REAR SONAR SYSTEMDI-69
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Symptom Chart EKS00BDA
SymptomRepair order
When the rear sonar system OFF switch is OFF, the indicator
lamp does not light and the buzzer does not sound. 1. Check rear sonar system OFF switch for malfunction. Refer to
DI-70, "
REAR SONAR SYSTEM OFF SWITCH" .
2. Check rear sonar system OFF switch ground circuit.
3. Check harness and connections between rear sonar system OFF switch and sonar control unit.
4. Replace sonar control unit. Refer to DI-70, "
SONAR CON-
TROL UNIT" .
When the rear sonar system OFF switch is OFF, the indicator
lamp does not light but buzzer sounds. 1. Check rear sonar system OFF indicator for malfunction. Refer
to DI-70, "
REAR SONAR SYSTEM OFF INDICATOR" .
2. Check harness and connections between rear sonar system OFF indicator and sonar control unit.
3. Replace sonar control unit. Refer to DI-70, "
SONAR CON-
TROL UNIT" .
When the rear sonar system OFF switch is OFF, the sonar
buzzer does not sound but indicator lamp illuminates. 1. Check sonar buzzer. Refer to
DI-70, "
SONAR BUZZER" .
2. Check harness and connections between sonar buzzer and sonar control unit.
3. Replace sonar control unit. Refer to: DI-70, "
SONAR CON-
TROL UNIT" .
When rear sonar system OFF switch is ON, the rear sonar sys-
tem OFF indicator lamp lights up and the sonar buzzer sounds
intermittently (for about 4 seconds). 1. Check harness between rear sonar sensors and sonar control
unit for an open condition.
2. Check rear sonar sensors for malfunction.
3. Replace sonar control unit. Refer to DI-70, "
SONAR CON-
TROL UNIT" .
The rear sonar system operates with the rear sonar system OFF
switch OFF. 1. Check rear sonar system OFF switch for malfunction. Refer to
DI-70, "
REAR SONAR SYSTEM OFF SWITCH" .
2. Check rear sonar system OFF switch ground circuit.
3. Check harness and connections between rear sonar system OFF switch and sonar control unit.
4. Replace sonar control unit. Refer to DI-70, "
SONAR CON-
TROL UNIT" .
When the transmission gear selector lever is in the R position
and the rear sonar system OFF switch is OFF, the sonar system
does not operate. 1. Check for PNP switch failure. Refer to
AT-86, "
SELF-DIAG-
NOSTIC RESULT MODE" .
2. Check harness and connections between sonar control unit and PNP/reverse lamp circuits.
3. Replace sonar control unit. Refer to DI-70, "
SONAR CON-
TROL UNIT" .
When the rear sonar system OFF switch is OFF, the indicator
lamp lights up and buzzer sounds although there is no obstacle
within the detection range. 1. Check for adhesion of snow, mud, or other foreign objects to
rear sonar sensors; dew condensation; etc. Refer to DI-66,
"Pre-diagnosis Inspection" .
2. Check that the rear sonar sensor is properly aligned (bumper is not misaligned, no deformation in sensor mounting area
3. Check harness and connections between rear sonar sensors and sonar control unit.
4. Check rear sonar sensors for malfunction.
5. Replace sonar control unit. Refer to DI-70, "
SONAR CON-
TROL UNIT" .
The rear sonar sensors do not operate according to the distance
between each sensor and the obstacle. (There is a large error in
the obstacle detection distance. 1. Check rear sonar sensors for malfunction.
2. Replace sonar control unit. Refer to
DI-70, "
SONAR CON-
TROL UNIT" .
3. Check for adhesion of snow, mud, or other foreign objects to rear sonar sensors; dew condensation; etc. Refer to DI-66,
"Pre-diagnosis Inspection" .
4. Check that the rear sonar sensor is properly aligned (bumper is not misaligned, no deformation in sensor mounting area

