SQUEAK AND RATTLE TROUBLE DIAGNOSES
GW-5
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
SQUEAK AND RATTLE TROUBLE DIAGNOSESPFP:00000
Work FlowAIS003A0
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to GW-9, "
Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.

The customer may not be able to provide a detailed description or the location of the noise. Attempt to
obtain all the facts and conditions that exist when the noise occurs (or does not occur).

If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
is concerned about. This can be accomplished by test driving the vehicle with the customer.

After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.

Squeak —(Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping

Creak—(Like walking on an old wooden floor)
Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
dependent on materials/often brought on by activity.

Rattle—(Like shaking a baby rattle)
Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.

Knock —(Like a knock on a door)
Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.

Tick—(Like a clock second hand)
Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
action or road conditions.

Thump—(Heavy, muffled knock noise)
Thump characteristics include softer knock/dead sound often brought on by activity.

Buzz—(Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.

Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
judge as acceptable may be very irritating to the customer.

Weather conditions, especially humidity and temperature, may have a great effect on noise level.
SBT842

IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
C
Camshaft inspection(VK45DE) ........................ EM-209
Camshaft inspection(VQ35DE) ......................... EM-84
Camshaft position sensor (PHASE) .. EC-308, EC-966
Camshaft(VK45DE) ......................................... EM-208
Camshaft(VQ35DE) ........................................... EM-82
CAN .................................................................... DI-29
CAN - Wiring diagram ......... EC-143, EC-793, LAN-22,
LAN-53
, LAN-89, LAN-135, LAN-169, LAN-208
CAN (Controller Area Network) . BL-25, BL-59, BL-93,
BL-185
, GW-22, GW-88, RF-13, SE-16, LAN-6, LAN-21,
LAN-52
, LAN-87, LAN-133, LAN-167, LAN-206
CAN communication EC-36, EC-142, EC-684, EC-792,
AT-31
, AT-105, TF-12, TF-31, WT-9, BRC-11, BL-25,
BL-59
, BL-93, BL-185, GW-22, GW-88, RF-13, SE-16,
WW-9
, LAN-6, LAN-21, LAN-52, LAN-87, LAN-133,
LAN-167
, LAN-206
Canister-See EVAP canister ........... EC-646, EC-1323
CHARGE - Wiring diagram ................................ SC-24
Charging system ................................................ SC-23
Chassis and body maintenance ........................ MA-28
CHIME - Wiring diagram ..................................... DI-59
CIGAR - Wiring diagram .................................. WW-52
Cigarette lighter ............................................... WW-52
Cigarette lighter illumination ............................. LT-156
Circuit breaker ................................................... PG-17
Clock ................................................................... DI-79
CLOCK - Wiring diagram .................................... DI-79
Closed loop control .............................. EC-33, EC-680
Collision diagnosis ........................................... SRS-56
Combination lamp, rear, removal and installation ........
LT-147
Combination meter ............................................... DI-4
Combination meter removal and installation - See
Instrument panel .................................................. IP-11
COMM - Wiring diagram ...................... AV-69, AV-116
COMPAS - Wiring diagram ................................. DI-37
Compass ............................................................ DI-35
Component Location (auto A/C) ...................... ATC-43
Compression pressure(VK45DE) .................... EM-224
Compression pressure(VQ35DE) ...................... EM-98
Compressor clutch removal and installation .. ATC-143
Compressor special service tool ...................... ATC-17
Condenser ..................................................... ATC-154
Connecting rod bearing clearance(VK45DE) .. EM-263
Connecting rod bearing clearance(VQ35DE) .. EM-138
Connecting rod bushing clearance(VK45DE) .. EM-258
Connecting rod bushing clearance(VQ35DE) . EM-138
Connecting rod(VK45DE) ................................ EM-258
Connecting rod(VQ35DE) ................................ EM-136
Console box - See Instrument panel ................... IP-10
CONSULT for VDC ......................................... BRC-25
CONSULT-II Reference value (A/T) .................. AT-91
Control units (terminal arrangement) ................. PG-77
Control valve (A/T) ............................................. AT-36
Controller Area Network (CAN) . BL-25, BL-59, BL-93,
BL-185
, GW-22, GW-88, RF-13, SE-16, LAN-6, LAN-21,
LAN-52
, LAN-87, LAN-133, LAN-167, LAN-206
Converter housing installation ........... AT-268, AT-272
COOL/F - Wiring diagram ................ EC-477, EC-1145
Coolant replacement(VQ35DE) ........................ MA-15
Cooling circuit (engine)(VK45DE) ..................... CO-34
Cooling circuit (engine)(VQ35DE) ...................... CO-9
Cooling fan motor ............................ EC-484, EC-1151
Cooling fan(VK45DE) ....................................... CO-47
Cooling fan(VQ35DE) ....................................... CO-21
Cowl top .............................................................. EI-24
Cowl top cover .................................................... EI-24
Crankcase ventilation system - See Positive crankcase
ventilation ......................................... EC-655
, EC-1332
Crankshaft position sensor (POS) ..... EC-302, EC-960
Crankshaft(VK45DE) ...................................... EM-241
Crankshaft(VQ35DE) ...................................... EM-136
Crash zone sensor .......................................... SRS-45
Cylinder block boring(VK45DE) ...................... EM-261
Cylinder block(VK45DE) ................................. EM-240
Cylinder block(VQ35DE) ................................. EM-120
Cylinder head bolt tightening(VK45DE) .......... EM-226
Cylinder head bolt tightening(VQ35DE) .......... EM-101
Cylinder head(VK45DE) ................................. EM-224
Cylinder head(VQ35DE) ................................... EM-98
D
D/LOCK - Wiring diagram ....................... BL-27
, BL-33
Daytime light system ........................................... LT-38
Daytime running light - See Daytime light system LT-38
Diagnosis sensor unit ..................................... SRS-48
Diagnostic trouble code (DTC) for OBD system EC-15,
EC-662
Direct clutch solenoid valve ............... AT-160, AT-162
Display and amp.assembly ............... ATC-51, ATC-63
Door glass ........................................... GW-76, GW-80
Door glass Fitting Adjustment(Front) ................ GW-78
Door glass Fitting Adjustment(Rear) ................. GW-83
Door lock .......................................................... BL-152
Door mirror ...................................................... GW-113
Door trim ............................................................. EI-35
Door, front ........................................... BL-148, GW-76
Door, rear ............................................ BL-148, GW-80
Drive belt inspection ......................................... MA-21
Drive belt inspection(VQ35DE) ......................... MA-14
Drive belt(VK45DE) ........................................ EM-169
Drive belt(VQ35DE) .......................................... EM-15
Drive pinion diff. inspection ............................. RFD-13
Drive shaft ......................................................... MA-37
Drive shaft (rear) ............................................... RAX-9
Driver air bag .................................................. SRS-36
DTRL - Wiring diagram ....................................... LT-41
Duct and grilles .............................................. ATC-133
E
ECM power supply EC-136
, EC-404, EC-785, EC-1060
ECM/PW - Wiring diagram ............... EC-405, EC-1061
ECTS - Wiring diagram ...................... EC-187, EC-844
Electric sunroof .................................................. RF-10

