2006 ACURA CSX TPMS

µ
(#'
)
GroundComponent or Circuit Grounded
22-64Ground Distribution
Ground to Components Index
G1 Battery
G2 Engine
G3 Transmission housing
G101 A/T clutch pressure control solenoid valves A, B, C (A/T), CKP sensor, CMP sensor A, CMP sensor B, Data link connector (DLC), ECM/PCM (LG1), ECM/PCM (LG2), ECM/PCM (PG1), ECM/PCM (PG2), ECM/PCM (PGMETCS), EGR valve (K20Z2 engine), Ignition
coils, Immobilizer-keyless control unit, Rocker arm oil control solenoid, Rocker arm oil pressure switch, Transmission range
switch (A/T), VTC oil control solenoid valve
Shielding between the ECM/PCM and Knock sensor (KS) has wire.
Shielding between the ECM/PCM and Secondary HO2S (Sensor 2) has wire.
G201 Right fog light , Right front parking light, Right front side marker light, Right front turn signal light, Right headlight (high/low beams), Right HID unit , Windshield washer motor, Windshield wiper motor
G202 ABS modulator-control unit , VSA modulator-control unit
G301 A/C condenser fan motor, Blower motor relay, ELD, Left fog light , Left front parking light, Left front side marker light, Left front turn signal light, Left headlight (high/low beams), Left HID unit , Radiator fan motor (via fan control relay)
G401 Brake fluid level switch, Clutch interlock switch (M/T), Clutch pedal position switch (M/T), Hood switch, MICU (PG), Power transistor, Washer fluid level switch (G401 connects to G601 via under-dash fuse/relay box)
G402 EPS control unit
G403 Torque sensor
G501 Dash lights brightness controller and odometer select/reset switch, Driver’s door key cylinder switch, Driver’s door lock knob switch, HandsFreeLink control unit , MICU (SG), VSA OFF switch
G502 Data link connector (DLC), Front accessory power socket, Glove box light, Right power mirror defogger, Right side turn signal light
G503 Accessory power socket relays (front and console), Driver’s door lock switch, Gauge control module (tach), Left power mirror defogger, Left side turn signal light, Moonroof control unit/motor, Power mirror switch light, Power mirror switch, Power
window master switch (main switch), Power window master switch, Vanity mirror lights (driver’s and front passenger’s)
G504 Cable reel (steering wheel switches ground), Climate control unit, Front passenger’s door lock knob switch, Front passenger’s door lock switch, Gauge control module (speedo), Gauge control module (tach), Ignition key switch, Navigation unit , TPMS
control unit
G505 Audio unit , Navigation unit
G506 Memory erase signal (MES) connector, SRS unit (2 wires)
G601 A/T gear position console panel light/Park-pin switch (A/T), Console accessory power socket , Fuel pump, MICU (PG), Seat heater relays (driver’s and front passenger’s), Seat heater switches (driver’s and front passenger’s), Seat heaters (driver’s and
front passenger’s), Stereo amplifier (G601 connects to G401 via under-dash fuse/relay box)
Shielding between the left side impact sensor (FIRST) and rear safing sensor has wire.
Shielding between the SRS unit and left side impact sensor (FIRST) has wire.
G602 Driver’s seat belt buckle switch, Front passenger’s seat belt buckle switch, Left rear door lock knob switch, MICU (SG), MICU service check connector, ODS unit, Right rear door lock knob switch, Yaw rate-lateral acceleration sensor
Shielding between the right side impact sensor (FIRST) and right side impact sensor (SECOND) have wires.
Shielding between the SRS unit and right side impact sensor (FIRST) has wire.
G603 Noise condenser Shielding between the rear safing sensor and left side impact sensor (SECOND) has wire.
G701 High mount brake light, Left back-up light, Left inner taillight, Left rear side marker light, Left rear turn signal light, Left taillight/ brake light, License plate lights, Right back-up light, Right inner taillight, Right rear side marker light, Right rear turn signal light,
Right taillight/brake light, Trunk lid release actuator/Trunk lid latch switch
G801 Rear window defogger ( )
1: ’06-07 Touring and Premium models
2: ’07 TYPE S and ’08-09 models
3: ’08-09 models
4: TYPE S and ’08 premium and ’09 models
5: With HID
6: Without navigation system
7: With navigation system
8: ’09 model with navigation system
9: ’06-08 models, and ’09 model without navigation system
10: TYPE S model
4
512 4
5
82 3
7
3
67
9
10
2
08/08/21 14:24:03 61SNR030_220_0066
ProCarManuals.com
DYNOMITE -2009-

