2006 ACURA CSX Engine filter

Î
Vacuum Distribution
K20Z2 engine
11-23
3ENGINE
COOLANT
9
5 18
4
6
7
8 20
19 2 26
16
15
25
11 13
14
10 21
23
12 ATMOSPHERE
1
ENGINE
COOLANT
24
17ATMOSPHERE
22
MASS AIR FLOW (MAF) SENSOR/
INTAKE AIR TEMPERATURE (IAT) SENSOR
AIR FUEL RATIO (A/F) SENSOR (SENSOR 1)
SECONDARY HEATED OXYGEN SENSOR
(SECONDARY HO2S) (SENSOR 2)
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
ENGINE COOLANT TEMPERATURE (ECT) SENSOR 1
CRANKSHAFT POSITION (CKP) SENSOR
KNOCK SENSOR
CAMSHAFT POSITION (CMP) SENSOR B
CAMSHAFT POSITION (CMP) SENSOR A
THROTTLE BODY
INJECTOR
FUEL PRESSURE REGULATOR
FUEL FILTER
FUEL PUMP
FUEL TANK INTAKE AIR RESONATOR
POSITIVE CRANKCASE VENTILATION (PCV) VALVE
THREE WAY CATALYTIC CONVERTER
EVAPORATIVE EMISSION (EVAP) CANISTER EVAPORATIVE EMISSION (EVAP) CANISTER
PURGE VALVE
EVAPORATIVE EMISSION (EVAP) CANISTER
VENT SHUT VALVE
FUEL TANK PRESSURE (FTP) SENSOR
INTAKE AIR BYPASS CONTROL THERMAL VALVE
FUEL TANK VAPOR CONTROL VALVE
AIR CLEANER EXHAUST GAS RECIRCULATION (EGR) VALVE and
POSITION SENSOR
(cont’d)
08/08/21 14:12:41 61SNR030_110_0023
ProCarManuals.com
DYNOMITE -2009-

Î
Vacuum Distribution (cont’d)
K20Z3 engine
11-24Fuel and Emissions Systems
System Description (cont’d)
3
ENGINE
COOLANT
9
5 17
4
6
7
8 19
18 2 25
16
15
24
11 13
14
10 20
22
12 ATMOSPHERE
1
ENGINE
COOLANT
23 ATMOSPHERE
21
MASS AIR FLOW (MAF) SENSOR/
INTAKE AIR TEMPERATURE (IAT) SENSOR
AIR FUEL RATIO (A/F) SENSOR (SENSOR 1)
SECONDARY HEATED OXYGEN SENSOR
(SECONDARY HO2S) (SENSOR 2)
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
ENGINE COOLANT TEMPERATURE (ECT) SENSOR 1
CRANKSHAFT POSITION (CKP) SENSOR
KNOCK SENSOR
CAMSHAFT POSITION (CMP) SENSOR B
CAMSHAFT POSITION (CMP) SENSOR A
THROTTLE BODY
INJECTOR
FUEL PRESSURE REGULATOR
FUEL FILTER
FUEL PUMP
FUEL TANK INTAKE AIR RESONATOR
POSITIVE CRANKCASE VENTILATION (PCV) VALVE
THREE WAY CATALYTIC CONVERTER
EVAPORATIVE EMISSION (EVAP) CANISTER EVAPORATIVE EMISSION (EVAP) CANISTER
PURGE VALVE
EVAPORATIVE EMISSION (EVAP) CANISTER
VENT SHUT VALVE
FUEL TANK PRESSURE (FTP) SENSOR
INTAKE AIR BYPASS CONTROL THERMAL VALVE
FUEL TANK VAPOR CONTROL VALVE AIR CLEANER
08/08/21 14:12:42 61SNR030_110_0024
ProCarManuals.com
DYNOMITE -2009-

(#'


