2004 PEUGEOT 407 DAG Owners Manual

90 -
11-10-2004
91
-
11-10-2004
Telephone function screens
Not in use
The screen indicates the presence
of voice messages or text messages
(SMS) not listened to, the cumulatve
time in use since the last zero reset
and the status of your telephone.
In use
The screen indicates the time
elapsed since the start of the con-
versation, as well as the number* or
name of the person to whom you are
speaking (if recorded in the directory)
and the status of your telephone.
* If this option and service are avail-
able. Press the button
to display the con-
textual menu of the telephone.
Pressing the end of the steering col-
umn control for more than 2 seconds
calls up a contextual menu limited
to the "Directory", "List of calls" and
"Voice mail" functions.
Making a call
Select the function
"Enter number" then
enter the number of
the person you wish to
speak to using the al-
phanumeric keypad.
Press the "Pick up" button to make
the call.
Entering a number
Making a call from a directory
Select the "Directory" function to
access all the iles containing a tele-
phone number or the "List of calls"

function to access the list of the
last twenty incoming (if the number
display option is active) or outgoing
calls.
There are two directories, the RT3
GPS audio/telephone directory and
the SIM card directory. To consult the
SIM directory, insert your SIM card
and enter your PIN code. When a ringing sounds
to let you know that a
call is waiting, you can
choose either to accept
it by pressing the "Pick
up" button or the end of the steer-
ing wheel control or not to accept it
by pressing the "Hang up" button or
by selecting and validating the "NO"
button on the "Answer?" screen.
Receiving a call
If you accept the call, to
end your communica-
tion, press the "Hang up"
button.
If you do not accept the
call, it is transferred to
your voice mail or to a call diversion
number.
You can activate or deactivate this
transfer by pressing the "Hang up"
button for more than two seconds.
407 saloon and 407 SW comfort

92 -
11-10-2004
93
-
11-10-2004
Text messages (SMS)
Accessing text messages
When the buzzer sounds (if the SMS
text messages buzzer option is ac-
tive) and a superimposed screen
announces "Do you wish to read the
new text message (SMS)?", you can
choose to read the text message
received by selecting and validating
"YES" or postpone reading it by se-
lecting and validating "NO", by press-
ing the "ESC" button or by waiting
until the announcement disappears.
Note:
the old text messages stored
and the new text messages, the read-
ing of which you wish to postpone,
can be consulted. Press the "MENU"
button then validate the telematic
icon, select "Text messages (SMS)"
and validate the function "Reading of
text messages received" by pressing
the navigator. Then scroll through the
list by turning the knob and press the
knob to select the text message to
be read (if the voice synthesiser is
active). Sending a text message
Before typing your irst text mes-
sage, check that your text messages
(SMS) centre number is stored cor-
rectly in the sub-menu "Server cen-
tre N°". If it is not, any text messages
typed before this number is entered
will not be sent.
In the menu "Text messages (SMS)"
validate the function "Typing of a text
message". Type your text message
using the alphanumeric keypad and
validate it using the "OK" button to
store it or validate the "Send" button
to send it. Validation of the "Send"
button enables you to enter the
number of your recipient or select it
from the directory or from the list of
calls and send the message.
"Telephone options" menu
Select the "Telephone options"
func-
tion from the "Telephone functions"
menu to access the functions:
• "Conigure the calls" which permits activation and deactivation of the
"show my number" and "automatic
answering after X rings" functions,
• "Ringing options" which permits adjustment of the ringing volume
for voice calls, activation of the text
messages (SMS) receipt buzzer
and selection of a ring tone from
the ive offered,
• "Diversion number/voice mail" which permits recording of the call
diversion number chosen by the
customer, otherwise the call will be
transferred to the voice mail.
407 saloon and 407 SW comfort
"Duration of calls" menu
Select the "Duration of calls" function
from the "Telephone functions" menu
to consult the duration counters for
the calls made. The part counter to-
tals the duration of the calls since the
last zero reset carried out using the
"Zero reset" button.

