17. DETECT MALFUNCTIONING PART
Check the following.

Check camshaft position sensor (PHASE) and circuit. Refer to EC-701, "DTC P0340 CMP SENSOR
(PHASE)" .

Check crankshaft position sensor (POS) and circuit. Refer to EC-693, "DTC P0335 CKP SENSOR (POS)"
.
OK or NG
OK >> GO TO 18.
NG >> 1. Repair or replace.
2. GO TO 4.
18. CHECK ECM FUNCTION
1. Substitute another known-good ECM to check ECM function. (ECM may be the cause of an incident, but
this is a rare case.)
2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer to BL-108,
"NATS (NISSAN ANTI-THEFT SYSTEM)" .
>> GO TO 4.

EC-584
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS

Symptom Matrix ChartEBS010X8
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel pump circuit 11232 22 3 2EC-906
Fuel pressure regulator system334444444 4EC-562
Injector circuit 11232 22 2EC-891
Evaporative emission system 334444444 4EC-962
Air Positive crankcase ventilation sys-
tem334444444 41EC-967
Incorrect idle speed adjustment 33 1111 1EC-578
Electric throttle control actuator 112332222 2 2EC-723
,
EC-726
,
EC-737
,
EC-745
IgnitionIncorrect ignition timing adjustment33111 11 1EC-578
Ignition circuit 11222 22 2EC-873
Main power supply and ground circuit 22333 33 23EC-625
Mass air flow sensor circuit 11222 22 2EC-644
Engine coolant temperature sensor circuit 11222322312EC-652
Throttle position sensor circuit 12 22222 2EC-658
,
EC-680
,
EC-771
,
EC-773
,
EC-830
Accelerator pedal position sensor circuit3212 2EC-
372,EC-
815 , EC-
822 , EC-
838
Heated oxygen sensor 1 circuit 1232 22 2EC-666
,
EC-673
,
EC-861
Knock sensor circuit 2 2 3EC-688
Crankshaft position sensor (POS) circuit 2 2EC-693
Camshaft position sensor (PHASE) circuit 2 2EC-701
Vehicle speed signal circuit 2 3 3 3EC-709
Power steering pressure sensor circuit 2 3333EC-711

TROUBLE DIAGNOSIS
EC-585
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

1 - 6: The numbers refer to the order of inspection.
(continued on next page)ECM 22333333333EC-716
,
EC-719
Intake valve timing control solenoid valve cir-
cuit332 13223 3EC-636
PNP switch circuit 3 33333 3EC-802,
MT-15
Refrigerant pressure sensor circuit 2 3 3 3 3 4EC-914
Electrical load signal circuit 3 3 3 3EC-920
Air conditioner circuit223333333 3 2AT C - 3 4,
MTC-3
ESP/TCS/ABS CONTROL UNIT
(models with ESP)
ABS actuator and electric unit (control unit)
(models without ESP)4BRC-12
,
BRC-60
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA

EC-586
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS

SYSTEM — ENGINE MECHANICAL & OTHER
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel tank
5
5FL-11
Fuel piping 5 5 5 5 5 5FL-3, EM-
34
Vapor lock—
Valve deposit
5 555 55 5—
Poor fuel (Heavy weight gaso-
line, Low octane)—
Air Air duct
55555 5EM-16
Air cleaner
Air leakage from air duct
(Mass air flow sensor —electric
throttle control actuator)
5555
Electric throttle control actuator
EM-18
Air leakage from intake manifold/
Collector/Gasket
Cranking Battery
111111 11SC-4
Alternator circuitSC-13
Starter circuit 3SC-23
Signal plate/Flywheel/Drive plate 6EM-89
PNP switch 4MT-15 or
AT- 4 0 8
Engine Cylinder head
55555 55 5EM-70
Cylinder head gasket 4 3
Cylinder block
66666 66 64
EM-89
Piston
Piston ring
Connecting rod
Bearing
Crankshaft

EC-596
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS

2PU/RHeated oxygen sensor 2
heater[Engine is running]

Warm-up condition

Engine speed is below 3,600 rpm after the
following conditions are met
–Keeping the engine speed between 3,500
and 4,000 rpm for 1 minute and at idle for
1 minute under no load0 - 1.0V
[Ignition switch: ON]

Engine stopped
[Engine is running]

Engine speed is above 3,600 rpmBATTERY VOLTAGE
(11 - 14V)
3W/BThrottle control motor relay
power supply[Ignition switch: ON]BATTERY VOLTAGE
(11 - 14V)
4GThrottle control motor
(Close)[Ignition switch: ON]

Engine stopped

Shift lever: D (A/T), 1st (M/T)

Accelerator pedal: Fully released0 - 14V
5RThrottle control motor
(Open)[Ignition switch: ON]

Engine stopped

Shift lever: D (A/T), 1st (M/T)

Accelerator pedal: Fully depressed0 - 14V
6*
1Y VIAS control solenoid valve[Engine is running]
Idle speedBATTERY VOLTAGE
(11 - 14V)
[Engine is running]

