GETTING TO KNOW YOUR CAR
159
If the Compact Disc player is already work-
ing and at the same time you want to re-
ceive traffic information, briefly pressing
(less than 1 second) the “AF-TA” button
(1) the radio tunes to the last station heard
in the FM band, the TA traffic information
function is activated and the traffic messages
are transmitted. If the station selected does
not send traffic information, the search for
an enabled station starts automatically.
If wishing to interrupt the traffic informa-
tion message, briefly press (less than 1 sec-
ond) the “AF-TA” button (1) during trans-
mission of the message.
c)To receive traffic information while not
listening to the radio:
– turn on the TAfunction, briefly pressing
(less than 1 second) “AF-TA” button (1),
so that the display shows “TA”
– tune to a station enabled to transmit
traffic information so that the display
shows“TP” take the volume to zero keep-
ing the “VOL-” button pressed (19).
This way, if that station broadcasts traffic
information, this will be heard at a minimum
predefined volume. IMPORTANTIn certain countries radio
stations exist which, even if the TPfunction
is on (the display shows “TP”), do not
transmit traffic information.
If the radio is working in the AM band
when the “AF-TA” button (1) is pressed,
it passes to the FM band on the last sta-
tion heard. If the station selected does not
broadcast traffic information (wording “TP”
not shown on the display), the search for
an enabled station starts automatically.
The volume with which the traffic bulletin
is transmitted varies depending on the lis-
tening volume:
– listening volume below 30: traffic bul-
letin volume = 20 (fixed value)
– listening volume above 30: traffic bul-
letin volume the same as the listening vol-
ume + 1.
If the volume is changed during a traffic
bulletin the value is not shown on the dis-
play and the new value is kept only for the
bulletin in progress.
During a traffic bulletin it is possible to turn
on sound adjustment with the “AUD” but-
ton (18). The new values set are also kept
at the end of the bulletin.IMPORTANTIf the TAfunction is on
and the station tuned is not able to provide
traffic information or it is no longer able to
provide this information (the display will not
show “TP”), so after 1 minute in which the
radio is in these conditions:
– if listening to a Compact Disc another
station is sought that is enabled to trans-
mit traffic information
– if when listening to the radio a “beep”
is given to alert that it is not possible to re-
ceive traffic information; to interrupt it, it is
necessary to tune to a station that can pro-
vide traffic information or switch off the TA
function.

GETTING TO KNOW YOUR CAR
160
Emergency alarm reception
In the RDS mode the radio is set to receive
emergency announcements in the case of
exceptional circumstances or events that
may cause general danger (earthquakes,
floods, etc. ) if they are broadcast by the
station tuned.
This function is activated automatically and
cannot be deactivated.
Program Type Function (PTY)
(selecting a type
of programme)
To turn on the PTY function, which makes
it possible to give top priority to PTY pro-
grammes, when present, which may involve
emergency messages or various topics (e.g.
music, news bulletins) briefly press the
“PTY” button (2) until the display shows
“PTY” and the subject of the last station
heard (e.g. “NEWS”).
IMPORTANTTo turn on the PTY func-
tion, the radio must be in the FM band.
If the station does not broadcast in the PTY
mode, the wording “NO-PTY” is shown
on the display for 5 seconds.
After 2 seconds the station name or fre-
quency is shown on the display.The list of the various subjects comprises:
NEWS
AFFAIRS
INFO
SPORT
EDUCATE
DRAMA
CULTURE
SCIENCE
VARIED(Variety)
POP M
ROCK M
M,O,R,M(Middle of the Road Music)
LIGHT M(Light music)
CLASSICS
OTHER M(Other music)
To change the type of PTY programme
press “
¯¯” (4) or “˙˙” (7) or one of
the 6 preset buttons. If the display shows
the station frequency or name, pressing
“
¯¯” (4) or “˙˙” (7) the current type
of programme will be displayed.To store the current type of programme on
one of the 6 preset buttons, give a pro-
longed press (over 1 second) on the pre-
set button. Storage is confirmed by a
“beep”. To seek a station with this pro-
gramme see the “Automatic tuning” and
“Scanning stations (Scan Function)” para-
graphs.
If no station is available with this type of
programme the system sounds a “beep”,
the station selected previously is heard and
for 2 seconds the display shows the word-
ing “NO-PTY”.
To turn the PTY function off briefly press
the “PTY” (2) button again.

