STARTING AND DRIVING
432If “E2” appears on the display,
the system may be having
trouble measuring the vehicle −to− vehicle distance because of
any of the following:
 The wipers are operating at high or low speeds
 Direct sunlight from the front
 It is difficult to make a measurement because of bad
weather (such as rainy, foggy, or snowy weather)
 Driving in “SNOW” mode
In the following cases, dynamic laser cruise control switches
to the ready mode:
 The wipers are stopped or are switched to variable
intermittent operation.
 No direct sunlight from the front
In the above conditions, push the lever up in the “+ RES”
direction and release it. Dynamic laser cruise control will be
restored. If the setting operation cannot be performed or if the
same code still appears even after the weather clears, the
system might have malfunctioned. Although there is no
problem to continue driving, please contact your Lexus dealer. If “E3” appears on the display,
a system malfunction has
been detected.
If this warning code appears, stop your vehicle in a safe place,
turn the ignition off, and then restart it to reset the system. If
the same code appears again or if the cruise control cannot be
set, the system may be malfunctioning. Although there is no
problem to continue driving, please contact your Lexus dealer.

STARTING AND DRIVING
438This electronically modulated air suspension allows the
driver to
control the vehicle’s height in order to adjust for
driving conditions. Select your desired height among the
“HI” (high), “N” (normal) and “LO” (low) modes with the
height select switch.
You can turn on or off the easy access mode with the easy
access mode switch. If the engine is stopped when the easy
access mode is on, the vehicle height is lowered automatically.
(a) Vehicle height modes
Vehicle’s height mm (in.)
“N”
− 7.0 (0.3)
Vehicle speedkm/h (mph)
80
(50) 100
(62)

“N” (normal) mode
“N” (normal) mode: The vehicle’s height in this mode is
standard.
This mode is suitable for ordinary driving.
When the vehicle speed exceeds approximately 100 km/h (62
mph), the vehicle’s height automatically lowers about 7 mm
(0.3 in.) from normal height to provide better stability. When the
vehicle speed reduces to under approximately 80 km/h (50
mph), the vehicle’s height automatically returns to the normal
height.

STARTING AND DRIVING
440
Vehicle’s height mm (in.)Vehicle speedkm/h (mph)
“N”
“LO”
− 15 (0.6)
 “LO” (low) mode
“LO” (low) mode: The vehicle’s height is about 15 mm (0.6 in.)
lower than the normal height.
This mode is suitable for sporty driving such as on winding
mountain roads and high speed driving.
When the engine is turned off and then restarted, the “N”
(normal) mode will automatically be selected.
Vehicle’s height mm (in.)
Vehicle speedkm/h (mph)
“N”
− 7.0 (0.3)
“LO”
− 15 (0.6)
Easy access − 30 (1.2 in.) 80
(50) 100
(62)
12
(8)
 Easy access mode
Easy access mode: The vehicle’s height is about 30 mm (1.2
in.) lower than the normal height.
This mode allows easy access to the vehicle (getting in and
out) and easy loading and unloading operations.
This mode is available when “N” or “LO” mode is selected.
When the engine is stopped, easy access mode is
automatically selected, and the height adjusted.

STARTING AND DRIVING
441
In the following cases, vehicle height is changed to “N”
(normal) mode height automatically.

Vehicle speed exceeds approximately 12 km/h (8 mph).
 The engine is restarted and the easy access mode is
canceled.
CAUTION
When the engine is stopped in easy access mode,
vehicle height is changed quickly. Be careful not to
get your head, hands or other parts of your body
caught by the lowering underbody of the vehicle.
 You must also make sure nobody places his or her
head, hands or other parts of their body between the
body of the vehicle and tires.
NOTICE
Be careful when you drive in any place where overhead
space is limited and you have selected the easy access
mode. When the vehicle begins to move after stopping,
“N” (normal) mode will automatically be selected,
raising the vehicle’s height, and potentially causing
damage to the vehicle.
(b) Automatic leveling function
Regardless of the number of occupants or the luggage
load, vehicle height in any mode is always adjusted
automatically to a fixed height.
(c) Selecting “LO”, “HI” or “N” mode
Selection conditions: To select the vehicle’s height, it is
necessary to meet the following conditions.
 The engine is running.
 The height control “OFF” indicator light is off.
 The vehicle is within the speed limitations. Refer to the
following table.
Yes = The mode can be selected.
No = The mode cannot be selected.
“LO”
mode“N”
mode“HI”
mode
At vehicle
stoppageYe sYe sYe s
Under
approximately
30 km/h (19 mph)
Ye sYe sYe s
Approximately
30 km/h (19 mph)
or over
Ye sYe sNo

