WIPER RELAY
DESCRIPTION
A wiper relay is standard equipment on all models.
The wiper relay (or intermittent wipe relay) is
located in a dedicated receptacle on the bottom left of
the fuse block on the underside of the steering col-
umn (Fig. 33). The wiper relay is a conventional
International Standards Organization (ISO) micro
relay. Relays conforming to the ISO specifications
have common physical dimensions, current capaci-
ties, terminal patterns, and terminal functions. The
relay is contained within a small, rectangular,
molded plastic housing. The relay is connected to all
of the required inputs and outputs through the
instrument panel wire harness connector by five
male spade-type terminals that extend from the bot-
tom of the relay base. The ISO designation for each
terminal is molded into the base adjacent to the ter-
minal. The ISO terminal designations are as follows:
²30 (Common Feed)- This terminal is con-
nected to the movable contact point of the relay.
²85 (Coil Ground)- This terminal is connected
to the ground feed side of the relay control coil.
²86 (Coil Battery)- This terminal is connected
to the battery feed side of the relay control coil.
²87 (Normally Open)- This terminal is con-
nected to the normally open fixed contact point of the
relay.
²87A (Normally Closed)- This terminal is con-
nected to the normally closed fixed contact point of
the relay.
The wiper relay cannot be adjusted or repaired. If
the relay is damaged or faulty, it must be replaced.
OPERATION
The wiper relay (or intermittent wipe relay) is an
electromechanical switch that uses a low current
input from the intermittent wipe logic circuitry
within the fuse block underneath the steering column
to control a high current output to the low speed
brush of the wiper motor. The movable common feed
contact point is held against the fixed normally
closed contact point by spring pressure. When the
relay coil is energized, an electromagnetic field is
produced by the coil windings. This electromagnetic
field draws the movable relay contact point away
from the fixed normally closed contact point, and
holds it against the fixed normally open contact
point. When the relay coil is de-energized, spring
pressure returns the movable contact point back
against the fixed normally closed contact point. A
resistor or diode is connected in parallel with the
relay coil in the relay, and helps to dissipate voltage
spikes and electromagnetic interference that can be
generated as the electromagnetic field of the relay
coil collapses.
The wiper relay terminals are connected to the
vehicle electrical system through a connector recepta-
cle in the fuse block. The inputs and outputs of the
wiper relay include:
²The common feed terminal (30) provides an out-
put to the wiper motor low speed brush through the
wiper control circuitry of the multi-function switch on
the steering column. When the wiper relay is de-en-
ergized, the common feed terminal is connected to
the input of the relay normally closed terminal (87).
When the wiper relay is energized, the common feed
terminal is connected to the input of the relay nor-
mally open terminal (87A).
²The coil ground terminal (85) is connected to
battery current through a fused ignition switch out-
put circuit whenever the ignition switch is in the On
position.
²The coil battery terminal (86) is connected to the
relay control output of the wiper, turn signals and
engine start control module within the fuse block
through the wiper relay control circuit. This elec-
tronic circuitry controls the ground path for this cir-
cuit internally to energize or de-energize the wiper
relay control coil based upon its programming and
inputs from the wiper and washer control circuitry of
the multi-function switch, the wiper motor park
switch, and the ignition switch.
²The normally open terminal (87) is connected to
the output of the wiper motor park switch through
the wiper motor park switch sense circuit. This cir-
cuit can carry either battery current (wipers are not
in park position) or ground (wipers are in park posi-
tion), depending upon the status of the wiper park
switch.
