CAMSHAFT

b. Push in chain tensioner plunger. Insert a stopper pin into hole on
chain tensioner body to secure chain tensioner plunger and
remove chain tensioner.
NOTE:
Use approximately 0.5 mm (0.02 in) dia. hard metal pin as a
stopper pin.
c. Secure hexagonal part of camshaft with a wrench. Loosen cam-
shaft sprocket mounting bolts and remove camshaft sprockets.
CAUTION:
Do not rotate crankshaft or camshaft while timing chain is
removed. It causes interference between valve and piston.
NOTE:
Chain tension holding work is not necessary. Crankshaft
sprocket and timing chain do not disconnect structurally while
front cover is attached.
8. Remove camshaft position sensor (PHASE) from cylinder head back side.
CAUTION:

Handle carefully to avoid dropping and shocks.

Do not disassemble.

Do not allow metal powder to adhere to magnetic part at sensor tip.

Do not place sensor in a location where it is exposed to magnetism.
9. Loosen mounting bolts in reverse order as shown in the figure,
and remove camshaft brackets and camshafts.

Remove camshaft bracket (No. 1) by slightly tapping it with a
plastic hammer.
10. Remove valve lifters.

Identify installation positions, and store them without mixing them up.
INSPECTION AFTER REMOVAL
Camshaft Runout
1. Put V-block on a precise flat table, and support No. 2 and 5 jour-
nal of camshaft.
CAUTION:
Do not support No. 1 journal (on the side of camshaft
sprocket) because it has a different diameter from the other
four locations.
2. Set dial indicator vertically to No. 3 journal.
3. Turn camshaft to one direction with hands, and measure the
camshaft runout on dial indicator. (Total indicator reading)
KBIA0048E
KBIA0049E
SBIA0255E
Standard: Less than 0.02 mm (0.0008 in).PBIC2499E

EM-60
[QR]
CAMSHAFT

2. Install dial indicator in thrust direction on front end of camshaft.
Read the end play of dial indicator when camshaft is moved for-
ward/backward (in direction to axis).

Measure the following parts if out of the standard.
–Dimension “A” for camshaft No. 1 journal
–Dimension “B” for cylinder head No. 1 journal

Refer to the standards above, and then replace camshaft and/
or cylinder head.
Camshaft Sprocket Runout
1. Put V-block on precise flat table, and support No. 2 and 5 journals of camshaft.
CAUTION:
Do not support No. 1 journal (on the side of camshaft sprocket) because it has a different diameter
from the other four locations.
2. Measure the camshaft sprocket runout with a dial indicator.
(Total indicator reading)

If it exceeds the limit, replace camshaft sprocket.
Valve Lifter
Check if surface of valve lifter has any wear or cracks.

If anything above is found, replace valve lifter. Refer to EM-64,
"Valve Clearance" .
Valve Lifter Clearance
VALVE LIFTER OUTER DIAMETERStandard: 0.115 - 0.188 mm (0.0045 - 0.0074 in)
PBIC2446E
Standard : 25.800 - 25.848 mm (1.0157 - 1.0176 in)
Standard : 25.660 - 25.685 mm (1.0102 - 1.0112 in)
KBIA2426J
Limit : 0.15 mm (0.0059 in)
PBIC0930E
KBIA0182E

CYLINDER BLOCK
EM-113
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM

CRANKSHAFT PIN JOURNAL DIAMETER

Measure the outer diameter of crankshaft pin journal with a micrometer.

If out of the standard, measure the connecting rod bearing oil clearance. Then use undersize bearing.
Refer to EM-113, "
CONNECTING ROD BEARING OIL CLEARANCE" .
OUT-OF-ROUND AND TAPER OF CRANKSHAFT

Measure the dimensions at four different points as shown in the
figure on each main journal and pin journal with a micrometer.

Out-of-round is indicated by the difference in dimensions
between “X” and “Y” at “A” and “B”.

Taper is indicated by the difference in dimension between “A”
and “B” at “X” and “Y”.

If the measured value exceeds the limit, correct or replace crankshaft.

If corrected, measure the bearing oil clearance of the corrected main journal and/or pin journal. Then
select main bearing and/or connecting rod bearing. Refer to EM-114, "
MAIN BEARING OIL CLEAR-
ANCE" and/or EM-113, "CONNECTING ROD BEARING OIL CLEARANCE" .
CRANKSHAFT RUNOUT

Place a V-block on a precise flat table to support the journals on
the both end of the crankshaft.

Place a dial indicator straight up on the No. 3 journal.

While rotating crankshaft, read the movement of the pointer on
the dial indicator. (Total indicator reading)

If it exceeds the limit, replace crankshaft.
CONNECTING ROD BEARING OIL CLEARANCE
Method by Calculation

Install connecting rod bearings to connecting rod and cap, and tighten connecting rod bolts to the speci-
fied torque. Refer to EM-94, "
ASSEMBLY" for tightening procedure.

Measure the inner diameter of connecting rod bearing with an
inside micrometer.
(Bearing oil clearance) = (Connecting rod bearing inner diame-
ter) – (Crankshaft pin journal diameter)

If clearance exceeds the limit, select proper connecting rod
bearing according to connecting rod big end diameter and
crankshaft pin journal diameter to obtain specified bearing oil
clearance. Refer to EM-100, "
HOW TO SELECT CONNECTING
ROD BEARING" .
Method of Using Plastigage

Remove engine oil and dust on crankshaft pin and the surfaces of each bearing completely. Standard: 44.956 - 44.974 mm (1.7699-1.7706 in) dia.
Limit:
Out-of-round (Difference between “X” and “Y”)
: 0.005 mm (0.0002 in)
Taper (Difference between “A” and “B”)
: 0.005 mm (0.0002 in)
PBIC2203E
Limit:
QR20DE: 0.03 mm (0.0012 in)
QR25DE: 0.05 mm (0.0020 in)
PBIC2541E
Standard : 0.028 - 0.045 mm (0.0011 - 0.0018 in)
Limit : 0.10 mm (0.0039 in)
PBIC1642E

CAMSHAFT
EM-181
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM


Loosen the camshaft sprocket mounting bolt by fixing the hex-
agonal portion of camshaft.
10.11. Remove camshaft as follows:
a. Loosen and remove the camshaft sprocket bolts in reverse order
shown in the figure.
b. Place distinguishing marks on the right and left sides with paint.
12. Remove adjusting shim and valve lifter.

Remove by taking notice of the installation position, and place outside engine in order to prevent confu-
sion.
INSPECTION AFTER REMOVAL
Visual Check of Camshaft

Check the camshaft for one sided wear or scratches.

Replace the camshaft if there are abnormalities.
Camshaft Runout

Prepare V-block on a flat surface and secure camshaft journals
No. 2 and No. 5.

Set the dial indicator vertically on journal No. 3.

Rotate camshaft in one direction by hand, then read needle
movement on dial indicator (total indicator reading).

If it exceeds the limit, replace camshaft.
Camshaft Cam Height

Measure the height of camshaft cam using the micrometer.

If out of the standard, replace camshaft.
JEM159G
JEM160G
Limit : 0.02 mm (0.0008 in)
PBIC2499E
Standard:
Intake : 39.505 - 39.695 mm (1.5553 - 1.5628 in)
Exhaust : 39.905 - 40.095 mm (1.5711 - 1.5785 in)
SEM549A
