2006 LEXUS RX330 stop start

GAUGES, METERS AND SERVICE REMINDER INDICATORS
83
(l) “VSC” Warning Light
This light warns that there is a problem somewhere in the
vehicle stability control system or traction control system.
The light will come on when the ignition key is turned to the
“ON” position and will go off after a few seconds.
If the light comes on while driving, the vehicle stability control
system and traction control system do not work. However, as
conventional braking operates when applied, there is no
problem to continue your driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to the “ON” position.
 The warning light remains on after the ignition key is turned
to the “ON” position.
 The warning light comes on while driving.
Tw o −wheel drive models only — The “TRAC OFF” indicator
light will come on when the “VSC” warning light comes on even
if the “TRAC OFF” switch is not pushed.
(m) Automatic Transmission Fluid Temperature Warning Light
(fourwheel drive models only)
This light warns that the automatic transmission fluid
temperature is too high.
If this light comes on while you are driving, slow down and pull
off the road. Stop the vehicle at a safe place and put the
selector lever in “P” and leave the engine idling until the light
goes off. If the light goes off, you can start the vehicle again.
If the light does not go off, call a Lexus dealer or qualified repair
shop for assistance.
NOTICE
Continued driving with the warning light on may
damage the automatic transmission.
(n) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
nearly empty. Fill the tank as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
88The following
information is displayed when you push the
“INFO” button with the ignition switch turned on.
Each time you push the “INFO” button, the display toggles
through this information.
(1) Driving time after engine start
(2) Average vehicle speed after engine start
(3) Average fuel consumption after refueling
(4) Instantaneous fuel consumption
(5) Driving distance after engine start
(6) Driving range
The displayed values in the cruise information display indicate
general driving conditions. Accuracy varies with driving habits
and road conditions.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear. If the electrical power source has been disconnected from the
cruise information display,
the display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
You can adjust the brightness of the display. To adjust the
brightness, see “Multi −display light control” on page 91.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
(1) Driving time after engine start
(“E/T”)
The elapsed time after the engine starts is displayed.
When the engine is started, driving time is counted from 0:00.
Up to 11:59 (11 hours, 59 minutes) can be displayed. When the
driving time exceeds 11:59, the counter returns to 0:00.
The calculation is reset when the ignition switch is turned off.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
89
(2) Average vehicle speed after engine start(“AVG MPH” or “AVG km/h”)
Average vehicle speed after engine start is calculated and
displayed based on total driving distance and total driving
time with the engine running.
The displayed value is updated every 10 seconds.
To reset the calculations, push and hold the “INFO” button for
about 1 second when the display indicates the average vehicle
speed after engine start.
(3) Average fuel consumption after refueling (“AVG MPG” or “AVG L/100 km”)
Average fuel consumption after refueling is calculated
and displayed based on total driving distance and total
fuel consumption with the engine running.
The displayed value is updated every 10 seconds.
The calculation is reset when the vehicle starts after refueling.
(4) Instantaneous fuel consumption(“MPG” or “L/100 km”)
The instantaneous fuel consumption is calculated and
displayed based on distance and fuel consumption for 2
seconds with the engine running.
The displayed value is updated every 2 seconds.
Note that an accurate figure may not be shown in the following
cases.
 The vehicle is stopped with the engine running. (The display
will indicate the extremely high fuel consumption.)
 The vehicle is driving down a long slope applying the engine
brake. (The display will indicate the extremely low fuel
consumption.)
(5) Driving distance after engine start
(“Distance miles” or “Distance km”)
The driving distance after engine start is calculated and
displayed based on vehicle speed after engine running.
The displayed value is updated every time the fuel equivalent
for 0.1 km or 0.1 mile is consumed.
To reset the calculations, push and hold the “INFO” button for
about 1 second when the display indicates the driving distance
after engine start.

OCCUPANT RESTRAINT SYSTEMS
226If any driving position memory switch is pushed while one of the
memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (“1” or “2”)\
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory will
be erased and the memorized positions will have
to be set again.
CAUTION
 Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch.

