Page 169 of 215
168 Navigation*During route guidanceChanging map orientation
Use or to select the desired
option.
Press .
The orientation changes.
Finally, press the
Back
soft key or wait
for the screen to change.If you activate GPS position display and
full-screen map display (
page 154), the
following data is displayed in the status
bar:
The current position as coordinates.
The number of satellites that can cur-
rently be received.
The current elevation (ALT = altitude)
above sea level.
In the Display menu (
page 165),
press the
GPS
soft key.
Option
On or
Off
appears.
iDuring route guidance, a symbol will
appear on the left-hand side of the bot-
tom status bar if map display is
switched ON.
North symbol :
Fixed map orientation, north is al-
ways pointing up;
Compass symbol :
Dynamic map orientation, driving
direction is always pointing up.
Switching GPS position display
ON/OFF
Page 170 of 215
169 Navigation*
During route guidance
Use or to select the desired
option.
Press .
Depending on the previous setting,
GPS position display will be switched
ON or OFF.
Finally, press the
Back
soft key or wait
for the screen to change.
If you have set the map view to full screen
(
page 154) and the automatic map tog-
gling function is activated, then the follow-
ing happens:
The system automatically switches to
the split-screen map display when a
driving maneuver is announced.
As soon as the driving maneuver is
completed, the system automatically
returns to full-screen map display.Switching automatic toggling ON/OFF
In the Display menu (
page 165),
press the
Auto
soft key.
Option
On or
Off
appears.
iThe solid circle shows the current
setting.
Automatic map toggling
Page 171 of 215
170 Navigation*During route guidance
Use or to select the desired
option.
Press .
Depending on the previous setting, au-
tomatic map toggling will be switched
ON or OFF.
Finally, press the
Back
soft key or wait
for the screen to change.
You can select whether the full-screen and
split-screen map scales are to be set to-
gether (default setting) or individually.
In the Display menu, press the
(page 165)
Zoom
soft key.
The
Standard setting
and
Manual
options
appear.
Standard setting
option:
The scales for full-screen and split-
screen map display are always
identical. Changing the scale
(
page 153) on one map changes
the scale of the other.
Manual
option:
The scales can be different. Chang-
ing the scale on one map has no ef-
fect on the current scale of the
other map.
iThe solid circle shows the current
setting.Scales for full-screen and
split-screen map display
iThe solid circle shows the current
setting.
Page 173 of 215
172 Navigation*Last destinations and destination memoryThe
Last destinations
memory automatical-
ly stores the last destination for which
route guidance had been started.
The current vehicle position and positions
selected via the map can also be stored as
destinations in this memory (
page 148).
Such destinations are marked with .
Altogether a maximum of 50 destinations
can be stored.
Open the Navigation main menu
(page 125).
Use to select the Last destinations
menu item.
Press .
The list of last destinations and map
positions is displayed. The most re-
cently stored destination is shown at
the top of the list.Selecting an entry from the Last desti-
nations memory
Open the
Last destinations
memory.
Use or to select an entry.
The
Page
soft keys allow scrolling
through the list page by page.
Last destinations memory
Page 174 of 215
173 Navigation*
Last destinations and destination memory
Selectable soft keysSave
soft key
Stores the selected entry in the Destina-
tion memory (
page 175),
Details
soft key
Displays details on the selected entry (if
available),
Delete
soft key
Allows the deletion the selected entry
(
page 173).
Starting route guidance to a destina-
tion from the Last destination memory
Select an entry (
page 172).
Press .
The Start Route Guidance menu with
the full displayed destination appears.
Press if you want to start route
guidance (
page 150), otherwise
press the
Back
soft key.Deleting an entry from the Last destina-
tions memory
Select an entry (
page 172).
Press the
Delete
soft key.
You are prompted to confirm whether
or not the destination is to be deleted.
Use to select the menu item
Yes
.
Press .
The destination is deleted.
Page 175 of 215
174 Navigation*Last destinations and destination memoryCalling up the Destination memory and
selecting a destination
Open the Navigation main menu
(page 125).
Use or to select the
Destination
memory
menu item.
Press .
The Destination memory appears. This
is indicated by
Destination memory
dis-
played in the status bar.
Use , , or to select the
desired entry.
Selectable soft keys and options
Details
soft key
Displays details on the selected entry
(if available),
Delete
soft key
Allows to delete the selected entry
(
page 174),Starting route guidance to a destina-
tion from the Destination memory
Select a destination.
Press .
The Start Route Guidance menu ap-
pears.
Press if you want to start route
guidance (
page 150), otherwise
press the
Back
soft key.
Deleting an entry from the Destination
memory
Select a destination.
Press the
Delete
soft key.
A delete entry prompt appears.
Destination memory
Page 177 of 215
176 Navigation*Last destinations and destination memoryTo select lower or upper case or to select
special characters, the following shift
fields on the display are available:
= upper case
= lower case
= special characters
Use , or to select one of
the shift fields.
Press .
Use , , , , + or ( to
select the characters. Press after
each selection.
If necessary, press the
Delete
soft key
to delete the character last entered.
Upon completion of the name entry
press and hold for approx. 2 sec-
onds;
or
Use or to select the sym-
bol and press .
The system will save the entry.
ABCabc...
iDo not confuse the
Delete
soft key (de-
letion of the last character) with the
Back
soft key (deletion of the complete
entry).
ok
Page 180 of 215
179 Navigation*
POIs (Points of Interest)
Selecting a POI category
Use or to select a category.
The
Page
soft keys allow scrolling
through the list page by page.
Press .If you have selected the Restaurant
category, another list will be displayed
from which you can select a sub-cate-
gory, e.g. Chinese food.
If you have selected any other catego-
ry, this will take you straight to the list
of POIs.
Selecting a POI
Use or to select a POI.
The
Page
soft keys allow scrolling
through the list page by page.
Press the
Details
soft key if you want to
see details of a selected POI.
The details disappear again after
approx. 3 seconds, or when pressing
the
Details
soft key again.
Press .
The Start Route Guidance menu
(page 150) appears.
