TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of selections Interpreting the display selectedCurrent fuel consumption(depending on the vehicle)
This value is displayed after a speed of approximately 18 mph (30 km/h)\
is
reached.
Estimated range with remaining fuel
This range takes into account the average fuel consumption since the las\
t time
the reset button was pressed.
The value is displayed after driving 400 metres.
Distance travelled since last reset.
Average speed since the last reset.
The value is displayed after driving 400 metres.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.69 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.70
1.70
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of selections Interpreting the display selectedc) Mileage before oil change/serviceDistance before the next service.
There are several scenarios:
 remaining mileage less than 900 miles (1,500 km)or next service due within
two months. The SERVICE DUE message is displayed along with the
Ê
symbol on the trip computer (while Mileage before service is displayed,\
or
for 15 seconds).
 mileage before service equal to 0 miles/km or date of service reached.
The message “SERVICE DUE” is displayed when the “mileage before oil
change” display is selected accompanied by the trip computer symbol
Ê
flashing continuously across all of the trip computer pages.
Resetting the display after service in accordance with the maintenance
schedule
The mileage before oil change/service must only be reset after a service\
in
accordance with the recommendations in the Warranty and Services booklet.
If you decide to change the oil more frequently, do not reset this data each
time the oil is changed. This prevents the replacement interval from bei\
ng
exceeded for other parts included in the maintenance schedule.
To reset the service distance display, press the reset button for about
10 seconds until the fixed service distance display appears.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.70 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23559

23560

23503

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.71
1.71
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of selections Interpreting the display selectedd) Cruise Control/Speed Limiter programmed speed (depending on vehicle)
See see information on Speed Limiter and Cruise Control in Section 2.
e) Computer log Successive display:
- of information messages (depending on vehicle: heated seats, automaticheadlight illumination, etc.),
- of operating fault messages (check the injection system, etc.).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.71 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.72
1.72
TRIP COMPUTER AND WARNING SYSTEM (continued)
Warning messages
They warn you to stop immediately
(as soon as traffic conditions allow)
and to call a RENAULT Dealer.
They appear with the
ûwarning
light. Examples of warning messages
are given on the following pages.
N.B.: the messages appear on the
display either individually or
alternately (when there are several
messages to be displayed), and may
be accompanied by a warning light
and/or a beep.
Information messages
These can help either in the vehicle
starting phase, or give information
about a choice or a driving status.
Examples of information messages
are given on the following pages.
Fault messages
You should immediately go to your
RENAULT Dealer for work to be
carried out on your vehicle.
These messages appear accompanied
by the warning light.
They disappear when the display
selection key is pressed or after
several seconds and are stored in the
computer log.
The warning light remains
lit. Examples of fault messages are
given on the following pages.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.72 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23505

23507

23508

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.73
1.73
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of information messages
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Insert the card"
Request to insert the RENAULT card in the reader.
"Oil level OK"
Indicates that the oil level is correct when the ignition is switched on\
.
"Automatic lights function off"
Indicates that the automatic lights function is deactivated.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.73 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23511

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.74
1.74
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of fault messages
Message Display
Instrument panel variant 2 Interpretation of messages
"ESP/ASR deactivated"
ASR traction control deactivated (see information on traction control \
in
section 2) and ESP, electronic stability program (see “electronic stability
program: ESP with understeer control” paragraph in section 2).
"No tyre sensor" or "Tyre sensor out of order"
Sensor fault on the missing wheel in zone Aof the display: this is displayed, for
example, when the emergency spare wheel is fitted on the vehicle (see T\
yre
pressure monitor in Section 2).
"Check tyre pressure"
Wheel inflation fault (underinflation) indicated on the multifunction \
display or
in zone Aon the information display; adjust the pressure as soon as possible.
"Bleed diesel filter" or "Check diesel filter"
Indicates that there is water present in the diesel fuel.
Consult your RENAULT Dealer as soon as possible.
Message Display
Instrument panel variant 1
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.74 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23512

23513

23514

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.75
1.75
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of fault messages
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Check gearbox"
Indicates that a fault has occurred in the gearbox, contact your RENAULT
Dealer as soon as possible.
"Card not detected"
The Hands-Free RENAULT card is not in the detection zone, or the vehicle has
not been able to detect it. Insert it in the reader, if the fault persists contact your
RENAULT Dealer.
"Change card battery"
Your RENAULT card battery has a service life of approximately two years.
This message appears when the battery begins to run flat (refer to RENA\
ULT
card: batteries in Section 5).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.75 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23501

23500

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.76
1.76
TRIP COMPUTER AND WARNING SYSTEM (continued)
Warning messages
These require you to stop immediately or as soon as the traffic conditio\
ns allow
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Injection fault" or "Faulty injection"
Indicates that the vehicle has a serious engine fault.
"Stop! Tyre puncture"
Indicates a puncture on the wheel shown in zone A of the display.
"Engine overheating"
Indicates that the engine is overheating.
