2005 TOYOTA AVENSIS air conditioning

02±50
± PREPARATIONHEATER & AIR CONDITIONER
AVENSIS REPAIR MANUAL (RM1018E)
09870±00025A/C Quick Joint Puller No.2AIR CONDITIONING RADIATOR
ASSY
09950±50013Puller C SetAIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
(09951±05010)Hanger 150AIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
(09952±05010)Slide ArmAIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
(09953±05020)Center Bolt 150AIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
(09954±05021)Claw No.2AIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
Recomended Tools
09040±00011Hexagon Wrench SetAIR CONDITIONING RADIATOR
ASSY
W/RECEIVER CONDENSER ASSY
(09043±20050)Socket Hexagon Wrench 5AIR CONDITIONING RADIATOR
ASSY
(09043±20100)Socket Hexagon Wrench 10W/RECEIVER CONDENSER ASSY
09041±00030Torx Driver T30AIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
09042±00010Torx Socket T30AIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
09070±20010Moulding RemoverAIR CONDITIONING CONTROL
ASSY
AIR CONDITIONING RADIATOR
ASSY
BLOWER ASSY
09216±00021Belt Tension GaugeV (COOLER COMPRESSOR TO
CRANKSHAFT PULLEY) BELT NO.1

± PREPARATIONHEATER & AIR CONDITIONER
02±51
AVENSIS REPAIR MANUAL (RM1018E)
95416±00140Gas Leak Detector
(Halogen Leak Detector)
(DENSO Part No.)REFRIGERANT
AIR CONDITIONING RADIATOR
ASSY
W/PULLEY COMPRESSOR
ASSY(1AZ±FE)
W/PULLEY COMPRESSOR
ASSY(1AZ±FSE)
W/PULLEY COMPRESSOR
ASSY(1CD±FTV)
W/PULLEY COMPRESSOR
ASSY(1ZZ±FE)
W/PULLEY COMPRESSOR
ASSY(2AZ±FSE)
W/PULLEY COMPRESSOR
ASSY(3ZZ±FE)
Equipment
Voltmeter
Anmeter
Ohmmeter
Vinyl tape
Hexagon wrench 4 mm (0.15 in.)
Hexagon wrench 14 mm (0.55 in.)
Gas leak detector
Dial indicator with magnetic base
Radiator cap tester
Torque wrench
Lubricant
ItemCapacityClassification
Compressor oil±ND±OIL 8 or equivalent

±
SERVICE SPECIFICATIONS ENGINE MECHANICAL
03±17
AVENSIS REPAIR MANUAL (RM1018E)Part Tightened
ft
lbf
kgf
cm
N
m
Engine mounting bracket x No, 2 RH x Transverse engine
engine mounting insulatorA
B
52
113530
1,15238
83
Clutch release cylinder x manual transaxleBolt A
Bolt B
Bolt C12
9.0
5.0122 92
5189
80 in.
lbf
44 in.
lbf
Vane pump assy x Timing chain cover4343931
Front suspension arm sub±assy lower No. 1 x Lower ball joint1271,29694
Front stabilizer link assy x Front suspension7475555
Floor panel brace front x Floor3030622
Engine service cover bracket RH x Body
w/o Air conditioning
RHD (w/ Air conditioning) steering position type
9.0
9.092
9280 in.
lbf
80 in.
lbf
Cooler bracket x BodyLHD (w/ Air conditioning) steering position type9.09280 in.
lbf
Oil reservoir bracket No. 1 x Body8.08271 in.
lbf
Return tube sub±assy x Frame8.08271 in.
lbf
Radiator reserve tank x sub±assy x body5.05144 in.
lbf
Compressor and magnetic clutch x Cylinder blockw/ Air conditioning2525518
Radiator relay block x Frame5.05144 in.
lbf
Engine cover No. 1 x Cylinder head cover7.07162 in.
lbf
Air cleaner assy x Body5.05144 in.
lbf
Cylinder head x Cylinder block1st
2nd79
Turn 90
806
Turn 90
58
Turn 90

Camshaft timing control valve assy x Cylinder head9.09280 in.
lbf
Camshaft timing gear assy x Camshaft5455140
Camshaft timing sprocket x Camshaft5455140
Camshaft bearing cap No. 1 x Cylinder head3030122
Camshaft bearing cap No. 2 x Cylinder head3030122
Camshaft bearing cap No. 3 x Cylinder head9.09280 in.
lbf
Chain tensioner assy No. 1 x Timing chain cover9.09280 in.
lbf
Chain tensioner plate x Stiffening crankcase assy121229
Oil pump drive sprocket x Oil pump3030122
Chain vibration damper No. 1 x Cylinder head9.09280 in.
lbf
Chain vibration damper No. 1 x Cylinder block9.09280 in.
lbf
Timing chain guide x Cylinder block9.09280 in.
lbf
Chain tensioner slipper x Cylinder block1919414
Timing chain cover (See page 14±139)Bolt A
Bolt B
Bolt C Nut9.021
43
9.092
214
438 9280 in.
lbf
15
32
80 in.
lbf
Oil pan x Stiffening crankcase assy9.09280 in.
lbf
Oil pan drain plug x Oil pan2525518
Crankshaft pulley x Crankshaft1701,733125
Cylinder head cover x Cylinder head Bolt A
Bolt B
Bolt C11
14
2111 2
143
2148.0 10
15
1AZ±FSE:
Part TightenedN
mkgf
cmft
lbf
Front wheel RH1031,05076
Drain plug (M/T)4950036
Engine hanger No.1 x Cylinder head3838728
Engine hanger No.2 x Cylinder head3838728
Engine coolant temperature sensor x Cylinder head2020815

