX7
Refer to LAN-4, "CAN Communication System" .

FRONT FOG LAMP
LT-47
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
5. CHECK FOG LAMP INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch OFF.
2. Disconnect front fog lamp connector.
3. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST” on “SELECT DIAG MODE” screen.
4. Select “EXTERNAL LAMPS” on “SELECT TEST ITEM” screen.
5. Touch “FOG” screen.
6. When front fog lamp relay is operating, check voltage between
front fog lamp harness connector and ground.
Without CONSULT-II
1. Turn ignition switch OFF.
2. Disconnect front fog lamp connector.
3. Start auto active test. Refer to PG-21, "
Auto Active Test" .
4. When front fog lamp relay is operating, check voltage between front fog lamp harness connector and
ground.
OK or NG
OK >> GO TO 7.
NG >> GO TO 6.
6. CHECK FOG LAMP CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector (A) and
front fog lamp harness connector (B).
OK or NG
OK >> Replace IPDM E/R. Refer to PG-29, "Removal and
Installation of IPDM E/R" .
NG >> Repair harness or connector.
(+)
(−)Voltage
Front fog lamp connector Terminal
RH E28
1 Ground Battery voltage
LH E27
(+)
(−)Voltage
Front fog lamp connector Terminal
RH E28
1 Ground Battery voltage
LH E27
PKIA6276E
CircuitAB
Continuity
Connector Terminal Connector Terminal
RH
E4751 E28
1Yes
LH 50 E27
WKIA4408E

LT-52
TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: June 20062007 Versa
Ground is supplied

to front combination lamp LH terminal 5

through grounds E15 and E24,

to rear combination lamp LH terminal 1

through grounds B7 and B19.
The BCM also sends a request, via the CAN communication lines, to the combination meter to flash the left
turn signal indicator. The unified meter control unit in the combination meter supplies ground to the left turn
signal indicator lamp and activates the audible turn signal indicator.
With power, ground and input supplied, the BCM controls the flashing of the turn signal lamps.
RH Turn Signal Lamp
When turn signal switch is moved to the right turn position, the BCM receives an input signal requesting right
turn signals to flash. The BCM then supplies power

through BCM terminal 61

to front combination lamp RH terminal 4 and

to rear combination lamp RH terminal 6.
Ground is supplied

to front combination lamp RH terminal 5

through grounds E15 and E24,

to rear combination lamp RH terminal 1

through grounds B117, B132 and B402.
The BCM also sends a request, via the CAN communication lines, to the combination meter to flash the right
turn signal indicator. The unified meter control unit in the combination meter supplies ground to the right turn
signal indicator lamp and activates the audible turn signal indicator.
With power, ground and input supplied, the BCM controls the flashing of the turn signal lamps.
HAZARD LAMP OPERATION
Power is supplied at all times

through 40A fusible link (letter g , located in fuse, fusible link and relay box)

to BCM terminal 70,

through 10A fuse [No. 8, located in fuse block (J/B)]

to BCM terminal 57,

through 10A fuse [No. 13, located in fuse block (J/B)]

to combination meter terminal 27.
Ground is supplied

to hazard switch terminal 1,

to BCM terminal 67, and

to combination meter terminals 21, 22 and 23

through grounds M57 and M61.
When hazard switch is depressed, ground is supplied

through hazard switch terminal 2

to BCM terminal 29.
BCM then supplies power

to front combination lamp LH terminal 4 and

to rear combination lamp LH terminal 6

through BCM terminal 60,

to front combination lamp RH terminal 4 and

to rear combination lamp RH terminal 6

through BCM terminal 61.
Ground is supplied

to front combination lamp LH and RH terminal 5

through grounds E15 and E24,

TURN SIGNAL AND HAZARD WARNING LAMPS
LT-53
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa

to rear combination lamp LH terminal 1

through grounds B7 and B19,

to rear combination lamp RH terminal 1

through grounds B117, B132 and D402.
The BCM also supplies input to combination meter across the CAN communication lines. This input is pro-
cessed by unified meter control unit in combination meter, which in turn supplies ground to the left and right
turn signal indicator lamps.
With power and input supplied, BCM controls flashing of hazard warning lamps.
REMOTE KEYLESS ENTRY SYSTEM OPERATION
Power is supplied at all times

through 40A fusible link (letter g , located in fuse, fusible link and relay box)

to BCM terminal 70,

through 10A fuse [No. 13, located in fuse block (J/B)]

to combination meter terminal 27.
Ground is supplied

to BCM terminal 67 and

to combination meter terminals 21, 22 and 23

through grounds M57 and M61.
When the remote keyless entry system is triggered by input from the keyfob, the BCM supplies power

through BCM terminal 60

to front combination lamp LH terminal 4 and

to rear combination lamp LH terminal 6,

through BCM terminal 61

to front turn signal lamp RH terminal 4 and

to rear combination lamp RH terminal 6.
Ground is supplied

to front combination lamp LH and RH terminals 5

through grounds E15 and E24,

to rear combination lamp LH terminal 1

through grounds B7 and B19,

to rear combination lamp RH terminal 1

through grounds B117, B132 and D402.
The BCM also supplies input to combination meter via the CAN communication lines. This input is processed
by the unified meter control unit in combination meter, which in turn supplies ground to the left and right turn
signal indicator lamps.
With power and ground supplied, BCM controls flashing of hazard warning lamps when keyfob is used to acti-
vate remote keyless entry system.
COMBINATION SWITCH READING FUNCTION
Refer toBCS-3, "COMBINATION SWITCH READING FUNCTION" .
CAN Communication System DescriptionEKS00HY1
Refer to LAN-4, "CAN Communication System" .