IP-4
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2004 November 2004 FX35/FX45
SQUEAK AND RATTLE TROUBLE DIAGNOSESPFP:00000
Work FlowAIS003CF
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to IP-8, "
Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.

The customer may not be able to provide a detailed description or the location of the noise. Attempt to
obtain all the facts and conditions that exist when the noise occurs (or does not occur).

If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
is concerned about. This can be accomplished by test driving the vehicle with the customer.

After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.

Squeak —(Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping

Creak—(Like walking on an old wooden floor)
Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
dependent on materials/often brought on by activity.

Rattle—(Like shaking a baby rattle)
Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.

Knock —(Like a knock on a door)
Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.

Tick—(Like a clock second hand)
Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
action or road conditions.

Thump—(Heavy, muffled knock noise)
Thump characteristics include softer knock/dead sound often brought on by activity.

Buzz—(Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.

Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
judge as acceptable may be very irritating to the customer.

Weather conditions, especially humidity and temperature, may have a great effect on noise level.
SBT842

INSTRUMENT PANEL ASSEMBLY
IP-11
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: 2004 November 2004 FX35/FX45
Removal and InstallationAIS003CJ
WORK STEP
When removing instrument panel and pad, combination meter, display unit and audio unit, center console take
steps in the order shown by the numbers below.
CAUTION:

Disconnect both battery cables in advance.

Disconnect air bag system line in advance.

