Page 131 of 215
130 Navigation*Destination entry1Character display
You can see which characters can be
entered when using the keys.
Each additional depression moves you
to the next available character.
The selected character appears black.
Wait until the character display disap-
pears, or press .
The character is entered.
Deleting a character
Press the
Delete
soft key if necessary.
The character last accepted by the sys-
tem is deleted.Confirming the data entry
After entering all the characters the data
entry must be confirmed.
Press and hold for approx. 2 sec-
onds;
or
Use or to select the sym-
bol and press .
.
iDo not confuse the
Delete
soft key (de-
letion of the last character) with the
Back
soft key (deletion of the complete
entry).
iThe symbol can only be selected if
the system has recognized the entry.
ok
ok
Page 133 of 215
132 Navigation*Destination entrySelectable menu items
Destination memory
:
You can select destinations from the
Destination memory
(page 174), only if
destinations have already been stored.
Destination entry
:
You can enter a destination manually
via the Destination entry menu
(
page 133),
Last destinations
:
You can select from the list of last des-
tinations (
page 172), only if the sys-
tem has already stored destinations.
POIs
:
You can enter POIs (points of interest),
for example gas stations, airports or
hospitals (
page 177).
Current locationProvides access to save the current lo-
cation as home address, or select a
home address using the map.
Saving current location as home
address
Use or to select the Current location
menu item.
Press .
To save the displayed address as home
address, press .
Selecting a home address using the
map
Use or to select the Current location
menu item and
press .
Press the
Map
soft key.
Proceed as described under “Moving
the map and selecting a destination”
(page 145).
Or, to store the selected destination as
home address, press .
Page 134 of 215
133 Navigation*
Destination entry
Open the Navigation main menu
(page 125).
Use or to select the Destination entry
menu item.
Press .
The Destination entry menu appears.The destination displayed last can now
be adopted (
page 135), or another
location can be entered (
page 135).
Open the Destination entry menu. The
Destination entry menu represents the
starting point.
Besides entering the name of a city
(
page 135), the following soft keys are
available for selecting a destination:
Destination entry menu
Entering a destination
Page 135 of 215
134 Navigation*Destination entrySelectable soft keys
Map
soft key
Provides access to destination input di-
rectly via road map (
page 144),
Region
soft key
Provides access to the region input
(
page 134),
Street
soft key
Provides access to the input of the des-
tination street (
page 138),
CityCtr
soft key
Provides access to the input of a city
section (center) (
page 137),
POIs
soft key
Provides access to the input of a POI
(Point of interest) (
page 177),
List
soft key
Allows selecting a destination city from
a city list (
page 136).In the Destination entry menu
(
page 133) the region currently selected
is indicated by the characters in parenthe-
sis in the status bar.
To change the region press the
Region
soft key.
The region list appears.
iThe
Street
, CityCtr
and
POIs
soft key
functions refer to the city on display.
If you wish to choose global POIs not
referring to a city (
page 177).
Selecting the region
Page 136 of 215
135 Navigation*
Destination entry
Use or to select a region.
The selected region appears black.
Press .
Selecting a different region deletes the
city last entered. The first city of the
newly selected region appears (in al-
phabetical order).
The Destination entry menu (
page 133)
represents the starting point.
Enter city (USA)
appears in the status bar.
The characters in parenthesis indicate the
selected region (page 134).Accepting the displayed destination
Press and hold for approx. 2 sec-
onds.
Entering a different city
Use the keypad menu or the 12 button
keypad to enter the data of the city
(page 129).
After entering the city a selection list of
cities appears indicated by
Select city
displayed in the status bar. Now contin-
ue with selecting a city.
Entering a city
iDo not confuse the button with the
symbol in the main screen. ok
Page 137 of 215
136 Navigation*Destination entrySwitching to a selection list is possible at
any time while entering a city.
Press the
List
soft key.
A selection list appears indicated by
Se-
lect city
displayed in the status bar.
Now continue with selecting a city.
Selecting a city
Use or to select the destina-
tion city.
The
Page
soft keys allow scrolling
through the list page by page.
Press .
After selecting the desired city, one of
the following menus appears:
For larger cities with more than 15
streets:
Enter Street menu (
page 139).
For smaller cities with up to
15 streets:
Select Street menu (
page 139).
If no streets are registered for the
selected city:
Select City Center menu
(page 137).
The appropriate menu can be identified
from the display in the status bar.
iThe selection is cancelled if the
Back
soft key is pressed.
Page 138 of 215
137 Navigation*
Destination entry
Besides entering a street name
(page 138), the following soft keys are
available for narrowing the destination.
Map
soft key
Provides access to destination input di-
rectly via road map (
page 144),
CityCtr
soft key
Provides access to the input of a city
section (center) (
page 137),
POIs
soft key
Provides access to the input of a POI
referring to the destination city
(
page 178).
After the destination city (
page 135) has
been entered, the associated city center
(section of the city) can be selected.
Press the
CityCtr
soft key.
Enter center
is displayed in the status
bar.
Accepting the destination displayed
Press .
Narrowing of the destination after
selecting a city
Entering a city center
Page 139 of 215
138 Navigation*Destination entryEntering a center
Use the keypad menu or the 12 button
keypad to enter the data of the center
(page 129).
After entering the center a selection
list of centers appears indicated by
Se-
lect center
displayed in the status bar.
Now continue with selecting a center.
Switching to a selection list is possible at
any time while entering a center.
Press the
List
soft key.
A selection list appears indicated by
Se-
lect center
displayed in the status bar.
Now continue with selecting a center.Selecting a center
Use or to select a city center.
The Page soft keys allow scrolling
through the list page by page.
Press .
The Start Route Guidance menu
(page 150) appears.
The system accesses one of the following
menus after entering of a destination city
(
page 135):
For larger cities with more than 15
streets:
Enter Street menu (
page 139).
For smaller cities with up to 15 streets:
Select Street menu (
page 139).
Entering a street in the destination
city