Fig. 33 Wiper Relay
1 - HOUSING
2 - TERMINAL (5)
3 - BASE
8R - 34 WIPERS/WASHERSVA

WIRING
TABLE OF CONTENTS
page page
WIRING DIAGRAM INFORMATION....... 8W-01-1
COMPONENT INDEX.................. 8W-02-1
POWER DISTRIBUTION............... 8W-10-1
FUSE BLOCK........................ 8W-11-1
GROUND DISTRIBUTION.............. 8W-15-1
BUS COMMUNICATIONS.............. 8W-18-1
CHARGING SYSTEM.................. 8W-20-1
STARTING SYSTEM.................. 8W-21-1
FUEL/IGNITION SYSTEM.............. 8W-30-1
TRANSMISSION CONTROL SYSTEM..... 8W-31-1
VEHICLE SPEED CONTROL............ 8W-33-1
ANTILOCK BRAKES................... 8W-35-1
VEHICLE THEFT SECURITY SYSTEM..... 8W-39-1
INSTRUMENT CLUSTER............... 8W-40-1
HORN/CIGAR LIGHTER................ 8W-41-1
AIR CONDITIONING-HEATER........... 8W-42-1
AIRBAG SYSTEM.................... 8W-43-1
INTERIOR LIGHTING.................. 8W-44-1CENTRAL TIMER MODULE............. 8W-45-1
AUDIO SYSTEM..................... 8W-47-1
REAR WINDOW DEFOGGER............ 8W-48-1
FRONT LIGHTING.................... 8W-50-1
REAR LIGHTING..................... 8W-51-1
TURN SIGNALS...................... 8W-52-1
WIPERS............................ 8W-53-1
TRAILER TOW....................... 8W-54-1
NAVIGATION/TELECOMMUNICATIONS.... 8W-55-1
POWER WINDOWS................... 8W-60-1
POWER DOOR LOCKS................ 8W-61-1
POWER MIRRORS................... 8W-62-1
POWER SEATS...................... 8W-63-1
SPLICE INFORMATION................ 8W-70-1
CONNECTOR PIN-OUTS............... 8W-80-1
CONNECTOR/GROUND/SPLICE
LOCATION........................ 8W-91-1
POWER DISTRIBUTION............... 8W-97-1 VAWIRING 8W - 1

Component Page
Ignition Lock Switch................... 8W-40
Ignition Switch....................... 8W-10
Instrument Cluster.................... 8W-40
Instrument Panel Socket................ 8W-41
Intake Air Pressure Sensor.............. 8W-30
Intake Air Temperature Sensor........... 8W-30
Interference Suppression Capacitor........ 8W-42
Interior Lamps....................... 8W-44
Interior Light Switches................. 8W-44
Interior Lighting Connector.............. 8W-44
Intrusion Sensors..................... 8W-39
Kickdown Switch...................... 8W-30
Lamp Relays......................... 8W-50
Lateral Acceleration Sensor.............. 8W-35
License Plate Lamps................... 8W-51
Lockeres............................ 8W-31
Low Fuel Pressure Sensor............... 8W-30
Low Pressure Switch................... 8W-42
Map/Reading Lamp Switch.............. 8W-44
Marker Lamp Connector................ 8W-51
Marker Lamps..................... 8W-50, 51
Mass Air Flow Sensor.................. 8W-30
Master Door Lock Switch............... 8W-61
Metering Pump....................... 8W-42
Microphone Connector.................. 8W-55
Multi-Function Switch......... 8W-50, 52, 53, 54
Optional Equipment Relay.............. 8W-11
Oxygen Sensor....................... 8W-30
Panic Alarm Switch.................... 8W-39
Parking Brake Switch.................. 8W-35
Power Distribution Center.............. 8W-10
Power Mirror Motors................... 8W-62
Power Mirror Switch................... 8W-62
Power Window Motors.................. 8W-60
Power Window Switches................ 8W-60
Radio............................... 8W-47
Radio Antenna........................ 8W-47
Radio/Cellular Antenna................. 8W-55
Rain Sensor.......................... 8W-53
Rain Sensor Control Module............. 8W-53
Reading Lamp Connector............... 8W-44
Rear Window Defogger Relay............ 8W-48
Recirculated Air Solenoid Valve........... 8W-42
Refrigerant Pressure Sensor............. 8W-42
Relay Block.......................... 8W-11
Rollover Switch....................... 8W-42
Rollover Switch Assembly............... 8W-42
Roof A/C Blower Fuses................. 8W-42
Roof A/C Blower Stage Relays............ 8W-42
Roof A/C Blowers...................... 8W-42
Roof A/C Compressor Fuse.............. 8W-42Component Page
Roof A/C Control Module................ 8W-42
Roof A/C Fan Fuse.................... 8W-42
Roof A/C Switch....................... 8W-42
Roof A/C Temperature Setting Control..... 8W-42
Roof Fan Motor....................... 8W-42
Roof Fan Switch...................... 8W-42
Roof Thermotronic Control Module........ 8W-42
SKREEM Antenna.................... 8W-39
SKREEM Transponder................. 8W-39
Seat Belt Switch...................... 8W-43