)
µ
µ µ
µ µ
µ
YES
NO
YES
NO
YES
NO
DTC P0171:
DTC P0172:
11-11311-113
29. Reconnect all connectors.
30. Update the ECM/PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
31. Start the engine, and let idle.
32. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the secondary HO2S (Sensor 2) and
the ECM/PCM. If the ECM/PCM was updated,
substitute a known-good ECM/PCM (see page 11-7),
then go to step 31. If the ECM/PCM was substituted,
go to step 1.
Go to step 33.
33. Monitor the OBD STATUS for DTC P0141 in the DTCs MENU with the HDS.
If the ECM/PCM was updated,
troubleshooting is complete. If the ECM/PCM was
substituted, replace the original ECM/PCM
(see page 11-228). If any other Temporary DTCs or
DTCs were indicated in step 32, go to the indicated
DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the secondary
HO2S (Sensor 2) and the ECM/PCM. If the ECM/
PCM was updated, substitute a known-good ECM/
PCM (see page 11-7), then go to step 31. If the ECM/
PCM was substituted, go to step 1. If the screen
indicates NOT COMPLETED, keep idling until a
result comes on. NOTE:
 Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
 If any of the DTCs listed below are indicated at the same time as DTC P0171 and/or P0172, troubleshoot
those DTCs first, then recheck for P0171 and/or P0172.
P0101, P0102, P0103: Mass air flow (MAF) sensor
P0107, P0108, P1128, P1129: Manifold absolute
pressure (MAP) sensor
P0133, P1157, P1172, P2195, P2238, P2252, P2A00: Air
fuel ratio (A/F) sensor (Sensor 1)
P0134, P0135: Air fuel ratio (A/F) sensor (Sensor 1)
heater
P0137, P0138, P0139, P2270, P2271: Sec ondary HO2S
(Sensor 2)
P0141: Secondary HO2S (Sensor 2) heater
P0401 , P0404 , P0406 , P2413 : Exhaust gas
recirculation (EGR) system
P0443, P0496: EVAP canister purge valve
P2646, P2647, P2648, P2649: VTEC system : K20Z2 engine
1. Check the fuel pressure (see page 11-325).
Go to step 2.
 If the pressure is too high, replace the fuel pressure regulator (see page 11-337), then go to
step 7.
 If the pressure is too low, check the fuel pump, the fuel feed pipe and the fuel filter. If they are
OK, replace the fuel pressure regulator (see page
11-337), then go to step 7.
(cont’d)Fuel System Too Lean
Fuel System Too Rich
Is DTC P0141 indicated?Does t he scr een i nd i cat e PASSE D? Is the fuel pressure OK?
08/08/21 14:17:24 61SNR030_110_0113
ProCarManuals.com
DYNOMITE -2009-

µ
µ
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
µ
µ
YES
NO
YES
NO
YES
NO YES
NO
YES
NO
YES
NO
11-116
PGM-FI System
DTC Troubleshooting (cont’d)
8. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3
MISFIRE, and/or CYL4 MISFIRE in the DATA LIST
for 10 minutes with the HDS.
Go to step 9.
Intermittent failure, the system is OK at this
time.
9. Turn the ignition switch to LOCK (0).
10. Check the fuel quality.
Go to step 11.
Drain the tank, fill it with a known-good fuel,
then go to step 25.
11. Inspect the spark plugs (see page 4-21). If the spark plugs are fouled or worn, replace them.
12. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters:
 ENGINE S PEED
 VSS
 REL TP SENSOR
 CLV (calculated load value)
 APP SENSOR
13. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE in the DATA LIST
for 10 minutes with the HDS.
Go to step 14.
Go to step 25. 14. Check the fuel pressure (see page 11-325).
Go to step 15.
 If the fuel pressure is too high, replace the fuel pressure regulator (see page 11-337), then go to
step 25.
 If the fuel pressure is too low, check the fuel pump, the fuel feed pipe, and the fuel filter. If
they are OK, replace the fuel pressure regulator
(see page 11-337), then go to step 25.
15. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle.
16. Check for these conditions:  Engine coolant temperature (ECT SENSOR 1)above80°C(176°F)
 A/T in P or N, M/T in neutral
 All electrical loads off
17. Monitor the ENGINE SPDEED in the DATA LIST with the HDS, and hold the engine speed at
2,500 rpm. Once the engine speed is met, hold the
accelerator pedal steady for more than 10 seconds.
Repeat step 17.
Go to step 18.
18. While holding the engine speed at 2,500 rpm, check the MAF SENSOR in the DATA LIST with the HDS.
Go to step 19.
Replace the MAF sensor/IAT sensor (see page
11-224), then go to step 25.
Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 M I SF I RE , and / or CY L4 M I SF I RE show mi sf i r ecounts?
Is the quality good?
Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3M I SF I RE , and / or CY L4 M I SF I RE show mi sf i r ecounts? Is the fuel pressure OK?
Di d t he engi ne speed v ar y mor e t han 100 r pm f r om2,500 rpm?
Is t her e about 6.0 8.6 ( K 20Z 2 engi ne) or5.7 8.3 (K 20Z 3 engine) gm/ s?
08/08/21 14:17:24 61SNR030_110_0116
ProCarManuals.com
DYNOMITE -2009-