DI-70
REAR SONAR SYSTEM
Revision: November 20092006 QX56
Component InspectionEKS00BDB
SONAR BUZZER
1. Disconnect the sonar buzzer connector.
2. Check continuity between buzzer terminal (1) and terminal (2)
REAR SONAR SYSTEM OFF SWITCH
Disconnect the rear sonar system OFF switch connector M116.
Check continuity between the following terminals.
REAR SONAR SYSTEM OFF INDICATOR
Disconnect the rear sonar system OFF switch connector M116, and
apply battery voltage (approx. 12V) to switch terminal 5. Check the
rear sonar system OFF indicator operation when switch terminal 6 is
connected to battery ground.
Removal and InstallationEKS00BDC
REAR SONAR SENSORS
Refer to EI-15, "Removal and Installation" for rear sonar sensor removal and installation procedures.
SONAR CONTROL UNIT
Removal
1. Remove luggage side finisher LH. Refer to EI-40, "LUGGAGE FLOOR TRIM" to gain access to sonar
control unit.
2. Disconnect electrical connector then remove sonar control unit. Refer to DI-60, "
Component Parts and
Harness Connector Location" .
Installation
Installation is in the reverse order of removal.(1) - (2)
: Continuity should exist
WKIA4417E
Rear sonar system OFF
switch Terminal to be inspected Continuity
Depressed 1 - 2Ye s
Released No
WKIA2025E
Terminal to be
inspected Condition Operation
Rear sonar sys-
tem OFF switch 5 Approx. 12V Rear sonar
system OFF
indicator lights
6
Ground
WKIA2026E

GW-68
REAR DOOR GLASS AND REGULATOR
Revision: November 20092006 QX56
REAR DOOR GLASS AND REGULATORPFP:82300
Removal and InstallationEIS0062O
REAR DOOR GLASS
Removal
1. Remove the rear door finisher. Refer to EI-33, "REMOVAL" .
2. Temporarily reconnect the power window switch.
3. Operate the power window switch to raise/lower the door win- dow until the glass bolts can be seen.
4. Remove the inside seal.
5. Remove the glass run from the partition glass.
6. Remove the partition sash bolt (lower) and screw (upper) to remove the sash.
7. Remove the glass bolts and glass.
Installation
Installation is in the reverse order of removal.

Reset the power window limit switch. Refer to GW-70, "SETTING AFTER INSTALLATION" .
Fitting Inspection

Check that the glass is securely fit into the glass run groove.

Lower the glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)], and check that the clearance to the
sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts,
guide rail bolts, and glass and carrier plate bolts to correct the glass position.
WIIA0298E
SIIA0290E
Glass bolts : 6.1 N·m (0.62 Kg-m, 54 in-lb)

INSTRUMENT PANEL ASSEMBLYIP-11
C
DE
F
G H
J
K L
M A
B
IP
Revision: November 2009 2006 QX56
REMOVAL
1. Remove center console. Refer to IP-17, "DISASSEMBLY AND ASSEMBLY" .
2. Remove instrument lower cover LH. Refer to IP-13, "
INSTRUMENT LOWER COVER LH" .
3. Remove steering column. Refer to PS-10, "
STEERING COLUMN" .
4. Remove glove box assembly. Refer to IP-14, "
Lower Instrument Panel RH and Glove Box" .
5. Remove front power socket LH. Refer to WW-54, "
Front Power Socket LH, Rear Cargo Power Socket" .
6. Remove front power socket RH. Refer to WW-54, "
Front Power Socket RH (For Cigarette Lighter), Con-
sole Power Socket" .
7. Remove combination meter. Refer to IP-14, "
Lower Instrument Panel RH and Glove Box" .
8. Remove audio unit. Refer to AV- 5 5 , "
AUDIO UNIT" .
9. Remove display unit. Refer to AV- 1 6 7 , "
DISPLAY CONTROL UNIT" .
10. Remove lower knee protector LH.
11. Remove GPS antenna. Refer to AV- 1 6 7 , "
Removal and Installation" .
12. Remove optical sensor. Refer to LT- 6 4 , "
Optical Sensor" .
13. Remove side ventilator assembly LH.
14. Remove side ventilator assembly RH.
15. Remove front pillar finisher. Refer to EI-36, "
FRONT PILLAR FINISHER" .
16. Remove passenger air bag module. Refer to SRS-50, "
FRONT PASSENGER AIR BAG MODULE"
17. Remove instrument panel.
18. Disconnect remaining instrument panel assembly electrical connectors.
INSTALLATION
Installation is in the reverse order of removal.
1. Steering member brackets2. Bracket assembly LH3. Steering member assembly
4. Combination meter cover 5. Defrost grille6. Instrument panel speaker LH
7. Instrument panel 8. Bin mat9. Side ventilator assembly LH
10. Instrument lower cover LH 11. Lower knee protector LH12. Steering column cover upper
13. Steering column cover lower 14. Center console lower cover LH 15. Combination meter
16. Audio unit bracket LH 17. Driver instrument stay18. Audio unit
19. Passenger instrument stay 20. Display assembly21. Switch assembly
22. Cluster lid A 23. Cluster lid D ventilator LH24. Front passenger air bag status light
25. Power socket LH and power socket RH 26. Clock 27. Cluster lid C
28. Front air control 29. Audio control30. Hazard switch
31. Cluster lid D ventilator RH 32. Cluster lid D33. Glove box door
34. Glove box assembly 35. Lower instrument panel RH 36. Glove box striker
37. Rubber bumpers 38. Glove box damper39. Audio unit bracket RH
40. Center console lower cover RH 41. Fuse block cover 42. Side ventilator assembly RH
43. Instrument panel bracket 44. Instrument panel speaker RH 45. Bracket assembly RH
46. Key cylinder escutcheon 47. Instrument lower cover RH

