4AT(H4DOTC)-118
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure without Diagnostic Trouble Code (DTC)
2 CHECK POWER SWITCH OPERATION.When the POWER switch is
turned to ON, does LED light
up?Go to step CHECK
HOLD SWITCH.
120, CHECK
HOLD SWITCH,
Diagnostic Proce-
dure without Diag-
nostic Trouble
Code (DTC).>Go to step 3.
3 CHECK POWER INDICATOR LIGHT.
1) Turn the ignition switch to OFF.
2) Remove the combination meter.
3) Remove the POWER indicator light bulb
from combination meter.Is the POWER indicator light
bulb OK?Go to step 4.Replace the
POWER indicator
light bulb.
tion Meter Assem-
bly.>
4 CHECK POWER SWITCH GROUND CIR-
CUIT.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from POWER
switch.
3) Measure the resistance of harness connector
between POWER switch and chassis ground.
Connector & terminal
LHD model
(R92) No. 4 — Chassis ground:
RHD model
(B133) No. 4 — Chassis ground:Is the resistance less than 1
Ω?Go to step 5.Repair the open
circuit in harness
between POWER
switch and chas-
sis ground.
5 CHECK POWER SWITCH.
1) Turn the POWER switch to ON.
2) Measure the resistance between terminals
of POWER switch.
Te r m i n a l s
No. 5 — No. 4:Is the resistance less than 1
Ω?Go to step 6.Replace the
POWER switch.
6 CHECK POWER SWITCH.
1) Turn the POWER switch to OFF.
2) Measure the resistance between terminals
of POWER switch.
Te r m i n a l s
No. 5 — No. 4:Is the resistance more than1
MΩ?Go to step 7.Replace the
POWER switch.
7 CHECK HARNESS CONNECTOR BETWEEN
TCM AND POWER SWITCH.
Measure the resistance of harness connector
between TCM and POWER switch.
Connector & terminal
(B54) No. 8 — (B133) No. 5:Is the resistance less than 1
Ω?Go to step 8.Repair the open
circuit in harness
between TCM and
POWER switch
connector.
8 CHECK HARNESS CONNECTOR BETWEEN
TCM AND POWER SWITCH.
Measure the resistance of harness connector
between TCM connector and chassis ground.
Connector & terminal
(B54) No. 8 — Chassis ground:Is the resistance more than 1
MΩ?Go to step 9.Repair the short
circuit in harness
between TCM and
POWER switch
connector.
9 CHECK INPUT SIGNAL FOR TCM.
1) Connect the connectors to TCM and
POWER switch.
2) Turn the ignition switch to ON (engine OFF).
3) Measure the signal voltage for TCM while
turning POWER switch to OFF.
Connector & terminal
(B54) No. 8 (+) — Chassis ground (–):Is the voltage more than 10 V? Go to step 10.Replace the TCM.
trol Module
(TCM).> Step Check Yes No
4AT(H4DOTC)-125
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure without Diagnostic Trouble Code (DTC)
3 CHECK KICK-DOWN SWITCH GROUND
LINE.
1) Disconnect the connector from kick-down
switch.
2) Measure the resistance of harness connector
between kick-down switch and chassis ground.
Connector & terminal
(B129) No. 1 — Chassis ground:Is the resistance less than 1
Ω?Go to step 4.Repair the open cir-
cuit in harness
between kick-down
switch and TCM.
4 CHECK KICK-DOWN SWITCH.
Measure the resistance for kick-down switch
when depressing the accelerator pedal.
Te r m i n a l s
No. 1 — No. 2:Is the resistance less than 1
Ω?Go to step 5.Replace the kick-
down switch.
Accelerator
Pedal.>
5 CHECK KICK-DOWN SWITCH.
Measure the resistance for kick-down switch
when pressing the accelerator pedal.
Te r m i n a l s
No. 1 — No. 2:Is the resistance more than 1
MΩ?Go to step 6.Replace the kick-
down switch.
6 CHECK HARNESS CONNECTOR BETWEEN
TCM AND KICK-DOWN SWITCH.
1) Turn the ignition switch to OFF.
2) Disconnect the connectors from kick-down
switch.
3) Measure the resistance of harness connec-
tor between TCM and kick-down switch.
Connector & terminal
(B54) No. 11 — (B129) No. 2:Is the resistance less than 1
Ω?Go to step 7.Repair the open
circuit in harness
between TCM and
kick-down switch.
7 CHECK HARNESS CONNECTOR BETWEEN
TCM AND KICK-DOWN SWITCH.
Measure the resistance of harness connector
between TCM connector and chassis ground.
Connector & terminal
(B54) No. 11 — Chassis ground:Is the resistance more than 1
MΩ?Go to step 8.Repair the short
circuit in harness
between TCM and
chassis ground.
8 CHECK INPUT SIGNAL FOR TCM.
1) Turn the ignition switch to OFF.
2) Connect the connector to kick-down switch.
3) Turn the ignition switch to ON (engine OFF).
4) Measure the signal voltage for TCM when
not depressing the accelerator pedal.
Connector & terminal
(B55) No. 11 (+) — Chassis ground (
−):Is the voltage less than 1 V? Go to step 9.Go to step 10.
