Text messages (SMS)
Accessing text messages Sending a text message "Duration of calls" menu
Select the "Duration of calls"
function from the "Telephone func-
tions" menu to consult the duration
counters for the calls made. The par-
tial counter totals the duration of the
calls since the last zero reset carried
out using the "Zero reset" button.
When the buzzer sounds (if the SMS
text messages buzzer option is ac-
tive) and a superimposed screen
announces "Do you wish to read
the new text message (SMS)?" ,
you can choose to read the text mes-
sage received by selecting and vali-
dating "YES" or postpone reading
it by selecting and validating "NO",
by pressing the "ESC" button or by
waiting until the announcement dis-
appears. The message is read by the
voice synthesiser, if it is active.
Note: the old text messages stored
and the new text messages, the
reading of which you wished to post-
pone, can be consulted. Press the
"MENU" button then validate the
telematic icon, select "Text mes-
sages (SMS)" and validate the func-
tion "Reading of text messages re-
ceived" by pressing button G. Then
scroll through the list by turning the
button and press the button to select
the text message to be read (if the
voice synthesiser is active). Note:
Before typing your irst text
message, check that your text mes-
sages (SMS) centre number is stored
correctly in the sub-menu "Server
centre N°" . If it is not, any text mes-
sages typed before this number is
entered will not be sent.
In the menu "Text messages
(SMS)" validate the function "Typing
of a text message" . Type your text
message using the alphanumeric
keypad and validate it using the
"OK" button to store it or validate the
"Send" button to send it. Validation
of the "Send" button enables you to
enter the number of your recipient or
select it from the directory or from the
list of calls and send the message. "Telephone options" menu
Select the
"Telephone options"
function from the "Telephone func-
tions" menu to access the func-
tions:
• "Conigure the calls" which
permits activation and deactivation
of the "show my number" and
"automatic answering after X rings"
functions
• "Ringing options" which permits
adjustment of the ringing volume
for voice calls, activation of the text
messages (SMS) receipt buzzer
and selection of a ring tone from
the ive offered
• "Diversion number/voice mail"
which permits recording of the call
diversion number chosen by the
customer, otherwise the call will be
transferred to the voice mail.
Audio equipment and telematics

56 -
31-01-2005
57
-
31-01-2005
Services* Emergency call*
"PEUGEOT Assistance"/
Emergency call
During a connection to "PEUGOT
Assistance" or an emergency call,
it is not possible to send or receive
calls or SMS text messages; these
will be transferred to your voice
mail.
In this case, a green diode lashes
on the RT3 GPS audio/telephone
panel, when the emergency call or
"PEUGEOT Assistance" call pro-
cedure begins, then lights continu-
ously when the call is taken by the
services concerned.
If your call to "PEUGEOT Assist-
ance" is located, a star "« " will ap-
pear in the text on the screen.
Press button E to dis-
play the "Services"
menu and select one
of the following serv-
ices:
• "Customer Contact
Centre" which
enables you to con-
tact the PEUGEOT Customer
Contact Centre directly and
access the services offered (this
type of call is suspended if an
emergency or breakown call is
made).
• "PEUGEOT Assistance" which
enables you to contact the call
centre which controls the PEUGEOT
breakdown service directly and
receive rapid assistance (you have
6 seconds within which to cancel
the call when it is made). During
the breakdown call phase it is not
possible to make any other calls
with the exception of emergency
calls. If you have signed the speciic
PEUGEOT contract, your call will be
located.
• "Operator services" which gives
access to the list of services
speciic to your operator (e.g.:
customer service, consumption
monitoring, news, stock market,
weather, travel, games, etc) if they
are available. In an emergency,
press but-
ton V until a signal is heard
and a call validation/deletion
screen is displayed (delay
of 6 seconds) or enter 112
directly.
Make an emergency call if
you are involved in an situ-
ation which leads you to fear serious
consequences (injuries, ...) for those
who are exposed to it (if you witness
or are involved in an accident result-
ing in injuries, an attack, ...).
Before making a call of this kind, the
audio/telephone must detect a cel-
lular network.
If you have not signed the speciic
PEUGEOT contract, the parameters
of the SOS button are set so that a
call is made to 112 - unique number
made available by the worldwide
GSM network, reserved for emer-
gency calls.
No security mode is required and,
depending on the network, you do
not need to insert your SIM card or
enter your PIN.
If you have signed the speciic
PEUGEOT contract, your call will be
located and you will be put in contact
with a PEUGEOT assistance team.
For further details, refer to the gen-
eral conditions of your contract.
* If option and service available.
Audio equipment and telematics

