2004 NISSAN 350Z ESP

INFO:
For approximately 3 or 4 minutes after system
startup, the GPS indicator
remains gray ,
even if accurate positioning is possible.
POSITIONING ADJUSTMENT
When the system judges that the vehicle po-
sition information is not accurate based on ve-
hicle speed and gyro sensor data calculations,
the system will adjust the vehicle position in-
formation using GPS signals.
RECEIVING SIGNALS FROM
GPS SATELLITES
Sometimes, satellite reception is weak. The fol-
lowing are places where signals tend to be
weak:

Inside tunnels and parking lots in structures

Areas with numerous tall buildings

Under multi-layered highways

In a dense forestVehicles in these areas may not receive GPS
signals (Indicator color: gray).
INFO:
The antenna for GPS is located in the instru-
ment panel.Do not place any objects, es-
pecially mobile phones or transceivers,
on the instrument panel. Because the
strength of the GPS signal is approximately
one billionth of that of TV waves, phones and
transceivers will decrease the strength or may
totally disrupt the signals.
DISPLAY OF GPS INFORMA-
TION
This system displays GPS information.
Please refer to “GPS information display” on
page 11-13.NOTE:
Directional guidance provided by the
navigation system does not take carpool
lane driving into consideration, espe-
cially when carpool lanes are separated
from other road lanes.
HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
2-3

ROUTE GUIDANCE
The main feature of the NISSAN Navigation
System is Visual and Audio Route Guidance in
selected detailed map coverage areas. Utilizing
a network of GPS (Global Positioning System)
satellites, the NISSAN Navigation System
tracks your location on the map and directs you
where you want to go.
Once you program a destination covered by a
detailed map, the NISSAN Navigation System
will determine a route from your current loca-
tion to your destination. The moving map dis-
play and turn-by-turn voice commands help
the driver determine upcoming turns.
This feature can be especially helpful in finding
unfamiliar locations or businesses. The system
may be unable to set a destination and/or cal-
culate distance when a destination is outside
a detailed map coverage area. Additionally , au-
dio route guidance may not be available if the
destination is outside a detailed map coveragearea. For more information on how to program
a destination, please refer to section 5.
POINT OF INTEREST (POI)
DIRECTORY
The NISSAN Navigation System offers an ex-
tensive Point of Interest directory in detailed
map coverage areas. This directory includes a
wide variety of destinations ranging from gas
stations, A TMs, and restaurants to casinos, ski
resorts, shopping centers and businesses. By
accessing the Point of Interest directory , you
can search for addresses and phone numbers
for a destination, and with a press of a button,
the NISSAN Navigation System will calculate a
route to the destination.
The Point of Interest directory offers many
uses. For example, the directory can be sorted
by the various types of restaurants near your
current location. If you need an A TM or gas
station, the NISSAN Navigation System canpoint you to the closest one or the closest one
of your favorite brand.
For more information on how to use the Point
of Interest directory , please refer to section 6.ADDRESS BOOK
Using the Address Book feature, you will have
the ability to store up to 50 locations in detailed
map coverage areas into a personal directory .
This is especially useful for frequently visited
locations, such as your clients, relatives, or
friends. The Address Book feature will provide
you with easy access to these frequently visited
locations when setting them as your destina-
tion.
For more information on how to use your ad-
dress book, please refer to section 7.
A VOID AREA
By using the Avoid Area feature, you can iden-
tify areas or freeways that you would like the
NISSAN Navigation System to avoid when
WHAT FEATURES ARE AVAILABLE ON THE NISSAN NAVIGATION SYSTEM?
3-2

