Handlebar fitting, left1Pushbutton, Tripmaster /
on-board computer (OE)
( 39) ( 41)
2 Pushbutton, ESA ( 56)
3 Pushbutton, horn
4 Pushbutton, left flash-
ing turn indicators and
hazard warning flashers
( 49) ( 38)
5 Switch, high-beam head-
light and headlight flash-
er ( 47)
215zGeneral views

Handlebar fitting, right1Emergency off switch (kill
switch) ( 45)
2 Pushbutton, starter
( 62)
3 Grip heating switch
( 45)
4 Pushbutton, right flash-
ing turn indicators and
hazard warning flashers
( 49) ( 38)
5 Pushbutton, cancel flash-
ing turn indicators and
hazard warning flashers
( 50) ( 39)
216zGeneral views

Instrument cluster1Speedometer
2 Rev. counter
3 Warning and telltale
lights ( 20)
4 Multifunction display
( 20)
5 Telltale light, anti-theft
alarm (OE) and sensor for
instrument lighting
6 Adjuster, clock ( 44)
The instrument-cluster
lighting has automatic
day and night switchover.
217zGeneral views

Headlight1High-beam headlights
2 Low-beam headlight
3 Parking light
218zGeneral views

Status indicators
Multifunction display . .......... 20
Warning and telltale lights . . .... 20
ABS warning light ............. 20
Function indicators . . . ......... 20
Warnings, general ............. 21
ABS warning indicators ........ 28
319zStatus indicators

Multifunction display1Clock
2 Panel for warnings
( 21)
3 Panel for the on-board
computer's status indic-
ators
4 Gear indicator ( 20)
5 Engine temperature
readout ( 21)
6 Panel for ESA status in-
dicators ( 56)
7 Tripmaster display ( 39)
8 Fuel gauge ( 20)
Warning and telltale
lights1Telltale light, left turn in-
dicator
2 Telltale light, high-beam
headlight
3 Warning light, general
4 Telltale light, neutral
5 ABS warning light
6 Telltale light, right turn
indicator
ABS warning lightThe way in which the ABS
warning light indicates status
can differ in some countries.
Alternative for the ABS
warning light.Function indicatorsFuel capacity
The horizontal bars be-
low the fuel-pump sym-
bol indicate the remaining
quantity of fuel.
Gear
Shows which gear is en-
gaged.
If no gear is engaged, the
gear indicator displays 0;
the 'neutral' telltale light also
lights up.
320zStatus indicators

Coolant temperature
The horizontal bars
below the temperature
symbol indicate the coolant
temperature.
Warnings, generalMode of presentation
General warnings are dis-
played by means of plain-text
messages and symbols in the
multifunction display. In some
cases, they are accompan-
ied by the 'General' warning
light showing red or yellow.
Two or more warnings can be
issued at the same time.
321zStatus indicators

Warnings, overview
Mode of presentation Meaning
Lights up yellow
EWS!
warning
appears on the
display Electronic immobiliser active ( 24)
Lights up yellow
FUEL!
warning
appears on the
display Fuel down to reserve ( 24)
Lights up red Coolant temperature too high ( 24)
Lights up yellow Appears on the displayEngine electronics ( 25)
Lights up red Appears on the displayInsufficient engine oil pressure
( 25)
Lights up red Appears on the displayInsufficient battery charge current
( 26)
Lights up yellow
LAMPR!
warning
appears on the
display Rear light bulb defective ( 26)
LAMPF!
warning
appears on the
display Front light bulb defective ( 26)
