IGNITION
IG(H4SO)
Page
1. General Description ....................................................................................2
2. Spark Plug...................................................................................................5
3. Ignition Coil & Ignitor Assembly ..................................................................8
4. Spark Plug Cord ..........................................................................................9

IG(H4SO)-2
IGNITION
General Description
1. General Description
A: SPECIFICATION
Item Designation
Ignition coil/igni-
tor assemblyModel FH0137
Manufacturer DIAMOND
Primary coil resistance 0.73 Ω±10%
Secondary coil resistance 12.8 kΩ±15%
Insulation resistance between primary terminal and
caseMore than 100 MΩ
Spark plugType and manufacturerCHAMPION: RC10YC4
NGK: BKR5E-11 (Alternate)
Thread size mm 14, P = 1.25
Spark plug gap mm (in) 1.0 — 1.1 (0.039 — 0.043)

IG(H4SO)-3
IGNITION
General Description
B: COMPONENT
(1) Spark plug (4) Spark plug cord (#2, #4)Tightening torque: N⋅m (kgf-m, ft-lb)
(2) Spark plug cord (#1, #3)T1: 21 (2.1, 15.2)
(3) Ignition coil & ignitor ASSYT2: 6.4 (0.65, 4.7)
IG-00042

IG(H4SO)-4
IGNITION
General Description
C: CAUTION
 Wear working clothing, including a cap, protec-
tive goggles, and protective shoes during opera-
tion.
 Remove contamination including dirt and corro-
sion before removal, installation or disassembly.
 Keep the disassembled parts in order and pro-
tect them from dust or dirt.
 Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly, and replacement.
 Be careful not to burn yourself, because each
part on the vehicle is hot after running.
 Be sure to tighten fasteners including bolts and
nuts to the specified torque.
 Place shop jacks or rigid racks at the specified
points.
 Before disconnecting electrical connectors of
sensors or units, be sure to disconnect the ground
cable from battery.

IG(H4SO)-5
IGNITION
Spark Plug
2. Spark Plug
A: REMOVAL
CAUTION:
All spark plugs installed on an engine, must be
of the same heat range.
1. RH SIDE
1) Disconnect the ground cable from battery.
2) Remove the air cleaner case. 8, REMOVAL, Resonator Chamber.>
3) Remove the spark plug cords by pulling boot, not
the cord itself.
4) Remove the spark plugs with spark plug sock-
ets.
2. LH SIDE
1) Disconnect the ground cable from battery.
2) Disconnect the washer motor connector.
3) Disconnect the rear window glass washer hose
from washer motor, then plug connection with a
suitable cap.
4) Remove the two bolts which hold washer tank,
then take the tank away from the working area.
5) Remove the spark plugs cord by pulling boot, not
the cord itself.
Spark plug
CHAMPION: RC10YC4
NGK: BKR5E-11 (Alternate)
FU-00009
IG-00017
IG-00018
FU-00009
IG-00019
IG-00020
IG-00021

IG(H4SO)-6
IGNITION
Spark Plug
6) Remove the spark plugs with spark plug sock-
ets.
B: INSTALLATION
1. RH SIDE
Install in the reverse order of removal.
Tightening torque (Spark plug):
21 N
⋅m (2.1 kgf-m, 15.2 ft-lb)
NOTE:
The above torque should be only applied to new
spark plugs without oil on their threads.
In case their threads are lubricated, the torque
should be reduced by approx. 1/3 of the specified
torque in order to avoid over-stressing.
2. LH SIDE
Install in the reverse order of removal.
Tightening torque (Spark plug):
21 N
⋅m (2.1 kgf-m, 15.2 ft-lb)
NOTE:
The above torque should be only applied to new
spark plugs without oil on their threads.
In case their threads are lubricated, the torque
should be reduced by approx. 1/3 of the specified
torque in order to avoid over-stressing.
C: INSPECTION
Check the electrodes and inner and ceramic insu-
lator of plugs, noting the type of deposits and the
degree of electrode erosion.
1) Normal:
Brown to grayish-tan deposits and slight electrode
wear indicates correct spark plug heat range.
2) Carbon fouled:
Dry fluffy carbon deposits on insulator and elec-
trode are mostly caused by slow speed driving in
city, weak ignition, too rich fuel mixture, dirty air
cleaner, etc.
It is advisable to replace with plugs having hotter
heat range.
IG-00022
(A) Electrode gap
(B) Carbon accumulation or wear
(C) Cracks
(D) Damage
(E) Damaged gasket
IG-00023
(A)
(B)
(C)
(D)
(E)
IG-00024
IG-00025