ØÚÓ

11-229
A
D
9.8 N·m
(1.0 kgf·m,
7.2 lbf·ft)
A
B
C
E
3. Make sure the HDS communicates with the ECM/ PCM and other vehicle systems. If it doesn’t, go to
the DLC circuit troubleshooting (see page 11-204). If
you are returning from DLC circuit troubleshooting,
skip steps 4 through 9, 20 through 25, and 28
through 30, and do these procedures after
replacing the ECM/PCM;
 Replace the engine oil (see page 8-10) and the engine oil filter (see page 8-11).
 Replace the ATF (A/T model) (see page 14-232).
 Clean the throttle body (see page 11- 344).
4. Select the PGM-FI system with the HDS.
5. Select the INSPECTION MENU with the HDS.
6. Select the ETCS TEST, then select the TP POSITION CHECK, and follow the screen prompts.
NOTE: If the TP POSITION CHECK indicates FAILED,
continue with this procedure.
7. Select the REPLACE ECM/PCM MENU, then select READ DATA, and follow the screen prompts.
NOTE: Doing this step copies (READS) the engine oil life data from the original ECM/PCM so you can later
download (WRITES) it into the new ECM/PCM.
 If READ DATA indicates FAILED, continue with this procedure.
8. A/T model: Select the A/T system with the HDS.
9. A/T model: Select the REPLACE TCM/PCM MENU, then select READ DATA and follow the screen
prompts.
NOTE: Doing this step copies (READS) the ATF life data from the original PCM so you can later download
(WRITES) it into the new PCM.
 If READ DATA indicates FAILED, continue with this procedure. 10. Turn the ignition switch to LOCK (0).
11. Jump the SCS line with the HDS.
12. Do the battery removal procedure (see page 22-69).
13. Remove the cover (A).
14. Remove the bolts (D), then remove the ECM/PCM
(E).
15. Disconnect ECM/PCM connectors A, B, and C. NOTE: ECM/PCM connectors A, B, and C have
symbols (A= , B= , C= ) embossed on them for
identification.
(cont’d)
08/08/21 14:23:40 61SNR030_110_0229
ProCarManuals.com
DYNOMITE -2009-

11-230PGM-FI System
ECM/PCM Replacement (cont’d)
16. Install the parts in the reverse order of removal.
17. Do the battery installation procedure (see page
22-69).
18. Turn the ignition switch to ON (II).
19. Manually input the VIN to the ECM/PCM with the HDS.
NOTE: DTC P0630 VIN Not Programmed or
Mismatch may be stored because the VIN has not
been programmed into the ECM/PCM; ignore it,
and continue this procedure.
20. If the READ DATA (engine oil life) failed in step 7, go to step 23 (A/T) or step 26 (M/T). Otherwise, go
to step 21.
21. Select the PGM-FI system with the HDS.
22. Select the REPLACE ECM/PCM MENU, then select WRITE DATA, and follow the screen prompts.
NOTE: If the WRITE DATA indicates FAILED,
continue with this procedure.
23. A/T model: If the READ DATA (ATF life) failed in step 9, go to step 26. Otherwise go to step 24.
24. A/T model: Select the A/T SYSTEM with the HDS.
25. A/T model: Select the REPLACE TCM/PCM MENU, then select WRITE DATA, and follow the screen
prompts.
NOTE: If the WRITE DATA indicates FAILED,
continue with this procedure.
26. Select IMMOBI system with the HDS.
27. Enter the immobilizer code that you got from the iN or use the ECM/PCM replacement procedure in the
HDS; it allows you to start the engine.
28. If the TP POSITION CHECK failed in step 7, clean the throttle body (see page 11- 344), then go to step
29. 29. IftheREADDATAfailedinstep8ortheWRITE
DATA failed in step 22, replace the engine oil
(see page 8-10) and engine oil filter (see page 8-11),
then go to step 30 (A/T) or step 31 (M/T).
30. If the READ DATA failed in step 10 or the WRITE DATA failed in step 27, replace the ATF (see page
14-232), then go to step 31.
31. Select PGM-FI system, and reset the ECM/PCM with the HDS.
32. Update the ECM/PCM if it does not have the latest software (see page 11-227).
33. Do the ECM/PCM idle learn procedure (see page 11-310).
34. Do the CKP pattern clear/CKP pattern learn procedure (see page 11-4).
08/08/21 14:23:41 61SNR030_110_0230
ProCarManuals.com
DYNOMITE -2009-


