2004 INFINITI QX56 reset

GW-70
FRONT DOOR GLASS AND REGULATOR
Revision: August 20072004 QX56
FRONT DOOR GLASS REGULATOR
Removal
1. Remove the front door speaker. Refer to AV- 4 5 , "Removal and Installation of Front Door Speaker" .
2. Remove the hole cover over rear door glass bolt.
3. Temporarily reconnect the power window switch to the door harness.
4. Operate the power window main switch to raise/lower the door glass until the door glass bolts can be
seen.
5. Remove the inside seal.
6. Remove the door glass bolts.
7. Raise the front door glass and hold it in place with suitable tool
(A).
8. Disconnect the harness connector from the regulator assembly.
9. Remove the bolts and the regulator assembly.
Inspection After Removal
Check the regulator assembly for the following items. If a malfunc-
tion is detected, replace or grease it.

Wire wear

Regulator deformation

Grease condition for each sliding part
The arrows in the figure show the application points of the body
grease.
Disassembly
Remove the regulator motor from the regulator assembly.
Installation
1. Install the regulator assembly. Refer to GW-69, "Removal and Installation" .
2. Connect the harness connector to the regulator assembly.
3. Align the door glass and install the door glass bolts.
4. Reset the limit switch. Refer to GW-71, "
Setting of Limit Switch" .
5. Install front door speaker. Refer to AV- 4 5 , "
Removal and Installation of Front Door Speaker" .
FITTING INSPECTION AND SETTING AFTER INSTALLATION
Fitting

Check that the door glass is securely fit into the door glass run groove.

Lower the door glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)] and check that the clearance to
the sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts,
guide rail bolts, and door glass and guide rail bolts to correct the door glass position.
WIIA0767E
LIIA0670E
Door glass bolts : 6.1 N·m (0.62 kg-m, 54 in-lb)

FRONT DOOR GLASS AND REGULATOR
GW-71
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
Setting of Limit Switch
If any of the following work has been done, set the limit switch (integrated in the motor).

Removal and installation of the regulator.

Removal and installation of the motor from the regulator.

Removal and installation of the door glass.

Removal and installation of the door glass run.
Resetting
After installing each component, perform the following procedure to reset the limit switch.
1. Raise the door glass to the top position.
2. While pressing and holding the reset switch, lower the door
glass to the bottom position.
3. Release the reset switch. Verify that the reset switch returns to the original position, if not, pull the switch
using suitable tool.
4. Raise the door glass to the top position.
CAUTION:
Do not operate the door glass automatically to raise the door glass to the top position.
SIIA0347E

RF-1
ROOF
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION RF
A
B
RF
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
Precautions .............................................................. 2
PREPARATION ........................................................... 3
Special service tool .................................................. 3
Commercial Service Tool ......................................... 3
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 4
Work Flow ................................................................ 4
CUSTOMER INTERVIEW ..................................... 4
DUPLICATE THE NOISE AND TEST DRIVE ....... 5
CHECK RELATED SERVICE BULLETINS ........... 5
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 5
REPAIR THE CAUSE ........................................... 5
CONFIRM THE REPAIR ....................................... 6
Generic Squeak and Rattle Troubleshooting ........... 6
INSTRUMENT PANEL .......................................... 6
CENTER CONSOLE ............................................. 6
DOORS ................................................................. 6
TRUNK .................................................................. 7
SUNROOF/HEADLINING ..................................... 7
OVERHEAD CONSOLE (FRONT AND REAR) ..... 7
SEATS ................................................................... 7
UNDERHOOD ....................................................... 7
Diagnostic Worksheet .............................................. 8
SUNROOF ................................................................ 10
Component Parts and Harness Connector Location ... 10
System Description ................................................ 10
OUTLINE ............................................................. 10
OPERATION ....................................................... 10RETAINED POWER OPERATION ...................... 11
MEMORY RESET PROCEDURE ....................... 11
INTERRUPTION DETECTION FUNCTION ........ 11
CAN Communication System Description .............. 12
Wiring Diagram — SROOF — ................................ 13
Terminals and Reference Values for BCM .............. 15
Terminals and Reference Values for Sunroof Motor
Assembly ................................................................ 15
Work Flow ............................................................... 15
CONSULT-II Function (BCM) ................................. 16
CONSULT-II OPERATION ................................... 16
Work Support .......................................................... 17
Active Test .............................................................. 17
Data Monitor ........................................................... 17
Trouble Diagnosis Chart by Symptom .................... 17
BCM Power Supply and Ground Circuit Check ...... 18
Sunroof Switch System Check ............................... 19
Sunroof Motor Assembly Power Supply and Ground
Circuit Check .......................................................... 20
Door Switch Check ................................................. 22
Fitting Adjustment ................................................... 24
GAP ADJUSTMENT ............................................ 24
HEIGHT DIFFERENCE ADJUSTMENT .............. 24
Removal and Installation ........................................ 24
SUNROOF UNIT ................................................. 26
GLASS LID .......................................................... 26
WIND DEFLECTOR ............................................ 27
SUNSHADE ........................................................ 27
SUNROOF MOTOR ............................................ 27
DRAIN HOSES .................................................... 28
WEATHERSTRIP ................................................ 29
LINK AND WIRE ASSEMBLY ............................. 29