Seat Belt Tensioners................... 8W-43
Security System Module................ 8W-39
Sentry Key Remote Entry Module......... 8W-39
Shifter Assembly...................... 8W-31
Siren............................... 8W-41
Speakers............................ 8W-47
Speed Control Switch.................. 8W-33
Splices.............................. 8W-70
Starter Motor........................ 8W-21
Starter Motor Relay................... 8W-21
Steering Angle Sensor.................. 8W-35
TCS Switch.......................... 8W-35
Tail Lamp Assemblies.................. 8W-51
Temperature Sensor................... 8W-42
Thermotronic Diode.................... 8W-42
Time Delay Relay..................... 8W-44
Towing/Intrusion Sensor On/Off Switch..... 8W-39
Trailer Tow Connector.................. 8W-54
Trailer Tow Control Module.............. 8W-54
Transmission Control Module............ 8W-31
Transmission Relay.................... 8W-31
Turn Signal Relay..................... 8W-52
Turn Signal Switch.................... 8W-50
Turn Signal/Anti-Theft Alarm Relays...... 8W-39
Turn Signals......................... 8W-52
Warm Air Auxiliary Control Module....... 8W-42
Warm Air Auxiliary Heater Assembly...... 8W-42
Washer On/Off Switch.................. 8W-53
Washer Pump Motor-Front.............. 8W-53
Water Cycle Valve..................... 8W-42
Water In Fuel Sensor.................. 8W-30
Wheel Speed Sensors................... 8W-35
Window Defogger Module-Rear........... 8W-48
Window Defogger Switch-Rear........... 8W-48
Window Defoggers..................... 8W-48
Wiper Motor-Front.................... 8W-53
Wiper On/Off Relay.................... 8W-53
Wiper Switch......................... 8W-53
Wiper/Turn Signal/Engine Start Control
Module................... 8W-30, 31, 52, 53
8W - 02 - 2 8W-02 COMPONENT INDEXVA

8W-10 POWER DISTRIBUTION
Component Page
A/C Compressor Clutch Relay............. 8W-10-11
A/C Roof Auxiliary Fan Relay............. 8W-10-11
Airbag Control Module................. 8W-10-19
Automatic Temperature Control Module..... 8W-10-30
Auxiliary Heater Control................ 8W-10-23
Battery........................... 8W-10-6, 11
Battery Relay-Auxiliary.................. 8W-10-6
Beam Select Switch.............. 8W-10-12, 18, 28
Blower Motor Resistor Block........... 8W-10-12, 30
Boost Pressure Servomotor............... 8W-10-29
Brake Lamp Switch.................... 8W-10-20
Brake Lamp Switch 4 Pole............... 8W-10-20
Central Timer Module.................. 8W-10-16
Cigar Lighter........................ 8W-10-23
Circulation Pump Diode................. 8W-10-30
Circulation Pump Relay-Cabin Heater
Module........................ 8W-10-22, 30
Courtesy Lamp-Driver Door.............. 8W-10-24
Courtesy Lamp-Left Sliding Door.......... 8W-10-24
Courtesy Lamp-Passenger Door........... 8W-10-24
Courtesy Lamp-Right Sliding Door......... 8W-10-24
Crankcase Heater..................... 8W-10-29
D+ Relay No. 1..................... 8W-10-9, 10
Data Link Connector................... 8W-10-20
Daytime Running Lamp Relay-Left Side . . . 8W-10-10, 27
Daytime Running Lamp Relay-Right Side . . 8W-10-10, 27
Daytime Running Lamps Relay........... 8W-10-25
Dome Lamp......................... 8W-10-24
EGR Valve.......................... 8W-10-29
Engine Control Module....... 8W-10-12, 15, 19, 29, 34
Engine Control Relay............. 8W-10-12, 29, 34
Fog Lamp Relay...................... 8W-10-28
Fuel Pump....................... 8W-10-12, 30
Fuel Pump Relay................... 8W-10-12, 30
Fuse 1.................. 8W-10-6, 8, 9, 17, 18, 25
Fuse 2....................... 8W-10-6, 8, 11, 18
Fuse 3........................ 8W-10-6, 8, 9, 18
Fuse 4.............. 8W-10-8, 11, 13, 14, 17, 19, 26
Fuse 5.................... 8W-10-8, 9, 11, 14, 20
Fuse 6.................. 8W-10-7, 8, 11, 14, 21, 33
Fuse 7....................... 8W-10-7, 8, 14, 22
Fuse 8....................... 8W-10-7, 9, 12, 23
Fuse 9.................... 8W-10-8, 9, 10, 12, 21
Fuse 10..................... 8W-10-9, 10, 11, 25
Fuse 11........................ 8W-10-9, 10, 26
Fuse 12.......................... 8W-10-7, 27
Fuse 13.......................... 8W-10-7, 27
Fuse 14.......................... 8W-10-7, 28
Fuse 15........................ 8W-10-7, 13, 16
Fuse 16......................... 8W-10-12, 29
Fuse 17......................... 8W-10-12, 29
Fuse 18........................ 8W-10-9, 14, 19