Nearby Display Iconskey:
Displays five types of points of interest around
the current location.
Please refer to “Setting with the
Nearby key”
on page 6-11.
Save Current Locationkey:
Stores the current vehicle location in the ad-
dress book.
Please refer to “Storing current vehicle posi-
tion” on page 7-3.
Adjust Current Locationkey:
Corrects the location and direction of the ve-
hicle icon.
Please refer to “Updating the current vehicle lo-
cation and the direction” on page 11-14.
Auto Re-route On/Offkey:
A new route to the desired destination will au-
tomatically be calculated again from the loca-tion when the vehicle is off the suggested route
during route guidance.
Please refer to “Automatic re-routing” on page
9-2.
Avoid Area Settingskey:
Defines areas to avoid when calculating a
route.
Please refer to “Setting avoid areas” on page
8-2.
Button T one/Beep Responsekey:
This key is used to turn on/off the automatic
beep sound.
Please refer to “Setting automatic beep sound”
on page 11-16.
Clear Memorykey:
Clears all the stored memory (Address Book,
Avoid Area, Previous Dest.).
Please refer to “Clearing the memory” on page
4-18.
Edit Address Bookkey:
Changes the names and positions of the reg-
istered locations.
Please refer to “Setting up and editing the ad-
dress book” on page 7-2.
GPS Informationkey:
GPS information will be displayed.
Please refer to “GPS information display” on
page 11-13.
Quick Stop Customer Settingskey:
Sets the user-defined [Quick Stop] POI (Point
Of Interest).
Please refer to “Quick stop customer settings”
on page 5-37.
Set Average Speed for Estimated Journey Time
key:
Please refer to “Setting the average speed” on
page 4-19.
HOW DO I OPERATE THE NISSAN NAVIGATION SYSTEM?
4-10

ABOUT ROUTE GUIDANCE

The NISSAN Navigation System may
not calculate routes longer than
about 1,100 miles (1,770 km). If your
trip is longer than 1,100 miles (1,770
km), please divide your trip by se-
lecting one or two intermediate des-
tinations. Set your destination as the
first intermediate destination. Once
you pass the intermediate destina-
tion, you may set your final destina-
tion as your destination if it is within
1,100 miles (1,770 km). Otherwise,
set your destination using your sec-
ond intermediate destination.
NOTE:
The navigation system does not take
driving in “carpool lanes” into consid-
eration for the guidance, especially
when carpool lanes are separated from
other road lanes.
NOTES ON ROUTE GUIDANCE

The route selected by the system may not
be the shortest, nor are other circumstances
such as traffic jams considered.

Because of the inevitable difference in road
conditions and circumstances between the
time you use this system and the time the
information was produced for the DVD,
there may be discrepancies in roads and
regulations. In such cases, follow the actual
information available.

During route calculation, the map will not
scroll, however the vehicle icon will move
with the actual vehicle’s movement.

During route calculation, buttons such as
MAP , DEST , ZOOM OUT and
ZOOM IN and the joystick will be dis-
abled.

In some cases, after the calculation is com-
plete, it may take some time to get the cal-
culated route on the display .
Waypoints that have been passed will not
be covered by the re-routing calculation.

If you scroll the map while the suggested
route is being drawn, it may take more time
to finish drawing.

If waypoints are set, the system is calculat-
ing multiple routes between waypoints si-
multaneously , and the following may result.
— If one section (or more) of the routes be-
tween the waypoints is not found, none of
the route will be displayed.
— The route may not connect completely at
some waypoints.
— The route may require a U-turn close to
some waypoints.

Route calculation may not be completed in
the following cases.
— If there is no main road within 3.1 miles (5
km) from the vehicle, a message saying so
will appear on the screen. T ry requesting
HOW DO I OPERATE THE NISSAN NAVIGATION SYSTEM?
4-21

route calculation when the vehicle is closer
to the main road.
— If there is no main road within 3.1 miles (5
km) from the destination or waypoint, a
message saying so will appear on the
screen. T ry setting the location closer to the
main road.
— If the vehicle is too close to the destination
or if there are no branches of the roads to
the destination. A message saying so will
appear on the screen.
— If it is deemed impossible to reach the des-
tination or waypoints because of traffic
regulations, etc.
— If the only route to reach the destination or
waypoints is extremely complicated.
— If the destination, current vehicle position
or waypoint is within the avoid area.
— If the setting of avoid areas covers the
routes to the destination, route calculationmay not be possible.