031H6±01
03±28
± SERVICE SPECIFICATIONSLUBRICATION
AVENSIS REPAIR MANUAL (RM1018E)
TORQUE SPECIFICATION
1ZZ±FE/3ZZ±FE:
Part TightenedN
mkgf
cmft
lbf
Oil pressure switch x Cylinder head1515311
Oil pan drain plug x Oil pan3737727
Oil pump x Cylinder block9.09280 in.
lbf
1AZ±FE:
Part TightenedN
mkgf
cmft
lbf
Oil pressure switch x Cylinder head1515311
Oil pan drain plug x Oil pan2525018
Oil pump x Cylinder block1919515
Timing chain guide x Cylinder block9.09280 in.
lbf
Chain vibration damper No.1 x Cylinder block9.09280 in.
lbf
Oil pan sub±assy x Cylinder block9.09280 in.
lbf
Transverse engine engine mounting insulator x Cylinder block5253038
Engine service cover bracket RH x Body w/o Air conditioning
RHD (w/ Air conditioning) steering position type9.0
9.092
9280 in.
lbf
80 in.
lbf
Cooler bracket RH x Body LHD (w/ Air conditioning) steering position type9.09280 in.
lbf
Engine x wire7.07162 in.
lbf
Oil reservoir bracket No. 1 x Body8.08271 in.
lbf
Cooler refrigerant suction hose No. 1 x cooler bracket No, 1
LHD (w/ Air conditioning) steering position type9.09280 in.
lbf
Return tube x Body8.08271 in.
lbf
Ignition coil assy x Cylinder head cover9.09280 in.
lbf
Vane pump x Cylinder block3737727
Engine cover sub±assy x Cylinder block7.07162 in.
lbf
Front wheel RH1031,05076
1AZ±FSE:
Part TightenedN
mkgf
cmft
lbf
Oil pressure switch x Cylinder head1515311
Oil pan drain plug x Oil pan2525018
Oil pump x Cylinder block1919515
Timing chain guide x Cylinder block9.09280 in.
lbf
Chain vibration damper No.1 x Cylinder block9.09280 in.
lbf
Oil pan sub±assy x Cylinder block9.09280 in.
lbf
Transverse engine engine mounting insulator x Cylinder block5253038
Engine service cover bracket RH x Body RHD steering position type9.09280 in.
lbf
Cooler bracket RH x Body LHD steering position type9.09280 in.
lbf
Engine x wire7.07162 in.
lbf
Oil reservoir bracket No. 1 x Body8.08271 in.
lbf
Cooler refrigerant suction hose No. 1 x cooler bracket No, 1
LHD steering position type9.09280 in.
lbf
Return tube x Body8.08271 in.
lbf
Ignition coil assy x Cylinder head cover9.09280 in.
lbf
Vane pump x Cylinder block3737727
Engine cover sub±assy x Cylinder block7.07162 in.
lbf
Front wheel RH1031,05076
1CD±FTV:
Part TightenedN
mkgf
cmft
lbf
Oil drain plug x Oil pan sub±assy No. 23435025
Oil pump x Cylinder block3132023

031HI±01
03±62
± SERVICE SPECIFICATIONSHEATER AND AIR CONDITIONING
AVENSIS REPAIR MANUAL (RM1018E)
TORQUE SPECIFICATION
Part TightenedN
mkgf
cmft
lbf
V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO. 1
Tighten2.52522 in.
lbf
Fully tighten3939029
AIR CONDITIONER RADIATOR ASSY
Air conditioning tube assy x Cooler evaporator sub±assy No. 13.53530 in.
lbf
Air conditioner unit assy x Body9.810087 in.
lbf
BLOWER ASSY
Blower assy x Body Bolt:9.810087 in.
lbf
W/PULLEY COMPRESSOR ASSY (3ZZ±FE)
W/pulley compressor assy x Engine2930021
Cooler refrigerant discharge hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
Cooler refrigerant suction hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
W/PULLEY COMPRESSOR ASSY (1ZZ±FE)
W/pulley compressor assy x Engine2930021
Cooler refrigerant discharge hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
Cooler refrigerant suction hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
W/PULLEY COMPRESSOR ASSY (1AZ±FSE)
W/pulley compressor assy x Engine2930021
Cooler refrigerant discharge hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
Cooler refrigerant suction hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
W/PULLEY COMPRESSOR ASSY (1AZ±FE)
W/pulley compressor assy x Engine2930021
Cooler refrigerant discharge hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
Cooler refrigerant suction hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
W/PULLEY COMPRESSOR ASSY (1CD±FTV)
W/pulley compressor assy x Engine2930021
Cooler refrigerant discharge hose No. 1 x W/pulley compressor assy9.810087 in.
lbf
Cooler refrigerant suction hose No. 1 x W/pulley compressor assy RHD:9.810087 in.
lbf
Suction servic valve x W/pulley compressor assy LHD:9.810087 in.
lbf
Cooler refrigerant suction hose No. 1 x Suction servic valve9.810087 in.
lbf
W/RECEIVER CONDENSER ASSY
Cap x W/receiver condenser assy2.92925 in.
lbf
Magnet valve x W/receiver condenser assy3.43530 in.
lbf
Discharge tube x Magnet valve3.43530 in.
lbf
Discharge tube x W/receiver condenser assy5.45547 in.
lbf
Liquid tube sub±assy B x W/receiver condenser assy5.45547 in.
lbf
Discharge hose sub±assy x W/receiver condenser assy5.45547 in.
lbf
Liquid tube sub±assy A x W/receiver condenser assy5.45547 in.
lbf
HEAER ASSY
Heater assy x Body7.57666 in.
lbf