Fuse 19......................... 8W-10-12, 30
Fuse 20........................ 8W-10-7, 12, 30
Fuse 21....................... 8W-10-12, 13, 30
Component Page
Fuse Block No. 1 . 8W-10-3, 11, 12, 13, 14, 15, 18, 19, 20,
21, 22, 23, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34
Fuse Block No. 2.............. 8W-10-10, 17, 25, 26
Fused Ignition Switch Run-Start Relay...... 8W-10-19
G200........................... 8W-10-31, 32
G202........................... 8W-10-10, 19
Generator........................... 8W-10-6
Glow Plug Control Module............... 8W-10-11
Hazard Warning Switch...... 8W-10-13, 14, 21, 31, 32
Headlamp Assembly-Left........ 8W-10-18, 26, 27, 28
Headlamp Assembly-Right....... 8W-10-17, 18, 27, 28
Headlamp Switch........... 8W-10-12, 18, 25, 26, 27
Horn.............................. 8W-10-22
Horn Relay......................... 8W-10-22
Ignition Switch.................. 8W-10-12, 13, 14
Instrument Cluster............... 8W-10-10, 18, 19
Interior Lamp-Left.................... 8W-10-24
Interior Lamp-Middle Front.............. 8W-10-24
Interior Lamp-Middle Rear.............. 8W-10-24
Interior Lamp-Rear No. 1................ 8W-10-24
Interior Lamp-Rear No. 2................ 8W-10-24
Interior Lamp-Right................... 8W-10-24
Lamp Relay-Left...................... 8W-10-26
Lamp Relay-Right..................... 8W-10-17
Mass Air Flow Sensor.................. 8W-10-22
Multi-Function Switch . . 8W-10-12, 13, 14, 18, 21, 25, 26,
27, 28, 31, 32, 33, 34
Optional Equipment Relay........... 8W-10-6, 7, 22
Oxygen Sensor....................... 8W-10-29
Power Distribution Center........... 8W-10-2, 6, 11
Radio........................... 8W-10-16, 23
Radio/Cellular Antenna................. 8W-10-16
Rain Sensor Control Module.............. 8W-10-33
Sentry Key Remote Entry Module.......... 8W-10-22
Shifter Assembly................... 8W-10-14, 19
Starter Motor..................... 8W-10-11, 15
Starter Motor Relay................... 8W-10-15
Tail Lamp Assembly-Left................ 8W-10-26
Tail Lamp Assembly-Right............... 8W-10-17
Trailer Tow Connector.................. 8W-10-17
Transmission Relay.................... 8W-10-22
Turn Signal Relay..................... 8W-10-31
Turn Signal Switch............... 8W-10-13, 26, 31
Turn Signal/Anti-Theft Alarm Relay-Left..... 8W-10-23
Turn Signal/Anti-Theft Alarm Relay-Right.... 8W-10-23
Washer On/Off Switch............... 8W-10-21, 34
Washer Pump Motor-Front............... 8W-10-34
Window Defogger Switch-Rear............ 8W-10-22
Wiper Motor-Front.................... 8W-10-33
Wiper On/Off Relay................. 8W-10-21, 33
Wiper Switch................... 8W-10-21, 32, 33
Wiper/Turn Signal/Engine Start Control
Module............. 8W-10-14, 21, 31, 32, 33, 34
VA8W-10 POWER DISTRIBUTION 8W - 10 - 1

8W-11 FUSE BLOCK
Component Page
A/C Auxiliary Fan Relay................ 8W-11-19
Additional Heat Exchanger Relay....... 8W-11-24, 34
Additional Heat Exchanger Switch......... 8W-11-27
Ash Receiver Lamp.................... 8W-11-27
Automatic Temperature Control Module . . . 8W-11-16, 27
Battery Relay-Auxiliary................. 8W-11-16
Body Plug Connector.............. 8W-11-28, 38, 39
CTEL Connector................... 8W-11-21, 30
Cabin Heater Module................ 8W-11-21, 34
Central Timer Module............... 8W-11-16, 18
Cigar Lighter Lamp.................... 8W-11-27
Circulation Pump Diode................. 8W-11-34
Controller Antilock Brake............. 8W-11-21, 33
D+ Relay No. 1............... 8W-11-14, 15, 25, 38
D+ Relay No. 2.................. 8W-11-16, 28, 38
Data Link Connector................... 8W-11-18
Daytime Running Lamp Relay-Left Side..... 8W-11-15
Daytime Running Lamp Relay-Right Side.... 8W-11-15
Daytime Running Lamps Relay...... 8W-11-16, 25, 26
Fan Stage 1 Relay..................... 8W-11-24
Fog Lamp Switch................... 8W-11-21, 27
Fuse 1................ 8W-11-13, 14, 19, 20, 25, 26
Fuse 2........... 8W-11-13, 17, 29, 30, 31, 33, 36, 37
Fuse 3................ 8W-11-13, 14, 17, 18, 19, 20,
21, 22, 23, 24, 25, 28
Fuse 4..................... 8W-11-13, 14, 17, 21
Fuse 5................... 8W-11-13, 14, 18, 21, 23
Fuse 6................ 8W-11-13, 18, 24, 29, 33, 36
Fuse 7................ 8W-11-13, 21, 29, 30, 33, 34
Fuse 8................ 8W-11-14, 20, 24, 29, 34, 35
Fuse 9............. 8W-11-13, 14, 15, 16, 21, 25, 38