STARTING AND DRIVING
443

Selecting the “N” mode
To change “HI” to “N” mode: Push the height select switch
on the “
” (lower) side once.
To change “LO” to “N” mode: Push the height select switch
on the “ ” (higher) side once.
The “N” indicator light blinks as the vehicle’s height changes.
When the vehicle’s height reaches the “N” mode, the indicator
light remains on.
Even if the engine stops while the vehicle’s height is being
lowered, the operation continues for up to one minute.
 Selecting the “LO” mode
To change “N” mode to “LO”: Push the height select switch
on the “
” (lower) side once.
To change “HI” mode to “LO”: Push the height select switch
on the “
” (lower) side twice.
The “LO” indicator light blinks as the vehicle’s height changes.
When the vehicle’s height reaches the “LO” mode, the indicator
light remains on.
Even if the engine stops while the vehicle’s height is being
lowered, the operation continues for up to one minute.
CAUTION
 Before you lower the vehicle’s height with the height
select switch, check under the vehicle to make sure
nothing that could damage the vehicle or no one who
could be injured is there and that the underbody of
the vehicle does not touch the ground.
 Do not select the “HI” mode when you load cargo on
the roof luggage carrier. Otherwise it may result in a
loss of control or vehicle rollover due to failure to
operate this vehicle correctly.
NOTICE
If the vehicle height is changed frequently, the
compressor may overheat, causing the vehicle
height adjustment operation to stop.
 After unloading, vehicle height rises slightly. Take
sufficient care where overhead space is restricted.
 Do not select “LO” mode when on bumpy roads. If
the underbody of the vehicle touches the rugged
road surface, the vehicle may be damaged.

STARTING AND DRIVING
444
(d) Selecting the easy access mode
1Easy access mode switch
2Easy access mode indicator light
To select the easy access mode, push the easy access
mode switch. The easy access mode indicator light
comes on.
When the engine is stopped, the vehicle height changes
automatically to the easy access mode. The indicator light
blinks while the height changes. When the vehicle height
reaches the easy access mode, the indicator light turns off.
This mode is available when “N” or “LO” mode is selected.
When the engine is restarted in the easy access mode, the
easy access mode indicator light blinks. When the vehicle
begins to run or you push the height select switch to change the
mode, the indicator light will remain on. When the vehicle’s speed exceeds approximately 12 km/h (8
mph) in the easy access mode, the “N” (normal) mode is
automatically selected.
The “N” indicator light blinks while the vehicle height changes.
When the vehicle’s height reaches the “N” mode, the indicator
light remains on.
To cancel the easy access mode, push the easy access mode
switch once again. The indicator light will turn off.
When
the engine is restarted after being stopped, easy access
mode is cancelled and “N” (normal) mode is automatically
selected.

STARTING AND DRIVING
445
1Higher2Lower
3Height control indicator lights
 Changing the mode
You can change the easy access mode to the “LO”, “N” or “HI”\
mode when the engine is running.
To change easy access mode to “LO” mode: Push the
height select switch on the “ ” (higher) side once.
To change easy access mode to “N”mode: Push the height
select switch on the “ ” (higher) side twice.
In the following cases, the vehicle’s height is automatically
changed to “N” (normal) mode.
 The vehicle speed exceeds approximately 12 km/h (8 mph).
 The engine is restarted and the easy access mode is
canceled. To change easy access
mode to “HI” mode: Push the height
select switch on the “ ” (higher) side for three times.
The “LO”, “N” or “HI” indicator light blinks while the\
vehicle’s
height changes. When the vehicle’s height reaches the “LO”,
“N” or “HI” mode, the indicator light remains on.
If the vehicle’s height is changed frequently, the raising or
lowering will take longer than usual. There is no problem in the
electronically modulated air suspension.
CAUTION
If you select easy access mode, check under the vehicle
to make sure nothing that could damage the vehicle or
no one who could be injured is there and that the
underbody of the vehicle does not touch the ground
before the engine is stopped.

STARTING AND DRIVING
446
(e) Turning off the electronically modulated airsuspension
1Height control switch
2Height control “OFF” indicator light
To turn off the electronically modulated air suspension
with the vehicle stopped, push the height control switch.
The height control “OFF” indicator light comes on and the
vehicle height is fixed in the same mode as was last
selected.
This status is maintained in the system even after the engine
is stopped.
If you push the switch again, the height control “OFF” indicator
light goes out and the electronically modulated air suspension
is turned on. When the vehicle’s speed exceeds 30 km/h (19 mph), the
height control “OFF” indicator light goes out and the
electronically modulated air suspension turns on
automatically.
CAUTION

If you drive through water, such as when crossing
shallow streams, first check the depth of the water
and the firmness of the bottom of the river bed then
put the vehicle height into “HI” mode with the height
select switch and turn off the electronically
modulated air suspension by pushing the height
control switch. Drive your vehicle at 30 km/h (19
mph) or slower and avoid deep water.
 When jacking up, installing tire chains or tying your
vehicle with chains or wires for transportation by a
flat bed, be sure to turn off the electronically
modulated air suspension with the height control
switch and stop the engine. Otherwise, the automatic
leveling function may cause the vehicle’s height to
change, resulting in an unexpected accident.
 If your vehicle must be towed, put the vehicle height
in the “N” mode and turn off the electronically
modulated air suspension. Otherwise, the automatic
leveling function may cause the vehicle’s height to
change, resulting in an unexpected accident.
