SE-13
SEAT
Rear Seat
3. Rear Seat
A: REMOVAL
1) Remove the bolts, and then detach the rear seat
cushion.
2) Remove the headrest.
3) Remove the luggage floor mat.
4) Fold down the rear seat backrest.
5) Turn over the mat to remove bolts.
6) Remove the rear seat backrest.
B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
Refer to COMPONENT in General Descrip-
tion.
NENT, General Description.>
C: DISASSEMBLY
1) Remove the rear seat.
AL, Rear Seat.>
2) Remove the hog rings (A) from around the seat
backrest.
3) Remove the hog rings (A) on front side of cush-
ion pad, and then remove the cover.
4) Remove the hog rings (A) from around the seat
cushion.
5) Remove the hog rings (A), and then remove the
cover.
SE-00023
SE-00153
SE-00025
: (A)SE-00154
: (A)
SE-00155
: (A)
SE-00156
: (A)
SE-00157
