2005 NISSAN 350Z ESP

INFO:
For approximately 3 or 4 minutes after system
startup, the GPS indicator
remains gray,
even if accurate positioning is possible.
POSITIONING ADJUSTMENTWhen the system judges that the vehicle posi-
tion information is not accurate based on vehicle
speed and gyro sensor data calculations, the
system will adjust the vehicle position informa-
tion using GPS signals.RECEIVING SIGNALS FROM GPS
SATELLITESSometimes, satellite reception is weak. The fol-
lowing are places where signals tend to be
weak:

Inside tunnels and parking garages

Areas with numerous tall buildings

Under multi-layered highways

In a dense forest
Vehicles in these areas may not receive GPS
signals (Indicator color: gray).INFO:
The antenna for GPS is located on the instru-
ment panel inside the vehicle.Do not place any
objects, especially mobile phones or trans-
ceivers, on the instrument panel. Because
the strength of the GPS signal is approximately
one billionth of that of TV waves; phones and
transceivers will decrease the strength or may
totally disrupt the signals.
DISPLAY OF GPS INFORMATIONThis system displays GPS information.
Please refer to “GPS information display” on
page 11-17.
NOTE:
Directional guidance provided by the navi-
gation system does not take carpool lane
driving into consideration, especially when
carpool lanes are separated from other
road lanes.This system is designed to help you reach your
destination, and also performs other functions as
outlined in this manual. However, you, the driver,
must use the system safely and properly. Infor-
mation concerning road conditions, traffic signs
and the availability of services may not always be
up-to-date. The system is not a substitute for
safe, proper, and legal driving.
Map data covers select metropolitan areas in the
United States.
Map data is available on map DVD-ROM. For
information about map DVD-ROMs, contact a
NISSAN dealer or call the NISSAN NAVIGA-
TION SYSTEM HELPDESK at 1-800-
NISSAN-1 (1-800-647-7261) for U.S., and at
1-800-777-0325 for CANADA.
Map data includes 2 types of areas: “Detailed
coverage areas” providing all detailed road data
and other areas showing “Main roads only”.
NOTE:
Detailed map data is not available in many
areas and is generally limited to select
major metropolitan areas.
For information on which metropolitan areas are
in detailed coverage areas, please refer to the
NISSAN Navigation System Software Booklet
(included). When you purchase an updated map
DETAILED MAP COVERAGE
AREAS (MCA) FOR THE
NAVIGATION SYSTEM
How does the NISSAN Navigation System work?
2-3


04.7.6/Z33-N


The main feature of the NISSAN Navigation
System is Visual and Audio Route Guidance in
selected detailed map coverage areas. Utilizing
a network of GPS (Global Positioning System)
satellites, the NISSAN Navigation System tracks
your location on the map and directs you where
you want to go.
Once you program a destination covered by a
detailed map, the NISSAN Navigation System
will determine a route from your current location
to your destination. The moving map display and
turn-by-turn voice commands help the driver
determine upcoming turns.
This feature can be especially helpful in finding
unfamiliar locations or businesses. The system
may be unable to set a destination and/or cal-
culate distance when a destination is outside a
detailed map coverage area. Additionally, audio
route guidance may not be available if the des-
tination is outside a detailed map coverage area.
For more information on how to program a
destination, please refer to section 5.The NISSAN Navigation System offers an exten-
sive Point of Interest directory in detailed map
coverage areas. This directory includes a wide
variety of destinations ranging from gas stations,
ATMs, and restaurants to casinos, ski resorts,
shopping centers and businesses. By accessing
the Point of Interest directory, you can search for
addresses and phone numbers for a destination,
and with a press of a button, the NISSAN
Navigation System will calculate a route to the
destination.
The Point of Interest directory offers many uses.
For example, the directory can be sorted by the
various types of restaurants near your current
location. If you need an ATM or gas station, the
NISSAN Navigation System can point you to the
closest one or the closest one of your favorite
brand.
For more information on how to use the Point of
Interest directory, please refer to section 6.Using the Address Book feature, you will have
the ability to store up to 50locations in detailed
map coverage areas into a personal directory.
This is especially useful for frequently visited
locations, such as your clients, relatives, or
friends. The Address Book feature will provide
you with easy access to frequently visited loca-
tions when setting them as your destination.
For more information on how to use your Ad-
dress Book, please refer to section 7.ROUTE GUIDANCE
POINT OF INTEREST (POI)
DIRECTORYADDRESS BOOK3-2
What features are available on the NISSAN Navigation System?