GETTING TO KNOW YOUR CAR
161
Controlling the station’s type of
PTY programme
To know the type of PTY programme of
the station heard, keep the “PTY” (2)
pressed until a “beep” is heard. After the
“beep” the display will show the type of pro-
gramme (see previous paragraph) offered
by the station tuned. If the station has no
PTY code, the display will show the wording
“NO-PTY”. After about 5 seconds the dis-
play will again show the RDS name or fre-
quency of the station tuned.
EON Function
(Enhanced Other Network)
Some countries have circuits which group
together several stations enabled to broad-
cast traffic information. In this case the pro-
gramme of the station being heard, will be
interrupted temporarily to receive traffic in-
formation (only with the TA function on),
every time these bulletins are given by one
of the stations of the same circuit. Scrolling transmissions
It is possible to receive different pro-
grammes in the same network and scroll
them in FM Band only) - e.g.: NDR1, NDR2,
NDR3, NDR4, N-JOY...
To turn on this function, briefly press the
“AF-TA” button (1) to turn on the AF func-
tion. The user can then start scrolling press-
ing “
˙˙” (7) or “¯¯” (4).
IMPORTANTThe station must have
been received previously at least once.
Stereophonic stations
If the signal received is weak, the device
switches automatically from Stereo to Mono.
MENU(fig. 137)
Functions of “MENU” button (9)
To turn on the menu function briefly press
(less than 1 second) the “MENU” button
(9). The display will show the word
“MENU”.
To scroll the Menu functions use “
▲” (6)
or “
▼” (8). To turn on/off the function se-
lected use “
˙˙” (7) or “¯¯” (4).
The display will show the current status
of the function selected.
The functions controlled by the menu are
the following:
–EQ SET(Equalizer settings, only if the
equalizer is on)
–PRESET/USER/CLASSIC/
ROCK/JAZZ(Turning on/off and choos-
ing predefined equalizer adjustments)
–HICUT(Treble reduction)
–PHONE(Volume of phone, if installed)
–CD NAME(Allocation of CD names,
only with CD inserted)
–SVC(Automatic volume control in re-
lation to speed)
–SENS DX/LO(Tuning sensitivity)
–CD(CD display setting)

GETTING TO KNOW YOUR CAR
162
–CDC(CD-Changer display setting, if in-
stalled)
–REG(Regional programmes).
–IGN TIME(Switching off mode)
To exit the Menu function, press the
“MENU” button again (9).
Turning the equalizer on/ off
(except versions with BOSE HI-FI
system)
The integrated equalizer can be turned on
or off. With the equalizer off, it is possible
to change the sound settings only adjust-
ing the bass (“BASS”) and treble tones
(“TREBLE”), while activating the function
makes it possible to adjust the sound curves.
To turn the equalizer off, select “PRE-
SET” with “
▲” (6) or“▼” (8).To turn on the equalizer, select one of the
following with “
▲” (6) or “▼” (8) :
– “USER” (adjustment of the 7 equal-
izer bands that can be changed by the user)
– “CLASSIC” (predefined equalizer ad-
justment)
– “ROCK” (predefined equalizer adjust-
ment)
– “JAZZ” (predefined equalizer adjust-
ment).
After selecting the last adjustment set in
the Menu using
▲” (6) or “▼” (8) use,
“
˙˙” (7) or “¯¯” (4) to change it.
When one of the equalizer settings is on,
the display shows “EQ”.
On versions with BOSE HI-FI system, ana-
logue equalizing in amplitude and phase of
the signal is done automatically by the am-
plifier.Equalizer settings
(only if the equalizer is on)
To set a personal equalizer adjustment, use
“
▲” (6) or “▼” (8) “USER”; the display
shows “EQ SET”.
To change the equalizer settings, use
“
˙˙” (7) or “¯¯” (4). The display
shows a graph with 7 bars, where each bar
represents a frequency for the left or right
channel. Choose the bar to be adjusted us-
ing “
˙˙” (7) or “¯¯” (4); the bar cho-
sen starts to flash and it is possible to adjust
it using “
▲” (6) or “▼” (8).
To store the new settings, press the
“MENU” button again (9). The display still
shows “EQ SET”.

