Page 177 of 286

Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.
Your vehicle is equipped with disc
brakes. A power assist helps reduce
the ef f ort needed on the brake pedal.
The ABS helps you retain steering
control when braking very hard.
Put your f oot on the brake pedal only
when you intend to brake. Resting
your f oot on the pedal keeps the
brakes applied lightly, builds up heat,
increases wear and reduces their
ef f ectiveness. It also keeps your
brake lights on all the time,
conf using drivers behind you.
Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear. If the brake pads need replacing, you
will hear a distinctive, metallic
screeching sound when you apply
the brake pedal. If you do not have
the brake pads replaced, they will
screech all the time. It is normal f or
the brakes to occasionally squeal or
squeak when you apply them.
Braking System
Brake Wear Indicators Braking System Design
176
—
—
y
y
('y
y
Page 178 of 286

The anti-lock brake system (ABS)
helps prevent the brakes f rom
locking up, and helps you retain
steering control by pumping the
brakes rapidly, much f aster than a
person can do it.
The ABS also balances the f ront-to-
rear braking distribution according
to vehicle loading.
this def eats the purpose of the ABS.
Let the ABS work f or you by always
keeping f irm, steady pressure on the
brake pedal as you steer away from
the hazard. This is sometimes
ref erred to as ‘‘stomp and steer.’’If the ABS indicator comes on, the
anti-lock f unction of the braking
system has shut down. The brakes
still work like a conventional system,
but without anti-lock. You should
have your dealer inspect your vehicle
as soon as possible.
If the ABS indicator and the brake
system indicator come on together,
and the parking brake is f ully
released, the front-to-rear braking
distribution system may also be shut
down.
You will f eel a pulsation in the brake
pedal when the ABS activates, and
you may hear some noise. This is
normal: it is the ABS rapidly
pumpingthebrakes.Ondry
pavement, you will need to press on
thebrakepedalveryhardbeforethe
ABS activates. However, you may
feel the ABS activate immediately if
you are trying to stop on snow or ice.
You should never pump the brake pedal;
CONT INUED
Anti-lock Brakes (ABS)
Anti-lock Brakes (ABS)
Activating the Anti-lock Brakes ABS Indicator
Driving
177
—
—
y
y
('y
y
Page 179 of 286

Test your brakes as instructed on
page . If the brakes f eel normal,
drive slowly and have your vehicle
repaired by your dealer as soon as
possible. Avoid sudden hard braking
which could cause the rear wheels to
lock up and possibly lead to a loss of
control.such as trying to take a
corner too f ast or making a sudden
lane change. Always drive at a safe
speed f or the road and weather
conditions.
It only helps with the steering control during braking.
Always steer moderately
when you are braking hard. Severe
or sharp steering wheel movement
can still cause your vehicle to veer
into oncoming traffic or off the road.
on loose or
uneven surf aces, such as gravel or
snow, than a vehicle without anti-
lock. Slow down and allow a greater
distance between vehicles under
those conditions. The TCS indicator will come on
alongwiththeABSindicator.
261
Anti-lock Brakes (ABS)
A BS will not prevent a skid that
results f rom changing direction
abruptly,
A BS does not reduce the time or
distance it takes to stop the
vehicle. A BS cannot prevent a loss of
stability.
A vehicle with A BS may require a
longer distance to stop
Import ant Saf et y Reminders
178
ABS INDICATOR
—
—
yy
('y
y
Page 180 of 286

