2004 PEUGEOT 206 Owners Manual

48 -
31-01-2005
49
-
31-01-2005
Briely press button H or I
to increase or decrease the
frequency displayed.
By continuing to press
the button in the direction
selected, you will obtain
continuous scrolling of the
frequency.
Scrolling stops at the irst
station found.
Manual station search
Manual station storing
Select the station required.
Press one of the buttons
"1" to "6"
for more than two seconds.
A sound cut-off conirms that the sta-
tion has been stored in the memory. Automatic storing of FM stations
in the memory (autostore)
Your audio/telephone automatically
stores the 6 stations with the strong-
est signal in FM. These stations are
stored in the FMast waveband.
If it is not possible to ind 6 stations,
the remaining memories are empty.
Press the
''BAND/
AST'' button for more
than two seconds.
Recalling stations stored in the
memory
For each waveband, briely press the
buttons "1" to "6" to recall the cor-
responding stored station.
Audio equipment and telematics

48 -
31-01-2005
49
-
31-01-2005
Regional following mode (REG)
When they are part of a network,
certain stations broadcast regional
programs in the various areas they
serve. With regional following mode
you can keep listening to the same
program.
To do this, press the "RDS" button
for more than two seconds to switch
the function on or off.
The multi-function screen will show:
- REG if the function is active,
- REG crossed out or greyed out
if the function is active but not
available.RDS SYSTEM
Using the RDS (Radio Data
System) function on FM
Radio Data System allows you to
continue listening to the same sta-
tion, whatever frequency it is using
for the region you are going through. Trafic information program
Briely press the
"RDS" button to
switch the function on
or off.
The multi-function screen will show:
- RDS if the function is active
- RDS crossed out or greyed out
if the function is active but not
available. Press the
''TA/PTY''
button to switch the
function on or off.
The multi-function screen will show: - TA if the function is selected
- TA crossed out or greyed out
if the function is selected but not
available.
Any trafic information lash will be
given priority, whatever source you
are listening to (radio, CD or CD
changer).
If you wish to interrupt the broadcast-
ing of a message, press the ''TA/
PTY'' button.
Note: the volume of the trafic
information is independent of the
volume of normal radio/telephone
listening.
You can adjust it by using the volume
button. The setting will be stored and
will be used when the next messages
are broadcast.
RDS station following
This display indicates the name of the
station selected. The audio/telephone
continuously searches for the trans-
mitter which transmits the same
program with the best reception. This
search may cause slight interference
with the transmission.
Audio equipment and telematics

50 -
31-01-2005
51
-
31-01-2005
PTY function
This allows you to listen to stations
broadcasting a speciic type of pro-
gram (news, culture, sport, rock,
etc.)
When FM is selected, press button
"TA/PTY" for more than two seconds
to switch the function on or off.
To ind a PTY program:
Audio functions menu
Select the "Audio functions" menu
from the general menu to:
- "Activate/Deactivate RDS frequency following",
- "Activate/Deactivate REG regional mode",
- "TMC trafic information". Contextual menu
- select the PTY button,
- turn button G to scroll down the
different types of programs offered,
then conirm your choice,
- when the program of your choice is displayed press button M or N
to carry out an automatic search
(after an automatic search the PTY
function is switched off if no station
has been found).
In PTY mode the different types of pro-
grams can be stored in the memory. To
do this, press the preselection buttons
"1" to "6'' for more than two seconds.
To recall the type of program stored
in the memory, briely press the cor-
responding button. EON system
This system connects stations which
are part of the same network. It ena-
bles the broadcast of trafic informa-
tion or a
PTY program, by a station
that is part of the same network as
the station to which you are listen-
ing.
The service is available when you
have selected the TA trafic informa-
tion program or the PTY function. By pressing knob
G, the contextual
menu allows you to access the fol-
lowing functions:
- 'Inputting a frequency',
- 'List of stations' to access the 30 sta- tions picked up locally directly,
- 'Refresh list' to update this list,
- "Display Radio Text" to display information connected with the
station being listened to, if "RT" is
displayed permanently.
Audio equipment and telematics

50 -
31-01-2005
51
-
31-01-2005
Ejecting a disc Selecting a track
By pressing knob G, the contextual
menu permits you to switch on or
switch off the shufle, play the start
of a track, track program and display
tracks played functions.
After inserting a disc, printed face
upwards, the CD drive starts auto-
matically.
If a disc has already been inserted,
press the
''SOURCE'' button to se-
lect CD mode.
COMPACT DISC
Selecting CD mode
Press button M to select the follow-
ing track.
Press button N to return to the start
of the current track or to select the
previous track.
Do not use copied CDs as
these could damage your
player.
Insert circular compact
discs only.
Press button
B to
eject the disc from the
drive. Accelerated play
Press and hold button
M or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released. Contextual menu
Audio equipment and telematics

52 -
31-01-2005
53
-
31-01-2005
Press button M to select the following
track.
Press button N to return to the start
of the current track or to select the
previous track. By pressing knob
G, the contextual
menu permits you to switch on or
switch off the shufle, playing the
start of a track or repeat a track and
display tracks played functions.
COMPACT DISC CHANGER
Selecting CD changer mode
Press the ''SOURCE'' button several
times.
Selecting a disc
Press one of the buttons ''1'' to ''5''
on the audio/telephone to select the
appropriate disc.
Buttons H and I allow you to select
respectively the previous or following
disc in the changer. Selecting a track Contextual menu
Accelerated play
Press and hold button
M or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Audio equipment and telematics