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-75
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
PARKING, LICENSE PLATE AND TAIL LAMPSPFP:26550
Component Parts and Harness Connector LocationEKS00HYY
System DescriptionEKS00HYZ
The control of the parking, license plate and tail lamp operation is dependent upon the position of lighting
switch. When the lighting switch is placed in the 1ST position, the BCM (body control module) receives input
signal requesting the parking, license plate and tail lamps to illuminate. This input signal is communicated to
the IPDM E/R (intelligent power distribution module engine room) via the CAN communication lines. The CPU
(central processing unit) located in the IPDM E/R controls the tail lamp relay coil. This relay, when energized,
directs power to parking, license plate and tail lamps, which then illuminate.
Power is supplied at all times

to ignition relay located in IPDM E/R,

to tail lamp relay located in IPDM E/R,

through 15A fuse (No. 52, located in IPDM E/R) and

through 20A fuse (No. 53, located in IPDM E/R)

to the CPU located in the IPDM E/R,

through 40A fusible link (letter g , located in fuse and fusible link block)

to BCM terminal 70,

through 10A fuse [No. 8, located in fuse block (J/B)],

to BCM terminal 57.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse [No. 6, located in fuse block (J/B)]

to BCM terminal 38,

to ignition relay located in IPDM E/R and

through the ignition relay

to the CPU of the IPDM E/R.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 20, located in fuse block (J/B)]

to BCM terminal 11.
Ground is supplied

to BCM terminal 67

through grounds M20 and M61,

to IPDM E/R terminals 59 and 39

through grounds E15 and E24.
OPERATION BY LIGHTING SWITCH
With the lighting switch in the 1ST or 2ND position, the BCM receives an input signal requesting parking,
license plate and tail lamps to illuminate. This input signal is communicated to the IPDM E/R via the CAN com-
munication lines. The CPU, located in the IPDM E/R, controls the tail lamp relay coil. When energized, the tail
lamp relay directs power
1. IPDM E/R E45, E46 and E48 2. BCM M18 and M20 (view with glove
box removed)3. Combination switch (lighting switch)
M28
WKIA5554E

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-83
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
5. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch OFF.
2. Disconnect front combination lamp, license plate lamp and rear combination lamp connectors.
3. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST” on “SELECT DIAG MODE” screen.
4. Select “EXTERNAL LAMPS” on “SELECT TEST ITEM” screen.
5. Touch “TAIL” on "ACTIVE TEST" screen.
6. When tail lamp relay is operating, check voltage between front combination lamp, license plate lamp and
rear combination lamp harness connector and ground.
Without CONSULT-II
1. Turn ignition switch OFF.
2. Disconnect front combination lamp, license plate lamp and rear combination lamp connectors.
3. Start auto active test. Refer to PG-21, "
Auto Active Test" .
4. When tail lamp relay is operating, check voltage between front combination lamp, license plate lamp and
rear combination lamp harness connector and ground.
OK or NG
OK >> GO TO 7.
NG >> GO TO 6.
Te r m i n a l
Voltage (+)
(−)
Front combination lamp
connectorTe r m i n a l
RH E54
6 Ground Battery voltage
LH E53
WKIA5502E
Te r m i n a l
Voltage (+)
(−)
License plate lamp
connectorTe r m i n a l
RH B17
1 Ground Battery voltage
LH B16
WKIA5503E
Terminal
Voltag e (+)
(−) Rear combination lamp
connector
(Tail lamp)Te r m i n a l
RH B107
4 Ground Battery voltage
LH B25
PK I C 111 8E

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-85
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
7. CHECK PARKING, LICENSE PLATE AND TAIL LAMPS GROUND CIRCUIT
1. Check continuity between front combination lamp harness con-
nector and ground.
2. Check continuity between license plate lamp harness connector
and ground.
3. Check continuity between rear combination lamp harness con-
nector and ground.
OK or NG
OK >> Check bulbs.
NG >> Repair harness or connector.
Parking, License Plate and Tail Lamps Do Not Turn OFF (After Approx. 10 Min-
utes)
EKS00HZB

This symptom is related to the ignition relay in IPDM E/R. Refer to PG-18, "Function of Detecting Ignition
Relay Malfunction" .

Select “BCM” on CONSULT-II. Select “HEADLAMP” on “SELECT TEST ITEM” screen and select “DATA
MONITOR” on “SELECT DIAG MODE” screen. If “LIGHT SW 1ST” is OFF when lighting switch is OFF,
replace IPDM E/R.
Front combination lamp connector Terminal
GroundContinuity
RH E54
7Yes
LH E53
WKIA5509E
License plate lamp
connectorTe r m i n a l
GroundContinuity
RH B17
2 Yes
LH B16
WKIA5510E
Rear combination lamp
connectorTe r m i n a l
GroundContinuity
RH B107
1Yes
LH B25
PKIC1029E