04.7.6/Z33-N


When the
Navigation
key is selected
The following display will appear when selecting
the
Navigation key and pressing the PUSH
ENTER button.
Viewkey:
This will let you choose between Birdview
TM
display and Planview display.
Please refer to “Switching between Birdview
TM
and Planview displays” on page 11-4.Headingkey:
You can set the map either to show the vehicle’scurrent forward direction as up, or to show North
as up.
Please refer to “Changing the display direction
(in Planview display)” on page 11-7.
Nearby Display Iconskey:
Displays five types of points of interest around
the current location.
Please refer to “Setting with the
Nearby key” on
page 6-12.
Save Current Locationkey:
Stores the current vehicle location in the ad-
dress book.
Please refer to “Storing current vehicle position”
on page 7-4.Adjust Current Locationkey:
Corrects the location and direction of the vehicle
icon.
Please refer to “Updating the current vehicle
location and the direction” on page 11-18.Auto Re-route On/Offkey:
A new route to the desired destination will
automatically be calculated again from the loca-
tion when the vehicle is off the suggested route
during route guidance.Please refer to “Automatic rerouting” on page
9-2.
Avoid Area Settingkey:
Defines areas to avoid when calculating a route.
Please refer to “Setting avoid areas” on page
8-2.Button Tone/Beep Responsekey:
This key is used to turn on/off the automatic
beep sound.
Please refer to “Setting automatic beep sound”
on page 11-20.Clear Memorykey:
Clears all the stored memory (Address Book,
Avoid Area, Previous Dest.).
Please refer to “Clearing the memory” on page
4-21.Edit Address Bookkey:
Changes the names and positions of the regis-
tered locations.
Please refer to “Setting up and editing the
address book” on page 7-2.GPS Informationkey:
GPS information will be displayed.
INV1451
4-10
How do I operate the NISSAN Navigation System?


04.7.6/Z33-N


— The route may not connect completely at
some waypoints.
— The route may require a U-turn close to some
waypoints.

Route calculation may not be completed in
the following cases.
— If there is no main road within a range of 1.5
miles (2.5 km) from the vehicle, a message
saying so will appear on the screen. Try
requesting route calculation when the vehicle
is closer to the main road.
— If there is no main road within a range of 1.5
miles (2.5 km) from the destination or way-
point, a message saying so will appear on the
screen. Try setting the location closer to the
main road.
— If the vehicle is too close to the destination or
if there are no branches of the roads to the
destination. A message saying so will appear
on the screen.
— If it is deemed impossible to reach the des-
tination or waypoints because of traffic regu-
lations, etc.
— If the only route to reach the destination or
waypoints is extremely complicated.
— If the destination, current vehicle position or
waypoint is within the avoid area.— If the setting of avoid areas covers the routes
to the destination, route calculation may not
be possible.

The following may occur when the route is
being displayed.
— If you are requesting a calculation from the
main road, the origin of the route may not
exactly match the current vehicle position.
— If you are requesting a calculation to a des-
tination on the main road, the end of the route
may not exactly match the destination.
— If you are requesting a calculation from the
main road, the system may show a route from
another main road. This may be because the
icon to show the current vehicle position
(vehicle icon) is not set accurately. In that
case, park the car in a safe place and reset
the vehicle icon, or continue driving to see if
the vehicle icon appears on the main road
before requesting route calculation again.
— There are cases in which the system shows a
detoured route to reach the destination or
waypoints, if you set them from memory or
facility information. In order to correct this,
you will have to be careful about the traffic
direction, especially when the lanes with dif-
ferent travel directions are shown separately.Such places are interchanges and service
areas.
— This system makes no distinction between
limited traffic control and total control (block-
age). It may show a detoured route even if the
road is usable.
— Even if the freeway preference is set to OFF,
the route may be set on them. To avoid this,
set a waypoint on another road type and
request calculation.
— Even if the preference is set to OFF for a ferry
line, the route may be set on it. To avoid this,
set a waypoint on a road and request calcu-
lation.
— Ferry lines, except those which accept only
pedestrians, bicycles and motorcycles, are
stored in this system. When using them, take
into consideration the travel time required
and operational condition to decide whether
to use them or not.
ABOUT THE DISPLAY ERRORThe following cases may affect the display ac-
curacy of the vehicle’s position or travel direc-
tion. The accuracy will return to normal if the
driving conditions return to normal.
— When there is a similar road nearby.
— When the vehicle is traveling on a long
How do I operate the NISSAN Navigation System?
4-25