Never temper with air bag lid or force air bag lid to open, as this may adversely affect air bag per-
formance.

Be careful not to scratch pad and other parts.
1. Front defroster grille (RH) 2. Instrument panel and pad 3. Front defroster grille (LH)
4. Screw 5. Bolt 6. Combination meter assembly
7. Steering lock escutcheon 8. Side ventilation (LH) 9. Display unit and audio unit
10. Wiper and washer switch 11. Clip 12. Rubber
13. Lighting and turn signal switch 14. Combination meter bracket 15. Cluster lid C
16. Steering column upper cover 17. Steering column lower cover 18. Steering column front lower cover
19. Instrument side panel (LH) 20. Instrument clock finisher 21. A/T console finisher
22. Instrument driver lower panel 23. Console finisher (LH) 24. Center console
25. Console finisher (RH) 26. Instrument side panel (RH) 27. Instrument lower cover
28. Instrument passenger lower panel 29. Side ventilation (RH) 30. Front passenger air bag module
Parts Refer toInstrument
panel and padCombination
meterDisplay unit and
audio unit Center console
A Front kicking plate (LH/RH)EI-39
(1) (1)
B Dash side finisher (LH/RH)EI-38
(2) (2)
C Front pillar garnish (LH/RH)EI-39
(3)
D A/T select lever knobAT- 2 3 3
(4) (1)
E Instrument clock finisherIP-12
(5) (2)
F A/T console finisherIP-12
(6) (3)
G Console finisher (LH/RH)IP-12
(7) (4)
H Center consoleIP-12
(8) (5)
I Instrument lower cover IP-13
(9)
J Instrument passenger lower panelIP-13
(10)
K Instrument driver lower panelIP-13
(11) (3)
L Steering column front lower coverIP-13
(12) (4)
M Steering column lower coverIP-13
(13) (5)
N Steering column upper coverIP-14
(14) (6)
O Wiper and washer switchIP-14
(15) (7)
P Lighting and turn signal switchIP-14
(16) (8)
Q Steering lock escutcheonIP-14
(17) (9)
R Combination meter assemblyIP-14
(18) (10)
S Instrument side panel (LH/RH) IP-14
(19)
T Cluster lid CIP-15
(20) (1)
U Display unit and audio unitIP-15
(21) (2)
V Front defroster grille (LH/RH)IP-15
(22)
W Combination meter bracketIP-15
(23)
X Side ventilation (LH)IP-16
(24)
Y Instrument panel and padIP-16
(25)

IP-12
INSTRUMENT PANEL ASSEMBLY
Revision: 2004 November 2004 FX35/FX45
( ): Number indicates step in removal procedures.
REMOVAL
(A) Front Kicking Plate (LH/RH)
Remove front kicking plate (LH/RH). Refer to EI-37, "BODY SIDE TRIM" .
(B) Dash Side Finisher (LH/RH)
1. Remove plastics nut.
2. Remove dash side finisher (LH/RH). Refer to EI-37, "
BODY SIDE TRIM" .
(C) Front Pillar Garnish (LH/RH)
Pull to inside of vehicle, disengage metal clips and remove front pillar garnish. Refer to EI-37, "BODY SIDE
TRIM" .
(D) A/T Select Lever Knob
1. Pull down knob cover.
2. Remove lock-pin of select lever knob.
3. Lift up select lever knob and remove it. Refer to AT- 2 3 3 , "
Control Device Removal and Installation" .
(E) Instrument Clock Finisher
1. Insert a remover into side between gaps of instrument clock fin-
isher and pull back to your side.
2. Disconnect clips and harness connector, and remove instrument
clock finisher.
(F) A/T Console Finisher
1. Insert a remover into side between gaps of A/T console finisher
and remove by lifting A/T console finisher.
2. Disconnect harness connector.
(G) Console Finisher (LH/RH)
1. Remove screws with power tool.
2. Remove console finisher (LH/RH).
(H) Center Console
1. Remove screws with power tool.
2. Remove console sub-harness
PIIA4997E
PIIA4996E
PIIA5001E

HEADLAMP - XENON TYPE -
LT-35
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
ADJUSTMENT USING AN ADJUSTMENT SCREEN (LIGHT/DARK BORDERLINE)
If the vehicle front body has been repaired and/or the headlamp assembly has been replaced, check aiming.
Use the aiming chart shown in the figure.