SUNROOF
RF-11
C
D
E
F
G
H
J
K
L
MA
B
RF
Revision: August 20072004 QX56
TILT UP OPERATION
When the tilt switch is operated for tilt up, ground is supplied

to sunroof motor assembly terminal 4

through sunroof switch terminal 4

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through sunroof motor assembly terminal 7

through grounds M57, M61 and M79.
Then, the sunroof will tilt up.
TILT DOWN OPERATION
When the tilt switch is operated for tilt down, ground is supplied

to sunroof motor assembly terminal 10

through sunroof switch terminal 6

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through sunroof motor assembly terminal 7

through grounds M57, M61 and M79.
Then, the sunroof will tilt down.
SLIDE OPEN OPERATION
When the switch is operated for slide open, ground is supplied

to sunroof motor assembly terminal 9

through sunroof switch terminal 3

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through sunroof motor assembly terminal 7

through grounds M57, M61 and M79.
Then, the sunroof will slide open.
SLIDE CLOSE OPERATION
When the switch is operated for slide close, ground is supplied

to sunroof motor assembly terminal 3

through sunroof switch terminal 1

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through sunroof motor assembly terminal 7

through grounds M57, M61 and M79.
Then, the sunroof will slide closed.
RETAINED POWER OPERATION
When the ignition switch is turned to OFF position from ON or START position, power is supplied for 45 sec-
onds.
The retained power operation is canceled when the driver or passenger side door is opened.
RAP signal period can be changed by CONSULT-II. Refer to RF-16, "
CONSULT-II Function (BCM)" .
MEMORY RESET PROCEDURE
To reset the sunroof motor memory from any sunroof position (full open, partially open, closed, partially
vented, and vented), push and hold the sunroof tilt switch in the forward (DOWN) position until the sunroof is
fully closed. After it has closed all the way, push and hold the tilt switch forward (DOWN) for more than 2 sec-
onds to re-establish the motor preset position. The sunroof should now operate normally.
INTERRUPTION DETECTION FUNCTION
The CPU (central processing unit) monitors the sunroof motor operation and the sunroof position (fully-closed
or other) by the signals from the sunroof motor.

RF-28
SUNROOF
Revision: August 20072004 QX56
1. Move the sunroof motor assembly laterally little by little so that
the gear is completely engaged into the wire on the sunroof unit
and the mounting surface becomes parallel. Then secure the
motor with bolts.
2. Connect the wire harness connector to the sunroof motor
assembly.
3. Install the roof console assembly. Refer to EI-37, "
HEADLINING" .
4. Reset the sunroof motor memory. Refer to RF-11, "
MEMORY RESET PROCEDURE" .
DRAIN HOSES
LIIA0270E
WIIA0239E

SE-14
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
MEMORY STORING AND KEYFOB INTERLOCK STORING

Store the 2 driving positions and shifts to the stored driving position with the memory switch.

Keyfob interlock function is set simultaneously with setting driving position memory. It can set driving posi-
tion to memory position.
NOTE:

If another keyfob interlock function setting is performed by same key, the newly registered setting is valid.