Loss of Communication DTC cross-reference chart
BUS OFF and Internal Error CodesDTC type Related Unit MICU Gauge ControlModuleClimate Control
Unit HandsFreeLink
Control Unit Immobilizer-
Keyless Control Unit
Transmitting Control Unit Message Receiving Unit/Loss of Communication DTC
MICU Gauge ControlModuleClimate Control
Unit Immobilizer-
Keyless Control Unit
22-76Multiplex Integrated Control System
General Troubleshooting Information (cont’d)
When an ECU on the CAN circuit is unable to communicate with other ECUs on the CAN circuit, one or more of the
control units will set a loss of communications DTC. Use this chart to find the control unit that is not communicating.
1. Find the Transmitting Control Unit that is in the same row as all of the loss of communication DTCs retrieved.
2. Do the input test for the transmitting control unit.
BUS OFF B1000 B1150 B1200 B1750 B1900
ECU (CPU) Error B1001
ECU (EEPROM)
Error B1002 B1152 B1202
ECU (Internal)
Error B1792
MICU RM B1188 HLSW B1155
WIPSW B1156 MICU B1157
DOORSW B1159
DRLOCKSW B1160 B1905
Gauge Control
Module VSP/NE B1011 B1205
A/T B1008 B1906
CDS (SRS) B1032 ECT B1206
ECM/PCM ENG B1168 A/T B1169
ABS or VSA
modulator-
control unit ABS or VSA B1170
TPMS Control
unit TPMS B1173
EPS Control unit EPS B1183
SRS SRS B1187
08/08/21 14:24:07 61SNR030_220_0078
ProCarManuals.com
DYNOMITE -2009-

Gauge Control ModuleDTC Description DTC typePage
22-78Multiplex Integrated Control System
DTC Troubleshooting Index (cont’d)
B1150 Communication bus line error (BUS-OFF)
Loss of
communication (see page 22-106)
B1152 Gauge control m odule internal error (EEPROM error) Internal error (see page 22-262)
B1155 Gauge control m odule lost communication with the MICU
(Headlight switch message) Loss of
communication(see page 22-263)
B1156 Gauge control m odule lost communication with the MICU
(Wiper switch message) Loss of
communication(see page 22-263)
B1157 Gauge control m odule lost communication with the MICU
(MICU message) Loss of
communication(see page 22-264)
B1159 Gauge control m odule lost communication with the MICU
(DOORSW message) Loss of
communication(see page 22-263)
B1160 Gauge control m odule lost communication with the MICU
(DRLOCKSW message) Loss of
communication(see page 22-264)
B1168 Gauge control m odule lost communication with the ECM/PCM
(Engine messages) Loss of
communication(see page 22-265)
B1169 Gauge control m odule lost communication with the PCM (A/T
message) Loss of
communication(see page 22-265)
B1170 Gauge control m odule lost communication with ABS/VSA
modulator-control unit (ABS/VSA message) Loss of
communication(see page 22-265)
B1173 Gauge control m odule lost communication with the TPMS
control unit (TMPS message) (’08-09 models) Loss of
communication(see page 22-266)
B1175 Fuel level sensor (Fuel gauge sending unit) circuit open Signal error (see page 22-267)
B1176 Fuel level sensor (Fuel gauge sending unit) circuit short Signal error (see page 22-268)
B1177 Battery voltage a bnormal (’06 model) Battery voltage (see page 22-269)
B1178 F-CAN communication line error Loss of
communication (see page 22-265)
B1183 Gauge control m odule lost communication with EPS control unit
(EPS message) Loss of
communication(see page 22-270)
B1187 Gauge control m odule lost communication with the SRS unit
(SRS message) Loss of
communication(see page 22-265)
B1188 Gauge control m odule lost communication with the MICU (RM
message) Loss of
communication(see page 22-263)
08/08/21 14:24:07 61SNR030_220_0080
ProCarManuals.com
DYNOMITE -2009-

Î
(#')

µµ
µ
Body Controller Area Network (B-CAN) and Fast Controller Area Network (F-CAN)
22-80 Multiplex Integrated Control System
System Description
GAUGE CONTROL MODULE (TACH)
CAN H CAN L
MICU
ECM/PCM
(F-CAN)
(B-CAN)UNDER-DASH FUSE/RELAY BOX
DATA LINK CONNECTOR
SRS UNIT
ABS MODULATOR-CONTROL UNIT*1
VSA MODULATOR-CONTROL UNIT*2
YAW RATE-LATERAL
ACCELERATION SENSOR*2
EPS CONTROL UNIT
TPMS CONTROL UNIT*3