LT-64
AUTO LIGHT SYSTEM
Revision: November 20092006 QX56
Optical SensorEKS00B96
REMOVAL AND INSTALLATION
Removal
1. Remove defrost grille. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect the connector.
3. Turn the optical sensor counterclockwise to remove it from defroster grille.
Installation
Installation is in the reverse order of removal.
WKIA1061E

LT-98
LIGHTING AND TURN SIGNAL SWITCH
Revision: November 20092006 QX56
LIGHTING AND TURN SIGNAL SWITCHPFP:25540
Removal and InstallationEKS00BA5
REMOVAL
1. Remove steering column cover.
2. While pressing tabs, pull lighting and turn signal switch toward
driver door and disconnect from the base.
INSTALLATION
Installation is in the reverse order of removal.
LKIA0013E

OIL PUMPLU-13
C
DE
F
G H
I
J
K L
M A
LU
Revision: November 2009 2006 QX56
OIL PUMPPFP:15010
Removal and InstallationEBS00LMW
REMOVAL
1. Remove front cover. Refer to EM-38, "REMOVAL" .
2. Remove the oil pump drive spacer.
3. Remove the oil pump.
INSTALLATION
Installation is in the reverse order of removal, paying attention of the following:

When inserting the oil pump drive spacer, align the crankshaft
key and the flat face of the inner rotor.

If they are not aligned, rotate the oil pump inner rotor by hand.

Make sure that the each part is aligned and tap lightly until it
reaches the end.
WBIA0415E
1. Oil pump body 2. Outer rotor3. Inner rotor
4. Oil pump cover 5. Oil pump drive spacer6. Regulator valve
7. Regulator spring 8. Regulator plug
KBIA2512E
KBIA2490E

RAX-8
REAR DRIVE SHAFT
Revision: November 20092006 QX56
5. Separate the drive shaft from the wheel hub and bearing assembly by lightly tapping the end with a suit-
able hammer and wood block. If it is difficult to separate, use a suitable puller.
6. Remove the drive shaft. CAUTION:
When removing the drive shaft, do not bend at an excessive angle to the drive shaft joint. Do not
excessively extend the slide joint.
INSPECTION AFTER REMOVAL

Move the joint up and down, left and right, and in the axial direc-
tion. Check for any rough movement or significant looseness.

Check the boot for cracks or other damage, and for any grease
leakage.

If necessary, disassemble the drive shaft, and repair as neces-
sary.
INSTALLATION
Installation is in the reverse order of removal.

Do not reuse the drive shaft inside flange bolts, discard after removal and use new bolts for installation.

Do not reuse the cotter pin, discard after removal and use a new cotter pin for installation.
Disassembly and AssemblyEDS001XQ
DISASSEMBLY
Final Drive Side
1. Mount the drive shaft in a vise.CAUTION:
When mounting the drive shaft in a vise, use copper or aluminum plates between the vise and the
drive shaft.
2. Remove the boot bands.
RAA0030D
1. Plug 2. Housing3. Snap ring
4. Ball cage, steel ball, liner race assembly 5. Stopper ring 6. Boot band
7. Boot 8. Shaft9. Circlip
10. Joint sub-assembly
SDIA1488E