If a new memory string is performed to memory switch that already set keyfob interlock function, keyfob
interlock function setting is reset.

If the keyfob has not been previously programmed to the vehicle, keyfob interlock function cannot set.
LIIA1666E

SE-34
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
Preliminary CheckEIS002YF
SETTING CHANGE FUNCTION
The settings of the automatic driving positioner system can be changed, using CONSULT-II and the display in
the center of the instrument panel.
×: Applicable –: Not applicable
It is possible to set sliding front seat for entry/exit of vehicle by pressing set switch.
*: Setting of sliding front seat for entry/exit of vehicle is ON at factory-shipment. But if custom settings are reset, setting turns OFF.
NOTE:
After the setting is registered, the new setting is effective, even if the battery is disconnected.
POWER SUPPLY AND GROUND CIRCUIT INSPECTION
1. CHECK BCM FUSE
Check if any of the following fuses for the BCM are blown.
NOTE:
Refer to SE-11, "
Component Parts And Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to SE-
11 , "Component Parts And Harness Connector Location" .
Setting item ContentCONSULT–II
(WORK SUPPORT)Display unitDefault
settingFactory
setting
SEAT SLIDE
VOLUME SETThe distance at exiting opera-
tion can be selected from the
following 3 modes.40 mm
—××
80 mm — —
150 mm — —
Sliding Front Seat and
Steering Wheel Raise
When Entry/ Exiting
VehicleThe seat sliding and steering
wheel raise turnout and return
at entry/exit can be selected:
ON (operated)–OFF (not
operated)ON ON: Indicator lamp ON —×
OFF OFF: Indicator lamp OFF×—
Reset custom settings* All settings to default. —Default: Setting button
ON——
Content Setting change operation Indicator LEDs
The seat sliding and steering
wheel raise turnout and return
at entry/exit can be operated.
Press the set switch for more than 10 secondsBlinking twice
The seat sliding and steering
wheel raise turnout and return
at entry/exit can be not oper-
ated.Blinking once
Unit Power source Fuse No.
BCMBattery power supplyf (50A)
ON or START power supply 59 (10A)
ACC or ON power supply 4 (10A)

AUTOMATIC DRIVE POSITIONER
SE-41
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
ACTIVE TEST
CAUTION:
During vehicle driving, do not perform active test.
NOTE:
If active test is performed, reset seat memory and key fob interlock drive positioner after performing work.
DISPLAY ITEM LIST
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)EIS002YH
1. SELF-DIAGNOSTIC RESULT CHECK
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect to CONSULT-II, and select “AUTO DRIVE POS.” on the “SELECT DIAG SYSTEM” screen.
2. Select “SELF-DIAG RESULTS” on "SELECT DIAG MODE" screen.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>>Inspection End.
Malfunction in CAN communication system>>After printing the monitor items, go to “CAN System”. Refer to
LAN-3, "
Precautions When Using CONSULT-II" .
Symptom ChartEIS002YI
MIR/SEN LH U–D “V” Voltage output from LH door mirror sensor (UP/DOWN) is displayed.
PEDAL SEN “V”The pedal position (voltage) judged from the pedal adjust sensor signal is dis-
played. Monitor item [OPERATION or UNIT] Contents
Test item Description
SEAT SLIDE The sliding motor is activated by receiving the drive signal.
SEAT RECLINING The reclining motor is activated by receiving the drive signal.
SEAT LIFTER FR The lifting motor (front) is activated by receiving the drive signal.
SEAT LIFTER RR The lifting motor (rear) is activated by receiving the drive signal.
PEDAL MOTOR The pedal adjust motor is activated by receiving the drive signal.
MEMORY SW INDCTR The memory switch indicator is lit by receiving the drive signal.
MIRROR MOTOR RHThe RH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
MIRROR MOTOR LHThe LH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
CONSULT-II display code Diagnosis item
U1000INITIAL DIAG
TRANSMIT DIAG
BSM
METER/M&A
ECM
SymptomDiagnoses / service procedure Refer to
page
Only setting change function cannot be set with display.1. Preliminary checkSE-34
2. CAN communication inspection using CONSULT-II (self-
diagnosis)SE-41
3. If the above systems are normal, check display systemAV- 6 1
