System Outline
19-108VSA System Components
System Description (cont’d)
CONTROL UNIT
MODULATOR UNIT VSA MODULATOR-
CONTROL UNIT
Brake pressure
signal
 Solenoid control
 Motor control
Communication via F-CAN
VSA
OFF
SWITCH
PARKING
BRAKE
SWITCH BRAKE
FLUID
LEVEL
SWITCH
WHEEL SPEED SENSOR
 Engine torque control request
 Control mode signal
 VSA control enable/disable
 Throttle open angle signal
 Engine revolution signal
 Brake pedal
position switch signal
 Service check signal
 Gear position signal
Wheel rotation
pulse signal
ECM/PCM
BRAKE
PEDAL
POSITION
SWITCH
GAUGE CONTROL MODULE (TACH)
YAW RATE-LATERAL
ACCELERATION
SENSORSTEERING ANGLE
SENSOR
VSAOFFswitchsignal
 Parking brake switch signal
 Brake fluid level switch signal
 Yaw rate signal
 Lateral acceleration signal Steering angle signal
 Indicator drive signal
 Buzzer request signal*
*: ’09 model
This system is composed of the VSA modulator-control unit, the wheel speed sensors, the steering angle sensor, the
yaw rate-lateral acceleration sensor, and the system indicators in the gauge control module (tach). The VSA
modulator-control unit controls the ABS, EBD, TCS, VSA, and brake assist with the brake pressure of each wheel and
reduces engine torque.
08/08/21 15:04:53 61SNR030_190_0108
ProCarManuals.com
DYNOMITE -2009-



ABS Features
Anti-lock control
Grip force of tire and road surface
Main Control
19-109
COEFFICIENT OF
FRICTIONTARGET SLIP RATE
ROTATIONAL
DIRECTION
RADIAL
DIRECTION
OF THE
ROTATIONAL
DIRECTION
SLIP RATE
LEFT-REAR
WHEEL SPEED
SENSOR RIGHT-REAR
WHEEL SPEED
SENSOR
LEFT-FRONT
WHEEL SPEED
SENSOR RIGHT-FRONT
WHEEL SPEED
SENSOR Select Low
Speed Wheel
Detect
Vehicle Speed
Drive
SolenoidRIGHT-REAR
SOLENOID
LEFT-REAR
SOLENOID
RIGHT-FRONT
SOLENOID
LEFT-FRONT
SOLENOID
CONTROL UNIT
ABS
Control
Reference
Slip Rate
Drive
Solenoid
ABS
Control
Drive
Solenoid
ABS
Control
Drive
Solenoid
ABS
Control
RIGHT-FRONT
LEFT-FRONT
Detect
Wheel Speed
Detect
Slip Rate
RIGHT-REAR
LEFT-REAR Detect
Slip Rate
Detect
Slip Rate
Detect
Slip Rate
Detect
Wheel Speed
Detect
Wheel Speed
Detect
Wheel Speed
Without ABS, when the brake pedal is pressed while driving, the wheels sometimes lock before the vehicle comes to a
stop. In such an event, the maneuverability of the vehicle is reduced if the front wheels are locked, and the stability of
the vehicle is reduced if the rear wheels are locked, creating an extremely unstable condition. With ABS, the system
precisely controls the slip rate of the wheels to ensure maximum grip force from the tires, and it thereby ensures
maneuverability and stability of the vehicle. The ABS calculates the slip rate of the wheels based on the four wheel
speeds, and then it controls the brake fluid pressure to reach the target slip rate.
The control unit detects the wheel speed based on the wheel speed sensor signals it receives, then it calculates the
vehicle speed based on the detected wheel speed. The control unit detects the vehicle speed during deceleration
based on the wheel speeds.
The control unit calculates the slip rate of each wheel, and transmits the control signal to the modulator unit solenoid
valve when the slip rate is high.
The hydraulic control has three modes: Pressure intensifying, pressure reducing, and pressure retaining.
(cont’d)
08/08/21 15:04:53 61SNR030_190_0109
ProCarManuals.com
DYNOMITE -2009-