58 -
31-01-2005
59
-
31-01-2005
The Directory
General
The "Directory" application gives
access to 400 iles divided into 4 in-
dependent sub-directories ("User1",
"User2", "User3" and "User4"). It
enables you to manage these iles,
make calls using the SIM card and
activate guidance.
Main menu
From the general menu , select the
"Directory" application to access its
main menu and select one of the fol-
lowing functions:
• "Call", to call a number stored in a ile,
• "Activate guidance to", to initiate guidance to a location stored in a
ile,
• "Management of directory iles", to add, delete, modify and consult
directory iles or exchange them
with the SIM card,
• "Directory coniguration", to select the working directory and deine
the directory when the system is
switched on. Creation/Modiication of a ile
To create a ile, from the
"Directory"
menu, select the function "Manage-
ment of directory iles" then "Add".
On the ile select the section to be
illed in, validate then enter the in-
formation.
To modify an existing ile, select it
using the "Consult or modify the
ile" function of the "Management of
directory iles" menu then make the
modiications.
Note: when the address is entered,
the navigation CD-Rom must be
present in order to obtain guidance
to this destination. Description of a directory ile
When a description is linked to a
directory ile, you can record the
description vocally so that it can be
used subsequently for direct access
by voice commands (e.g.:
"Call"
"[Name of the voice description]"
or "Guide to" "[Name of the voice
description]" ).
Select "Consult or modify the ile"
from the "Management of direc-
tory iles" menu to access the screen
which permits entering and recording
of the description.
Press the record button and follow
the instructions.
TMC (Trafic Message Channel)
RDS Trafic Information
You can access information regard-
ing the trafic conditions from the
"Telematics" menu, then from the
"TMC Trafic Information" function
(see section "Satellite navigation
system").
Audio equipment and telematics

58 -
31-01-2005
59
-
31-01-2005
VOICE COMMANDS
The voice commands make it pos-
sible to use pre-recorded words or
phrases to control a certain number
of functions of the RT3 GPS audio/
telephone.
They are organised in three levels
(levels 1, 2 and 3).
When you say a level 1 command,
the system makes the level 2 com-
mands available; when you say a
level 2 command, the system makes
the level 3 commands available. Notes:

- between two key words, a screen indicates the time remaining and
the key word recognised,
- in the absence of any voice commands, this function will be
switched off after approximately
ive seconds,
- if a command is not understood, the system transmits "Pardon" and
displays "Word not recognised"
on the screen.
Saying the phrase "Help" or "What
can I say" displays all of the com-
mands available on the screen.
Saying the word "Cancel" cancels
all of the voice commands.
Miscellaneous words: STOP/DELETE/
YES/NO/PREVIOUS/NEXT
Activation of the voice commands
Press the button on the end of the
lights stalk to activate or deactivate
this function.
Example:
to recall the radio station
stored on button 3, the key words
are: "Radio" "Memory" "3" .
To use these key words, you must
say the word "Radio", wait for the
audible conirmation signal, then
say the word "Memory", wait for the
audible conirmation signal, then end
with the word "3", wait for the audible
conirmation signal which will carry
out the action requested.
Audio equipment and telematics

60 -
31-01-2005
61
-
31-01-2005
The list of voice commands available is presented in th is table:
Level 1 Level 2 Level 3
RADIO PREVIOUS
NEXT
MEMORY 1 ... 6
AUTOSTORE
LIST
CD PLAYER PREVIOUS TRACK
NEXT TRACK
TRACK NUMBER 1 ... 20
RANDOM
SCAN
REPEAT
LIST
CHANGER PREVIOUS TRACK
NEXT TRACK
TRACK NUMBER 1 ... 20
PREVIOUS DISC
NEXT DISC
DISC NUMBER 1 ... 6
RANDOM
SCAN
REPEAT
LISTLevel 1 Level 2 Level 3
TELEPHONE LAST NUMBER
DIRECTORY
DESCRIPTION
SERVICES
VOICE BOX
VOICE MAIL
SMS/MESSAGE DISPLAY
READ
TRAFFIC INFO DISPLAY
READ
NAVIGATION/
GUIDANCE STOP
RESUME
DIRECTORY
DESCRIPTION
ZOOM IN
ZOOM OUT
SHOW
DESTINATION
VEHICLE
DISPLAY AUDIO
TELEPHONE
NAVIGATION
TRIP COMPUTER
GUIDANCE
CALL DESCRIPTION
GUIDE TO DESCRIPTION
Audio equipment and telematics