Fuse 10.................. 8W-11-14, 15, 19, 26, 36
Fuse 11....................... 8W-11-14, 15, 20
Fuse 12....................... 8W-11-28, 29, 33
Fuse 13.................... 8W-11-28, 29, 30, 39
Fuse 14.................... 8W-11-28, 29, 30, 38
Fuse 15....................... 8W-11-29, 31, 32
Fuse 18....................... 8W-11-14, 22, 39
Fuse 19............................ 8W-11-16
Fuse 20......................... 8W-11-29, 31
Fuse Block No. 1................ 8W-11-26, 33, 39
Fuse Block No. 2.............. 8W-11-4, 15, 17, 18,
25, 26, 28, 30, 31, 34, 38, 39
Fuse Block No. 3......... 8W-11-5, 16, 20, 21, 22, 24,
30, 31, 32, 33, 34, 36
Fuse/Relay Block......... 8W-11-2, 19, 20, 21, 23, 33
Fused Ignition Switch Run-Start Relay.... 8W-11-28, 39
G202................. 8W-11-16, 25, 33, 34, 38, 39
Headlamp Adjust Switch................ 8W-11-27
Headlamp Assembly-Left............. 8W-11-15, 25
Headlamp Assembly-Right............ 8W-11-15, 25
Headlamp Switch..................... 8W-11-26
Heated Seat Switch-Driver............ 8W-11-27, 32
Heated Seat Switch-Passenger.......... 8W-11-27, 32
Heater Timer-Auxiliary................. 8W-11-20
High Idle Switch................... 8W-11-27, 33
Component Page
Instrument Cluster................. 8W-11-18, 25
Instrument Panel Socket................ 8W-11-25
Interior Light Switch................ 8W-11-22, 27
Interior Light Switch-Driver.............. 8W-11-22
Interior Light Switch-Passenger........... 8W-11-22
Interior Light Switch-Rear............... 8W-11-22
Interior Lighting Connector.............. 8W-11-22
Intrusion Sensor No. 1.................. 8W-11-37
Intrusion Sensor No. 2.................. 8W-11-37
Intrusion Sensor No. 3.................. 8W-11-37
Lamp Relay-Left................... 8W-11-16, 17
Lamp Relay-Right.................. 8W-11-16, 17
License Plate Lamp No. 1............... 8W-11-25
License Plate Lamp No. 2............... 8W-11-25
Locker Switch No. 1................. 8W-11-27, 33
Locker Switch No. 2................... 8W-11-33
Map/Reading Lamp Switch............ 8W-11-22, 27
Master Door Lock Switch................ 8W-11-27
Multi-Function Switch.................. 8W-11-26
Optional Equipment Relay . . 8W-11-29, 30, 31, 32, 33, 34
Panic Alarm Switch.................... 8W-11-27
Power Distribution Center . . 8W-11-13, 17, 18, 19, 20, 21,
22, 23, 24, 25, 28, 29, 30, 31, 33, 36
Power Mirror Motor-Driver.............. 8W-11-35
Power Mirror Motor-Passenger............ 8W-11-35
Power Mirror Switch................... 8W-11-35
Power Window Switch-Driver............. 8W-11-30
Power Window Switch-Master............ 8W-11-31
Power Window Switch-Passenger.......... 8W-11-31
Radio.............................. 8W-11-27
Rear Window Defogger Relay............. 8W-11-19
Relay Block . . 8W-11-3, 14, 15, 16, 17, 19, 23, 24, 25, 28,
29, 30, 31, 32, 33, 34
Rollover Switch Assembly............. 8W-11-21, 34
Roof A/C Control Module................ 8W-11-20
Roof A/C Switch.................... 8W-11-16, 27
Roof A/C Temperature Setting Control....... 8W-11-27
Roof Fan Switch................... 8W-11-27, 31
Security System Module........... 8W-11-30, 36, 37
Sentry Key Remote Entry Module.......... 8W-11-23
Shifter Assembly...................... 8W-11-27
Siren.............................. 8W-11-37
Steering Angle Sensor.................. 8W-11-33
TCS Switch......................... 8W-11-27
Time Delay Relay..................... 8W-11-22
Towing/Intrusion Sensor On/Off Switch...... 8W-11-27
Trailer Tow Connector.................. 8W-11-24
Trailer Tow Control Module.............. 8W-11-24
Transmission Relay.................... 8W-11-17
Turn Signal/Anti-Theft Alarm Relay-Left..... 8W-11-23
Turn Signal/Anti-Theft Alarm Relay-Right.... 8W-11-23
Warm Air Auxiliary Heater Assembly....... 8W-11-20
Window Defogger Module-Rear......... 8W-11-16, 19
Window Defogger Switch-Rear............ 8W-11-27
VA8W-11 FUSE BLOCK 8W - 11 - 1

8W-15 GROUND DISTRIBUTION
Component PageA/C Auxiliary Fan..........................8W-15-4
A/C Auxiliary Fan Relay......................8W-15-12
A/C Compressor Clutch Relay...................8W-15-30
A/C Roof Auxiliary Fan......................8W-15-30
A/C Roof Auxiliary Fan Relay...................8W-15-30
Additional Heat Exchanger....................8W-15-12
Additional Heat Exchanger Relay.................8W-15-12
Additional Heat Exchanger Switch................8W-15-24