AUDIO
274When the system can show the station name, “RDS” appears
on the display. Each time you push the “TEXT” button,
indication on
the display changes form the band to the station
name, a radio text in this order. After 6 seconds passes,
indication returns to the band.
Cassette tape player operation
(a) Playing a cassette tape
When you insert a cassette tape, the exposed tape should
face to the right.
The player will automatically start when you insert a cassette
tape. At this time, “TAPE” appears on the display.
To stop or eject the cassette tape, push the “
” (eject) button.
Autoreverse feature: After the cassette player reaches the
end of a tape, it automatically reverses and begins to play the
other side, regardless of whether the cassette was playing or
fast forwarding.

AUDIO
294
Cassette tape player operation
(a) Playing a cassette tape
When you insert a cassette tape, the exposed tape should
face to the right.
The player will automatically start when you insert a cassette
tape. At this time, “TAPE” appears on the display.
To stop or eject the cassette tape, push the “
” (eject) button.
Autoreverse feature: After the cassette player reaches the
end of a tape, it automatically reverses and begins to play the
other side, regardless of whether the cassette was playing or
fast forwarding.
If a cassette is already in the slot, push the “TAPE” button.
Dolby\b Noise Reduction* feature: If you are listening to a
tape that was recorded with Dolby \b Noise Reduction*, push
the “
” button. The display will indicate that the Dolby noise
reduction system is on.
The Dolby NR mode reduces tape noise by about 10 dB. For
best sound reproduction, play your tapes with the Dolby NR on
or off according to the mode used for recording the tape.
To play a tape recorded without Dolby NR, push the button
again to turn off the Dolby NR.
* Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation. “DOLBY” and the double −D
symbol
are trademarks of Dolby Laboratories Licensing
Corporation.

AUDIO
337
DVD video/DVD audio player operation
NOTE: The playback condition of some DVD discs may be
determined by a DVD software producer . This DVD player
plays a disc as the software producer intended. So, some
functions may not work properly. Be sure to read the
instruction manual for the DVD disc separately provided.
For the detailed information about DVD video discs, see
“DVD video disc information” on page 366.
Precautions for DVD video discs
When recording on a DVD video, DVD audio, video CD or
audio tracks may not record in some cases while the menu is
displayed. As audio will not play in this case, verify that the
video tracks are playing and then activate playback.
When playback of a disc is completed:
 If an audio CD is playing, the first track starts.
 If a DVD video, DVD audio or video CD is playing, playback
will stop or the menu screen will be displayed.
The title/chapter number and playback time display may not
appear while playing back certain DVD video discs.CAUTION
Conversational speech on some DVDs is recorded at a
low volume to emphasize the impact of sound effects.
If you adjust the volume assuming that the
conversations represent the maximum volume level
available for the DVD, you may be startled by louder
sound effects or when you change to a different audio
source. Loud sounds may have a significant impact on
the human body or pose a driving hazard. Keep this in
mind when you adjust the volume.

STARTING AND DRIVING
394
(c) Using the “3”, “2” and “L” positions
The “3”, “2” and “L” positions are used for strong engine\
braking
as described previously.
With the selector lever in “3”, “2” or “L”, you can start the vehicle
in motion as with the lever in “D”.
With the selector lever in “3” or “2”, the vehicle will start in firs\
t
gear and automatically shift to second gear or third gear.
With the selector lever in “L”, the transmission is engaged in
first gear.
NOTICE
 Be careful not to overrev the engine. Watch the
tachometer to keep engine rpm from going into the
red zone. The approximate maximum allowable
speed for each position is given below for your
reference.
“3” 144 km/h (90 mph). . . . . . . .
“2” 92 km/h (58 mph)
. . . . . . . . .
“L” 51 km/h (32 mph)
. . . . . . . . .
 Do not continue hill climbing or hard towing for a long
time in the “3”, “2” or “L” position. This may cause
severe automatic transmission damage from
overheating. To prevent such damage, “4” position
should be used in hill climbing or hard towing.
(d) Backing up
1Brake pedal2“R” (Reverse) position
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the
selector lever to the “R” position.
NOTICE
Never shift into reverse while the vehicle is moving.
Vehicles with driving position memory system —
When the shift lever is shifted into “R” position, the outside rear
view mirrors automatically down to help backing up. For
details, see page 231.
