NOTE:Once the top is lowered and the audible signal
is heard, you can continue to push the convertible top
switch down or push it within 2 seconds to raise the
windows.
The windows can also be closed/opened later using the
power window switches.CAUTION!
To prevent mildew, the convertible top must be dry
before lowering it into the storage compartment.
Do not lower a frozen convertible top until thawed
and dry. Doing so may result in damage not covered
by the DaimlerChrysler Limited Warranty.
CAUTION!
Do not place anything on the tonneau cover.
The tonneau cover must never be used as a seating
area.
To Raise The Top:
1. Make sure the rear cargo compartment divider is still
secured in the vertical position.
2. Make sure the decklid is closed.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57
3

3. Turn the ignition key to the ON/RUN position and
press down on the front of the convertible top switch.
4. If the windows are raised, they will lower as soon as
the convertible switch is pressed down. The tonneau
cover will open, and the top will then close until it
reaches approximately 8 inches (200 mm) from the
header. The tonneau cover will then close and the rear of
the top will close and latch. At the completion of this
cycle, a single audible signal will sound.NOTE:If the top is latched to the windshield header
before the rear of the top is properly latched, an audible
warning will sound.
5. Push the latch handle release button, pull the latch
handle down from the storage position and turn it
clockwise just over one quarter turn.
6. Pull the latch handle and convertible top down to
engage the top with the header.
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. When the top engages to the header, turn the latch
handle counterclockwise just over one quarter turn to the
lock position and push the latch handle up to the stored
position. The top is now secured in the closed position.
NOTE:The convertible top switch indicator will light
up and an audible warning will be heard if you start
driving the vehicle without the top fully locked in the
closed position.8. Once the top has been raised and locked, the cargo
compartment divider can be unhooked and folded for-
ward to increase the cargo compartment capacity. Follow
the steps shown on the label affixed to the decklid trim.WARNING!
To prevent possible accidents, drive the vehicle only
with the convertible top either completely closed
and locked, or fully lowered into its storage compart-
ment.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 59
3

CAUTION!
Once the cargo compartment divider is folded for-
ward to increase the cargo compartment capacity, the
tonneau cover flaps are exposed and can be damaged
by long items being put into the cargo compartment.
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Convertible Top Lamp and Audible Signal Chart
Below is a table containing all of the visual and audible
signals that can be seen or heard during top operation or
if a fault is present.
Visual and Audible Signals Operation Mode or
Fault
Single audible signal is
heardRoof reaches fully open
position
Roof reaches fully
closed position
Convertible top switch lamp
flashes slowly and a slow
audible beep is heardDecklid open
Cargo compartment
divider not secured in
vertical position
Top latched at wind-
shield header before
top cycle is complete
Top unlatched but not
pushed up from wind-
shield header
Vehicle speed greater
than 9 mph (15 km/h)
while trying to initiate
top operation
Battery voltage less
than 10.6 Volts
Convertible top switch lamp
flashes quickly and a quick
audible beep is heardMaximum hydraulic
pump run-time reached
Power window mo-
tor(s) inoperative
Vehicle speed greater
than 9 mph (15 km/h)
during top operation
Top operation sus-
pended longer than 10
minutes
Convertible top switch lamp
flashes rapidlyGeneral top control
module fault
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3

CONSOLE FEATURES
The console has a power outlet/cigar lighter, an ash tray
with a coin holder, a cupholder, and the passenger airbag
light. In addition, there are switches to control the heated
seats, electronic stability program (ESP), hazard flashers,
central locking, rear defroster and towing alarm.
Operating controls for the heating and air conditioning
systems, power windows, power mirrors, convertible top
switch (if equipped), and the automatic transmission
program mode selector switch (if equipped) are also
located in the console.
Storage Compartments
There is a storage compartment in the console. To open
the storage compartment, lift the lid with the finger
depressions on either side. To close, lower the lid until
the lock engages.
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

A cargo net for storage is located in the footwell area on
the passenger side.
Additionally, storage pockets are located on the wall
behind each seat and on each door panel.
A storage pouch is located on the rear wall between the
seats, and the driver’s sunvisor has a document strap.WARNING!
Keep compartment lids closed. This will help to
prevent stored objects from being thrown about and
injuring vehicle occupants during an accident.
Ashtray
Lightly touch the bottom of the ashtray cover. The
ashtray will open automatically.
To remove the ashtray insert, pull the ashtray past the
detent. Hold both sides of the insert, and pull up. To
install the ashtray, place it in the frame and push down to
engage.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 63
3

WARNING!
Remove the ashtray only with the vehicle stopped
and the ignition off. Otherwise, the vehicle might
move unexpectedly as a result of unintended contact
with the gear selector lever.
Coin Holder
With the ashtray open, folding down the cover plate
reveals the coin holder, which can accommodate nine
coins in various sizes up to a U.S. quarter. The coin slots
are shaped to retain the coins, and the cover plate ensures
that the coins remain in the coin holder.
