2004 Lexus GX470 Engine / LEXUS 2004 GX470 FROM JAN. 2004 THROUGH JUL. 2004 PROD. OWNER'S MANUAL (OM60A87U)

AUDIO
293
Display
To use the display, push the lock release button and lower
the display until you hear a click.
You can adjust the display to your desired angle.
To close, push up the display until you hear a click.
The illumination of the screen is automatically turned off when
the display is closed. However, the rear seat entertainment
system is not turned off.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, close the display when it is
not in use.

AUDIO
294
NOTICE
The screen should be cleaned with a dry soft cloth.If the screen is pushed by hand or wiped with a hardcloth, the surface of the screen may be scratched.
Benzene or alkaline solutions may damage thecoated surface of the screen.

To prevent the battery from being discharged, do not turn on the rear seat entertainment system longerthan necessary when the engine is not running.

AUDIO
295
Rear seat entertainment system controller
The rear seat entertainment system can be operated with
the rear seat entertainment system controller. The system
cannot be operated by touching the switches on the
screen directly.CAUTION
Do not disassemble or modify the controller. It may
cause an accident, fire or electric shock.
NOTICE
Keep the controller away from direct sunlight, high heat
and high humidity. These conditions could cause the case to deform or the battery to explode or leak.

AUDIO
296(a) Before using the controller (for new vehicle owners)
A battery is already set in the controller with an insulating
sheet, which prevents the battery from being discharged.
Before using the controller, remove the insulating sheet.
(b) Using the controllerTo use the rear seat entertainment system controller,
direct the signal output portion of the controller to the
signal reception portion of the rear seat entertainment
system display.
The controller does not operate properly when the signal
reception portion of the display is exposed to direct sunlight.
Block the display from direct sunlight.

AUDIO
297
NOTICE
Observe the followings, otherwise the controller may be
damaged.
Do not drop or strongly knock the controller against hard objects.
Do not sit on or place heavy objects on the controller.

AUDIO
298(c) Controller holder
The controller can be stowed in the holder when it is not
in use. The holder can be hooked on the back of the
driver's or front passenger's seatback.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop while driving, stow the controller in the
holder when it is not in use.

AUDIO
299
NOTICE
Do not leave the controller exposed to hightemperatures (such as on the instrument panel) for along time, otherwise the controller may be damaged.

AUDIO
300
Quick reference for your remote controller
22PY153
