2006 MERCEDES-BENZ S55AMG Owner's Manual

208 Controls in detailPower windowsOpening and closing the power windows
The side windows are opened and closed
electrically. The switches for all side win-
dows are on the driver’s door. The switch-
es for the respective windows are on the
front passenger door and the rear doors.
1Left front window
2Right front window
3Right rear window
4Left rear window
5Rear window override switch
(
page 77)
Warning!
G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if the switch was pressed past the resis-
tance point and released, by pressing the re-
spective switch.
The door windows are equipped with the ex-
press-close and automatic reversal func-
tion. If the window encounters an
obstruction that blocks its path in a circum-
stance where you pressed the switch past
the resistance point and released it to close
the window, the automatic reversal function
will stop the window and open it slightly.
If the window encounters an obstruction
t h a t b l o c k s i t s p a t h i n a c i r c u m s t a n c e w h e r e
you are closing the window by pressing and
holding the switch, by pressing and holding
button ‹ on the SmartKey, by pressing
and holding the lock button (vehicles with
KEYLESS-GO*) on an outside door handle,
or by pressing and holding button
,
or
button
e
on the climate control panel,
the automatic reversal function will not op-
erate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
iYou can also open or close the win-
dows using the SmartKey, see “Sum-
mer opening feature” (
page 210) and
“Convenience closing feature”
(
page 211).
You can close and reopen the windows
using the air recirculation button,
or the charcoal filter buttone in the
climate control panel (
page 193).

209 Controls in detail
Power windows

Switch on the ignition (
page 34).
Opening the windows

Press switch1 to 4 at the
symbolk to the resistance point.
The corresponding window will move
downwards until you release the
switch.Closing the windows

Press switch1 to 4 at the
symbolj to the resistance point.
The corresponding window will move
upwards until you release the switch.
Fully opening the windows
(Express-open)

Press switch1 to 4 at the
symbolk past the resistance point
and release.
The corresponding window opens com-
pletely.Fully closing the windows
(Express-close)

Press switch1 to 4 at the
symbolj past the resistance point
and release.
The corresponding window closes com-
pletely.
iOperating the windows from the rear is
not possible if you activate the override
switch (
page 77).
iWith the SmartKey in starter switch po-
sition 0 or removed from the starter
switch, the power windows can be op-
erated:

until you open the driver’s or front
passenger door


for at least five minutes
Warning!
G
If you press and hold the switch up when
closing the window, and upward movement
of the window is blocked by some obstruc-
tion including but not limited to arms, hands,
fingers, etc., the automatic reversal will not
operate.
Warning!
G
Driver’s door only:
If within five seconds you again press the
switch past the resistance point and re-
lease, the automatic reversal will not func-
tion.!If the upward movement of the window
is blocked during the closing proce-
dure, the window will stop and open
slightly. Remove the obstruction, press
the respective power window switch at
the symbolj again past the resis-
tance point and release. If the window


210 Controls in detailPower windowsStopping windows during Express-op-
eration
Briefly press the respective power win-
dow switch again.
Synchronizing the power windows
The power windows must be synchronized

after the battery has been disconnect-
ed


if the power windows cannot be fully
opened (Express-open) or closed
(Express-close)
Each power window must be synchronized.

Close all doors.

Switch on the ignition (
page 34).

Press and hold switch1 to 4 at the
symbolj until the windows are
completely closed.

Hold on to switches1 to 4 for ap-
proximately one second.
The power windows are synchronized.
Summer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously:

opening the side windows


opening the tilt/sliding sunroof


turning on the seat ventilation* for the
driver’s seat

Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle. The
SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s door handle.

Press and hold button Πuntil the
side windows and tilt/sliding sunroof
have reached the desired position.

Release button Πto interrupt pro-
cedure. still does not close when there is no ob-
struction, press and hold the respec-
tive power window switch at the
symbolj. The side window will
then close without the obstruction sen-
sor function.
iThe seat ventilation* for the driver’s
seat is automatically set to the highest
level if activated via summer opening
feature.


211 Controls in detail
Power windows
Convenience closing feature
When you lock the vehicle, you can close
the side windows and tilt/sliding sunroof
simultaneously.
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(page 210). The SmartKey or
SmartKey with KEYLESS-GO* must be
in close proximity to the driver’s door
handle.

Press and hold button ‹ until the
side windows and tilt/sliding sunroof
are completely closed.

Release button ‹ to interrupt pro-
cedure.Vehicles with KEYLESS-GO*:

Press and hold the lock button on an
outside door handle (
page 58) until
the side windows and the tilt/sliding
sunroof are completely closed.

Release the lock button on the outside
door handle to interrupt procedure.
Warning!
G
When closing the side windows and the
tilt/sliding sunroof, make sure that there is
no danger of anyone being harmed by the
closing procedure.
If potential danger exists, proceed as fol-
lows:

Release button ‹to stop the closing
procedure. To open, press and hold but-
ton Œ. To continue the closing after
making sure that there is no danger of
anyone being harmed by the closing pro-
cedure, press and hold button‹.
Vehicles with KEYLESS-GO*:


Release the lock button on the outside
door handle (
page 58) to stop the
closing procedure.