 F-CAN
TRANSCEIVER
B-CAN
TRANSCEIVER
IMMOBILIZER-
KEYLESS CONTROL
UNITCLIMATE
CONTROL
UNIT
HANDSFREELINK
CONTROL UNIT*4
*1: ’06 07 Touring and Premium models
*2: ’07 TYPE S and ’08 09 models
*3: ’08 09 models
*4: ’09 model with navigation system
The body controller area network (B-CAN) and the fast controller area network (F-CAN) share information between
multiple electronic control units (ECUs). B-CAN communication moves at a slower speed (33.33 kbps) for convenience
related items and for other functions. F-CAN information moves at a faster speed (500 kbps) for ‘‘real time’’ functions
such as fuel and emissions data. To allow both systems to share information, the gauge control module translates
information from B-CAN to F-CAN and from F-CAN to B-CAN.
 The single wire method is used between the units not requiring the communication to move at a fast speed.
 Using a single wire method reduces the number of the wires used on the body controller area network.
08/08/21 14:24:08 61SNR030_220_0082
ProCarManuals.com
DYNOMITE -2009-

µ
µ
HDS Inputs and Commands
Input:System Menu Data List Data List Indication
22-88Multiplex Integrated Control System
System Description (cont’d)
Certain inputs happen so quickly that the HDS cannot update fast enough. Hold the switch that is being tested while monitoring the Data List.
This should give the HDS time to update the signal on the Data List.
Because the HDS software is updated to support the release for newer vehicles it is not uncommon to see system function tests that are not
supported.
Make sure that the most current software is loaded.
Gauges Cruise Control Main Switch OFF/ON Cruise Control Set Switch OFF/ON
Cruise Control Resume Switch OFF/ON
Washer Fluid Level Switch OFF/ON
VSA/TCS Off Switch OFF/ON
Gauge Select/Reset Switch OFF/ON
Parking Brake Switch OFF/ON
Brake Fluid Level Switch OFF/ON
Illumination Volume Plus Switch OFF/ON
Illumination Volume Minus Switch OFF/ON
Km/h mph Select Switch OFF/ON
Fuel Sending Unit Input 1 deg
Fuel Sending Unit Input 2 VOLTAGE
VSA/TCS Active Indicator OFF/ON
VSA/TCS Indicator (Warning) OFF/ON
ABS Indicator OFF/ON
Cruise Control Main Switch Indicator OFF/ON
MIL Indicator OFF/ON
Washer Fluid Level Indicator OFF/ON
DRL Indicator OFF/ON
Low Oil Pressure Indicator OFF/ON
Charging System Indicator OFF/ON
Cruise Main Switch ON Indicator OFF/ON
Maintenance Minder Indicator OFF/ON
High Beam Indicator OFF/ON
Parking Light ON Indicator OFF/ON
Low Fuel Warning Indicator OFF/ON
Security Indicator OFF/ON
Fog Light Indicator OFF/ON
Seat Belt Indicator OFF/ON
Speed Indicator (km/h) 0 249 km/h, over 250 km/h, Fail
Speed Indicator (mph) 0 154 mph, over 155 mph, Fail
Low Tire Pressure Indicator OFF/ON
TPMS Indicator OFF/ON
A/TGearPositionSwitch(R) OFF/ON
A/TGearPositionSwitch(P) OFF/ON
08/08/21 14:24:09 61SNR030_220_0090
ProCarManuals.com
DYNOMITE -2009-

Î(#')
22-100Multiplex Integrated Control System
Circuit Diagram
K5
G3 Q1 Q9
D2
LT BLU RED
No. 22 (7.5 A)
BLK
G501 T34
G602E6
BLK SG
G601E33
BLK
PG
H2
H1 Q6
B-CAN
MICU
G401 PNK
K4 G2
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHTBRN
No. 10 (7.5 A)
BLK F20
No. 2 (IG) (50 A)
ORNIG1
BAT
BLU
WHT
No. 23 (10 A)
BATTERY
IGNITION SWITCH
No. 1 (BAT) (100 A)
MICU
SERVICE
CHECK
CONNECTOR IG1 HOT in ON (II)
and START (III)
CEILING
LIGHT
H1
D4 D2
LT BLU K-LINEQ8