The following may occur when the route is
being displayed.
— If you are requesting a calculation from the
main road, the origin of the route may not
exactly match the current vehicle position.
— If you are requesting a calculation to the
destination on the main road, the end of the
route may not exactly match the destination.
— If you are requesting a calculation from the
main road, the system may show a route
from another main road. This may be be-
cause the icon to show the current vehicle
position (vehicle icon) is not set accurately .
In that case, park the car in a safe place and
reset the vehicle icon, or continue driving
to see if the vehicle icon appears on the
main road before requesting route calcula-
tion again.
— There are cases in which the system shows
a detoured route to reach the destination orwaypoints, if you set them from memory or
facility information. In order to correct this,
you will have to be careful about the traffic
direction, especially when the lanes with
different travel directions are shown sepa-
rately . Such places are interchanges and
service areas.
— This system makes no distinction between
limited traffic control and total control
(blockage). It may show a detoured route
even if the road is usable.
— Even if the freeway preference is set to OFF ,
the route may be set on them. T o avoid this,
set a waypoint on another road type and re-
quest calculation.
— Even if the preference is set to OFF for a
ferry line, the route may be set on it. T o
avoid this, set a waypoint on a road and re-
quest calculation.
— Ferry lines, except those which accept only
pedestrians, bicycles and motorcycles, are
HOW DO I OPERATE THE NISSAN NAVIGATION SYSTEM?
4-22

Point of Interest (POI)
INFO:

Use the
Address Book key and the
Point of Interest (POI) key in the same
way as in Expert Mode.
Please refer to “Setting with the
Address Book key” on page 5-3 and
“Setting with the
Point of Interest (POI)
key” on page 6-2.

If the
Short Menus key is highlighted in
green in the [SETTING] screen, the screen
is in Easy Mode. In this case, the keys dis-
played are different from the screen in Ex-
pert Mode.

If you set a destination or waypoints, they
will be displayed with icons.

If you want to go to places close to the
stored locations or facilities, use categories
such as facility , nearby facility or memory
for easier setting.
When using either the Point of Interest
(POI) or nearby Points of Interest catego-
ries, the names called up can be set as the
destination if you do not scroll the screen.
If you want to choose a different place on
the screen from the one called up, you will
have to scroll the screen.
SETTING WITH THEAddress Book
KEY
The Address Book will allow you to store lo-
cations in the memory . This is especially useful
for locations that you visit frequently .
Please refer to “Setting up and editing the ad-
dress book” on page 7-2.1. Press the DEST button.
2. Select the
Address Book key on the
[DEST . SETTING] screen.
The [DEST . SETTINGS (Address Book)] screen
will be displayed.
INV1453
HOW DO I PROGRAM A DESTINATION?
5-3

If less than 5 suggested streets remain, they
will be displayed automatically without se-
lecting the
List key .

The city names and street names will be
displayed.

Use the joystick to scroll the display .

When the
Next Search key is selected, it
is possible to narrow down cities. T o use
this function, refer to “Setting with the
City key” on page 5-11.

When the PREVIOUS button is pressed,the screen to input street names will be dis-
played.
4. Select one street of your destination.
5. Enter the house number .
Select the
OK key .
INFO:
It may be not possible to specify a location after
selecting the
OK key . In that case, a list of
locations which correspond to the entered
house number will be displayed.NOTE:
If a house number is entered and it is not
a “direct hit” for house numbers already
stored in the database, then only a map
to the general vicinity will be displayed.
6. T o set the destination (waypoints), refer to
“Making the system guide the route with
detailed options” on page 5-27.
INV1488
INV1489
INV1490
HOW DO I PROGRAM A DESTINATION?
5-8

7. T o slightly alter the destination.
Select the
Map key to display the map
screen of the area around the specified des-
tination (waypoints).
INFO:

An approximate location corresponding to
the house number entered is displayed. If
necessary , correct the location using the
joystick.

The location displayed by the calculation
using the house number may differ from theactual location. In that case, correct the lo-
cation using the joystick.
8. If necessary , operate the joystick to adjust
the location of the destination (waypoint).
Press the PUSH ENTER button. Select the
Destination key to confirm. The
[DEST . SETTINGS (Address/Street)] screen
will be displayed.
T o set the destination (waypoint), refer to
“Making the system guide the route with
detailed options” on page 5-27.
Setting with theStatekey
TheState key is used when you select a
state/province to set the destination.
1. Select the
State key .
INV1491
INV1492
INV1493
HOW DO I PROGRAM A DESTINATION?
5-9
