2005 MERCEDES-BENZ SLK-Class stop start

Contents
Entering an intersection . . . . . . . . 141
Entering a house number . . . . . . . 142
Entering a destination using the
map . . . . . . . . . . . . . . . . . . . . . . . 144
Entering a destination via geo
coordinates. . . . . . . . . . . . . . . . . . 146
Storing map locations. . . . . . . . . . 148
Route guidance . . . . . . . . . . . . . . . . . 150
Starting route guidance menu . . . 150
Route calculation . . . . . . . . . . . . . 150
Route re-calculation . . . . . . . . . . . 151
Navigation announcements . . . . . 151
Navigation displays. . . . . . . . . . . . 152
Destination reached . . . . . . . . . . . 155
Cancelling route guidance . . . . . . 155
During route guidance . . . . . . . . . . . . 156
Showing soft key displays . . . . . . 156
Info menu . . . . . . . . . . . . . . . . . . . 157
Displaying the route on the map . 157
Displaying the route list . . . . . . . . 158
Detour function . . . . . . . . . . . . . . 159
Stop-over . . . . . . . . . . . . . . . . . . . 161
Defining route guidance displays . 165
Setting symbols display . . . . . . . . 166
Setting map orientation . . . . . . . . 167
Switching GPS position display ON/OFF . . . . . . . . . . . . . . . . . . . . 168
Automatic map toggling . . . . . . . . 169
Scales for full-screen and
split-screen map display . . . . . . . . 170
Last destinations and destination
memory . . . . . . . . . . . . . . . . . . . . . . . 172
Last destinations memory . . . . . . 172
Destination memory . . . . . . . . . . . 174
POIs (Points of Interest) . . . . . . . . . . . 177
Entering POIs . . . . . . . . . . . . . . . . 177
Selecting POI in the local area of
the current position . . . . . . . . . . . 178
Selecting POI for a selected city. . 180
Selecting POI for a long-distance
destination . . . . . . . . . . . . . . . . . . 180
Selecting a POI using the map . . . 182
Service . . . . . . . . . . . . . . . . . . . . . . . 185
Tele Aid* . . . . . . . . . . . . . . . . . . . . . . 186
Emergency call system . . . . . . . . . 186
Roadside Assistance. . . . . . . . . . . 186
Information . . . . . . . . . . . . . . . . . . 187
System . . . . . . . . . . . . . . . . . . . . . . . 189
System settings . . . . . . . . . . . . . . . . . 190
Calling up the System menu . . . . . 190
Setting the date/time . . . . . . . . . . 190
Setting the language . . . . . . . . . . . 193
Switching confirmation beeps and
acoustic signals ON/OFF . . . . . . . 193
Display settings . . . . . . . . . . . . . . 194
Voice control settings* . . . . . . . . . 195
Reset function. . . . . . . . . . . . . . . . 199Glossary . . . . . . . . . . . . . . . . . . . . . . 201Index . . . . . . . . . . . . . . . . . . . . . . . . . 205

44 AudioRadio operationTuning via scan search
Scan search is characterized as follows:
Scan search performs two runs.
During the first run, stations with ex-
tremely good reception are played.
During the second run, stations with
weaker reception are played.

Scan search plays each receivable sta-
tion for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
station listened to before the scan
search was started.Starting scan search

Switch to the desired waveband
(page 40).

Press the
Scan
soft key.
Scanning begins.
Ending Scan search manually

Press the
Scan
soft key again.Manual tuning

Switch to the desired waveband
(page 40).

Press- or, for at least 2
seconds to scroll up or down.
Manual tuning is activated.

Keep the button pressed or release it
and keep tapping- or, in
quick succession.
The frequency will change by the tuning
increments for the respective wave-
band each time one of the buttons is
pressed or for as long as a button is
pressed and held.
Manual tuning is deactivated if no but-
ton is pressed for approx. 3 seconds.

54 AudioSingle CD operation1Number of tracks on the CD (12 tracks)
Entry example: Track 1
Press3.
Entry example: Track 12

Press3 and  in quick succession.

Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterized as follows:

Scan search plays each track on the
current CD for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
track listened to before the scan
search was started.
Starting scan search

Press the
Scan
soft key.
Ending scan search manually

Press the
Scan
soft key.
The track playing at the time the scan
is ended remains playing.
iEntries beyond the number of available
tracks on the CD are not possible.
iWhen you start the scan search, play-
back option
Normal Sequence
(page 55) is activated automatically.

65 Audio
MP3 operation
1Number of tracks in the current folder
(10 tracks)
Example entry: Track 1
Press3.
Example entry: Track 10

Press3 and " in quick succession.

Wait approx. 3 seconds after entering
the number.
The selected track is played.
Selecting via scan search
Scan search is characterized as follows:

Scan search plays each track in the
current folder for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
track listened to before the scan
search was started.Starting scan search

In the MP3 main menu (
page 61)
press the
Scan
soft key.
The scan search starts.
iIt is not possible to enter a number
greater than the number of tracks in
the current folder.
iThe scan search will not function if the
current folder only contains one track.
When you start scan search, playback
option
Normal sequence
(page 66) is
activated automatically.
Therein scan search is restricted to the
current folder.

71 Audio
CD changer* operation
Loading a single magazine compart-
ment
Open the glove box
(Vehicle owner's manual).

Briefly press the button 2 of the emp-
ty magazine compartment to be load-
ed.

Wait until the LED in the button 2
flashes green.
This indicates that the CD changer re-
quests a CD.

Insert an audio CD into the CD slot 1
within approx. 15 seconds. Insert the
CD face up.
The CD is pulled in. The red LED in the
corresponding magazine compartment
button 2 lights up continuously. The
system starts playing the CD.
The loading procedure is completed.
Loading all six magazine compart-
ments
Initial situation: all magazine compart-
ments are empty.
The CD changer loads all magazine com-
partments beginning with compartment 1.

Open the glove box
(Vehicle owner's manual).
1CD slot
2Magazine compartment buttons
iLoading a magazine slot will stop the
playback of a CD in the changer.


79 Audio
CD changer* operation

Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterized as follows:

Scan search plays each track on the
current CD for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
track listened to before the scan
search was started.Starting scan search

Press the
Scan
soft key.
Ending scan search manually

Press the
Scan
soft key.
The track playing at the time the scan
is terminated remains playing.

Open the CD changer main menu
(page 74).

Press and hold- or ,.

To stop release- or ,.
The following options are available:

Normal sequence


Repeat track

Repeat CD


Track Random


CD Random
iEntries beyond the number of available
tracks on the CD are not possible.
iWhen you start scan search, playback
option
Normal sequence
(page 80) is
activated automatically.
Therein scan search is restricted to the
current CD.
Fast forward/reverse Playback options

86 Satellite radio*Satellite radio operationStation information is displayed on the
main area and in the center of the status
bar.
Main area, in this example:
ROCK
= selected category (
page 88)

Vault
= name of the selected stationStatus bar, in this example:

SAT (on the left) = the selected mode

SAT5 = location in the program
memory, if the current channel is pre-
stored

Ch16 = number of the current channel
Selectable soft keys

Presetsshows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 91) and re-
quest stored stations (page 87).

Infoshows additional text information relat-
ed to the current channel.

Scanis used to start and stop the scan
search (
page 90).

Servicedisplays a screen showing the tele-
phone number of the Sirius Service
Center and electronic serial number
(ESN) of the receiver in your vehicle.
SAT main menu

90 Satellite radio*Satellite radio operationTuning using the multifunction steering
wheel
Switch the multifunction display in the
instrument cluster to Satellite radio
display (
page 25).

Pressk.
The search proceeds in ascending or-
der;
or

Pressj.
The search proceeds in descending or-
der.
The search stops at the first receivable
station. Tuning via scan search
Scan search is characterized as follows:

Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current
category.

Scan search can be ended manually.

Scan search stops automatically at the
station that was playing when scan
search was started.

Press the
Scan
soft key.
The scan search starts.

Press the
Scan
soft key again.
The scan search stops.Additional text information (artist and
track title) related to the current broadcast
can be displayed.

Press the
Info
soft key.
Obtaining additional text
information