9 CHECK INPUT SIGNAL FOR TCM.
Measure the signal voltage for TCM when press-
ing the accelerator pedal.
Connector & terminal
(B55) No. 11 (+) — Chassis ground (
−):Is the voltage more than 6.5 V? A temporary poor
contact of the con-
nector and har-
ness may be the
cause. Repair the
harness and con-
nector in TCM.Go to step 10.
10 CHECK POOR CONTACT.Is there poor contact? Repair the poor
contact.Replace the TCM.
trol Module
(TCM).> Step Check Yes No
4AT(H4DOTC)-126
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Symptom Related Diagnostic
15.Symptom Related Diagnostic
A: INSPECTION
Symptom Problem parts
Starter does not rotate when select lever is in “P” or “N” range,
starter rotates when select lever is in “R”, “D”, “3” or “2” range. Inhibitor switch
Select cable
Select lever
Starter motor and harness
Abnormal noise when select lever is in “P” or “N” range. Strainer
Transfer duty solenoid
Oil pump
Drive plate
ATF level too high or too low
Hissing noise occurs during standing start. Strainer
ATF level too high or too low
Noise occurs while driving in “D1”. Final gear
Planetary gear
Reduction gear
Differential gear oil level too high or too low Noise occurs while driving in “D2”.
Noise occurs while driving in “D3”. Final gear
Low & reverse brake
Reduction gear
Differential gear oil level too high or too low
Noise occurs while driving in “D4”. Final gear
Low & reverse brake
Planetary gear
Reduction gear
Differential gear oil level too high or too low
Engine stalls while shifting from “1” range to another. Control valve
Lock-up damper
Engine performance
Input shaft
Vehicle moves when select lever is in “N” range. Select cable
Inhibitor switch
TCM
Low clutch
Shock occurs when select lever is shifted from “N” to “D” range. Accelerator pedal position sensor
ATF temperature sensor
Line pressure linear solenoid
Low clutch duty solenoid
Low clutch
TCM
Harness
Control valve
ATF deterioration
Excessive time lag occurs when select lever is shifted from “N”
to “D” range. Control valve
Low clutch
Line pressure duty solenoid
Seal ring
Front gasket of transmission case
Shock occurs when select lever is shifted from “N” to “R” range. Accelerator pedal position sensor
ATF temperature sensor
Line pressure linear solenoid
TCM
Harness
Control valve
ATF deterioration
4AT(H4DOTC)-127
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Symptom Related Diagnostic
Excessive time lag occurs when select lever is shifted from “N”
to “R” range. Control valve
Low & reverse clutch
Reverse clutch
Line pressure linear solenoid
Seal ring
Front gasket of transmission case
Vehicle does not start in any shift range (engine stalls). Parking brake mechanism
Planetary gear
Vehicle does not start in any shift range (engine revving up). Strainer
Line pressure linear solenoid
Control valve
Drive pinion
Hypoid gear
Axle shaft
Differential gear
Oil pump
Input shaft
Output shaft
Planetary gear
Drive plate
ATF level too low
Front gasket of transmission case
Vehicle does not start in “R” range only (engine revving up). Select cable
Select lever
Line pressure linear solenoid
Control valve
Low & reverse clutch
Reverse clutch
Vehicle does not start in “R” range only (engine stalls). Low clutch
2-4 brake
Planetary gear
Parking brake mechanism
Vehicle does not start in “D”, “3” range only (engine revving up). Low clutch
One-way clutch
Vehicle does not start in “D”, “3” or “2” range only (engine rev-
ving up).Low clutch
Vehicle does not start in “D”, “3” or “2” range only (engine
stalls).Reverse clutch
Vehicle starts in “R” range only (engine revving up). Control valve
Acceleration during standing starts is poor (high stall rpm). Control valve
Low clutch
Reverse clutch
ATF level too low
ATF deterioration
Front gasket of transmission case
Differential gear oil level too high or too low
Acceleration during standing starts is poor (low stall rpm). Oil pump
Torque converter one-way clutch
Engine performance
Acceleration is poor when select lever is in “D”, “3” or “2” range
(normal stall rpm).TCM
Control valve
High clutch
2-4 brake
Planetary gear
Acceleration is poor when select lever is in “R” (normal stall
rpm). Control valve
High clutch
2-4 brake
Planetary gear Symptom Problem parts
4AT(H4DOTC)-128
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Symptom Related Diagnostic
No shift occurs from 1st to 2nd gear.TCM
Rear vehicle speed sensor
Front vehicle speed sensor
Throttle position sensor
Control valve
2-4 brake
No shift occurs from 2nd to 3rd gear.TCM
Control valve
High clutch
No shift occurs from 3rd to 4th gear.TCM
ATF temperature sensor
Control valve
2-4 brake
Engine brake is not effected when select lever is in “3” range. Inhibitor switch
TCM
Throttle position sensor
Control valve
Engine brake is not effected when select lever is in “3” or “2”
range.Control valve
Engine brake is not effected when select lever is in “1” range. Control valve
Low & reverse brake
Shift characteristics are erroneous. Inhibitor switch
TCM
Front vehicle speed sensor
Rear vehicle speed sensor
Throttle position sensor
Control valve
Ground earth
No lock-up occurs.TCM
Torque converter turbine speed sensor
Throttle position sensor
ATF temperature sensor
Control valve
Lock-up facing
Engine speed signal
Parking brake is not effected. Select cable
Select lever
Parking mechanism Shift lever cannot be moved or is hard to move from “P” range.
