ENGINE OILPFP:KLA92
InspectionEBS00KO3
ENGINE OIL LEVEL
NOTE:
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
2. Insert oil level gauge and make sure the engine oil level is within
the range shown in the figure.
3. If it is out of range, adjust it.
ENGINE OIL APPEARANCE

Check engine oil for white turbidity or heavy contamination.

If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following area.

Oil pan

Oil pan drain plug

Oil pressure switch

Oil filter

Oil cooler

Intake valve timing control cover and intake valve timing control solenoid valve

Front cover

Mating surface between cylinder block and lower cylinder block

Mating surface between cylinder block and cylinder head

Mating surface between cylinder head and rocker cover

Crankshaft oil seals (front and rear)
OIL PRESSURE CHECK
WARNING:

Be careful not to burn yourself, as engine oil may be hot.

Engine oil pressure check should be in “ Parking position” (A/T models) or “Neutral position” (M/T
models), and should apply parking brake securely.
1. Check engine oil level. Refer to LU-7, "
ENGINE OIL LEVEL" .
2. Remove RH undercover.
PBIC0249E

LU-20
[YD22DDTi]
ENGINE OIL

ENGINE OILPFP:KLA92
InspectionEBS00B03
ENGINE OIL LEVEL
NOTE:
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
2. Insert oil level gauge and make sure the engine oil level is within
the range shown in the figure.
3. If it is out of range, adjust it.
ENGINE OIL APPEARANCE

Check engine oil for white turbidity or heavy contamination.

If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following area.

Oil pan (upper and lower)

Oil pan drain plug

Oil pressure switch

Oil filter bracket

Oil cooler

Oil pump housing

Va c u u m p u m p

Cylinder head rear cover assembly

Front and rear chain cases

Mating surface between cylinder block and cylinder head

Mating surface between cylinder head and rocker cover

Front and rear oil seals

Turbocharger

Oil tube connecting parts from turbocharger
ENGINE OIL PRESSURE CHECK
WARNING:

Be careful not to burn yourself, as the engine oil is hot.

Be sure to check oil pressure in “ Neutral position” and parking brake should be applied securely.
1. Check the engine oil level. Refer to LU-20, "
ENGINE OIL LEVEL" .
2. Remove RH engine undercover.
3. Remove exhaust front tube. Refer to EX-2, "
EXHAUST SYSTEM" .
SBIA0122E