04.7.6/Z33-N


EASY MODE CATEGORIESWhen the Expert Mode is canceled, the follow-
ing three categories will be displayed as Easy
Mode.

Home

Street Address

Point of Interest (POI)
INFO:

Use the
Address Book key and the
Point of Interest (POI) key in the same way
as in Expert Mode.Please refer to “Setting with the
Address Book key” on page 5-3 and “Set-
ting with the
Point of Interest (POI) key” on
page 6-2.

If the
Short Menus key is highlighted in
amber in the [SETTINGS] screen, the screen
is in Easy Mode. In this case, the keys
displayed are different from the screen in
Expert Mode.

If you set a destination or waypoints, they will
be displayed with icons.

If you want to go to places close to the stored
locations or facilities, use categories such as
facility, nearby facility or memory for easier
setting.

When using either the Point of Interest (POI)
or nearby Points of Interest categories, the
names called up can be set as the destination
if you do not scroll the screen. If you want to
choose a different place on the screen from
the one called up, you will have to scroll the
screen.
SETTING WITH THE
Address Book
KEYThe Address Book will allow you to store loca-
tions in the memory. This is especially useful for
locations that you visit frequently.
Please refer to “Setting up and editing the
address book” on page 7-2.
INV2316
How do I program a destination?
5-3


04.7.6/Z33-N


If less than 5 suggested streets remain, they
will be displayed automatically without se-
lecting the
List key.

The city names and street names will be
displayed.

Use the joystick to scroll the display.

When theNext Search key is selected, it is
possible to narrow down cities. To use this
function, refer to “Setting with the
City key” on page 5-12.

When the PREVIOUS button is pressed,
the screen to input street names will be
displayed.4. Select one street of your destination.
5. Enter the house number.
Select the
OK key.
INFO:
It may not be possible to specify a location after
selecting the
OK key. In that case, a list of
locations which correspond to the entered
house number will be displayed.
NOTE:
If a house number is entered and it is not a
“direct hit” for house numbers already
stored in the database, then only a map to
the general vicinity will be displayed.
INV2322
INV2324
How do I program a destination?
5-9


04.7.6/Z33-N


6. To set the destination (waypoints), refer to
“Making the system guide the route with
detailed options” on page 5-32.7. To slightly alter the destination.
Select the
Map key to display the map
screen of the area around the specified des-
tination (waypoints).
INFO:

An approximate location corresponding to
the house number entered is displayed. If
necessary, correct the location using the
joystick.

The location displayed by the calculation
using the house number may differ from the
actual location. In that case, correct the
location using the joystick.8. If necessary, operate the joystick to adjust the
location of the destination (waypoint). Press
the PUSH ENTER button. Select the
Destination key to confirm. The [DEST.
SETTING (Street Address)] screen will be
displayed.
To set the destination (waypoint), refer to
“Making the system guide the route with
detailed options” on page 5-32.
INV2325
INV2323
INV1492
5-10
How do I program a destination?


04.7.6/Z33-N


7. If necessary, operate the joystick to adjust the
location of the destination (waypoint). Press
the PUSH ENTER button. Select the
Destination key to confirm. The [DEST.
SETTING (Intersection)] screen will be dis-
played.
To set the destination (waypoint), refer to
“Making the system guide the route with
detailed options” on page 5-32.
NOTE:
When the corresponding data does not
exist under the following conditions, the
street name list may not be displayed:
A street name is being input after the
Citykey has been selected.

The list is being displayed by selection
of the
Listkey.
Setting with the
State
key
The
State key is used when you select a
state/province to set the destination.
1. Select the
State key.
INV1510
INV2393
How do I program a destination?
5-17


04.7.6/Z33-N