Airbag Control Module.......................8W-15-11
Ash Receiver Lamp........................8W-15-22
Automatic Temperature Control Module.............8W-15-24
Auxiliary Heater Control.....................8W-15-24
Battery................................8W-15-8
Battery Relay-Auxiliary......................8W-15-11
Battery-Auxiliary..........................8W-15-11
Blower Motor-Front.........................8W-15-9
Brake Fluid Level Switch......................8W-15-8
Brake Wear Sensor-Left Front...................8W-15-8
Brake Wear Sensor-Left Rear...................8W-15-28
Brake Wear Sensor-Right Front..................8W-15-8
Brake Wear Sensor-Right Rear..................8W-15-28
CTEL Connector..........................8W-15-21
Cabin Heater Module........................8W-15-3
Center High Mounted Stop Lamp.................8W-15-6
Central Timer Module.......................8W-15-15
Cigar Lighter............................8W-15-22
Cigar Lighter Lamp........................8W-15-22
Circulation Pump..........................8W-15-9
Circulation Pump Relay-Cabin Heater Module..........8W-15-12
Clockspring.............................8W-15-10
Controller Antilock Brake....................8W-15-2, 28
Crankcase Heater..........................8W-15-4
Cylinder Lock Switch-Driver...................8W-15-10
D+ Relay No. 1...........................8W-15-12
D+ Relay No. 2...........................8W-15-14
Data Link Connector........................8W-15-10
Daytime Running Lamp Relay-Left Side.............8W-15-13
Daytime Running Lamp Relay-Right Side............8W-15-13
Daytime Running Lamps Relay..................8W-15-13
Differential Lock Solenoid Valve..................8W-15-2
Dome Lamp.............................8W-15-6
Dosing Pump............................8W-15-2
Engine Control Module.......................8W-15-7
Engine Coolant Level Switch....................8W-15-2
Fan Stage 1 Relay.........................8W-15-11
Fog Lamp Relay..........................8W-15-11
Fog Lamp Switch.........................8W-15-22
Fuel Pump.............................8W-15-19
Fuse Block No. 1..........................8W-15-7
Fused Ignition Switch Run-Start Relay..............8W-15-14
G100...............................8W-15-2, 3
G101.................................8W-15-4
G102.................................8W-15-4
G103.................................8W-15-4
G200...........................8W-15-6, 7, 8, 9, 10
G201................................8W-15-11
G202................8W-15-11, 12, 13, 14, 15, 16, 17, 18, 19
G203......................8W-15-20, 21, 22, 23, 24, 25
G300............................8W-15-26, 27, 28
G301................................8W-15-28
G302................................8W-15-28
G303................................8W-15-31
G304................................8W-15-31
G305..............................8W-15-29, 30
Glow Plug Control Module.....................8W-15-2
Hazard Warning Switch.......................8W-15-7
Headlamp Adjust Switch.....................8W-15-22
Headlamp Assembly-Left......................8W-15-3
Headlamp Assembly-Right.....................8W-15-4
Heated Seat Module-Driver....................8W-15-19
Heated Seat Module-Passenger..................8W-15-19
Heated Seat Switch-Driver....................8W-15-25
Heated Seat Switch-Passenger..................8W-15-25
Heater Timer-Auxiliary......................8W-15-24
High Idle Switch..........................8W-15-25
Hood Ajar Switch..........................8W-15-4
Horn Relay.............................8W-15-11
Horn Switch............................8W-15-10
Ignition Lock Switch........................8W-15-10
Instrument Cluster........................8W-15-10
Instrument Panel Socket.....................8W-15-20
Interior Lamp No. 1.........................8W-15-6
Interior Lamp No. 2.........................8W-15-6
Interior Lamp No. 3.........................8W-15-6Component PageInterior Lamp No. 4.........................8W-15-6
Interior Lamp No. 5.........................8W-15-6
Interior Lamp-Left.........................8W-15-6
Interior Lamp-Middle Front...................8W-15-5, 6
Interior Lamp-Middle Rear...................8W-15-5, 6
Interior Lamp-Rear No. 2......................8W-15-5
Interior Lamp-Right.......................8W-15-5, 6
Interior Light Switch.......................8W-15-21
Interior Lighting Connector.....................8W-15-6
