NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.77
1.77
TRIP COMPUTER AND WARNING SYSTEM (continued)
Warning messages
These require you to stop immediately or as soon as the traffic conditio\
ns allow
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Steering fault" or "Faulty steering"
Indicates a fault in the vehicle’s power assisted steering.
"Electronic fault"
Indicates a problem with the vehicle electronic management system.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.77 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
3

1
2

NU761_2_G1-FRA.qxd 10/11/05 15:55 Page 1.78
1.78
Exterior temperature
indicator
As ice formation is related
to exposure, local air
humidity and temperature, the
external temperature alone is not
sufficient to detect ice.
CLOCK AND OUTSIDE TEMPERATURE
Vehicles equipped with a
navigation system, a radio, etc.
For vehicles not equipped with
buttons 2and 3, refer to the specific
equipment manual for details on
these vehicles.
Exterior temperature indicator
Special note:
When the outside temperature is
–3°C to +3°C, the °C characters flash
(signalling a risk of ice on the road).
With the ignition on , the time and,
depending on the vehicle, the
temperature is displayed.
Setting the time 1
For vehicles equipped with these
functions, setting buttons 2and 3
are used to set the clock.
Press button 2to set the hours and
press button 3to set the minutes. If the electrical supply is cut
(battery disconnected, power
supply wire broken, etc.), the
clock will lose its time setting.
The clock must be reset.
We recommend that you do not
adjust these settings while
driving.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.78 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

4

1

3

2

NU761_2_G1-FRA.qxd 10/11/05 15:55 Page 1.82
1.82
EXTERIOR LIGHTING AND SIGNALS
Switching on the side ulights
Turn the end of switch stalk 1until
the symbol is opposite mark 4.
The instrument panel will light up.
The brightness can be adjusted by
turning control knob 2.
Switching on the dipped kbeam headlights
Manual operation
Turn the end of switch stalk 1until
the symbol is opposite mark 4.
In all cases, an indicator light on the
instrument panel comes on. Automatic operation (depending on
vehicle)
With the engine running, the dipped
beam headlights are switched on or
off automatically depending on the
level of ambient light, without the
need to operate stalk
1(position 0).
This function can be deactivated or
reactivated.
- To activate it , press button 3for at
least four seconds. The message
“Auto lights ON” is displayed on
the instrument panel.
- To deactivate it, with the engine
switched off , press button 3for at
least four seconds. The message
“Auto lights OFF” is displayed on
the instrument panel.
If stalk 1is operated, it overrides
and cancels the automatic function
temporarily.
Before driving at night, check that the electrical equipment is operatin\
g correctly and adjust the headlight
beams (if your vehicle is not carrying its normal load). In general, c\
heck that the lights are not obscured (by dirt,
mud, snow or objects which could cover them).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.82 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

3

4

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.03
STARTING THE ENGINE
Special features of vehicles with an
automatic transmission
Depress the brake pedal with the
lever in the Nor Pposition.
Note:
- if any one of the starting conditions is not applied, the message “brake
+ start” is displayed on the
instrument panel.
- in some cases it will be necessary to move the steering wheel while
pressing Start button 3to assist in
unlocking the steering column; a
message on the instrument panel
“Steering not unlocked” warns of
this.
Remote control RENAULT card
The message Insert card appears on
trip computer display 1.
Insert the RENAULT card fully into
card reader 2.
Hands-free RENAULT card
The card must be in detection area 4
(passenger compartment and
luggage compartment except for
certain high-up areas such as the
sun visor, spectacle holder,
dashboard upper section, etc.) or in
the card reader 2.
Starting conditions.
Follow the starting instructions on
the instrument panel describing the
following conditions:
To start, depress the brake or clutch
pedal (the pedal must be held down
for the duration of starting) and
press button 3. If a gear is selected,
only depressing the clutch pedal
will enable starting.
2.03
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.03 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

3

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.04
2.04
STARTING THE ENGINE (continued)
Starting with the luggage
compartment open (in hands-free
mode)
Insert the card in card reader 2after
having pulled back the cover, if you
wish to start the engine with the
luggage compartment open.Operating faults
In certain cases, the RENAULT card
may not work:
- if the vehicle is located in a zone of high electromagnetic radiation;
- if appliances are operating on the same frequency as the card (mobile
phone, video game, etc.);
- drain on the RENAULT Card battery, flat battery, etc.
Trip computer display 1 will show
the message Card not detected
followed by Insert card.
Insert the RENAULT card fully into
card reader 2.
Accessories function
To switch on certain functions with
the engine off, (radio, navigation
system, etc.) press button 3 without
pressing the pedals.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.04 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

1

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.08
2.08
SPECIAL FEATURES OF DIESEL VEHICLES FITTED WITH AN EXHAUST PARTICLE FILT\
ER
When driving, depending on the
grade of fuel used, it is possible that
white smoke may be emitted.
This is due to the exhaust particle
filter being cleaned automatically,
and does not affect the way the
vehicle runs.
Diesel engine speed
Diesel engines are fitted with
injection equipment which prevents
the engine from over-revving,
irrespective of the gear engaged.
Precautions to be taken in winter
To avoid any faults in icy weather:
- ensure that the battery is always fully charged;
- always keep the fuel tank relatively full to avoid water vapour
condensing in it and accumulating
at the bottom of the tank.
Do not park the vehicle or
run the engine in locations
where combustible
substances or materials
such as grass or leaves can come
into contact with the hot exhaust
system.
The warning light comes on
to indicate a filter saturation risk.
To clean the particle filter, we
recommend that you drive the
vehicle as soon as possible until the
warning light goes out, at an average
speed of 48 mph (80 km/h) provided
that traffic conditions and the speed
limit allow it.
As an indication, cleaning should
last about 20 minutes in this case.
If the message “Check emission
control” or “Regenerate particle
filter” is displayed alongside the
warning light, refer to your
RENAULT dealer as soon as possible.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.08 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

1

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.17
TYRE PRESSURE MONITOR (continued)
Emergency spare wheel
The spare wheel has no sensor, and
cannot be recognised by the system.
When it is fitted in the place of
another wheel, the system then
detects an operation fault.
Replacing wheels/tyres
This system requires special
equipment (wheels, wheel trims, etc.).
Contact your RENAULT Dealer to
find out about accessories
compatible with the system and
which may be purchased from
RENAULT outlets: the use of any
other accessory could affect the
correct operation of the system.
Tyre repair aerosols
Because the valves are specially
designed, use only aerosols
approved by Renault’s Technical
Department.
Display
Display 1on the instrument panel
informs you of any tyre pressure
faults (flat tyre, punctured tyre,
system fault, etc.). The following pages show the
possible warning lights, symbols
and messages.
2.17
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.17 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
A

B

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.18
2.18
TYRE PRESSURE MONITOR (continued)Examples of messages which may appear on the display
"Check tyre pressure"
A shaded wheel B, indicates a
deflated tyre.
"Stop! Tyre puncture"
Replace the wheel affected Bor
contact a RENAULT Dealer.
This message appears along with the
ûwarning light.
"Inflate a tyre to motorway
pressure"
The tyre pressure is not suitable for
the speed of travel. Slow down or
inflate all fourtyres to motorway
pressure (refer to the tyre pressure
table).
"No tyre sensors" or "Tyre sensor
out of order"
One wheel A, disappears, indicating
that the sensor on this wheel is
missing or faulty (e.g. if the
emergency spare wheel is fitted
etc.).
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.18 (Black/Process Black\
plate)