GETTING TO KNOW YOUR CAR
163
Treble tone reduction function
(HICUT)
Using this function it is possible to reduce
the treble tones, in accordance with the sig-
nal transmitted. To turn this function on/off,
use “
¯¯” (4) or “˙˙” (7).
The display will show the current status
of the function:
– “HICUT ON”: function on
– “NO HICUT”: function off.
Phone volume adjustment
function (PHONE)
With this function it is possible to adjust
(setting from 1 to 66) or cut off (OFF set-
ting) the telephone sound.
To turn on/off, use “
¯¯” (4) or “˙˙”
(7).
To adjust the sound, use “VOL+” (21)
or “VOL-” (19).
The display will show the current status
of the function:
– “PHONE 23”: function on with vol-
ume setting 23
– “PHONE OFF”: function off.Allocating a name to a CD
(CD NAME)
This function can be chosen only if a Com-
pact Disc is inserted. To turn on, use “
¯¯”
(4) or “
˙˙” (7): the display will show
“CD-NAME”. If the CD already has a
name, this will be shown on the display, if
not, eight dashes will be shown. If storage
is no longer available for a new name, the
display will show the first name stored.
To change the name or give a name to the
new CD press “
¯¯” (4) or “˙˙” (7).
Press the buttons again to choose the posi-
tion of the character to be changed. Press
“
▲” (6) or “▼” (8) to choose or change
the character.
To store the name, press the “MENU”
button again (9). The display will show
“CD-NAME”.
To clear a name, turn the function on and
press “
▲” (6) or “▼” (8) to choose the
name to be cleared, then press the
“MENU” button for about 2 seconds (9).
The system beeps and the display shows
“ONE CLR” for about 2 seconds. At this
point the procedure can be started to give a
new name.To clear all the names, turn the function
on and keep the “MENU” button pressed
for about 4 seconds “MENU” (9). The set
gives two beeps and the display shows
“ALL CLR” for about 2 seconds. At this
point, it is possible to start the name allo-
cation procedure.
Volume changing with speed
function (SVC)
The SVC function makes it possible to au-
tomatically adapt the volume level to the
speed of the car, increasing it as the speed
increases to maintain the ratio with the noise
level inside the passenger compartment.
To turn the function on/off use “
¯¯” (4)
or “
˙˙” (7). The display will show the cur-
rent status of the function:
– “SVC-ON”: function on
– “SVC-OFF”: function off.

GETTING TO KNOW YOUR CAR
164
Tuner sensitivity
adjustment (SENS DX/LO)
With this function it is possible to change
the sensitivity of automatic station search-
ing. When low sensitivity is set “SENS-
LO” only stations with excellent reception
are sought, when high sensitivity is set
“SENS-DX” all stations are sought. There-
fore, if the car is in an area with a consid-
erable number of stations and you want to
choose only those with a strong signal, set
to low sensitivity “SENS-LO”.
To set the sensitivity, use “
¯¯” (4) or
“
˙˙” (7). The display will show the cur-
rent status of the function:
– “SENS-LO”: low sensitivity
– “SENS-DX”: high sensitivity.Compact Disc data display
function (CD)
With this function it is possible to choose
the information shown by the display, when
listening to a Compact Disc.
Two settings are available:
–TIME(time elapsed since the start of
the track)
–NAME(CD name).
After choosing “CD” in the Menu using
“
▲” (6) or “▼” (8), the display
shows“CD-DISP”. To change the setting
use “
¯¯” (4) or “˙˙” (7).
CD-Changer data display function
(CDC) (if installed)
This function can be chosen only if a CD-
Changer is connected. In this case the dis-
play will show “CDC-DISP”.
To change function, use “
¯¯” (4) or
“
˙˙” (7).
The display shows the setting among the
two possible: “TIME” and “CD-NR”.Regional broadcast reception
function (REG)
Some national broadcasters, at determi-
nate times of the day, transmit regional pro-
grammes which differ from region to region.
This function makes it possible to tune in on-
ly on local stations (regional). However if
a regional programme is heard and you wish
to stay tuned to it, the function must be ac-
tivated.
To turn the function on/off, use “
˙˙”
(7) or “
¯¯” (4).
The display will show the current status
of the function:
– “REG-ON”: function on
– “REG-OFF”: function off.
If the function is off and a regional pro-
gramme is tuned that works in a determi-
nate area and the car enters a different area,
the regional station of the new area is re-
ceived.
IMPORTANTWhen the function is off
(“REG-OFF”) and the AF function is on
(alternative frequencies) the radio auto-
matically tunes to the frequency of the sta-
tion selected with the strongest signal.

