µAfter everyone has entered the
vehicle, be sure the doors are closed
and locked.
The f ollowing pages provide
instructions on how to properly
protect the driver, adult passengers
and teenage children who are large
enough and mature enough to drive
or ride in the f ront seat.
Locking the doors also helps prevent
an outsider f rom unexpectedly
opening a door when you come to a
stop. Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash, and it
helps prevent passengers f rom
accidentally opening a door and
f alling out. If any door or the trunk is not closed
tightly, the multi-information display
reminds you to close the open
door(s) or the trunk bef ore you start
driving (see page ).
See page f or how to lock the
doors.
See pages f or important
guidelines on how to properly
protect inf ants, small children, and
larger children who ride in your
vehicle.
Adjust the driver’s seat as far to the
rear as possible while allowing you to
maintain f ull control of the vehicle.
Have your f ront passenger adjust
their seat as f ar to the rear as
possible.
If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inf lating f ront
airbag, or by striking the steering
wheel or dashboard.
34 38
69
92
CONT INUED
Protecting A dults and Teens
Adjust the Front Seats
Close and L ock the Doors
Introduction 2.
1.
Driver and Passenger Saf ety
13

Your seat belt system includes lap/
shoulder belts in all f ive seating
positions. The f ront seat belts are
also equipped with automatic seat
belt tensioners.The lap and shoulder belt goes over
your shoulder, across your chest,
and across your hips.
To fasten the belt, insert the latch
plate into the buckle, then tug on the
belt to make sure the buckle is
latched (see page f or how to
properly position the belt).
To unlock the belt, press the red
PRESSbuttononthebuckle.Guide
the belt across your body so that it
retracts completely. Af ter exiting the
vehicle, be sure the belt is out of the
way and will not get closed in the
door.All seat belts have an emergency
locking retractor. In normal driving,
the retractor lets you move f reely in
your seat while it keeps some
tension on the belt. During a collision
or sudden stop, the retractor
automatically locks the belt to help
restrain your body.
The seat belts in all positions except
the driver’s have an additional
locking mechanism that must be
activated to secure a child seat (see
page ).
If the shoulder part of the belt is
pulled all the way out, the locking
mechanism will activate. The belt
will retract, but it will not allow the
passenger to move f reely.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals, and you
will also see a ‘‘FASTEN SEAT
BELT’’ message on the multi-
inf ormation display. The seat belt system
includes an indicator on the
instrument panel to remind you and
your passengers to f asten your seat
belts.
If you turn the ignition switch to the
ON (II) position without f astening
your belt, a beeper will sound and
the indicator will flash. If you do not
f asten your seat belt bef ore the
beeper stops, the indicator will stop
f lashing but remain on. 16
46
Seat Belt System Components L ap/Shoulder Belt
Additional Inf ormation About Your Seat Belts
20

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .58
............................
Instrument Panel .59
..........
Instrument Panel Indicators .60
.............................................
Gauges .66
...................
Temperature Gauge .66
..................................
Fuel Gauge .66
.............
Multi-Inf ormation Display .67
......
Controls Near Steering Wheel .82
.
Windshield Wipers and Washers .83
...........
Turn Signal and Headlights .84
........................................
Fog Lights .85
........
Instrument Panel Brightness .85
..................
Automatic Lighting Off .86
.................
Hazard Warning Button .86
.................
Rear Window Def ogger .87
..........
Steering Wheel Adjustment .88
..................................................
Keys .89
................................
Ignition Switch .90
........................
Immobilizer System .91
......................................
Door Locks .92
................................................
Trunk .93
........
Emergency Trunk Opener .94
..................
Childproof Door Locks .94
.......................
Remote Transmitter .95
.................................................
Seats .98
..........
Trunk Pass-through Cover .100 ...........................................
Mirrors .101
Driving Position Memory ........................................
System .103
..................................
Seat Heaters .106
............................
Power Windows .107
.......................................
Moonroof .110
..............................................
Clock .112
...............................
Parking Brake .112
...............................
Interior Lights .113
.........
Interior Convenience Items .114
.....................
Beverage Holders .115
........
Accessory Power Sockets .115
..................................
Glove Box .116
.............
Console Compartment .116
..................
Front Door Pockets .117
Instruments and Controls
Inst rument s and Cont rols
57