92 -
11-10-2004
93
-
11-10-2004* If option and service available.
If you have signed the speciic
PEUGEOT contract, your call will be
located and you will be put in contact
with a PEUGEOT emergency repre-
sentative.
For further details, refer to the gen-
eral conditions of your contract.
"PEUGEOT Assistance"/
Emergency call
A green diode lashes on the RT3
GPS audio/telephone panel, when
the emergency call procedure or a
call to "PEUGEOT Assistance" be-
gins, then lights continuously when
the call is taken by the services con-
cerned.
Services*
Press the button to
display the "Services"
menu and select one
of the following serv-
ices:
• "Customer Contact Centre" con-
tacts the PEUGEOT Customer
Contact Centre directly and permits
access to the services offered (this
call is suspended if an emergency
or assistance call has been made).
• "PEUGEOT Assistance" enables
you to contact the call centre which
controls the PEUGEOT assistance
service directly, make an assist-
ance request and receive rapid
assistance (you have 6 seconds
within which to cancel the call
when it is made) . During the as-
sistance call phase it is not pos-
sible to make any other calls with
the exception of emergency calls.
Signing the speciic PEUGEOT
contract means that you will be
located.
• "Operator services" gives access to
the list of services speciic to your
operator (e.g.: customer service,
consumption monitoring, news,
stock market, weather, travel,
games, etc) if access is available.
* If option and service available.
Emergency call*
In an emergency,
press and hold the
"SOS" button until a
signal is heard and
a call validation/de-
letion screen is dis-
played (delay of 6 seconds) or enter
112 directly.
Make an emergency call when you
are involved in a situation which leads
you to fear serious consequences
(injuries, ...) for those exposed to
it (if you witness or are involved in
an accident resulting in injuries, an
attack, ...).
Before making a call of this kind,
the audio/telephone must detect a
cellular network.
If you have not signed the speciic
PEUGEOT contract, the parameters
of the "SOS" button are set so that a
call is made to 112 - unique number
made available by the worldwide
GSM network, reserved for emer-
gency calls.
No security mode is required and,
depending on the network, you do
not need to insert your SIM card or
enter your PIN.
407 saloon and 407 SW comfort

94 -
11-10-2004
95
-
11-10-2004
Main menu
From the general menu, select the
"Directory"
application to access its
main menu and select one of the fol-
lowing functions:
• "Call", to call a number stored in a ile,
• "Activate guidance to", to initiate guidance to a location stored in a
ile,
• "Management of directory iles", to add, delete, modify and consult di-
rectory iles or exchange them with
the SIM card,
• "Directory coniguration", to select the working directory and deine
the default directory when the sys-
tem is switched on. Creation/Modiication of a ile
To create a ile, from the "Directory"
menu, select the "Management of di-
rectory iles" function, then "Add".
In the ile, select the section to be
illed in, conirm and then enter the
information.
To modify an existing ile, select it by
means of the "Consult or modify the
ile" function of the "Management of
directory iles" menu, then make the
modiications.
When entering the address, the navi-
gation CD ROM must be present to
obtain guidance to this destination.
Description of a directory ile
When a description is associated
with a directory ile, you can record
the description vocally to use it later
for direct access by means of voice
commands (e.g.: "Call" "[Name of
voice description]" or "Guide to"
"[Name of voice description]").
Select "Consult or modify the ile"
from the "Management of directory
iles" menu to access the description
entering and recording screen.
Validate the record button and follow
the instructions.
The "Directory" appli-
cation gives access to
400 iles divided into 4
independent sub-direc-
tories ("User1", "User2",
"User3" and "User4"). It
enables you to manage these iles,
make calls using the SIM card and
activate guidance.
The directory
General
407 saloon and 407 SW comfort
RDS TMC (Traffic Message
Channel) Traffic Information
You can access the information re-
lating to trafic conditions from the
"Audio functions" or "Telematics"
menu, then from the "TMC Trafic
Information" function (see section
"Satellite navigation system").

88 -
11-10-2004
MONOCHROME DISPLAY CT
COLOUR AND MAP DISPLAY
DT
Displays the following information:
- the time,
- the date,
- the exterior temperature (the value displayed lashes if there is a risk of
ice),
- the accesses check,
- the vehicle function status mes- sages, displayed temporarily,
- the warning displays,
- the RT3 audio equipment displays, the direct inputting of the frequency
of a transmitter on the numeric key-
pad,
- the telematic systems displays (tele- phone, services, ...),
- the trip computer displays,
- the air conditioning displays,
- the satellite navigation system dis- plays.
407 saloon and 407 SW comfort
The general menu
Press the "MENU" button to access
the general menu and select one of
the following parameters and func-
tions: Navigation - Guidance, Audio
functions, Trip computer, Person-
alisation-coniguration, Directory,
Telematics, Map*, Video* and Air
Conditioning.
The "Personalisation-Conigura-
tion" menu provides access to suc-
cessive conirmation windows. Display coniguration
- selection of the colours for the DT
display: selection of the colours
available for display.
- Sound: selection of the sound am- bience, setting of the voice synthe-
siser and of the voice commands.
- Brightness.
- Selection of the units of measure- ment.
* With the DT colour display only.
Deine the vehicle parameters
Permits the activation or deactiva-
tion of certain driving and comfort
functions:
- Deactivation of the driver welcome function,
- Automatic switching on of the lights,
- Duration of the "follow-me-home" lighting,
- Activation of the automatic "follow- me-home" lighting,
- Activation of the permanent locking of the boot (407 Saloon). Selection of the language
German, Spanish, French, English,
Italian, Dutch, Portuguese and Bra-
zilian Portuguese.

