2004 SUBARU LEGACY Owners Manual

5-1
5
Audio
Antenna system ............................................ 5-2 Printed antenna ................................................. 5-2
Pillar mounted antenna .................................... 5-3
Installation of accessories ........................... 5-3
Audio set ........................................................ 5-4 Type A and type B audio set ............................ 5-4
Type C audio set ............................................... 5-4
McIntosh audio set ........................................... 5-5
In-dash 6 CD auto changer (Optional audio unit – if equipped) .......................................... 5-5
Type A and B audio set (if equipped) .......... 5-6 Radio operation ................................................ 5-6
Compact disc player operation ....................... 5-11
CD changer control (If optional in dash CD changer is connected) ................................... 5-14
Type C audio set (if equipped) ..................... 5-17 Radio operation ................................................ 5-17
Built-in CD changer operation ......................... 5-23
OnStar® system operation (models with OnStar® system) ............................................ 5-27
McIntosh audio set (if equipped) ................. 5-27 Radio operation ................................................ 5-28
Built-in CD changer operation ......................... 5-34
OnStar® system operation (models with OnStar® system) ............................................ 5-38
In-dash 6 CD auto changer (if equipped) .... 5-39
Precautions to observe when handling a compact disc (CD) .................................. 5-42

5-2
Audio
AudioAntenna system „
Printed antenna
Do not use sharp instruments or window clean-
er containing abrasives to clean the inner sur-
face of the window on which the antenna is
printed. Doing so may damage the antenna
printed on the window.
T Sedan The antenna is printed on the inside of the rear window glass. T
Wagon
The antenna is printed on the inside of the left side
rear quarter window glass.
UBF013IA
UB5038AA

5-3
Audio
– CONTINUED –
„Pillar mounted antenna
Pull the antenna out to extend it to its full length. T FM reception
Although FM is normally static free, reception can be
affected by the surrounding area, atmospheric condi-
tions, station strength and transmitter distance. Build-
ings or other obstructions may cause momentary stat-
ic, flutter or station interference. If reception continues
to be unsatisfactory, switch to a stronger station.Installation of accessories
Always consult your SUBARU dealer before installing
a citizen band radio or other transmitting device in
your vehicle. Such devices may cause the electronic
control system to malfunction if they are incorrectly in-
stalled or if they are not suited for the vehicle.
OM-U2376

5-4
Audio
Audio set
Your SUBARU may be equipped with one of the fol-
lowing audio sets. See the pages indicated in this sec-
tion for operating details. „
Type A and type B audio set
y Radio operation: refer to page 5-6
y CD (compact disc) player operation: refer to page 5-
11 y CD changer control: refer to page 5-14 „
Type C audio set
y Radio operation: refer to page 5-17
y Built-in CD changer operation: refer to page 5-23
UB5052AA
UB5064AA

5-5
Audio
– CONTINUED –
„McIntosh audio set
y Radio operation: refer to page 5-28
y B uilt-in CD cha nger op era tion: re fe r to p a ge 5-34 „
In-dash 6 CD auto changer (Optional
audio unit – if equipped)
y Inserting and removing a disc or all discs: refer
t o pa ge 5-39
UB5063AA
HS5011AA

5-6
Audio
Type A and B audio set (if equipped)
Type A: Without weather band
Type B: With weather band
The audio set will operate only when the ignition switch is in the “ACC” or
“ON” position. „
Radio operation
(1)
(2)
(3)
(4)
(5)
(6)
UB5052BB
(1) Power switch/Volume, Tone,
Balance, Fader control dial
(2) BAND button
(3) Tuning buttons
(4) Preset buttons
(5) AUDIO button
(6) SCAN button

5-7
Audio
– CONTINUED –
TPower switch and volume/bass/treble/fader/
balance control
V Power switch and volume control (PWR/VOL)
The dial (1) is used for both power (ON/OFF) and vol-
ume control. The radio is turned ON and OFF by push-
ing the dial and the volume is controlled by turning the
dial. V Tone and balance control (AUDIO)
The volume control dial (1) normally functions as a vol-
ume control. This dial becomes a control for Bass,
Treble, Fader or Balance when you select the appro-
priate tone and balance control mode.
Choose desired volume level for each mode by turning
the volume control dial. The control function returns to
volume control mode after about 5 seconds.
To change control modes: Each brief press of the
“AUDIO” button (5) changes control modes in the fol-
lowing sequence starting from volume control mode.
(When the radio is first turned on, the control mode is
in the volume control.) The “AUDIO” button (5) is used for selecting the fol-
lowing control modes:
Volume
(VOL)
Bass(BAS)Treble(TRE)Balance(BAL)
Fader
(FAD)
