LUGGAGE COMPARTMENT
To open
Press button 1and lift the luggage
compartment lid.
To close
Lower the luggage compartment lid
by first using the inside handles 2.
Opening the doors from inside
the vehicle
If it is impossible to lock the luggage
compartment, it can be done from
inside.
- access the boot by folding forward
the seatback(s) of the rear bench
seat,
- insert a pencil or similar object into cavity 3and slide the assembly as
shown in the diagram.
- push the luggage compartment lid to open it.
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.31 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

NU761_2_G3-FRA.qxd 4/11/05 10:52 Page 3.32
3.32
REAR PARCEL SHELF
Removal
Unhook the two shelf retaining
cords 1. Lift the rear parcel shelf slightly and
pull it towards you.
To refit it, proceed in reverse order
to removal. Special point for utility versions,
unclip the fixings
2from each side
of the shelf, then take the shelf out
through the rear door.
To refit it, proceed in reverse order
to removal.
Do not place any objects,
especially heavy or hard
objects, on the parcel shelf.
These may pose a risk to
the vehicle occupants if the driver
has to brake suddenly or if the
vehicle is involved in an accident.
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.32 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1
2
1
1

1

NU761_2_G3-FRA.qxd 4/11/05 10:52 Page 3.33
3.33
STORAGE COMPARTMENTS/LUGGAGE COMPARTMENT FITTINGS
Locations for anchorage points 1
These are useful for securing items
transported in the luggage
compartment (see the information
on transporting objects in the
luggage compartment).
Storage compartment inside the
emergency spare wheel area
To open, fold the carpet 2back
towards the rear bench seat (this
storage compartment can be used
to store tools, cloths, an oil
container, etc.).
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.33 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
A

B

NU761_2_G3-FRA.qxd 4/11/05 10:52 Page 3.34
3.34
TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT
Always position the objects
transported so that the largest
surface is against:
- The rear seatback for normal loads
(example A).
- The folded down seat for maximum loads (example B). If you have to place objects on the
folded seatback, remove the front
head restraints before folding the
seatback so that is can be folded as
flat as possible against the seat base.
Always position the
heaviest items directly on
the floor. Use the lashing
points on the luggage
compartment floor, if these are
fitted to the vehicle. The luggage
should be loaded in such a way
that no items will be thrown
forward and strike the occupants
if the driver has to brake
suddenly. Fasten the rear seat
belts, even if the seats are not
occupied.
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.34 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

NU761_2_G3-FRA.qxd 4/11/05 10:52 Page 3.35
3.35
ROOF BARS
Each trim strip has two flaps. These
flaps cover the mounting points for
the roof rack bars.
A hinged cover 1is fitted over each
of these flaps. For vehicles not equipped with the
flaps
1, consult your RENAULT
Dealer.
Authorised load on the roof
rack: refer to the information on
weights in section 6.
Refer to the manufacturer’s
instructions for information on
how to fit and use the roof rack
bar.
Please keep these instructions
with the rest of the vehicle
documentation.
Access to the mounting points
Swivel each flap 1upward.
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.35 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G3-FRA.qxd 4/11/05 10:52 Page 3.36
3.36
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.36 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G4-FRA.qxd 14/11/05 10:10 Page 4.01
Section 4: Maintenance
Bonnet ........................................................................\
..............................................................................................4.02 - 4.03
Engine oil level/Oil change
........................................................................\
.......................................................4.04 ➟4.07
Levels : Engine coolant
........................................................................\
....................................................... .....................4.08
brake fluid
........................................................................\
....................................................... ............................4.09
Windscreen/headlight washer reservoir
........................................................................\
...............................4.10
Filters
........................................................................\
....................................................... ...................................................4.10
Battery
........................................................................\
....................................................... ..................................................4.11
Bodywork maintenance
........................................................................\
....................................................... ........4.12 - 4.13
Interior trim maintenance
........................................................................\
....................................................... ................4.14
4.01
NU761_2_G4-ENG.qxp 1/5/2006 5:29 PM Page 4.01 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

NU761_2_G4-FRA.qxd 14/11/05 10:10 Page 4.02
4.02
BONNET
To open, pull handle1, located on
the left-hand side of the dashboard.Bonnet safety catch
To release, pull the tab that passes
through the radiator grille panel 2.
Take care when working in
the engine compartment as
the engine cooling fan may
start to operate at any
moment without warning.
Risk of injury.
