2006 MERCEDES-BENZ SL600 Owner's Manual

96 Controls in detailIn the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed on your vehi-
cle. If you are already familiar with the
basic functions of your vehicle, this section
will be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are giv-
en at the beginning of each segment.
For more information on locking and un-
locking, see the “Getting started” section
(page 34).
Locking and unlocking
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are a differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors


the trunk lid


the glove box


the storage compartment under the
armrest


the storage compartment in the rear


the fuel filler flap
SmartKey with remote control1‹Lock button
2Š Unlock button for the trunk lid
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 81)

97 Controls in detail
Locking and unlocking
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is possible
for children to open a locked door from the
inside, which could result in an accident
and/or serious injury.!To prevent possible malfunction, avoid
exposing the SmartKey to high levels of
electromagnetic radiation.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause interfer-
ence, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.iYou can also open and close the power
windows (
page 192) and the retract-
able hardtop using the SmartKey
(
page 199).

98 Controls in detailLocking and unlockingFactory setting
Global unlocking
Press button Œ.
All turn signals flash once. The locking
knobs in the doors move up. The
anti-theft alarm system is disarmed.
The vehicle will lock again automatically
and reactivate the alarm system within ap-
proximately 40 seconds of unlocking if:


neither door nor trunk is opened


the SmartKey is not inserted in the
starter switch


the central locking switch is not acti-
vated
Global locking

Press button ‹.
With the trunk and all doors closed, all
turn signals flash three times. The lock-
ing knobs in the doors move down.
The anti-theft alarm system is armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressingŒ only unlocks the driver’s
door, interior lockable storage compart-
ments and the fuel filler flap.

Press and hold buttons Πand
‹simultaneously for about
6 seconds until battery check lamp5
flashes twice.
The SmartKey will then function as fol-
lows:
Unlocking driver’s door and fuel filler
flap

Press button Πonce.
All turn signals flash once. The locking
knob in the driver’s door moves up.
The anti-theft alarm system is disarmed.Global unlocking

Press button Πtwice.
All turn signals flash once. The locking
knobs in the doors move up. The anti-theft
alarm system is disarmed.
Global locking

Press button ‹.
All turn signals flash three times. The lock-
ing knobs in the doors move down.
The anti-theft alarm system is armed.
Restoring to factory setting

Press and hold buttons Œ and ‹
simultaneously for about 6 seconds
until battery check lamp5
(page 96) flashes twice.

99 Controls in detail
Locking and unlocking
Checking the batteries
Press button ‹or Œ.
Battery check lamp5 (
page 96)
comes on briefly to indicate that the
SmartKey batteries are in order.Unlocking the trunk
You can unlock the trunk separately.
A minimum height clearance of
6.2 ft (1.88 m) is required to open the
trunk lid.

Press and hold button Š on the
SmartKey until trunk unlocks.
!If you can no longer lock or unlock the
vehicle with the SmartKey, then the
batteries in the SmartKey are dis-
charged, the SmartKey is malfunction-
ing or the vehicle battery is drained.

Check the batteries in the
SmartKey (
page 99) and replace
them if necessary (
page 389).


Use the mechanical key to unlock
the driver’s door (
page 385) and
the trunk (
page 110).


Have the vehicle batteries and their
connections checked
(page 413).


Use the mechanical key to lock or
unlock the doors (
page 387).
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz
Center.
iIf battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.

Replace the batteries (
page 389).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing
the‹orŒ button will lock or
unlock the vehicle accordingly.
iIf the trunk does not unlock, it is still
locked separately (
page 110).

100 Controls in detailLocking and unlockingLoss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:
Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.

Report the loss of the SmartKey or the
mechanical key to your car insurance
company immediately.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote controls and a remov-
able mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are a different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The function of the SmartKey overrules the
KEYLESS-GO function.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you grasp a door
handle. If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks


the doors


the trunk lid


the glove box


the storage compartment under the
armrest


the storage compartment in the rear


the fuel filler flap

101 Controls in detail
Locking and unlocking
SmartKey with KEYLESS-GO1‹Lock button
2Š Unlock button for the trunk lid
3Mechanical key locking tab
4ŒUnlock button
5Battery check lamp
6Â Panic button (
page 81)
For information on using the SmartKey
buttons, see “SmartKey” (page 96).
Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.

102 Controls in detailLocking and unlocking
Important notes on using KEYLESS-GO

You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 96).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the ‹ button).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of a door or the
trunk.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


All doors must be closed.


The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.


If you have started the engine with the
KEYLESS-GO start/stop button
(page 37), you can only turn it off
again with this button, even if you have
put the SmartKey in the starter switch
in the meantime.
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause interfer-
ence, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.iYou can also close the power windows
(page 192) and the retractable hard-
top using the SmartKey with
KEYLESS-GO (
page 199).
iWhen you unlock the vehicle, the
electro-hydraulic brake system is acti-
vated.

103 Controls in detail
Locking and unlocking


This does not apply if, after starting, the
selector lever is still in positionP and
the SmartKey is then inserted in the
starter switch. The SmartKey will then
have priority over the KEYLESS-GO
function and the vehicle’s electrical
system will operate according to the
position of the SmartKey in the starter
switch, even stopping the engine.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle then cannot be locked or
the engine started via the KEYLESS-GO
system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the en-
gine is running (e.g. if passenger exits
the vehicle with the SmartKey with
KEYLESS-GO), the message
Key not
detected!
will appear in the multifunc-
tion display while driving off.Find the SmartKey or change its
present location immediately (e.g.
place it on the front passenger seat or
insert it in shirt pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, the message
Key
recognized in vehicle!
w i ll a p pe a r i n
the multifunction display.
Factory setting
Global unlocking

Grasp an outside door handle.
All turn signals flash once. The locking
knobs in the doors move up. The
anti-theft alarm system is disarmed.The vehicle will lock again automatically
and reactivate the alarm system within ap-
proximately 40 seconds of unlocking if
neither a door nor the trunk is opened.
iIf the vehicle has been parked for more
than 72 hours, you must pull an outside
door handle in order to activate the
KEYLESS-GO function.iThe vehicle could inadvertently unlock
if the SmartKey with KEYLESS-GO is
within 3 ft (1 m) of the vehicle and

an door handle is splashed with wa-
ter
or


you attempt to clean an outside
door handle