ATF spurts out. ATF level too high
Differential oil spurts out. Differential gear oil too high
Differential oil level changes excessively. Seal pipe
Double oil seal
Odor is produced from ATF supply pipe.High clutch
2-4 brake
Low & reverse clutch
Reverse clutch
Lock-up facing
ATF deterioration
Shock occurs from 1st to 2nd gear.TCM
Torque converter turbine speed sensor
Accelerator pedal position sensor
2-4 brake duty solenoid
ATF temperature sensor
Line pressure linear solenoid
Control valve
2-4 brake
ATF deterioration
Engine performance
Low & reverse duty solenoid Symptom Problem parts
4AT(H4DOTC)-129
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Symptom Related Diagnostic
Slippage occurs from 1st to 2nd gear.TCM
Accelerator pedal position sensor
2-4 brake duty solenoid
ATF temperature sensor
Line pressure linear solenoid
Control valve
2-4 brake
Shock occurs from 2nd to 3rd gear.TCM
Torque converter turbine speed sensor
Accelerator pedal position sensor
2-4 brake duty solenoid
ATF temperature sensor
Line pressure linear solenoid
Low & reverse duty solenoid
Control valve
High clutch
2-4 brake
ATF deterioration
Engine performance
High clutch duty solenoid
Slippage occurs from 2nd to 3rd gear.TCM
Accelerator pedal position sensor
2-4 brake duty solenoid
ATF temperature sensor
Line pressure linear solenoid
Control valve
High clutch
2-4 brake
Low & reverse duty solenoid
Shock occurs from 3rd to 4th gear.TCM
Torque converter turbine speed sensor
Accelerator pedal position sensor
2-4 brake duty solenoid
ATF temperature sensor
Line pressure linear solenoid
Control valve
Low clutch duty solenoid
2-4 brake
ATF deterioration
Engine performance
Slippage occurs from 3rd to 4th gear.TCM
Accelerator pedal position sensor
2-4 brake duty solenoid
ATF temperature sensor
Line pressure linear solenoid
Control valve
2-4 brake
Shock occurs when select lever is shifted from “3” to “2” range.TCM
Torque converter turbine speed sensor
Accelerator pedal position sensor
ATF temperature sensor
Line pressure linear solenoid
Control valve
2-4 brake duty solenoid
2-4 brake
ATF deterioration
High clutch duty solenoid Symptom Problem parts
4AT(H4DOTC)-130
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Symptom Related Diagnostic
Shock occurs when select lever is shifted from “D” to “1” range.TCM
Torque converter turbine speed sensor
Accelerator pedal position sensor
ATF temperature sensor
Line pressure linear solenoid
Control valve
ATF deterioration
Low & reverse brake duty solenoid
Low & reverse clutch solenoid
Shock occurs when select lever is shifted from “2” to “1” range.TCM
Torque converter turbine speed sensor
Accelerator pedal position sensor
ATF temperature sensor
Line pressure linear solenoid
Control valve
Low & reverse clutch
ATF deterioration
2-4 brake duty solenoid
Low & reverse brake duty solenoid
Shock occurs when accelerator pedal is released at medium
speeds.TCM
Accelerator pedal position sensor
ATF temperature sensor
Line pressure linear solenoid
Control valve
Lock-up damper
Engine performance
Vibration occurs during straight-forward operation.TCM
Lock-up duty solenoid
Lock-up facing
Lock-up damper
HOLD switch
Vibration occurs during turns (tight corner “braking” phenome-
non).TCM
Front vehicle speed sensor
Rear vehicle speed sensor
Accelerator pedal position sensor
ATF temperature sensor
Transfer clutch
Transfer valve
Transfer duty solenoid
ATF deterioration
Harness
HOLD switch
Front wheel slippage occurs during standing starts.TCM
Front vehicle speed sensor
Accelerator pedal position sensor
ATF temperature sensor
Control valve
Transfer clutch
Transfer valve
Transfer pipe
Transfer duty solenoid
Vehicle is not set in FWD mode.TCM
Transfer clutch
Transfer valve
Transfer duty solenoid
Select lever is hard to move. Select cable
Select lever
Detente spring
Manual plate Symptom Problem parts
5MT-26
MANUAL TRANSMISSION AND DIFFERENTIAL
General Description
498255400 PLATE Used for measuring backlash.
498077400 SYNCHRONIZER
CONE REMOVER Used for removing synchronizer cone of main
shaft.
Used for removing 5th driven gear of drive pin-
ion shaft.
41099AA010 ENGINE SUPPORT
BRACKETUsed for supporting engine.
41099AA020 ENGINE SUPPORT Used for supporting engine. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-498255400
ST-498077400
ST41099AA010
ST41099AA020