031HH±01
± SERVICE SPECIFICATIONSHEATER AND AIR CONDITIONING
03±61
AVENSIS REPAIR MANUAL (RM1018E)
HEATER AND AIR CONDITIONING
SERVICE DATA
Refrigerant charge volume Standard:440
30 g (15.51
1.06 oz.)
Belt deflection New belt:
Used belt:11 ± 13 mm (0.43 ± 0.51 in.)
13.5 ± 16.5 mm (0.53 ± 0.64 in.)

A76859
Hand±Held Tester
DLC3
05±298
±
DIAGNOSTICS SFI SYSTEM(1AZ±FSE)
AVENSIS REPAIR MANUAL (RM1018E)
(a)Checking the DTCs using the hand±held tester. (1)Connect the hand±held tester to the DLC3.
(2)Turn the ignition switch ON and switch the hand±held tester main switch ON.
(3)Use the hand±held tester to check the DTCs and freeze frame data and note them down (for operat-
ing instructions, see the hand±held tester's instruc-
tion book).
(4)See page 05±309 to confirm the details of the DTCs.
HINT:
In the event that 2 or more DTCs are detected, the CHK ENG
lamp will indicate the smaller number DTC first.
(b) Clearing the DTCs using the hand±held tester. (1) Connect the hand±held tester to the DLC3.
(2) Turn the ignition switch ON.
(3) When operating the hand±held tester to erase thecodes, the DTCs and freeze frame data will be
erased. (See the hand±held tester's instruction
book for operating instructions.)
(c) Clearing the DTCs not using the hand±held tester. (1) Disconnect the battery terminal or remove the EFIand THROTTLE fuses from the engine room R/B
No. 1 for more than 60 seconds.
3. DTC CHECK (Check Mode)
HINT:
Hand±held tester only:
Compared to the normal mode, the check mode has more sens-
ing ability to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check (test) mode.
(a) Procedure for check mode using the hand±held tester.
(1) Check the initial conditions

Battery positive voltage 11 V or more.

Throttle valve fully closed.

Transmission in the ºPº or ºNº position.

Air conditioning switched OFF.
(2) Turn the ignition switch OFF.
(3) Connect the hand±held tester to the DLC3.
(4) Turn the ignition switch ON and switch the hand±
held tester main switch ON.

BR3904
ON
OFF0.13 sec.
0.13 sec.
± DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U241E(1AZ±FE))05±867
AVENSIS REPAIR MANUAL (RM1018E)
3. INSPECT DIAGNOSIS (CHECK MODE)
HINT:
Hand±held tester only:
Compared to the normal mode, the check mode has high sens-
ing ability to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
Normal mode can also be detected in Check mode.
(a) Check the DTC.
(1) Check the initial conditions.

Battery voltage 11 V or more

Throttle valve fully closed

Shift lever in P range

Air conditioning switched OFF
(2) Turn the ignition switch OFF.
(3) Prepare the hand±held tester.
(4) Connect the hand±held tester to DLC3.
(5) Turn the ignition switch ON and switch the hand±
held tester ON.
(6) Switch the hand±held tester from Normal mode to
Check mode (Check that the MIL flashes).
(7) Start the engine (MIL goes out after the engine
starts).
(8) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTCs, etc.
(9) After simulating the malfunction conditions, use the
hand±held tester diagnosis selector to check the
DTCs and freeze frame data, etc.
HINT:
Take care not to turn the ignition switch OFF, as turning it off
switches the diagnosis system from Check mode to Normal
mode, which all DTCs etc. are erased.
(10) After checking the DTC, inspect the applicable cir-
cuit.
(b) Clear the DTC.
(1) When using hand±held tester:
The following operation will erase the DTC and
freeze frame data. Operate a hand±held tester to
erase the codes.
(2) When not using the hand±held tester:
Remove the EFI fuse from engine room J/B for 10
seconds or more.
