2004 YAMAHA XVS125 Owners Manual

8-1
1
2
3
4
5
6
7
8
9

SPECIFICATIONS
EAU26333
Dimensions:
Overall length:
2320 mm (91.3 in)
Overall width:
910 mm (35.8 in)
Overall height:
1075 mm (42.3 in)
Seat height:
670 mm (26.4 in)
Wheelbase:
1530 mm (60.2 in)
Ground clearance:
150 mm (5.91 in)
Minimum turning radius:
2900 mm (114.2 in)
Weight:
With oil and fuel:
156.0 kg (344 lb)
Engine:
Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement:
V-type 2-cylinder
Displacement:
124.0 cm
3

(7.57 cu.in)
Bore
×
stroke:
41.0
×
47.0 mm (1.61
×
1.85 in)
Compression ratio:
11.00 :1
Starting system:
Electric starter
Lubrication system:
Wet sump

Engine oil:
Type:
SAE10W30 or SAE10W40 or SAE15W40
or SAE20W40 or SAE20W50
Recommended engine oil grade:
API service SE, SF, SG type or higher
Engine oil quantity:
Without oil filter element replacement:
1.40 L (1.48 US qt) (1.23 Imp.qt)
With oil filter element replacement:
1.60 L (1.69 US qt) (1.41 Imp.qt)
Air filter:
Air filter element:
Dry element
Fuel:
Recommended fuel:
Regular unleaded gasoline only
Fuel tank capacity:
11.0 L (2.91 US gal) (2.42 Imp.gal)
Fuel reserve amount:
3.4 L (0.90 US gal) (0.75 Imp.gal)
Carburetor:
Manufacturer:
MIKUNI
Type x quantity:
BDS26 x 1
Spark plug(s):
Manufacturer/model:
NGK/CR7HSA
Manufacturer/model:
DENSO/U22FSR-U
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Clutch:
Clutch type:
Wet, multiple-disc
Transmission:
Primary reduction system:
Spur gear
Primary reduction ratio:
85/25 (3.400)
Secondary reduction system:
Chain drive
Secondary reduction ratio:
59/16 (3.688)
Transmission type:
Constant mesh 5-speed
Operation:
Left foot operation
Gear ratio:
1st:
37/14 (2.643)
2nd:
32/19 (1.684)
-20 -10 0
10 20 30
40
50 ˚C
SAE 10W-30
SAE 15W-40SAE 20W-40SAE 20W-50
SAE 10W-40

SPECIFICATIONS
8-2
2
3
4
5
6
7
89

3rd:
29/23 (1.261)
4th:
26/26 (1.000)
5th:
23/27 (0.852)
Chassis:
Frame type:
Double cradle
Caster angle:
35.0 °
Trail:
135.0 mm (5.31 in)
Front tire:
Type:
With tube
Size:
80/100-18M/C 47P
Manufacturer/model:
CHENG SHIN/C-916
Manufacturer/model:
IRC/MARBELLA NF27
Rear tire:
Type:
With tube
Size:
130/90-15M/C 66P
Manufacturer/model:
CHENG SHIN/C-915
Manufacturer/model:
IRC/MARBELLA NR31

Loading:
Maximum load:
183.0 kg (404 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):
Loading condition:
0.0–90.0 kg (0–198 lb)
Front:
175 kPa (25 psi) (1.75 kgf/cm
2

)
Rear:
200 kPa (29 psi) (2.00 kgf/cm
2

)
Loading condition:
90.0–183.0 kg (198–404 lb)
Front:
175 kPa (25 psi) (1.75 kgf/cm
2

)
Rear:
200 kPa (29 psi) (2.00 kgf/cm
2

)
Front wheel:
Wheel type:
Spoke wheel
Rim size:
18x1.60
Rear wheel:
Wheel type:
Spoke wheel
Rim size:
15M/C x MT3.00
Front brake:
Type:
Single disc brake
Operation:
Right hand operation
Recommended fluid:
Dot 4
Rear brake:
Type:
Drum brake
Operation:
Right foot operation
Front suspension:
Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
140.0 mm (5.51 in)
Rear suspension:
Type:
Swingarm
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
100.0 mm (3.94 in)
Electrical system:
Ignition system:
Transistorized coil ignition (digital)
Charging system:
A.C. magneto

SPECIFICATIONS
8-3
1
2
3
4
5
6
7
8
9Battery:

Model:
GT6B-3
Voltage, capacity:
12 V, 6.0 Ah
Headlight:
Bulb type:
Halogen bulb
Bulb voltage, wattage x quantity:
Headlight:
12 V, 60.0 W/55.0 W
×
1
Tail/brake light:
12 V, 5.0 W/21.0 W
×
1
Front turn signal light:
12 V, 21.0 W
×
2
Rear turn signal light:
12 V, 21.0 W
×
2
Auxiliary light:
12 V, 4.0 W
×
1
Meter lighting:
12 V, 1.7 W
×
1
Neutral indicator light:
12 V, 1.7 W
×
1
High beam indicator light:
12 V, 1.7 W
×
1
Turn signal indicator light:
12 V, 1.7 W
×
1
Engine trouble warning light:
12 V, 1.7 W
×
1

Fuses:
Main fuse:
30.0 A Headlight fuse:
15.0 A
Signaling system fuse:
10.0 A
Ignition fuse:
10.0 A
Carburetor heater fuse:
10.0 A

CONSUMER INFORMATION
9-1 2
3
4
5
6
7
8
9

EAU26351 Identification numbers
Record the key identification number,
vehicle identification number and mod-
el label information in the spaces pro-
vided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the vehi-
cle is stolen.
KEY IDENTIFICATION NUMBER:
VEHICLE IDENTIFICATION NUM-
BER:
MODEL LABEL INFORMATION:
EAU26380 Key identification number

The key identification number is
stamped into the key tag. Record this
number in the space provided and use
it for reference when ordering a new
key.
EAU26400 Vehicle identification number

The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.
NO TE:

The vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area. 1. K ey identification n umber
1

1. V ehicle identification n umber
1

CONSUMER INFORMATION
9-2
1
2
3
4
5
6
7
8
9

EAU26460
Model label
The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This in-
formation will be needed when ordering
spare parts from a Yamaha dealer.
1. Model label
1

5JX-28199-E3
XVS125
PRINTED ON RECYCLED PAPER
YAMAHA MOTOR CO., LTD.
PRINTED IN JAPAN
2003.6–0.1×1 !
(E)
OWNER’S MANUAL