Î
Î
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
:
Instrument Panel
Inst rument s and Cont rols
59
HIGH BEAM INDICATOR
SUPPLEMENTAL
RESTRAINT
SYSTEM INDICATOR LIGHTS ON
INDICATOR
CRUISE MAIN
INDICATOR
SEAT BELT REMINDER
INDICATOR
CRUISE CONTROL
INDICATOR
VEHICLE
STABILITY
ASSIST (VSA)
SYSTEM
INDICATOR MULTI-INFORMATION
DISPLAY
LOW FUEL INDICATOR
VSA ACTIVATION
INDICATOR
MALFUNCTION INDICATOR LAMP
(P.62)
(P.60)
(P.61) (P.63)
(P.62) (P.62)(P.63)
(P.60)
(P.61)
(P.64)
(P.64)
(P.64)
LOW OIL PRESSURE INDICATOR
CHARGING SYSTEM INDICATOR FOG LIGHT INDICATOR (P.65)
TIRE PRESSURE MONITORING
SYSTEM INDICATOR
IMMOBILIZER SYSTEM INDICATOR ANTI-LOCK BRAKE SYSTEM INDICATOR
DAYTIME RUNNING LIGHT INDICATOR (P.63) LOW TIRE PRESSURE
INDICATOR
(P.65)
PARKING BRAKE AND
BRAKE SYSTEM INDICATOR
SIDE AIRBAG OFF
INDICATOR
(P.60,256) (P.60,256) (P.62,202)(P.61,201)
(P.60,257)(P.67)

The instrument panel has many
indicators to give you important
inf ormation about your vehicle. The engine can be severely damagedif this indicator f lashes or stays on
when the engine is running. For
more information, see page .
If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
See page .This indicator has two f unctions:
If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, it can
indicate a problem in the brake
system. For more inf ormation, see
page .
This indicator comes on when you
turn the ignition switch to the ON
(II) position. It reminds you and your
passengers to f asten your seat belts.
A beeper also sounds if you have not
f astened your seat belt.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals, and you
will also see a ‘‘FASTEN SEAT
BELT’’ message on the multi-
inf ormation display (see page ).
If you drive without releasing the
parking brake, a chime will sound,
and you will also see a ‘‘RELEASE
PARKING BRAKE’’ message on the
multi-inf ormation display (see page
).
If you turn the ignition switch to the
ON (II) position bef ore f astening
your seat belt, the beeper sounds,
and the indicator f lashes. If you do
notfastenyourseatbeltbeforethe
beeper stops, the indicator stops
f lashing but remains on. Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. Driving with
the parking brake not f ully
released can damage the brakes
and tires.
1.
2.
69 256
256 257 258
70
Instrument Panel Indicators
Seat Belt Reminder
Indicator L ow Oil Pressure
Indicator
Charging System
Indicator
Malf unction Indicator
Lamp Parking Brake and
Brake System
Indicator
60
Canada
U.S.

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it means that one or more of your
vehicle’s tires are extremely low on
pressure. You will also see a
‘‘CHECK TIRE PRESSURE’’
message on the multi-inf ormation
display. The multi-inf ormation
display will show you which tire has
lost the pressure and how much
pressure it has lost (see page ).This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If this indicator comes on and stays
on at any other time, or if it does not
come on when you turn the ignition
switch to the ON (II) position, there
is a problem with the TPMS. You will
also see ‘‘CHECK TPMS SYSTEM’’
message on the multi-information
display. With this indicator on, the
low tire pressure indicator will not
come on, and the tire pressure
monitor on the multi-inf ormation
display will not be displayed.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost the pressure on the multi-
inf ormation display, and determine
the cause. If it is because of a flat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service.
For more inf ormation, see page .
245
204 204
Low Tire Pressure
Indicator
Tire Pressure Monitoring
System (T PMS) Indicator
Instrument Panel Indicators
65

The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably.
Others help to keep you aware of the
periodic maintenance your vehicle
needs f or continued trouble-f ree
driving.Driver 1 or 2 Detected
Door and Trunk Open
Fasten Seat Belt
Release Parking Brake
Odometer
Trip Meter
Outside Temperature
Engine Oil Lif e Maintenance Messages
Auto door lock conditions
Auto door unlock conditions
Whenever unlocking (driver’s
door, or all doors)
Keyless lock acknowledgment
conditions
Security relock timer
Headlight auto of f timer
Interior light dimming time
To customize these control settings,
see page .
Low Windshield Washer Fluid
Level (Canada only)
Here is a list of the messages you
can see. The f ollowing pages give
you more inf ormation on these
messages.
Tighten Fuel Cap With the multi-information display
and the two buttons next to it, you
can also customize these vehicle
control settings to your liking.Language Selection (Canada only) HandsFree Link
Keyless Memory Settings
Trip Computer
Tire Pressure
76
Multi-Inf ormation Display
67
SELECT/
RESET
BUTTON
INFO
BUTTON
TMTM

¼»
With the ignition switch in the ON
(II) position, the basic display
changes, as shown in the illustration,
each time you press the side of
the INFO button. If you press the
side of the INFO button, the display
returns to the previous message.
On Canadian models, the language in
the multi inf ormation display can be
set to English or French. To change
the language see page .
81
Multi-Inf ormation Display
Inst rument s and Cont rols
68
(CANADIAN MODELS ONLY)