EBD Features
TCS Features
19-110VSA System Components
System Description (cont’d)
REAR WHEEL
BRAKE PRESSURE
With EBD under HEAVY LOAD
at REAR WHEELS
With EBD under LIGHT LOAD
at REAR WHEELS
Without EBD
FRONT WHEEL BRAKE PRESSURE
ANTI-POWER of BRAKE FORCE
TOTAL TRACTION DRIVING POWER
TOTAL TRACTION
BRAKE FORCE
SLIPPERY ROAD SURFACE
NORMAL ROAD SURFACE
The electronic brake distribution (EBD) feature helps control vehicle braking by adjusting the rear brake force in
accordance with the rear wheel load before the ABS operates. Based on the wheel speed sensor signals, the control
unit uses the modulator to control the rear brakes individually. When the rear wheel speed is less than the front wheel
speed, the VSA modulator-control unit retains the current rear brake fluid pressure by closing the inlet valve in the
modulator. As the rear wheel speed increases, and approaches the front wheel speed, the VSA modulator-control unit
increases the rear brake fluid pressure by momentarily opening the inlet valve. This whole process is repeated very
rapidly. While this is happening, kickback may be felt at the brake pedal.
When a drive wheel loses traction on a slippery road surface and starts to spin, the VSA modulator-control unit applies
brake pressure to the spinning wheel, and sends an engine torque control request to the ECM/PCM to slow the
spinning wheel and keep traction.
08/08/21 15:04:54 61SNR030_190_0110
ProCarManuals.com
DYNOMITE -2009-



Modulator Unit
Mode VSA NOValveVSA NC
Valve Inlet
Solenoid Valve Outlet
Solenoid Valve Brake Fluid
Pressure
intensifying
mode
Pressure
retaining
mode
Pressure
reducing
mode
Pressure
adding
mode
19-113
FL RR RL
FR
OUT OUT
IN
IN
VSA NO VSA NC
REGULATOR
VALVE PRESSURE
SENSOR
DAMPING
CHAMBER
RESERVOIR MOTOR
RESERVOIRVSA NC VSA NO
REGULATOR
VALVE IN
IN OUT
OUT
MODULATOR UNIT
IN : INLET SOLENOID VALVE (NORMALLY OPEN)
OUT : OUTLET SOLENOID VALVE (NORMALLY CLOSED)
MASTER CYLINDER
The modulator unit consists of the inlet solenoid valve, the outlet solenoid valve, the VSA NO (normally open)
solenoid valve, the VSA NC (normally closed) solenoid valve, the reservoir, the pump, the pump motor, and the
damping chamber.
The hydraulic control has three modes at ABS action; pressure intensifying, pressure retaining, and pressure reducing.
Pressure adding mode is combined the TCS, VSA, and brake assist action.
The hydraulic circuit is an independent four channel type; one channel for each wheel.




open closed open closed Master cylinder fluid is pumped out to
the caliper.
open closed closed closed Caliper fluid is retained by the inlet and outlet valves.
open closed closed open Caliper fluid flows through the outlet valve to the reservoir.
The motor pumps the reservoir fluid
through the damping chamber to
the master cylinder .
closed open open closed Master cylinder fluid is pumped out by pump with motor through VSA
NC valve to the caliper.
Caliper fluid pressure exceeds
master cylinder pressure.
: The motor will keep running until the operation of the one anti-lock brake control is finished with the first pressure reducing mode.
08/08/21 15:04:55 61SNR030_190_0113
ProCarManuals.com
DYNOMITE -2009-

Î(#'
)
´ ´
19-114VSA System Components
Circuit Diagram
UNDER-DASH
FUSE/RELAY BOX
No. 4 (7.5 A)
IGNITION SWITCH
IG1 HOT in ON (II) and START (III)
BRAKE PEDAL
POSITION SWITCH
Closed: Brake pedal pressed 1
2
WHTRED
YAW RATE-
LATERAL
ACCELERATION
SENSOR
WHT RED 1
3
4
YEL
5
BLK
4
2
1 VSA OFF SWITCH
WHT
WHT
RED
5
No. 3 (40 A)
No.1(100A) No.2(50A)
No. 3 (30 A)
No. 12 (15 A)
UNDER-HOOD FUSE/RELAY BOX
BATTERY
ABS
INDICATOR
BRAKE SYSTEM
INDICATOR
1
VSA ACTIVATION
INDICATOR VSA
INDICATOR
19
28
27
GAUGE CONTROL
MODULE (TACH)
BRNB
WHT
29
RED
GRN
14
RED
G501
C2 C1
E24
F16
YEL
G602
BLU
LT GRN GRYREDBRN
BLK
WHT
LT GRN GRY
H1
D8 36 D2
G502
BLK
WHT
RED
WHT
LT BLU
B
G401
BRAKE FLUID
LEVEL SWITCH
Closed: Low fluid
1 2
BLK
ORN ORN
1
PARKING
BRAKE SWITCH
Closed: Parking
brake applied DATA LINK
CONNECTOR (DLC)
ORN
IG1
6
16
4 714
08/08/21 15:04:55 61SNR030_190_0114
ProCarManuals.com
DYNOMITE -2009-