GETTING TO KNOW YOUR CAR
165
IGN TIME function
With this function it is possible to choose
if when turning the engine (or the instru-
ment panel) off, the sound system shall
turn off immediately (00 MIN) or if it
shall stay on for other 20 minutes (20
MIN).
After selecting “IGN TIME” in the
menu using buttons
▲or▼, the display
will show the message “IGN TIME”.
To change setting use button
¯¯or
˙˙.
Two settings are available:
– “00 MIN”: sound system going off
immediately when turning the engine (or
the instrument panel) off;
– “20 MIN”: sound system staying on
for 20 minutes after turning the engine
(or the instrument panel) off.
COMPACT DISC PLAYER
(fig. 137)
Selecting the Compact player
To turn on the Compact Disc player inte-
grated in the set, when a CD is already in-
serted, turn the set on, then briefly and re-
peatedly press the “SRC” button (14) to
select the “CD” operating mode. Inserting
a CD, also with the device off, the CD play-
er is turned on.
Inserting/ejecting a CD
To insert the CD set it gently in place (3)
to activate the powered loading system,
which will position it correctly.
Press “
˚” (5), with the device on, to op-
erate the powered CD eject system.
After ejection, the source heard before play-
ing the CD will return. The CD cannot be
ejected if the device is off.
Possible error messages
If the CD inserted is illegible, the display
will show the wording “CD-ERROR” for
about 2 seconds, then the CD is ejected and
the previous source before CD was select-
ed returns.Display information
When the CD Player is working, the dis-
play shows information which has the fol-
lowing meaning:
“T05”: shows the number of the track on
the CD
“03:42”: shows the time elapsed since
the start of the track (if the corresponding
Menu function is on)
“MADONNA”: shows the name given
to the CD.
Select track (forward/backward)
Briefly press “
▲” (6) to play the next
track on the CD and “
▼” (8) to play the
previous one.
To select tracks continuously, keep the but-
ton pressed.
If playing the track started more than 3
seconds ago, pressing “
▼” (8) the track is
played again from the start. In this case if
wanting to play the previous track, press the
button twice consecutively.

GETTING TO KNOW YOUR CAR
166
Fast forward/backward
Keep “
˙˙” (7) pressed to move the track
selected forward at high speed and keep
“
¯¯” (4) pressed to move it quickly back-
ward. Fast forward/backward is interrupt-
ed once the button is released.
If the CD name display has been chosen
in the menu, this will be replaced by the
CD time display. After about 2 seconds from
the last time the button is pressed, the CD
name will be displayed again.
Pause function
To pause the CD player press the preset
button 3 (15). The display will show “CD-
PAUSE”.
To listen again, press the preset button 3
again (15).Scannning pieces on the
CD (Scan Function)
With this function it is possible to hear all
the pieces contained on a CD.
Keep the “SRC” button pressed (14) for
over one second to play the first 10 seconds
of each track on the CD. While the track is
playing the display will alternately show, for
2 seconds, the CD function chosen (CD time
or name) and the word ing “SCAN”. If the
Scan function is on, Repeat and Mix are
turned off.
The scanning sequence is the following:
– from the track played up to the last one
on the CD
– from the first one on the CD up to the
one played the moment scanning was start-
ed.The Scan function is interrupted in the fol-
lowing cases:
– turning the set off
– pressing the “SRC” button again (14)
to continue listening to the track that was
being played
– pressing “
▲” (6) or “▼” (8) (press-
ing them together the track will be skipped)
– pressing a preset button
– turning Autostore on
– turning PTY on
– changing the sound source
– pressing “AUD” (18)
– If the TA function is on and the station
selected is broadcasting a traffic bulletin
– pressing “MENU” (9).
If the Scan function is not interrupted, at
the end it will continue playing the track
played before scanning was started.
