2004 Lexus GX470 Engine / LEXUS 2004 GX470 FROM JAN. 2004 THROUGH JUL. 2004 PROD. OWNER'S MANUAL (OM60A87U)

Finish
SECTION 1 ± 4
77
INSTRUMENTS AND CONTROLS
Interior equipment
Sun visors78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated entry system 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . .
Power outlets 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear console box 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener 88
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holders 91
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead console box 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary box 95
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning reflector holder 97
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . .
Coat hooks 97
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover 98
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie-down hooks s 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Finish
INTERIOR EQUIPMENT
78
SUN VISORS
To block out glare, move the sun visor as shown.
1To block out glare from the front, swing the sun visor
down.
2To block out glare from the side, remove the sun visor
from the hook and swing it to the side.
3To block out glare coming obliquely from behind you,
slide the visor backwards.
At this position, the vanity light does not come on.
4To block out glare from the front with the sun visor in
the position 2
or 3
, swing the other sun visor
down.
INTERIOR LIGHTS
Center
Vehicles with rear seat audio system
Vehicles without rear seat audio system

Finish
INTERIOR EQUIPMENT
79
To turn on the interior light, slide the switch.
The interior light switch has the following positions:
ONº Ð Keeps the light on all the time.
OFFº Ð Turns the light off.
DOORº Ð Turns the light on when any side door is opened.
The light goes off when all the doors are closed. For details,
see Illuminated entry systemº on page 78.
Rear
To turn on the interior light, slide the switch.
The interior light switch has the following positions:
ONº Ð Keeps the light on all the time.
OFFº Ð Turns the light off.
DOORº Ð Turn the light on when the back door is opened.
The light goes out immediately when the back door is closed.

Finish
INTERIOR EQUIPMENT
80
PERSONAL LIGHTS
1DOORº position2OFFº position
To turn on the personal light, push the lens. To turn the
light off, push the lens once again.
The personal light switch has the following positions:
DOORº Ð Turn the lights on when any side door is opened
without pushing the lens. The light goes off when all the doors
are closed. For details, see Illuminated entry systemº on page
78.
OFFº Ð Turn the lights on only when you push the lens.
ILLUMINATED ENTRY SYSTEM
14PY027

Finish
INTERIOR EQUIPMENT
81

1Foot lights
2Ignition switch light
3Personal lights (with the DOORº position)
4Center console spot lights
5Inside door handle lights
6Center interior light (with the DOORº position)
7Running board lights
All of the lights except the center console spot lights will
come on when any of the side doors are opened.* After all
the doors are closed, the lights remain on for about 15
seconds before fading out.**
NOTE:
* The operating condition can be changed.** The duration of lighting can be changed, and the footlights and inside door handle lights can be set not to comeon.Ask your Lexus dealer for details.
However, in the following cases, the lights go out immediately:
 All of the lights except the center console spot lights Ð All
the side doors and back door are locked.
 Ignition switch light, personal lights and center interior light
Ð All the side doors are closed and the ignition key is in the
ACCº or ONº position.
 Running board lights Ð The vehicle speed exceeds about
8 km/h (5 mph). When
any of the side doors is unlocked, all of the lights except
the center console spot lights will come on and remain on for
about 15 seconds before fading out.
To prevent the battery being discharged, all of the lights will
automatically turn off when the ignition key removed and the
door is left opened for about 30 minutes.
Ignition switch light, personal lights and center interior
light
The ignition switch light, personal lights and center interior light
also come on and remain on for about 15 seconds before
fading out when the ignition switch is turned to the LOCKº
position.
Foot lights and inside door handle lights
The foot lights and inside door handle lights also come on when
the ignition switch is in the ONº position with the selector lever
in the Pº position. When the selector lever is moved out of the
Pº position, the foot lights and inside door handle lights will be
dimmed.*
NOTE: * The foot lights and inside door handle lights can be set toturn off when the selector lever is moved out of the Pºposition.
Ask your Lexus dealer for details.
Center console spot lights
The center console spot lights come on when the ignition
switch is in the ACCº or ONº position.

Finish
INTERIOR EQUIPMENT
82
CIGARETTE LIGHTER ANDASHTRAY
Front
To use the cigarette lighter and ashtray, first push against
the cigarette lighter and ashtray covers. Then when the
cigarette lighter cover opens, press in the cigarette lighter.
After it finishes heating up, it automatically pops out ready
for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in the
ACCº position to use the lighter. When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, push it back in completely.
To remove the ashtray, press down on the lock spring plate and
pull out.
Use a Lexus genuine cigarette lighter or equivalent for
replacement.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always completely close the
ashtray after use.

Finish
INTERIOR EQUIPMENT
83
Rear
To use the ashtray, raise the lid.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, close the lid completely.
To remove the ashtray, raise the lid and pull it out.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always completely close the
ashtray after use.
POWER OUTLETS
12 VDC
The power outlet is designed for power supply for car
accessories.
The ignition key must be in the ACCº or ONº position for the
power outlet to be used.

Finish
INTERIOR EQUIPMENT
84
NOTICE
To prevent the fuse from being blown, do not use theelectricity over the total vehicle capacity of 12VDC/120W.
To prevent the battery from being discharged, do notuse the power outlet longer than necessary when theengine is not running.
Close the power outlet lid when the power outlet isnot in use. Inserting anything other than anappropriate plug that fits the outlet, or allowing anyliquid to get into the outlet may cause electricalfailure or short circuits.
11 5 VA C
This power outlet is designed for use as a power supply
for electric appliances in the vehicle. The key must be in the ONº position for the power outlet to be
used.
The maximum capacity for this power outlet is 115 V
AC/100W.
If you attempt to use an appliance that requires more than 115
VAC or 100W, the protection circuit will activate and cut the
power supply. The power supply will restart automatically
when you use an appliance that operates within the 115
VAC/100W limits.
