2004 PEUGEOT 206 Owners Manual

12 -
31-01-2005
13
-
31-01-2005
BOOT LAYOUT (206 SW)
1 - Grab handles and coat hook
2 - Coat hooks
3 - High load retaining net ixings
4 - Hooks
5 - 12 V accessories socket
6 - Storage nets
7 - Retaining straps
8 - Load space cover
9 - Lashing rings
: 116
Familiarisation

6 -
31-01-2005
7
-
31-01-2005
Precautions regarding the
passenger air bag
For a vehicle itted with a disarming
switch:
Starting a petrol engine
Do not press the accelerator.
Operate the starter, without releasing
the key, until the engine turns.
Starting a diesel engine
Do not press the accelerator.
Turn the key to the ''Run-
ning'' position.
If the engine is warm enough, the
pre-heat light does not come on and
you can start immediately.
If the pre-heat light comes on, wait
for it to go out before operating the
starter.
If the engine stalls, it is necessary to
return the key to the ''STOP'' position
before restarting.
Never race a cold engine.
Never run the engine in a
conined space.
Do not make any modiica-
tions to the steering lock. Operating check
With the ignition on (2nd
notch of the ignition), illumi-
nation of this warning light,
accompanied by a message on the
multifunction display, indicates that
the passenger air bag is disarmed
(switch in the "OFF" position).
The warning light remains on
throughout the period of disarming.
FRONT AIR BAGS
Disarming the passenger air bag*
Insert the ignition key into switch 1
and turn it to:
- the ON position; the passenger air
bag is armed.
- the OFF position; the passenger air
bag is disarmed.
- disarm the air bag if you install a rear-
facing child seat,
- arm the air bag for an adult pas-
senger.
For a vehicle not itted with a disarm-
ing switch: - do not install a rear-facing child seat on
the front passenger
seat.
In no circumstances should you
place your feet or any other object
on the fascia.
* According to country.
: 124
Familiarisation

8 -
31-01-2005
9
-
31-01-2005
ELECTRIC WINDOWS
: 109
2. Passenger's electric window.
3. Rear left electric window.
4. Rear right electric window.
ELECTRIC MIRRORS
Turn knob
5 to the right or to the left
to select the corresponding mirror.
Move knob 5 in all four directions to
adjust.
: 110
1. Driver's electric window
Manual operation:
press or pull the
switch lightly. The window stops as
soon as the switch is released.
Automatic operation: press or pull
the switch irmly. One touch com-
pletely opens or closes the window.
Automatic opening and closing only
operate when the engine is running. Electric folding mirrors
With the ignition on, turn knob
5 to
position A.
Familiarisation

8 -
31-01-2005
9
-
31-01-2005
DOORS
The boot and the rear screen cannot be opened simultane ously.
With the rear screen closed, to open the boot, pull the handle A and lift.
Front doors
Rear doors (206 SW)
LOCKING/UNLOCKING THE BOOT AND THE REAR SCREEN
(206 SW)
With the boot closed, to open the
rear screen
, press and hold the un-
locking button on the remote control
or pull the handle B, then lift the rear
screen using the windscreen wiper
arm (at C).
The lighting is switched on by
opening the boot or the rear
screen.
Note: Close the rear screen using
the windscreen wiper arm C or by
pressing the centre of the window.
: 97: 99
Familiarisation

16 -
31-01-2005
"PORSCHE TIPTRONIC
SYSTEM" AUTOMATIC
GEARBOX
The four-speed automatic gearbox
offers the choice between the com-
fort of fully automatic gear chang-
ing , enhanced by a sport program
and a snow program, or manual
gear changing .
STEERING WHEEL HEIGHT
ADJUSTMENT
When stationary, lower the handle to
unlock the steering wheel.
Adjust to the desired height and
lift the handle to lock the steering
wheel.
OPENING THE BONNET
From inside the vehicle: pull the
handle.
From the outside: lift the catch and
raise the bonnet. Secure the strut to
hold the bonnet open.
: 119: 101 Position selection grid
F
Move the lever in the grid to select
a position.
The indicator light for the position
selected comes on on the instrument
panel display.
Familiarisation

14 -
31-01-2005
15
-
31-01-2005
HEATING/AIR CONDITIONING
N° Symbol Function
1 Setting the air
distribution.
2 Air intake control.
3 Temperature
adjustment.
4 Demisting the rear
screen and mirrors.
5 Air low adjustment.
6 Air conditioning
control.
:
76
: 78
Familiarisation

14 -
31-01-2005
15
-
31-01-2005
AUTOMATIC AIR CONDITIONING
N° Symbol Function
1 Air low adjustment.
2 Setting the air
distribution.
3 Air intake control.
4 Air conditioning
control.
5 Demisting the rear
screen and mirrors.
6 Switching off.
7 Temperature
adjustment.
8 Automatic comfort
program.
9 Automatic visibility
program.
:
80
Familiarisation

17
-
31-01-2005
1. Seat belt not fastened warning
light*
2. Passenger air bag disarmed
warning light*
3. Air bags warning light
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)
warning light
6. Rear fog lamp indicator light
7. Diesel pre-heat warning light
8. Left hand direction indicator
9. Total distance recorder, service
indicator and engine oil level
indicator 10.
Right hand direction indicator
11. Engine diagnostics warning light
12.
Main beam headlamps indicator light
13. Handbrake, low brake luid
level and electronic brake force
distribution warning light
14. Dipped beam headlamps
indicator light
15. Battery charge warning light
16. Engine oil pressure and
temperature warning light
17. Water in diesel ilter warning light
18. Coolant low level warning light
(Diesel)
19. Engine oil temperature indicator 20.
Total distance recorder button
21. Central (STOP) warning light
22. Speedometer
23. Coolant temperature indicator
24. Rev counter
25. Lighting rheostat button
26. Fuel level indicator
27. Low fuel level warning light
28. Dynamic stability control
(ESP/ASR) warning light
INSTRUMENT DIALS: PETROL - DIESEL MANUAL GEARBOX (saloon and 206 SW )
* According to destination.
Instruments and controls