Intrusion Sensor No. 1.......................8W-15-6
Intrusion Sensor No. 2.......................8W-15-6
Intrusion Sensor No. 3.......................8W-15-6
Kickdown Switch..........................8W-15-8
Lamp Relay-Left..........................8W-15-13
Lamp Relay-Right.........................8W-15-13
License Plate Lamp No. 1.....................8W-15-27
License Plate Lamp No. 2.....................8W-15-27
Locker Switch No. 1........................8W-15-20
Map/Reading Lamp Switch....................8W-15-21
Marker Lamp Connector......................8W-15-17
Marker Lamp No. 1-Left Front..................8W-15-16
Marker Lamp No. 1-Right Front.................8W-15-16
Marker Lamp No. 2-Left Front..................8W-15-16
Marker Lamp No. 2-Right Front.................8W-15-16
Marker Lamp-Left Center.....................8W-15-17
Marker Lamp-Left Rear......................8W-15-27
Marker Lamp-Right Center....................8W-15-17
Marker Lamp-Right Rear.....................8W-15-27
Master Door Lock Switch.....................8W-15-25
Metering Pump...........................8W-15-18
Multi-Function Switch.......................8W-15-7
Optional Equipment Relay....................8W-15-19
Panic Alarm Switch........................8W-15-20
Parking Brake Switch.......................8W-15-15
Power Mirror Motor-Driver....................8W-15-23
Power Mirror Motor-Passenger..................8W-15-23
Power Mirror Switch........................8W-15-23
Power Window Switch-Driver...................8W-15-23
Power Window Switch-Master...................8W-15-23
Radio................................8W-15-21
Rain Sensor............................8W-15-31
Rain Sensor Control Module..................8W-15-19, 31
Reading Lamp Connector......................8W-15-6
Rear Window Defogger Relay...................8W-15-14
Recirculated Air Solenoid Valve...................8W-15-9
Rollover Switch Assembly......................8W-15-3
Roof A/C Blower..........................8W-15-29
Roof A/C Blower Stage I And Ii Relay...............8W-15-29
Roof A/C Blower Stage I Relay..................8W-15-29
Roof A/C Blower Stage Ii Relay..................8W-15-29
Roof A/C Control Module.....................8W-15-28
Roof A/C Switch..........................8W-15-24
Roof Fan Switch..........................8W-15-21
Roof Thermotronic Control Module................8W-15-30
Seat Belt Switch..........................8W-15-15
Security System Module......................8W-15-15
Sentry Key Remote Entry Module.................8W-15-7
Shifter Assembly..........................8W-15-20
Siren.................................8W-15-9
Steering Angle Sensor........................8W-15-7
TCS Switch.............................8W-15-25
Tail Lamp Assembly-Left.....................8W-15-26
Tail Lamp Assembly-Right.....................8W-15-26
Thermotronic Diode........................8W-15-30
Time Delay Relay.........................8W-15-17
Towing/Intrusion Sensor On/Off Switch..............8W-15-22
Trailer Tow Connector.......................8W-15-28
Trailer Tow Control Module....................8W-15-19
Transmission Control Module...................8W-15-19
Transmission Relay........................8W-15-19
Turn Signal No. 1-Left Front....................8W-15-3
Turn Signal No. 1-Right Front...................8W-15-4
Turn Signal No. 2-Left Front....................8W-15-3
Turn Signal No. 2-Right Front...................8W-15-4
Warm Air Auxiliary Heater Assembly...............8W-15-18
Washer Pump Motor-Front.....................8W-15-4
Water Cycle Valve..........................8W-15-9
Window Defogger Module-Rear..................8W-15-15
Window Defogger Switch-Rear..................8W-15-20
Window Defogger-Left Rear....................8W-15-26
Window Defogger-Right Rear...................8W-15-26
Wiper Motor-Front.........................8W-15-9
Wiper/Turn Signal/Engine Start Control Module.........8W-15-7
VA8W-15 GROUND DISTRIBUTION 8W - 15 - 1

8W-30 FUEL/IGNITION SYSTEM
Component Page
Accelerator Pedal Position Sensor.... 8W-30-10, 21
Airbag Control Module................ 8W-30-9
Boost Pressure Sensor............. 8W-30-9, 25
Boost Pressure Servomotor............ 8W-30-24
Boost Pressure Solenoid.............. 8W-30-14
Camshaft Position Sensor.............. 8W-30-6
Central Timer Module................ 8W-30-9
Crankcase Heater................ 8W-30-17, 24
