2005 CHRYSLER CROSSFIRE SRT Owners Manual

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS

Convertible Top Operation................52
▫To Lower The Top......................53
▫To Raise The Top......................57
▫Convertible Top Lamp And Audible Signal
Chart...............................61

Console Features.......................62
▫Storage Compartments..................62
▫Ashtray.............................63
▫Coin Holder..........................64
▫Power Outlet/Cigar Lighter...............65
▫Glove Compartment....................65

Cupholder............................65

Mirrors..............................66
▫Inside Day/Night Mirror.................66
▫Exterior Mirrors Folding Feature...........67
▫Heated Remote Control Mirrors............67
▫Outside Mirrors.......................67
▫Power Remote Control Outside Mirrors......68
▫Vanity Mirrors........................69

Seats................................69
▫Driver Eight-Way Power Seat..............69
▫Passenger Four-Way Power Seat............70
▫Heated Seats.........................71
3

To Open And Close The Hood.............71

Interior Lights.........................72
▫Front Map/Reading Lights...............73
▫Battery Saver Feature...................73
▫Instrument Panel Lighting................73
▫Night Security Illumination...............73

Exterior Lights.........................74
▫Headlights And Parking Lights............74
▫Daytime Running Lights (Where Applicable) . . .74
▫Fog Lights...........................74
▫Standing Lights.......................75

Multifunction Control Lever...............75
▫Turn Signals..........................75
▫Headlight Dimmer Switch................76
▫Passing Light.........................77
▫Windshield Wipers And Washer............77▫Mist Function.........................78

Telescoping Steering Column..............79

Tire Pressure Monitor System..............80

Brake Assist System (BAS)................82

Electronic Stability Program (ESP)...........83
▫Synchronizing ESP.....................85

Electronic Speed Control..................86
▫To Vary The Speed Setting................87
▫To Deactivate.........................88
▫To Resume Speed......................88
▫Using Speed Control On Hills.............89

Garage Door Opener....................89
▫Programming The Universal Transceiver......90
▫Gate Operator/Canadian Programming......92
▫Using The Universal Transceiver...........93
▫Erasing Universal Transceiver Buttons........93
50 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫Reprogramming a Single Button............93
▫Security.............................93
Umbrella Hook........................94
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 51
3

CONVERTIBLE TOP OPERATION
WARNING!
The convertible top does not provide the structural
protection that a reinforced metal roof does and the
fabric top cannot be expected to prevent the ejection
of the occupants of a vehicle in a collision. There-
fore, it is important that all occupants wear their seat
belts at all times when riding in a convertible.
Studies have shown that it is generally safer to
remain inside a vehicle during a collision than to be
ejected from the vehicle.
For safety reasons, the convertible top should only be
opened and closed when the vehicle is standing still. Top
operation is allowed up to a maximum of 9 mph (15
km/h). Above this speed, top operation will cease and an
audible warning will sound. The top operation can be
resumed after the vehicle is below the maximum speed
by pressing the convertible top switch again.
WARNING!
Before operating the switch for the convertible top,
make sure that no persons can be injured by the
moving parts (convertible top frame and tonneau
cover).
Hands must never be placed near the sport bar,
convertible top frame, upper windshield area, shelf
behind sport bar, or convertible top storage compart-
ment while the convertible top is being raised or
lowered. Serious personal injury may occur.
If potential danger exists, release the convertible top
switch. This immediately interrupts the raising or
lowering procedure. You then can operate the con-
vertible top switch to raise or lower the convertible
top away from the danger zone.
52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
When opening and closing the convertible top, make
sure that:
•There is sufficient clearance of at least 6 ft. (1.8m)
for the convertible top to move up.
•Nothing is placed on the tonneau cover.
•The outside temperature is above 32°F(0°C).
Otherwise the convertible top and other parts of the
vehicle could be damaged.
CAUTION!
Use caution when putting items into the storage
compartment with the top in the closed position. The
tonneau cover extensions are exposed and can be
damaged if luggage or other items are pushed to far
into the storage compartment.
To Lower The Top:
WARNING!
Top operation can be suspended for a maximum of
10 minutes. Thirty seconds before the end of this
period an audible warning will begin to sound
continuously. At the end of this period, hydraulic
pressure will be released and the top and tonneau
cover will slowly collapse. Hands should be kept
away from moving parts of the top compartment
mechanism to avoid injury as hydraulic pressure is
reestablished. In order to re-initialize the top cycle,
the tonneau cover must be moved to its full open
position manually and lower the top assembly into
the storage compartment. Once the top is lowered
into the storage compartment, lower the tonneau
cover to its closed position. The hydraulic pressure
can now be reestablished by turning the ignition to
the ON/RUN position and pushing down on the
convertible top switch twice. Refer to Convertible
Top Emergency Operation in the What To Do In
Emergencies section of this manual.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53
3

CAUTION!
To avoid possible damage to the tonneau cover and
convertible top, do not allow the convertible top to
remain in the suspended position. After approxi-
mately 10 minutes in the suspended position an
audible beep will be heard and the hydraulic pres-
sure will be released which will allow the top and
the tonneau cover to lower. The convertible top
switch can be pressed to cancel this operation.
CAUTION!
To avoid damage to either the top or the rear win-
dow, check the tonneau cover area at the rear of the
vehicle interior to be sure that it is clear of debris or
other items. Do not use the tonneau cover area for
other storage purposes.
CAUTION!
To fully insure that no damage occurs, be sure that
the vehicle is at a complete stop before attempting to
lower or raise the top.
NOTE:If the top does not operate or stops during the
raising or lowering procedure, start the engine and
continue operation.
1. Make sure the rear cargo compartment divider is
unfolded and secured in the vertical position. A slow
audible information signal will be heard and the convert-
ible top switch lamp will flash slowly if the cargo
compartment divider is not in the vertical position. If the
divider is in its stowed position, first unfold the panels
towards the rear of the vehicle. Pull up on the vertical
panel using the center cutout shown, and hook the pins
at the top into the brackets mounted to the cargo com-
partment trim on each side near the forward edge of the
decklid opening. The pins must be hooked in these
brackets in order for the top to operate.
NOTE:See label attached to underside of decklid.
54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Make sure the decklid is closed.
3. Turn the ignition key to the ON/RUN position.
CAUTION!
Be sure to turn the ignition to the“ON/RUN”
position before releasing the top from the wind-
shield header. The windows will not go down if the
top is released from the header without the ignition
turned“ON”. The side windows can be damaged if
the doors are opened or closed with the windows up
and the top released from the windshield header and
pushed to the overcenter position.
4. Unlock the top from the windshield header by push-
ing the latch handle release button, pulling the latch
handle down and turning it clockwise just over one
quarter turn.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55
3

NOTE:Once the release handle is rotated, the windows
will automatically go down.
5. Push up on the convertible top latch handle to create a
gap between the header and top of approximately 8
inches (200 mm). As soon as the top is free, rotate the
latch handle counterclockwise just over one quarter turn
and push it up into the stored position.
NOTE:Failure to perform any of these steps will
prevent the top from operating with the convertible top
switch and will cause an audible information signal to
sound.6. Push down on the rear of the convertible top switch to
begin top operation. The rear of the top will unlatch and
the tonneau cover will open before the top begins to fold.
Hold the switch down until the convertible top is com-
pletely lowered into its storage compartment and the
tonneau cover is closed and latched. A single audible
signal will sound to indicate completion of the top
opening operation.