µ
µ
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO YES
NO
YES
NO
11-277
A
8. Monitor the OBD STATUS for DTC P0011 in the
DTCs MENU with the HDS.
Go to step 9.
If the screen indicates PASSED, intermittent
failure, the system is OK at this time. If the screen
indicates NOT COMPLETED, go to step 5 and
recheck.
9. Turn the ignition switch to LOCK (0).
10. Remove the auto-tensioner (see page 4-32).
11. Remove the VTC strainer (A), and check it for clogging.
Go to step 12.
Clean the VTC strainer, replace the engine oil
filter and the engine oil, then go to step 14.
12. Test the VTC oil control solenoid valve (see page 11-294).
Go to step 13.
Replace the VTC oil control solenoid valve
(see page 11-294), then go to step 14. 13. Inspect the VTC actuator (see page 6-11).
Go to step 14.
Replace the VTC actuator (see page 6-42),
then go to step 14.
14. Turn the ignition switch to ON (II).
15. Reset the ECM/PCM with the HDS.
16. Clear the CKP pattern with the HDS.
17. Do the ECM/PCM idle learn procedure (see page 11-310).
18. Do the CKP pattern learn procedure (see page 11-4).
19. Do the VTC TEST in the INSPECTION MENU with the HDS.
20. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the VTC oil control solenoid valve and
theECM/PCM,thengotostep1.
Go to step 21.
(cont’d)
Does t he scr een i nd i cat e F AILE D?
Is the strainer OK ?I s t he V T C oi l cont r ol sol enoi d v al v e OK ? I s t he V T C act uat or OK ?
I s DT C P0011 i nd i cat ed ?
08/08/21 14:28:22 61SNR030_110_0277
ProCarManuals.com
DYNOMITE -2009-


(#'

)
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
DTC P1009:
11-28311-283
A
8. Check for damage on the CMP sensor A pulser
plate (see page 6-41).
Replace the CMP sensor A pulser plate
(see page 6-41), then go to step 11.
Go to step 9.
9. Turn the ignition switch to LOCK (0).
10. Replace CMP sensor A (see page 11-295).
11. Turn the ignition switch to ON (II).
12. Reset the ECM/PCM with the HDS.
13. Do the ECM/PCM idle learn procedure (see page 11-310).
14. Start the engine, and let it idle for 10 seconds.
15. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at CMP sensor A and the ECM/PCM, then
go to step 1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting. NOTE:
 Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
 If DTC P0341 is stored at the same time as DTC P1009, troubleshoot DTC P1009 first, then recheck for DTC
P0341.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time.
5. Turn the ignition switch to LOCK (0).
6. Remove the cam chain auto-tensioner (see page 6-29).
7. Remove the VTC strainer (A), and check it for clogging.
Go to step 8.
Clean the VTC strainer, replace the engine oil
filter and the engine oil, then go to step 10.
(cont’d)VTC Advance Malfunction
Is the pulser plate damaged?
I s DT C P0344 i nd i cat ed ? Is DTC P1009 indicated?
Is the strainer OK ?
08/08/21 14:28:24 61SNR030_110_0283
ProCarManuals.com
DYNOMITE -2009-