Crankshaft Position Sensor............ 8W-30-7
Data Link Connector................. 8W-30-4
Daytime Running Lamps Relay......... 8W-30-2
EGR Valve..................... 8W-30-17, 24
Engine Control Module . . . 8W-30-2, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14, 15, 16, 17,
18, 19, 20, 21, 22, 23, 24, 25
Engine Control Relay........... 8W-30-8, 17, 24
Engine Coolant Level Switch........... 8W-30-3
Engine Coolant Temperature Sensor..... 8W-30-6
Engine Oil Sensor................... 8W-30-17
Fuel Injector No. 1............... 8W-30-15, 22
Fuel Injector No. 2............... 8W-30-16, 23
Fuel Injector No. 3............... 8W-30-15, 22
Fuel Injector No. 4............... 8W-30-15, 22
Fuel Injector No. 5............... 8W-30-16, 23
Fuel Level Sensor.................... 8W-30-3
Fuel Pressure Sensor................. 8W-30-5
Fuel Pressure Solenoid................ 8W-30-7
Fuel Pump........................ 8W-30-18
Fuel Pump Relay................... 8W-30-18
Fuel Quantity Control Valve........... 8W-30-7
Fuel Shutdown Solenoid............... 8W-30-7
Fuel Temperature Sensor.............. 8W-30-5
Fuse 5......................... 8W-30-13, 19
Fuse 7............................ 8W-30-20
Fuse 12............................ 8W-30-2Component Page
Fuse 16............................ 8W-30-8
Fuse 17........................ 8W-30-17, 24
Fuse 18............................ 8W-30-9
Fuse 19........................... 8W-30-18
Fuse Block No. 1....... 8W-30-8, 9, 17, 18, 20, 24
Fuse Block No. 3.................... 8W-30-2
G100........................ 8W-30-3, 13, 19
G103............................. 8W-30-17
G200........................... 8W-30-8, 12
G202............................. 8W-30-18
G203.............................. 8W-30-2
Glow Plug Control Module......... 8W-30-13, 19
Glow Plug No. 1................. 8W-30-13, 19
Glow Plug No. 2................. 8W-30-13, 19
Glow Plug No. 3................. 8W-30-13, 19
Glow Plug No. 4................. 8W-30-13, 19
Glow Plug No. 5................. 8W-30-13, 19
High Idle Switch.................... 8W-30-2
Instrument Cluster................... 8W-30-3
Intake Air Pressure Sensor............ 8W-30-20
Intake Air Temperature Sensor...... 8W-30-10, 21
Kickdown Switch................... 8W-30-12
Low Fuel Pressure Sensor............ 8W-30-11
Mass Air Flow Sensor............. 8W-30-14, 20
Optional Equipment Relay............. 8W-30-2
Oxygen Sensor..................... 8W-30-24
Power Distribution Center......... 8W-30-13, 19
Relay Block........................ 8W-30-2
Speed Control Switch................ 8W-30-12
Starter Motor Relay.............. 8W-30-11, 18
Transmission Control Module........... 8W-30-4
Water In Fuel Sensor............. 8W-30-11, 25
Wiper/Turn Signal/Engine Start Control
Module.......................... 8W-30-8
VA8W-30 FUEL/IGNITION SYSTEM 8W - 30 - 1

8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
Brake Lamp Switch.................. 8W-31-9
Crankcase Heater.................... 8W-31-3
Data Link Connector............... 8W-31-2, 9
Daytime Running Lamps Relay....... 8W-31-8, 9
Differential Lock Solenoid Valve......... 8W-31-8
EGR Valve......................... 8W-31-3
Electrohydraulic Control Unit........ 8W-31-5, 6
Engine Control Module.............. 8W-31-3, 4
Engine Control Relay................. 8W-31-3
Fuse 2.......................... 8W-31-2, 7
Fuse 4.......................... 8W-31-7, 9
Fuse 7............................ 8W-31-7
Fuse 12............................ 8W-31-8
Fuse 16............................ 8W-31-3
Fuse 17............................ 8W-31-3
Fuse Block No. 1................ 8W-31-3, 7, 9
Fuse Block No. 2.................. 8W-31-2, 7Component Page
Fuse Block No. 3.................... 8W-31-8
G100.............................. 8W-31-8
G202............................ 8W-31-2, 7
G203............................ 8W-31-8, 9
Locker Switch No. 1.................. 8W-31-8
Locker Switch No. 2.................. 8W-31-8
Optional Equipment Relay............. 8W-31-8
Shifter Assembly............... 8W-31-2, 4, 7, 9
Tail Lamp Assembly-Left.............. 8W-31-9
Tail Lamp Assembly-Right............. 8W-31-9
Trailer Tow Connector................ 8W-31-9
Transmission Control Module . . . 8W-31-2, 4, 5, 6, 7
Transmission Relay................ 8W-31-2, 7
Wiper/Turn Signal/Engine Start Control
Module.......................... 8W-31-3
VA8W-31 TRANSMISSION CONTROL SYSTEM 8W - 31 - 1
