2005 MERCEDES-BENZ C CLASS COUPE display

152 Controls in detailControl system
Resetting fuel consumption statistics
Press buttonÿ orè repeatedly
until the first function of the trip
computer menu appears in the
multifunction display.

Press button j ork repeatedly
until the reading that you want to reset
appears in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 119) until
the value is reset to0. Call up range (distance to empty)

Press button
ÿ orè repeatedly
until the first function of the trip
computer menu appears in the
multifunction display.

Press button j ork repeatedly
until the message
Distance
appears in
the multifunction display.
The calculated range based on the
current fuel tank level appears in the
multifunction display.
iAll statistics stored since the last
engine start will be reset approximately
four hours after the SmartKey in the
starter switch is turned to position 0 or
removed from the starter switch.
Resetting will not occur if you turn the
SmartKey back to position 1 or 2
within this time period.


153
Controls in detail
Control system
TEL menu*
You can use the functions in the
TEL
menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.

Switch on the telephone and
COMAND*.

Press button ÿ orè on the
steering wheel repeatedly until the
message
TEL
appears in the multifunc-
tion display.
Which messages will appear in the multi-
function display field depends on whether
your telephone is switched on or off:


If the telephone is off, the message PHONE OFF
appears in the multifunction
display.


If the telephone is on:
The telephone will then search for a
network. During this time the
multifunction display is empty.
As soon as the telephone has found a
network, the message
READY
appears in
the multifunction display.
This standby message indicates that your
telephone is ready for use and you can
operate it using the control system.
Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we
recommend that you pull over to a safe
location and stop before placing or taking a
telephone call. If you choose to use the
telephone while driving, please use the
hands-free device and only use the
telephone when weather, road and traffic
conditions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a
vehicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system,
possibly resulting in an accident and
personal injury.

154 Controls in detailControl systemAnswering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will then see
the message:
Press buttons.
You have answered the call. The
duration of the call appears in the
multifunction display. Ending a call

Press button
t.
You have ended the call. The standby
message appears in the multifunction
display. Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.

Press button
ÿ orè repeatedly
until the message
TEL
appears in the
multifunction display.

Press button j ork .
The control system reads the phone
book which is stored in the telephone.
This may take up to 30 seconds. The
message
Please wait
appears in the
multifunction display.
When the message
Please wait

disappears, the phone book has been
loaded.

155
Controls in detail
Control system

Press button
j ork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in
ascending or descending alphabetical
order.
1 Name from the phone book

Press button s.
The system dials the selected phone
number.

If the connection is successful, the
name of the party you called and
the duration of the call will appear
in the multifunction display.


If no connection is made, the
control system stores the dialed
number in the redial memory.
iIf you press and hold button j
or k for longer than one second,
the system scrolls rapidly through the
list of names until you release the
button again.
Cancel the quick search mode by
pressing button t.

156 Controls in detailControl systemRedialing
The control system stores the most
recently dialed phone numbers. This
eliminates the need to search through your
entire phone book.
Press buttonÿ orè repeatedly
until the message
TEL
appears in the
multifunction display.

Press button s.
The first number in the redial memory
appears in the multifunction display.

Press button j ork repeatedly
until the desired name appears in the
multifunction display.

Press button s.
The control system dials the selected
phone number.

159
Controls in detail
Automatic transmission*
 Automatic transmission*
For more information on driving with an
automatic transmission, see “Automatic
transmission*” (
page 49).
Your vehicle’s transmission adapts its gear
shifting process to your individual driving
style by continually adjusting the shift
points up or down. These shift point adjust-
ments are performed based on current
operating and driving conditions.
If the operating conditions change, the
automatic transmission reacts by
adjusting its gear shift program.
Gearshift pattern for automatic
transmissionThe automatic transmission selects indi-
vidual gears automatically, depending on:

the gear selector lever
position D(
page 162) with gear
ranges 4, 3 , 2 , 1 (
page 161)


the selected program mode ( C/S)
(page 164)


the position of the accelerator pedal
(page 165)


the vehicle speed 1
Current gear range/gear selector lever
position
2 Current program mode
The current gear range/gear selector lever
position and program mode (
C/S) appear
in the multifunction display.
An additional indication of the current gear
selector lever position can be found on the
cover of the shifting-gate.
The indicators come on when you activate
a switch (e.g. unlocking the vehicle or
opening a door) and go out after approxi-
mately 15 minutes.
iDuring the brief warm-up, transmission
upshifting is delayed. This allows the
catalytic converter to heat up more
quickly to operating temperature.

161
Controls in detail
Automatic transmission*
Canceling gear range limit
Press and hold the gear selector lever
in the
D+direction until
D reappears in
the multifunction display.
The transmission will shift from the current
gear range directly to gear range D.
Shifting into optimal gear range

Press and hold the gear selector lever
in the D-direction.
The transmission will automatically select
the gear range suited for optimal
acceleration and deceleration. This will
involve shifting down one or more gears.
Gear ranges
With the gear selector lever in position D,
you can limit the transmission’s gear range
by pressing the gear selector lever to the
left ( D-), and reverse the gear range limit
by pressing the gear selector lever to the
right ( D+).
The selected gear range appears in the
multifunction display. If you press on the
accelerator when the engine has reached
its rpm limit, the transmission will upshift
beyond any gear range limit selected.
Effect
é
The transmission shifts through
fourth gear only.
è
The transmission shifts through
third gear only.
With this selection you can use
the braking effect of the engine.
Effect
ç
The transmission shifts through
second gear only.
Allows the use of engine’s
braking power when driving:

on steep downgrades


in mountainous regions


under extreme operating
conditions
æ
The transmission operates in
first gear only.
For maximum use of engine’s
braking effect on very steep or
lengthy downgrades.

164 Controls in detailAutomatic transmission*Automatic shift program
The program mode selector switch is
located on the lower part of the center
console.1 Program mode selector switch
C Comfort For comfort driving
S Sport For standard driving

Press program mode selector
switch 1 repeatedly until the letter of
the desired program mode appears in
the multifunction display (
page 159).
Select Cfor comfort driving:


The vehicle starts out in second
gear (both forward and reverse) for
gentler starts. This does not apply if
full throttle is applied or gear
range 1 is selected.


Traction and driving stability are
improved on icy roads.


Upshifts occur earlier even when
you give more gas. The engine then
operates at lower rpms and the
wheels are less likely to spin.
!Never change the program mode when
the gear selector lever is out of
position P. This could result in a
change of driving characteristics for
which you may not be prepared.iThe last selected program
mode ( Sor C) is switched on when
the engine is restarted in the
automatic program mode.