 AUDIO UNIT*6
NAVIGATION
UNIT*5
DATA LINK
CONNECTOR
IMMOBILIZER-
KEYLESS
CONTROL UNIT
SRS UNIT
TPMS CONTROL
UNIT*3
ABS
MODULATOR-
CONTROL UNIT *1 EPS CONTROL
UNIT
VSA MODULATOR-
CONTROL UNIT *2 IG1
LT BLU
LT BLU F14
F28VBU
16
G501 BLK
1
18
PNK
No. 35 (7.5 A)
FUSE
(UNDER-DASH
FUSE/
RELAY BOX)
No. 23 (10 A)
FUSE
(UNDER-DASH
FUSE/
RELAY BOX)
15
PUR
WHT
HANDSFREELINK
CONTROL UNIT *4
(B-CAN)
PNK
PNK
(B-CAN)
08/08/21 14:25:00 61SNR030_220_0102
ProCarManuals.com
DYNOMITE -2009-

Î
µµ
µ
22-101







 124
19
1
RED
WHT CAN L
F-CAN TRANSCEIVER
CAN H
LT GRN
3
G504BLK
5
32
PNK
(B-CAN) (B-CAN) BRN/YELBRNLG
G101 BLK
7 2
IG1
YEL
VBU
B-CAN 1
4
PNK
16
BLK
G504 WHT
21
PNK GAUGE CONTROL MODULE (TACH)
BRN
WHT
17
18
MAIN CIRCUIT
B-CAN
TRANSCEIVER LCD DISPLAY
(DTC CODE DISPLAY)
IMMOBILIZER-KEYLESS
CONTROL UNIT
CLIMATE
CONTROL UNIT
No. 36 (10 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX)
ABS MODULATOR-CONTROL UNIT*1
VSA MODURATOR-CONTROL UNIT*2
YAW RATE-LATERAL ACCELERATION
SENSOR*2
DATA LINK CONNECTOR
SRS UNIT
ECM/PCM
TPMS CONTROL UNIT*3
EPS CONTROL UNIT
WHT
: CAN line
No. 2 (15 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX)
: Other communication line
*1: ’06 07 Touring and Premium models
*2: ’07 TYPE S and ’08 09 models
*3: ’08 09 models
*4: ’09 model with navigation system
*5: With navigation system
*6: Without navigation system
BLK*2
PNK
PNK
08/08/21 14:25:01 61SNR030_220_0103
ProCarManuals.com
DYNOMITE -2009-

´µ

The Indicator Drive Circuit Check
Switch Input Check
The Beeper Drive Circuit Check
The LCD Segment Check
The Gauge Drive Circuit Check
22-242Gauges
Self-diagnostic Function (cont’d)
OFF ON
OFF ON
OFF ON
OFF ON
Gauge needles
Beeper
5sec.
Self-diagnostic
mode
SEL/RESET
SWITCH
When entering the self-diagnostic mode, the following indicators blink:
A/T gear position indicator, ABS indicator, brake system indicator, charging system indicator, cruise control indicator,
cruise main indicator, door indicator, DRL indicator, EPS indicator, fog light indicator , high beam indicator,
immobilizer indicator, lights-on indicator, low fuel indicator, low oil pressure indicator, low tire pressure indicator ,
maintenance minder indicator, malfunction indicator lamp (MIL), REV limit indicator (TYPE S model), seat belt
reminder indicator, security indicator, side airbag cutoff indicator, SRS indicator, TPMS indicator , trunk indicator,
VSA activation indicator , VSA indicator , and washer fluid level indicator.
1: ’07 TYPE S and ’08-09 models
2: ’08-09 models
3: TYPE S and ’08 Premium and ’09 models
At the initial stage of the self-diagnostic function, the beep sounds intermittently, the beeper sounds continuously
when any of the following switch inputs are switched from OFF to ON:
Cruise control main, dash lights brightness controller volume ( ), ( ) button, mph km/h switch, parking brake switch,
SEL/RESET switch, SET, RESUME, CANCEL switches, and VSA OFF switch . : ’07 TYPE S and ’08-09 models
When entering the self-diagnostic mode, the beeper sounds five times.
When entering the self-diagnostic mode, all the segments blink five times.
When entering the self-diagnostic mode, the tachometer needle sweeps from the minimum position to maximum
position, then returns to the minimum position.
NOTE:
After the beeper stops sounding and the gauge needle returns to the minimum position, pushing the SEL/RESET
switch starts the Beeper Drive Circuit Check (one beep) and the Gauge Drive Circuit Check again.
The check cannot be started again until the gauge needle returns to the minimum position.
If the needle fails to sweep, or the beeper does not sound, replace the gauge control module (tach).
3 2
2
11
The needle sweeps from the
minimum position to the
maximum position, then return
to the minimum position.
08/08/21 14:35:12 61SNR030_220_0244
ProCarManuals.com
DYNOMITE -2009-
