AUTOMATIC TRANSMISSION (continued)
Operating faults
- when driving , if the message
“Check gearbox” along with the
warning light appears on the
instrument panel, this indicates a
fault.
Consult your RENAULT Dealer as
soon as possible.
- when driving , if the message
“Gearbox overheating” along with
the warning light appears on
the instrument panel, avoid leaving
the lever in position D(or R), traffic
permitting: systematically return to
position Nwhile stopping.
Consult your RENAULT Dealer as
soon as possible.
- Recovering a vehicle with an
automatic transmission : refer to
the information on Towing in
Section 5.
When setting off , if the lever is
locked in position Peven though
you are pressing the brake pedal, the
lever can be released manually. To
do this, unclip the upper section of
the cover at the base of the lever.
At the same time, press on the mark
on the gaiter and the unlocking
button on the lever.
2.37
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.37 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:49 Page 2.38
2.38
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.38 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G3-FRA.qxd 4/11/05 10:50 Page 3.01
Section 3: Your comfort
Air vents ........................................................................\
..........................................................................................3.02 - 3.03
Heating and air conditioning
........................................................................\
....................................................3.04 ➟3.16
Electric windows
........................................................................\
....................................................... ..................3.17 ➟3.20
Windscreen
........................................................................\
....................................................... .........................................3.20
Sun visor
........................................................................\
....................................................... ..............................................3.21
Electric sunroof
........................................................................\
....................................................... .......................3.22 - 3.23
Interior lighting
........................................................................\
....................................................... ..................................3.24
Storage compartments/passenger compartment fittings
........................................................................\
.....3.25 ➟3.28
Ashtrays/Cigarette lighter
........................................................................\
....................................................... ................3.29
Rear bench seat
........................................................................\
....................................................... ..................................3.30
Luggage compartment
........................................................................\
....................................................... .......................3.31
Rear parcel shelf
........................................................................\
....................................................... ..................................3.32
Storage compartments/luggage compartment fittings
........................................................................\
......................3.33
Transporting items in the luggage compartment
........................................................................\
...............................3.34
Roof rack
........................................................................\
....................................................... ..............................................3.35
3.01
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.01 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
12 3 4 5 678

NU761_2_G3-FRA.qxd 4/11/05 10:50 Page 3.02
3.02
AIR VENTS (air outlets)
1- left-hand air vent
2 - left-hand window demister outlet
3 - windscreen demister outlets
4 - centre air vents 5
- control panel
6 - right-hand window demister
outlet
7 - right-hand air vent
8 - passenger footwell heater outlets
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.02 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

2
2

3

4

NU761_2_G3-FRA.qxd 4/11/05 10:50 Page 3.03
3.03
AIR VENTS (continued)
Air flow
Move wheel 1(beyond the point of
resistance).
Up: maximum flow.
Down: closed.
Move control knob 4(beyond the
point of resistance).
To the right: maximum flow.
To the left: closed.
Direction
Right/left: move control 2or 3.
Up/down: lower or raise control 2
or 3.
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.03 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
ABC D
FE

NU761_2_G3-FRA.qxd 4/11/05 10:51 Page 3.04
3.04
HEATING/AIR CONDITIONING
The controls
A - Air recirculation control.
B - Air temperature adjustment.
C - Ventilation speed adjustment.
D - Adjusting the passenger
compartment air distribution. E
- Heated rear screen and heated
door mirror control and
indicator light (depending on
vehicle).
F - Air conditioning control and
warning light (depending on
vehicle).
Adjusting the air temperature
Turn control Bto obtain the desired
temperature. The further the slide is
in the red, the more the temperature
will be increased.
When the air conditioning system is
used for long periods, it may begin
to feel cold. This can be corrected by
increasing the quantity of hot air
(turn control Bto the right).
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.04 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
D

NU761_2_G3-FRA.qxd 4/11/05 10:51 Page 3.05
3.05
HEATING/AIR CONDITIONING (continued)
Distribution of air in the
passenger compartment
Move control Dto position the slide
opposite the marked positions.
Position
d
All the air flow is directed to the
demisting vents for the windscreen
and the side windows. Position
j
The air flow is distributed between
the demisting vents for the
windscreen, the side windows and
the front and rear footwells.
This is the recommended position
for the best temperature in cold
weather.Position
h
The air flow is mainly directed
towards the passenger footwells.
Position
The air flow is directed to all the air
vents and the front and rear
passenger footwells.
This is the recommended position
for the best temperature in hot
weather.
Position
The air flow is directed towards all
the air vents.
Note:
for quick demisting, set the
controls to the
dpositions:
- external air,
- maximum temperature,
- demisting.
Using the air conditioning increases
the speed of demisting.
NU761_2_G3-ENG.qxp 1/5/2006 5:28 PM Page 3.05 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
F
C

NU761_2_G3-FRA.qxd 4/11/05 10:51 Page 3.06
3.06
HEATING/AIR CONDITIONING (continued)
Position 0
In this position:
- air conditioning stops automaticallyeven if button Fis activated (the
indicator light remains lit);
- the ventilation speed of air in the passenger compartment is zero;
- there is, however, a slight flow of air when the vehicle is moving.
This position should not normally
be used.
Switching air conditioning
on or off
The air conditioning is switched on
(indicator light on) or off (indicator
light off) using button F.
The air conditioning system can be
used to:
- lower the temperature inside the passenger compartment;
- eliminate condensation more quickly.
The air conditioning does not
operate when the external
temperature is low.
Adjusting the blower speed
Normal use
Turn control Cto one of the four
positions to start the blower and
adjust the power.
Select position 1for minimum
ventilation and position 4for
maximum ventilation.