Pull on the outside door handle and hold
firmly. The side windows and the
tilt/sliding sunroof will open for as long
as the outside door handle is held but
the door is not opened.

212 Controls in detailPower tilt/sliding sunroofOpening and closing the power tilt/sliding sunroof
The tilt/sliding sunroof is opened and
closed electrically. The switch for the
tilt/sliding sunroof is on the overhead con-
trol panel.
1Push up to raise sunroof at rear
2Pull down to lower sunroof at rear
3Push forward to slide sunroof closed
4Push back to slide sunroof openWith the sunroof closed or tilted open, a
screen can be slid into the roof opening to
help provide shade. When sliding the sun-
roof open, the screen will also retract.
Warning!
G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
The closing procedure of the tilt/sliding sun-
roof can be immediately halted by releasing
the switch or, if the switch was moved past
the resistance point and released, by mov-
ing the switch in any direction.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts
properly as entire body parts or portions of
them may protrude from the passenger
compartment.

213 Controls in detail
Power tilt/sliding sunroof

Switch on the ignition (
page 34).
Opening and closing the power
tilt/sliding sunroof

To open, close, raise or lower the
tilt/sliding sunroof, move the switch to
resistance point in the required
direction1to4.

Release the sunroof switch when the
tilt/sliding sunroof has reached the de-
sired position.
Fully opening (Express-open) and clos-
ing (Express-close) the power the
tilt/sliding sunroof

To open, close, raise or lower the
tilt/sliding sunroof, move the switch
past the resistance point in the re-
quired direction1to4 and release.
The tilt/sliding sunroof opens or closes
completely.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.!To avoid damaging the seals, do not
transport any objects with sharp edges
which can stick out of the tilt/sliding
sunroof.
Do not open the tilt/sliding sunroof if
there is snow or ice on the roof, as this
could result in malfunctions.
The tilt/sliding sunroof can be opened
or closed manually should an electrical
malfunction occur (
page 391).
iYou can also open or close the tilt/slid-
ing sunroof using the SmartKey, see
“Summer opening feature”
(page 210) and “Convenience clos-
ing feature” (
page 211).
You can close and reopen the tilt/slid-
ing sunroof using the air recirculation
button, or the charcoal filter
buttone in the climate control pan-
el (
page 193).
iWith the SmartKey in starter switch po-
sition 0 or removed from the starter
switch, the tilt/sliding sunroof can be
operated

until you open the driver’s or pas-
senger door


for up to approximately five min-
utes


214 Controls in detailPower tilt/sliding sunroof
Stopping the power tilt/sliding sunroof
during Express-operation
Move the switch in any direction.
Synchronizing the power tilt/sliding
sunroof
The tilt/sliding sunroof must be synchro-
nized

after the battery has been
disconnected or discharged


after the tilt/sliding sunroof has been
closed manually (
page 391)


the tilt/sliding sunroof does not open
smoothly


after a malfunction

Switch on the ignition (
page 34).

Press and hold the sunroof switch in
the direction of arrow1 until the
tilt/sliding sunroof is fully raised at the
rear.
Keep holding the sunroof switch in the
direction of arrow1 for approximately
one second.

Check the Express-open feature
(page 213).
If the tilt/sliding sunroof opens com-
pletely, the sunroof is synchronized.
Otherwise repeat the above steps.
iThe selecting a tilt/sliding sunroof
opening position feature is activated
for Canada vehicles, but deactivated
for U.S. vehicles at the factory. If you
w i s h t o ha v e i t a ct i v a t e d , c o n t a c t a n a u -
thorized Mercedes-Benz Center.
To select a tilt/sliding sunroof opening
position, press the sunroof switch to
the resistance point and release it
when the tilt/sliding sunroof has
reached the desired position. The
tilt/sliding sunroof now opens to the
position set when the sunroof switch is
pressed past the resistance point in the
“open” direction.
iIf the movement of the tilt/sliding sun-
roof is blocked during the closing pro-
cedure, the sunroof will stop and
reopen slightly.


215 Controls in detail
Driving systems
Driving systems
The driving systems of your vehicle are de-
scribed on the following pages:

Cruise control and Distronic*, with
which the vehicle can maintain a preset
speed.


Airmatic adjusts the vehicle suspen-
sion characteristics automatically and
controls the vehicle level.


ABC* with vehicle level control system,
with which you can change vehicle sus-
pension characteristics.


Parktronic*, which serves as a parking
assistant.
For information on the BAS, ABS, and
ESP® driving systems, see “Driving safety
systems” (
page 79).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set or resume
cruise control at any speed over 20 mph
(30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 22).
Warning!
G
Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver is and must remain at all
times responsible for the vehicle speed and
for safe brake operation.
Only use cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate cruise control when driving
in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.