Engine speed is above 5,000 rpm0 - 1.0V
12 PPower steering pressure
sensor[Engine is running]

Steering wheel is being turned0.5 - 4.0V
[Engine is running]

Steering wheel is not being turned0.4 - 0.8V TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
PBIB1104E
PBIB1105E

TROUBLE DIAGNOSIS
EC-597
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

13 L/WCamshaft position sensor
(PHASE)[Engine is running]

Warm-up condition

Idle speed
NOTE:
The pulse cycle changes depending on
rpm at idle1.0 - 4.0V
[Engine is running]

Engine speed is 2,000 rpm1.0 - 4.0V
14 PU/RCrankshaft position
sensor (POS)[Engine is running]

Warm-up condition

Idle speed
NOTE:
The pulse cycle changes depending on
rpm at idleApproximately 3.0V
[Engine is running]

Engine speed is 2,000 rpmApproximately 3.0V
15 W Knock sensor[Engine is running]

Idle speedApproximately 2.5V
16 OR/B Heated oxygen sensor 2[Engine is running]

Warm-up condition

Revving engine from idle to 3,000 rpm
quickly after the following conditions are
met
–Keeping the engine speed between 3,500
and 4,000 rpm for 1 minute and at idle for
1 minute under no load0 - Approximately 1.0V TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
PBIB0525E
PBIB0526E
PBIB0527E
PBIB0528E

EC-598
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS

19 PEVAP canister purge vol-
ume control solenoid valve[Engine is running]

Idle speedBATTERY VOLTAGE
(11 - 14V)
[Engine is running]

Engine speed is about 2,000 rpm (More
than 100 seconds after starting engine)Approximately 10V
22
23
41
42G/B
R/B
L/B
Y/BInjector No. 3
Injector No. 1
Injector No. 4
Injector No. 2[Engine is running]

Warm-up condition

Idle speed
NOTE:
The pulse cycle changes depending on
rpm at idleBATTERY VOLTAGE
(11 - 14V)
[Engine is running]

Warm-up condition

Engine speed is 2,000 rpmBATTERY VOLTAGE
(11 - 14V)
24 G/WHeated oxygen sensor 1
heater[Engine is running]

Warm-up condition

Engine speed is below 3,600 rpmApproximately 7.0V
[Engine is running]

Engine speed is above 3,600 rpmBATTERY VOLTAGE
(11 - 14V)
29 BSensor ground
(Camshaft position sensor)[Engine is running]

Warm-up condition

Idle speedApproximately 0V
30 BSensor ground
(Crankshaft position sen-
sor)[Engine is running]

Warm-up condition

Idle speedApproximately 0V
34 Y/GIntake air temperature sen-
sor[Engine is running]Approximately 0 - 4.8V
Output voltage varies with intake
air temperature. TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
PBIB0050E
PBIB0520E
PBIB0529E
PBIB0530E
PBIB0519E

TROUBLE DIAGNOSIS
EC-599
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
35 P/L Heated oxygen sensor 1[Engine is running]
Warm-up condition

Engine speed is 2,000 rpm0 - Approximately 1.0V
(Periodically change)
46 RSensor power supply
(Refrigerant pressure sen-
sor)[Ignition switch: ON]Approximately 5V
47 RSensor power supply
(Throttle position sensor)[Ignition switch: ON]Approximately 5V
49 W Throttle position sensor 1[Ignition switch: ON]

Engine stopped

Shift lever: D (A/T), 1st (M/T)

Accelerator pedal: Fully releasedMore than 0.36V
[Ignition switch: ON]

Engine stopped

Shift lever: D (A/T), 1st (M/T)

Accelerator pedal: Fully depressedLess than 4.75V
50 OR Mass air flow sensor[Ignition switch: ON]Approximately 0.4V
[Engine is running]

Warm-up condition

Idle speed0.7 - 1.1V (QR20DE)
0.8 - 1.2V (QR25DE)
[Engine is running]

Warm-up condition

Engine is revving from idle to about 4,000
rpm0.7 - 1.1 to approximately 4.0V
(QR20DE)
0.8 - 1.2 to approximately 4.0V
(QR25DE)
(Check for liner voltage rise in
response to engine being
increased to about 4,000 rpm)
54 —Sensor ground
(Knock sensor)[Engine is running]

Warm-up condition

Idle speedApproximately 0V
57 B Sensor ground[Engine is running]

Warm-up condition

Idle speedApproximately 0V
60
61
79
80L/R
BR
GY/R
PUIgnition signal No. 3
Ignition signal No. 1
Ignition signal No. 4
Ignition signal No. 2[Engine is running]

Warm-up condition

Idle speed
NOTE:
The pulse cycle changes depending on
rpm at idle0 - 0.1V
[Engine is running]

Warm-up condition

Engine speed is 2,000 rpm0 - 0.2V TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
PBIB0521E
PBIB0522E