52 -
31-01-2005
53
-
31-01-2005
TELEPHONE
This function is a GSM dual-band
telephone (900 and 1 800 MHz) in-
corporated in the RT3 GPS audio/
telephone system.
It is a ''hands free'' telephone. This
function is provided by a microphone
located next to the front courtesy light,
the speakers, a steering column con-
trol and voice commands which allow
access to most of the functions (the
audio/telephone control panel buttons
allow access to all the functions).
Display of the principal ''mobile''
type functions, as well as consulta-
tion of the indexes, is provided by the
multi-function display.
This function is active, whatever
position the ignition key is in even af-
ter thirty minutes, when the message
''Economy mode active'' appears
on the multi-function display. Using the menus
Press the
''MENU'' button to dis-
play the general menu . Select the
telematics application, validate
"Telephone functions" to access
the principal telephone functions,
then the various menus, in order to
reach the one required.
This menu allows you to access the
following functions: Within each menu:
- Network: allows you to select the
network search mode and to see
the networks available.
- Duration of calls: allows you to
consult the duration recorder of
calls made and zero re-set.
- Security: allows you to use or
modify the PIN code and to erase
the list of calls and text messages
(SMS).
- Telephone options: allows you to
conigure the calls with entering of
my number, automatic answering
after X rings, speciication of ring
options and allows you to conigure
the call diversion number. Move around and se-
lect a function by turn-
ing the
G button then
validate by pressing
the button.
Cancel an operation
using the ''ESC'' but-
ton.
Using the alphanumeric keypad
For a given button, to input a charac-
ter in the second or subsequent rows
press until you obtain the character
required.
Buttons Associated characters
[1] 1 or space
[2] 2 or A B C 2 or a b c 2
[3] 3 or D E F 3 or d e f 3
[4] 4 or G H I 4 or g h i 4
[5] 5 or J K L 5 or j k l 5
[6] 6 or M N O 6 or m n o 6
[7] 7 or P Q R S 7 or p q r s 7
[8] 8 or T U V 8 or t u v 8
[9] 9 or W X Y Z 9 or w x y z 9
[0] 0 or + (long press)
[#] # or validation
[*] * or erasing of last character
input (long press)
Audio equipment and telematics

54 -
31-01-2005
55
-
31-01-2005
Open lap L by pressing the
point of a pencil on the circu-
lar opening above the lap.
Insert your Micro-SIM card,
available from a mobile tele-
phone operator, as indicated
in the graphics, then close the lap.
Note: removal or insertion of the SIM
card must only be carried out after
the RT3 audio/telephone has been
switched off.
Installing the SIM card Inputting the PIN code
Input your PIN code using the al-
phanumeric keypad and validate by
pressing button G or button # to ac-
cess the network. Connection to the
network is validated by the appear-
ance of a symbol on the screen.
Warning: if you make three errors in
succession when inputting your PIN
code, your SIM card will be blocked.
To unblock it, you will need to input
the PUK code. The PUK code will be
supplied to you by the person sell-
ing your SIM card (input of the PUK
code allows for 10 errors in succes-
sion; after this the SIM card becomes
permanently unusable).
Note: the PIN code is required each
time the ignition is switched on, un-
less the PIN code has been stored in
the memory or protection by PIN code
is not activated on the SIM card. Cancelling of PIN code request
In the menu
''Telephone functions''
select ''Security'' , then ''Process
the PIN code'' , then validate the
''Cancel'' function.
Warning: in this case, do not lose
your SIM card. Losing it would mean
anyone who inds it would be able to
make unlimited calls.
Audio equipment and telematics

54 -
31-01-2005
55
-
31-01-2005
Telephone function screens
Not in use
In use
This screen indicates the presence
of voice messages or text mes-
sages (SMS) not listened to/read,
the cumulative time in use since the
last zero reset and the status of your
telephone.
This screen indicates the time
elapsed since the start of the con-
versation, as well as the number* or
name of the person to whom you are
speaking (if recorded in the index)
and the status of your telephone.
* If this option and service are
available. Making a call
Press button
D to display the contex-
tual menu of the telephone.
Note: pressing the end 5 of the steer-
ing column control for more than
2 seconds calls up a contextual menu
limited to the "Directory", "List of
calls" and "Voice mail" functions.
Entering a number Select the function
''Enter number'' then
enter the number of
the person you wish
to speak to using the
alphanumeric keypad.
Press button D to
make the call. Making a call from a directory
Select the
"Directory" function to
access all the iles containing a tele-
phone number or the "List of calls"
function to access the list of the last
twenty incoming (if the number display
option is active) or outgoing calls.
Note: there are two directories, the
RT3 audio/telephone directory and
the SIM card directory. To consult the
SIM directory, insert your SIM card
and enter your PIN code.
Receiving a call
When a ringing
sounds to let you
know that a call is
waiting, you can
choose either to ac-
cept it by pressing
button D or the end
of the steering wheel
remote control or not to accept it by
pressing the button Q or by selecting
and validating the "NO" button on
the "Answer?" screen.
If you accept the call, to end your
communication, press button Q.
If you do not accept the call, it is
transferred to your voice mail or to a
call diversion number.
You can activate or deactivate this
transfer by pressing button Q for
more than two seconds.
Audio equipment and telematics