60 -
31-01-2005
61
-
31-01-2005
5 CD CHANGER*
This is located in the glove box. It
holds up to 5 discs.
To load the changer, insert the discs
with the printed side upwards.
To remove a disc, press and hold one
of the buttons "1" to "5" .
The use of copied com-
pact discs may cause
faults.
Insert circular compact discs
only.
* According to country.
RADIO RECEPTION
(aerial adjustment)
Notes on radio reception
Your radio will be subject to phenom-
ena which do not affect domestic
radio sets. Both MW/LW and FM re-
ception are subject to various forms
of interference, which are no relec-
tion on the quality of your equipment
but are due to the nature of the sig-
nals and the way in which they are
transmitted.
On MW/LW, interference may be no-
ticed when passing underneath high
voltage power lines, under bridges or
in tunnels. On FM, interference may be the re-
sult of increasing distance from the
transmitter, delection of the signal
by obstacles (mountains, hills, build-
ings, etc.), or of being in an area not
covered by a transmitter.
Saloon: recommended position for
the front aerial for best reception.
No particular position for the ixed
rear aerial (preset aerial).
Audio equipment and telematics

62 -
31-01-2005
206 AUDIO SYSTEM (RD3 and RT3)
Presentation
Your 206 is itted with a JBL audio
system, designed speciically for the
passenger compartment.
At the heart of the system, a
240 watt multi-function ampliier (1)
(integrated in the subwoofer in
the boot) independently controls
8 high acoustic deinition speakers
and the subwoofer.The speakers are situated:
- in the front door pillars: two
Tweeters (2) for reproduction of
the treble (high frequency) in the
front.
- in the front doors: two Woofers (3)
for reproduction of the bass (low
frequencies) in the front.
- in the rear doors: two Tweeters (4)
set into two Woofers (5) , providing a
balance of frequencies in the rear.
- in the boot: a Subwoofer (6)
for reproduction of the bass and
ultra-bass (very low frequencies)
throughout the whole of the
passenger compartment.
You will appreciate the clarity
and depth and notice that the
sound ills the whole of the vehi-
cle perfectly.
This system provides optimal re-
production and distribution of the
sound in the vehicle, both in the
front and the rear. Adjusting in CD or Radio mode
The basic functions remain those of
the audio set.
There is no need for any further ad-
justment. However, in order to take
full advantage of your JBL audio
system, you are advised to set the
AUDIO functions
(BASS, TREB,
FAD, BAL) to position "0" (zero), the
Loudness (LOUD) to the "ON" posi-
tion for CD mode and to the "OFF"
position for radio mode.
Audio equipment and telematics

63
-
31-01-2005
SATELLITE NAVIGATION
SYSTEM
Introduction
The satellite navigation system guides
you, by means of vocal and visual
instructions (graphics), to your cho-
sen destination.
The heart of the system lies in the
use of a map data base and GPS
(Global Positioning System) . With
this system you can ix the position
of your vehicle by means of a satel-
lite network.
The system uses the following ele-
ments:
- the CD-Rom drive,
- the coniguration CD-Rom,
- the navigation CD-Rom,
- the last voice message recall control,
- the control keypad,
- the CT monochrome screen.
For safety reasons, the
inputting of navigation
information by the driver
must be carried out when
the vehicle is stationary.
The CD-Rom drive
This is part of the RT3 GPS audio/
telephone.
1. CD-Rom ejection button.
2. CD-Rom housing.
The navigation CD-Rom
The last voice message recall
control
Pressing for more than two seconds on
the button at the end of the lights stalk
repeats the last voice information.
This contains all the map data.
It must be inserted in the drive, printed
face upwards.
Use only CD-Roms approved by
PEUGEOT.
Certain functions or services de-
scribed may vary depending on
the version of CD-Rom or the
country where the vehicle is sold.
Audio equipment and telematics