Basic illumination area for adjustment should be within the range shown on the aiming chart.
Adjust headlamp accordingly.
CAUTION:
Be sure aiming switch is set to “0” when performing aiming
adjustment.
Bulb ReplacementAKS007MW
HEADLAMP HIGH/LOW BEAM
1. Turn lighting switch OFF.
2. Disconnect negative battery cable or remove power fuse.
3. Remove air cleaner case (LH) or radiator reservoir tank (RH).
Refer to EM-17, "
Removal and Installation" , EM-172, "Removal
and Installation" , CO-14, "Removal and Installation" , CO-39,
"Removal and Installation" .
4. Turn plastic cap counterclockwise and unlock it.
5. Turn bulb socket counterclockwise and unlock it.
6. Unlock retaining spring and remove bulb from headlamp.
7. Install in the reverse order of removal.
SKIA5545E
SKIA5546E
SKIA5549E

LT-36
HEADLAMP - XENON TYPE -
Revision: 2004 November 2004 FX35/FX45
NOTE:
After installation, perform aiming adjustment. Refer to LT- 3 4 , "
Aiming Adjustment" .
PARKING LAMP (CLEARANCE LAMP)
1. Turn lighting switch OFF.
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb from its socket.
4. Install in the reverse order of removal.
FRONT TURN SIGNAL LAMP
1. Turn lighting switch OFF.
2. Turn bulb socket counterclockwise with suitable tool and unlock
it.
3. Remove bulb from its socket.
4. Install in the reverse order of removal.
FRONT SIDE MARKER LAMP
1. Turn lighting switch OFF.
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb from its socket.
4. Install in the reverse order of removal.
CAUTION:
After installing bulb, be sure to install plastic cap and bulb
socket securely to insure watertightness.
Removal and InstallationAKS007MX
REMOVAL
1. Disconnect the battery negative cable.
2. Remove front bumper. Refer to EI-14, "
Removal and Installa-
tion" in “EI” section.
3. Remove headlamp mounting bolts.
4. Remove plastics bumper bracket, then pull headlamp toward
vehicle front, disconnect connector, and remove headlamp.
INSTALLATION
Note the following, and install in the reverse order of removal. Headlamp high/low beam (Xenon) : 12V - 35W (D2S)
Parking lamp (Clearance lamp) : 12V - 5W
SKIA5550E
Front turn signal lamp : 12V - 21W (amber)
SKIA6182E
Front side marker lamp : 12V - 3.8W
SKIA5552E
SKIA5553E

HEADLAMP - XENON TYPE -
LT-37
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
NOTE:
After installation, perform aiming adjustment. Refer to LT- 3 4 , "
Aiming Adjustment" .
Disassembly and Assembly AKS007MY
DISASSEMBLY
1. Turn plastic cap counterclockwise and unlock it.
2. Turn xenon bulb socket counterclockwise, and unlock it.
3. Unlock retaining spring, and remove xenon bulb.
4. Disconnect HID control unit connector, and remove HID control unit screws.
5. Turn parking lamp bulb socket counterclockwise and unlock it.
6. Remove parking lamp bulb from its socket.
7. Turn front turn signal lamp bulb socket counterclockwise and unlock it.
8. Remove front turn signal lamp bulb from its socket.
9. Turn front side marker lamp bulb socket counterclockwise and unlock it.
10. Remove front side marker lamp bulb from its socket.
ASSEMBLY
Note the following, and assemble in the reverse order of disassembly.
CAUTION:

When HID control unit is removed, reinstall it securely and avoid any looseness.

After installing bulb, be sure to install plastic cap and bulb socket securely to insure watertight-
ness. Headlamp mounting bolt
: 6.1 N·m (0.62 kg-m, 54 in-lb)
1. Headlamp housing assembly 2. Side marker lamp bulb 3. Side marker lamp bulb socket
4. Plastic cap 5. Seal packing 6. Screw
7. HID C/U 8. Parking lamp (Clearance lamp) bulb socket 9. Parking lamp (Clearance lamp) bulb
10. Retaining spring 11. Front turn signal lamp bulb 12. Front turn signal lamp bulb socket
13. Xenon bulb 14. Xenon bulb socket 15. Seal packing
PKIA6525E
HID control unit mounting screw
: 3.2 N·m (0.33 kg-m, 28 in-lb)
