2004 PEUGEOT 407 DAG Owners Manual

20 -
1 1 - 1 0 -2004
21
-
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
Keep your card in a safe place,
never inside the vehicle.

The conidential card contains the
identiication code necessary for any
work carried out by a PEUGEOT
dealer on the electronic immobiliser
system. This code is hidden by a
ilm, which should be removed only
if necessary.
CHILD LOCK ON THE DOORS
Manual mode
This prevents each of the rear doors
from being opened from inside.
F Turn the switch on the edge of the
door a quarter of a turn using the
ignition key.
A message* appears on the display,
if the two rear doors are locked.
Electric mode
This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-
function display.
Warning: this system is independent
of the central locking control.
Always remove the ignition key
when leaving the vehicle, even for
a short time.
* During the year. Access and starting
11-10-2004

22 -23
-
1 1 - 1 0 -
2004
Make a careful note of the
number on each key. The key
number is coded on the label
attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock your ve-
hicle, without you being aware of it.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle.
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more dificult in an emergency.
As a safety precaution (with children
on board), remove the ignition key
when you leave the vehicle, even for
a short time.
Do not repeatedly press the button
of your remote control out of range
of your vehicle. You run the risk of
stopping it from working and the
remote control would have to be re-
programmed. When purchasing a second-hand
vehicle:
- ensure that you are given the coni-
dential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that
the keys in your possession are
the only ones which can start the
vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
Access and starting
11-10-2004

20 -21
-
1 1 - 1 0 -
2004
CHANGING THE REMOTE
CONTROL BATTERY
The information is given by an audi-
ble signal accompanied by a mes-
sage on the multifunction display or
by the
service indicator light.
REPROGRAMMING THE
REMOTE CONTROL
F Switch off the ignition.
F Switch the ignition on again.
F Press the remote control locking
button immediately for a few sec-
onds.
F Switch off the ignition and remove
the remote control key from the
ignition lock. The remote control
is now working again.
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system as
soon as the ignition has been switched
off and therefore prevents starting of the
vehicle by anyone who does not have
the key.
The ignition key has an electronic chip
which has a special code. When the ig-
nition is switched on, the code must be
recognised for starting to be possible.
If the system does not function
correctly, the following indicator light
comes on:
To change the battery, unclip the
casing using a coin at the notch
(CR 1620/3 volt battery).
If the remote control does not work
after the battery has been changed,
re-program the remote control. Service indicator
light
Electronic engine
immobiliser
indicator light
or
It is accompanied by a message on
the multi-function display.
Your vehicle will not start.
Contact a PEUGEOT dealer.
Access and starting
11-10-2004

22 -
11-10-2004
23
-
11-10-2004
Make a careful note of the
number on each key. The key
number is coded on the label
attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock your ve-
hicle, without you being aware of it.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle.
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more dificult in an emergency.
As a safety precaution (with children
on board), remove the ignition key
when you leave the vehicle, even for
a short time.
Do not repeatedly press the button
of your remote control out of range
of your vehicle. You run the risk of
stopping it from working and the
remote control would have to be re-
programmed. When purchasing a second-hand
vehicle:
- ensure that you are given the coni-
dential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that
the keys in your possession are
the only ones which can start the
vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
Access and starting

20 -
1 1 - 1 0 -2004
21
-
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
Keep your card in a safe place,
never inside the vehicle.

The conidential card contains the
identiication code necessary for any
work carried out by a PEUGEOT
dealer on the electronic immobiliser
system. This code is hidden by a
ilm, which should be removed only
if necessary.
CHILD LOCK ON THE DOORS
Manual mode
This prevents each of the rear doors
from being opened from inside.
F Turn the switch on the edge of the
door a quarter of a turn using the
ignition key.
A message* appears on the display,
if the two rear doors are locked.
Electric mode
This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-
function display.
Warning: this system is independent
of the central locking control.
Always remove the ignition key
when leaving the vehicle, even for
a short time.
* During the year. Access and starting
11-10-2004

22 -23
-
1 1 - 1 0 -
2004
Make a careful note of the
number on each key. The key
number is coded on the label
attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock your ve-
hicle, without you being aware of it.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle.
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more dificult in an emergency.
As a safety precaution (with children
on board), remove the ignition key
when you leave the vehicle, even for
a short time.
Do not repeatedly press the button
of your remote control out of range
of your vehicle. You run the risk of
stopping it from working and the
remote control would have to be re-
programmed. When purchasing a second-hand
vehicle:
- ensure that you are given the coni-
dential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that
the keys in your possession are
the only ones which can start the
vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
Access and starting
11-10-2004

20 -
1 1 - 1 0 -2004
21
-
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
Keep your card in a safe place,
never inside the vehicle.

The conidential card contains the
identiication code necessary for any
work carried out by a PEUGEOT
dealer on the electronic immobiliser
system. This code is hidden by a
ilm, which should be removed only
if necessary.
CHILD LOCK ON THE DOORS
Manual mode
This prevents each of the rear doors
from being opened from inside.
F Turn the switch on the edge of the
door a quarter of a turn using the
ignition key.
A message* appears on the display,
if the two rear doors are locked.
Electric mode
This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-
function display.
Warning: this system is independent
of the central locking control.
Always remove the ignition key
when leaving the vehicle, even for
a short time.
* During the year. Access and starting
11-10-2004

22 -
1 1 - 1 0 -2004
23
-
FILLING WITH FUELThe ignition must be switched off and
the vehicle must be unlocked when
illing with fuel.
F
Open the fuel iller lap.
F Turn the cap to the left.
F Remove the cap and hang the
end on the hook located on the
inside of the lap.
A label afixed to the inside of the fuel
iller lap indicates which type of fuel
to use.
When you ill your tank, do not con-
tinue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
The capacity of the tank is approxi-
mately 67 litres.
F After illing the tank, screw on the
cap and close the fuel iller lap.
When this warning light comes
on in certain driving conditions
and depending on the engine,
the distance which can be
travelled with the fuel remaining may
be less than 30 miles (50 kilometres).
Note: should you run out of fuel, you
must add at least 6 litres.
Operating check
A fuel gauge fault is indicated by the
fuel level indicator needle returning
to zero.
Contact a PEUGEOT dealer.
Fuel warning
Access and starting