106 -
11-10-2004
107
-
11-10-2004
You can connect video equipment
(camcorder, digital photographic
equipment, ...) to the three video
sockets, located in the glove box.
Video display is only possible when
stationary.
Select the Video menu from the
general menu:
- "Activate video mode" to activate/
deactivate the video.
- "Video parameters" to set the display format, the brightness, the
contrast and the colours.
Press the "ESC" or "DARK" button to
exit video mode.
Press the "SOURCE" button several
times in succession to select an audio
source other than that of the video.
VIDEO MENU**
** DT colour screen only.
407 saloon and 407 SW comfort

94 -
11-10-2004
95
-
11-10-2004
SATELLITE NAVIGATION
SYSTEM
Introduction
The satellite navigation system
guides you, by means of vocal and
visual instructions, to your chosen
destination.
The heart of the system lies in the
use of a map data base and of the
GPS system. With this system you
can ix the position of your vehicle by
means of a satellite network.
The system uses the following
elements:
- the CD-Rom drive,
- the coniguration CD-Rom,
- the navigation CD-Rom,
- the last voice message recall control,
- the control keypad,
- the monochrome screen or the
colour screen.
Certain functions or services de-
scribed may vary depending on the
version of CD-Rom or the country
where the vehicle is sold. 1.
Ejection button on CD-Rom.
2. CD-Rom housing.
The navigation CD ROM contains all
the map data.
It must be inserted in the drive,
printed face upwards.
Use only CD-Roms approved by
PEUGEOT. Pressing for more than two seconds
on the button at the end of the lights
stalk repeats the last voice informa-
tion.
For safety reasons, the in-
putting of navigation infor-
mation by the driver must be
carried out when the vehicle
is stationary.
The CD-Rom drive
This is part of the RT3 GPS audio/
telephone.
The last voice message recall
control
The control panel
This lets you navigate, select, choose
and validate the functions, from the
parameters displayed.
407 saloon and 407 SW comfort

96 -
11-10-2004
97
-
11-10-2004
Pressing the dial - navigator:
This allows:
-
access to the list of controls (con-
textual menu) of the permanent
display, if there is no other display
superimposed.
- conirmation of the selected func-
tion or the modiied value.
- selection of a 'setting' or 'list'
type parameter for modiication.
"C" button:
- Brief press:
deletion of the last
character entered.
- Press for more than two seconds: deletion of the entire line.
"NAV" button:
- Brief press: access to the navi-
gation - guidance permanent ap-
plication.
"MENU" button:
- Brief press: access to the general
menu .
- Press for more than two seconds: access to the help menu.
"ESC" button:
- Brief press: cancellation of the
operation in progress or clearing
of the last superimposed display.
- Press for more than two seconds: clearing of all of the superimposed
displays and return to the perma-
nent application.
" 5 " and " 6" buttons:
- Vertical movement in the menus,
screens and on the map on the DT
colour screen.
" 3 " and " 4" buttons:
- Horizontal movement in the men-
us, screens and on the map on the
DT colour screen. Permanent locating
This function enables you to display
the name of the street along which
the vehicle is travelling when guid-
ance is not active, on condition that
the navigation CD ROM is in the
drive.
Press the dial for more than two
seconds to display the name of the
street along which you are travelling.
Rotation of the dial - navigator:
This allows you to
move round the
screen and thus select a function.
It also allows you :
- with a 'setting' type parameter,
after selection, to increase or de-
crease the value,
- with a 'list' type parameter, after
opening the list, to scroll through
the values,
- with map guidance, to increase or
reduce the zoom.
407 saloon and 407 SW comfort