When starting out or driving on a
loose or slippery road surf ace, you
may notice that the vehicle does not
respond to the accelerator in the
samewayitdoesatothertimes.This
is a sign TCS is activating. You will
seetheTCSActivationindicator
light f lash.TheTCSindicator(seepage )
andtheTCSactivationindicator
comeonandstayonwhenthereisa
problem with the TCS.
You should still install winter tires on
your vehicle during the winter. Make
sure to use the same size originally
supplied with the vehicle. Exercise
the same caution in winter driving as
you would if your vehicle was not
equipped with TCS.
Your vehicle is equipped with a
traction control system (TCS) to
assist you in maintaining traction
while driving slowly on loose or
slippery surf aces.
TCS monitors the speed of all f our
wheels. When it senses a f ront wheel
losing traction, it applies braking to
that wheel. The TCS Activation
indicator f lashes when this occurs.
Driving with TCS requires no special
skills or technique. The TCS does
not control your vehicle’s whole
braking system and cannot prevent
skidding if you enter a corner too
f ast. It is still your responsibility to
drive at reasonable speeds and to
leave a sufficient margin of safety.
Driving with the compact spare tire
installed (see page ) may
activate the TCS. You should turn of f
the system.56
236On Canadian model
Traction Control System
Driving
179
TCS ACTIVATION INDICATOR TCS INDICATOR
—
—
y
y
('y
y
Page 181 of 286

Push the TCS Off switch to turn the
TCS off. Push the switch again to
turn the TCS on. The TCS does not
turn off while the TCS activation
indicator is blinking.
TheTCSturnsoneachtimeyou
start the engine.When you turn the ignition switch to
the ON(II) position, this indicator
comes on f or a f ew seconds and then
goes off.
This indicator stays on;
When the TCS is off.
When there is something wrong
with the TCS.
This indicator blinks while the TCS
is working to prevent wheelspin. If this indicator comes on while you
are driving, stop your vehicle in a
safe place, turn the engine off and
restart it. If the indicator stays on, or
comes on again while you are driving,
contact your dealer to have the
vehicle serviced. The TCS does not
work when the indicator is on. The
vehicle is drivable even when the
indicator is on.
Occasionally, the indicator comes on
momentarily even when there is
nothing wrong with the TCS.
Traction Control System
T CS Of f Switch
T CS A ctivation IndicatorT CS Indicator
180
TCS OFF SWITCH
—
—
yy
('y
y
Page 182 of 286
The TCS indicator and the ABS
indicator are on when there is
something wrong with the anti-lock
brake system (see
on page ).
The TCS indicator and the brake
system indicator are on when there
is something wrong with the brake
system (seeon page ).
177
54
Traction Control System
ABS Indicator
Brake System
Indicator
Driving
181
—
—
yy
('y
y
Page 183 of 286

Your vehicle has been designed to
primarily carry passengers and their
cargo. You can also use it to tow a
trailer if you caref ully observe the
load limits, use the proper equipment,
and f ollow the guidelines in this
section.The
maximum allowable weight of the
trailerandeverthinginoronit
must not exceed 1,000 lbs (450 kg).
Towing a load that is too heavy
can seriously af f ect your vehicle’s
handling and perf ormance. It can
also damage the engine and
drivetrain. The weight that
the tongue of a f ully-loaded trailer
puts on the hitch should be
approximately 10 percent of the
total trailer weight. Too much
tongue load reduces f ront-tire
traction and steering control. Too
little tongue load can make the
trailer unstable and cause it to
sway.
Towing a Trailer
Load Limits
T otal T railer Weight: T ongue L oad:
182
Exceeding any load limit or
improperly loading your vehicle
and trailer can cause a crash in
which you can be seriously hurt
or killed.
Check the loading of your
vehicle and trailer carefully
beforestartingtodrive.
—
—
yy
('y
y
Page 184 of 286
To achieve a proper tongue load,
start by loading 60 percent of the
load toward the front of the trailer
and 40 percent toward the rear, then
re-adjust the load as needed.The maximum allowable weight of
the vehicle, all occupants, all cargo,
and the tongue is: The best way to conf irm that vehicle
and trailer weights are within limits
is to have them checked at a public
scale.
Using a suitable scale or a special
tongue load gauge, check the tongue
load the f irst time you set up a
towing combination (a f ully-loaded
vehicle and trailer), then recheck the
tongue load whenever the conditions
change.
The maximum allowable weight of
the vehicle axles is:
on the f ront axle
on the rear axle
Gross Vehicle Weight Rating
(GVWR): Checking L oads
Gross Axle Weight Rating
(GA WR):
Towing a Trailer
Driving
183
4,453 lbs (2,020 kg) 2,390 Ibs (1,085 kg)
2,095 Ibs (950 kg)
—
—