19-116VSA System Components
Circuit Diagram (cont’d)
BRAKE PEDAL POSITION
SWITCH 4P CONNECTOR
PARKING BRAKE SWITCH
1P CONNECTOR
DATA LINK CONNECTOR (DLC) VSA OFF SWITCH
5P CONNECTOR
YAW RATE-LATERAL
ACCELERATION SENSOR
5P CONNECTOR
STEERING ANGLE SENSOR
5P CONNECTOR
BRAKE FLUID LEVEL SWITCH
2P CONNECTOR
UNDER-HOOD
FUSE/RELAY BOX
CONNECTOR C (2P)
WHEEL SPEED SENSOR
2P CONNECTOR
ECM/PCM CONNECTOR A (44P)
GAUGE CONTROL MODULE (TACH) 36P CONNECTOR
VSA MODULATOR-CONTROL UNIT 37P CONNECTOR UNDER-DASH FUSE/RELAY BOX CONNECTOR F (34P)
UNDER-DASH FUSE/RELAY BOX CONNECTOR E (42P)
Wire side of female terminals
Terminal side of female terminals
08/08/21 15:04:57 61SNR030_190_0116
ProCarManuals.com
DYNOMITE -2009-

(#' 
'

)
µ
µ
µ
µ µ
µ
DTC 41-21:
DTC 42-21:
DTC 43-21:
DTC 44-21:
DTC Appropriate Wheel
YES
NO
YES
NO YES
NO
19-137
Right-front Wheel Lock
Left-front Wheel Lock
Right-rear Wheel Lock
Left-rear Wheel Lock
The DTCs may be indicated under these conditions:
 The vehicle goes into a spin.
 The ABS or VSA continues to operate for a long time.
 Snow, dirt, or debris build-up on the wheel speed sensor or magnetic encoder.
 Misadjusted brake pedal position switch.
 Contaminated brake fluid.
1. Raise the vehicle, and support it with safety stands in the proper locations (see page 1-11).
2. Turn the appropriate wheel by hand.
41-21 Right-front
42-21 Left-front
43-21 Right-rear
44-21 Left-rear
Repair the brake drag.
Go to step 3.
3. Check that the appropriate wheel speed sensor is properly mounted (see page 19-173).
Go to step 4.
Reinstall the wheel speed sensor, and check
the mounting position (see page 19- 173).
4. Turn the ignition switch to ON (II).
5. Clear the DTC with the HDS.
6. Test-drive the vehicle at 10 km/h (7 mph) for 20 seconds or more.
NOTE: Drive the vehicle on a straight section of
road, not on a lift. 7. Check for DTCs with the HDS.
Check for loose terminals in the VSA
modulator-control unit 37P connector. If necessary,
substitute a known-good VSA modulator-control
unit (see page 19-171), and retest.
If any other DTCs are indicated, go to the
indicated DTCs troubleshooting. If DTCs are not
indicated, intermittent failure, the system is OK at
this time.
Is there brake drag?
Is t he w heel speed sensor i nst al l at i on OK ? Is DT C 41-21, 42-21, 43-21, and/ or 44-21
indicated?
08/08/21 15:05:56 61SNR030_190_0137
ProCarManuals.com
DYNOMITE -2009-


(#' 
'

)
µ
µ µ
µ
YES
NO
YES
NO
DTC 66-11:
DTC 66-12:
DTC 66-13:
DTC 66-14:
DTC 66-16:
19-14819-148VSA System Components
DTC Troubleshooting (cont’d)
ORN
BRAKE FLUID LEVEL SWITCH 2P CONNECTOR
12. Check for continuity between brake fluid level
switch 2P connector terminal No. 2 and body
ground.
Repair short to body ground in the wire
between the gauge control module (tach) and the
brake fluid level switch.
Substitute a known-good gauge control
module (tach), then go to step 1, and recheck. If no
DTCs are indicated, replace the original gauge
control module (tach) (see page 22-277). 1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Turn the ignition switch to LOCK (0), then turn it to
ON (II) again.
4. Check for DTCs with the HDS.
Replace the VSA modulator-control unit
(see page 19-171).
Intermittent failure, the system is OK at this
time.Pressure Sensor (Inside of VSA
Modulator-control Unit) Malfunction
Pressure Sensor (Inside of VSA
Modulator-control Unit) Malfunction
Pressure Sensor (Inside of VSA
Modulator-control Unit) Malfunction
Pressure Sensor (Inside of VSA
Modulator-control Unit) Malfunction
Pressure Sensor (Inside of VSA
Modulator-control Unit) Malfunction
Wire side of female terminals
Is there continuity?
Is DT C 66-11, 66-12, 66-13, 66-14, or 66-16indicated?
08/08/21 15:05:58 61SNR030_190_0148
