2004 Lexus IS300 Electrical Components / LEXUS 2004 IS300 OWNER'S MANUAL (OM53461U)

OCCUPANT RESTRAINT SYSTEMS
146
SV16074
If the driver's seat position does not allow sufficient
space for safe installation, install the child restraint
system on the rear right seat.
SV16032
1. Run the lap and shoulder belt through or around the infant
seat following the instructions provided by its manufacturer
and insert the tab into the buckle taking care not to twist the
belt. Keep the lap portion of the belt tight.
CAUTION
After inserting the tab, make sure the tab and buckle
are locked and that the lap and shoulder portions of
the belt are not twisted.
 Do not insert coins, clips, etc. in the buckle as this
may prevent your child from properly latching the tab
and buckle.
 If the seat belt does not function normally, it cannot
protect your child from death or serious injury.
Contact your Lexus dealer immediately. Do not
install the child restraint system on the seat until the
seat belt is fixed.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
147
SV16033
2. Fully extend the shoulder belt to put it in the lock mode.
When the belt is then retracted even slightly, it cannot be
extended.
To hold the infant seat securely, make sure the belt is in the lock
mode before letting the belt retract.
SV16034
3. While pressing the infant seat firmly against the seat
cushion and seatback, let the shoulder belt retract as far as it
will go to hold the infant seat securely.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
148
SV16035
CAUTION
Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its manufacturer.
SV16070
4. To remove the infant seat, press the buckle-release button
and allow the belt to retract completely. The belt will move
freely again and be ready to work for an adult or older child
passenger.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
149
(B) Convertible seat installation
SV16030
A convertible seat must be used in forward-facing or
rear-facing
position depending on the age and size of the
child. When installing, follow the manufacturer's
instructions about the appropriate age and size of the
child as well as directions for installing the child restraint
system.
SV16037
CAUTION
 Never install a rear-facing child restraint system on
the front passenger seat. In the event of an accident,
the force of the rapid inflation of the front passenger
airbag can cause death or serious injury to the child
if the rear-facing child restraint system is installed
on the front passenger seat.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
150
SV16055

Move seat fully back
A forward-facing child restraint system should be
allowed to be installed on the front passenger seat
only when it is unavoidable. Always move the seat as
far back as possible, because the front passenger
airbag could inflate with considerable speed and
force. Otherwise, the child may be killed or seriously
injured.
 On vehicles with side airbags and curtain shield
airbags, do not allow the child to lean his/her head or
any part of his/her body against the door or the area
of the seat, front or side pillar or roof side rail from
which the side airbags or curtain shield airbags
deploy even if the child is seated in the child restraint
system. It is dangerous if the side airbag and curtain
shield airbag inflate, and the impact could cause
death or serious injury to the child.
SV16075
 If the driver's seat position does not allow sufficient
space for safe installation, install the child restraint
system on the rear right seat.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
151
SV16039
1. Run the lap and shoulder belt through or around the
convertible seat following the instructions provided by its
manufacturer and insert the tab into the buckle taking care not
to twist the belt. Keep the lap portion of the belt tight.
CAUTION
 After inserting the tab, make sure the tab and buckle
are locked and that the lap and shoulder portions of
the belt are not twisted.
 Do not insert coins, clips, etc. in the buckle as this
may prevent your child from properly latching the tab
and buckle.
 If the seat belt does not function normally, it cannot
protect your child from death or serious injury.
Contact your Lexus dealer immediately. Do not
install the child restraint system on the seat until the
seat belt is fixed.
SV16040
2. Fully extend the shoulder belt to put it in the lock mode.
When the belt is then retracted even slightly, it cannot be
extended.
To hold the convertible seat securely, make sure the belt is in
the lock mode before letting the belt retract.
SV16041
3. While pressing the convertible seat firmly against the seat
cushion and seatback, let the shoulder belt retract as far as it
will go to hold the convertible seat securely.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
152
SV16042
CAUTION
Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its manufacturer.
SV16058
4. To remove the convertible seat, press the buckle-release
button and allow the belt to retract completely. The belt will
move freely again and be ready to work for an adult or older
child passenger.
03 07.09

OCCUPANT RESTRAINT SYSTEMS
153
(C) Booster seat installation
SV16031
A booster seat must be used in forward-facing position
only.
SV16044

Move seat fully back
CAUTION

A forward-facing child restraint system should be
allowed to be installed on the front seat only when it
is unavoidable. Always move the seat as far back as
possible, because the front passenger airbag could
inflate with considerable speed and force.
Otherwise, the child may be killed or seriously
injured.
03 07.09
