2004 INFINITI FX35 Lock

REAR COMBINATION LAMP
LT-147
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
REAR COMBINATION LAMPPFP:26554
Bulb ReplacementAKS007FP
REAR FENDER SIDE (REAR SIDE MARKER LAMP BULB)
1. Remove rear combination lamp.
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb.
BACK DOOR SIDE (BACK-UP LAMP)
1. Remove rear combination lamp.
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb.
Removal and InstallationAKS007FQ
REMOVAL
Rear Fender Side
1. Remove bumper side cover A. Refer to EI-18, "Removal and
Installation" in “EI” section.
2. Disconnect rear combination lamp connector.
3. Remove rear combination lamp mounting bolts.
4. Pull rear combination lamp toward side of the vehicle and
remove from the vehicle.
SKIA5569E
SKIA5570E
Stop/tail lamp (rear fender side) : LED (Replace together with rear combination
lamp assembly.)
Rear side marker lamp (rear fender side) : 12V - 3.8W
Back-up lamp (back door side) : 12V - 18W
Rear turn signal lamp (rear fender side) : LED (Replace together with rear combination
lamp assembly.)
SKIA5571E

IGNITION KEY HOLE ILLUMINATION
LT-153
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
IGNITION KEY HOLE ILLUMINATIONPFP:48476
Bulb Replacement, Removal and InstallationAKS007FR
1. Remove combination meter. Refer to DI-26, "Removal and
Installation" in “DI” section.
2. Remove screw and remove NATS antenna amp.
3. Pull out ring and turn bulb socket to left to release lock.
4. Install in the reverse order of removal.Key cylinder illumination : 12V - 1.4W
SKIA5575E

LT-154
GLOVE BOX LAMP
Revision: 2004 November 2004 FX35/FX45
GLOVE BOX LAMPPFP:68520
Bulb Replacement, Removal and InstallationAKS007FS
1. Remove instrument passenger lower panel. Refer to IP-13, "(J)
Instrument Passenger Lower Panel" in “IP” section.
2. Turn bulb socket left to release lock and remove it.
3. Install in the reverse order of removal.Glove box lamp : 12V - 1.4W
SKIA5576E

ASHTRAY ILLUMINATION
LT-155
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
ASHTRAY ILLUMINATIONPFP:25860
Bulb Replacement and Removal and InstallationAKS007NZ
1. Remove A/T console finisher. Refer to IP-12, "(F) A/T Console Finisher" in “IP” section.
2. Remove instrument ashtray and hazard switch. Refer to IP-17,
"A/T CONSOLE FINISHER" in “IP” section.
3. Use a screwdriver to undo ashtray finisher hooks.
4. Turn bulb socket on circuit board to left to undo lock. Remove
bulb socket.
5. Install in the reverse order of removal.
Ashtray and cigarette
lighter illumination: 12V - 1.4W
PKIA2850E

INTERIOR ROOM LAMP
LT-157
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
INTERIOR ROOM LAMPPFP:26410
Component Parts and Harness Connector LocationAKS007O8
System DescriptionAKS007F7
When room lamp and personal lamp switch is in DOOR position, room lamp and personal lamp ON/OFF is
controlled by timer according to signals from switches including key switch, front door switch driver side,
unlock signal from keyfob, door lock and unlock switch, key cylinder lock and unlock switch, ignition switch.
When room lamp and personal lamp turns ON, there is a gradual brightening over 1 second. When room lamp
and personal lamp turns OFF, there is a gradual dimming over 1 second.
The room lamp and personal lamp timer is controlled by the BCM (body control module).
Room lamp and personal lamp timer control settings can be changed with CONSULT-II.
Ignition keyhole illumination turns ON at time when driver door is opened (door switch ON) or removed keyfob
from key cylinder. Illumination turns OFF when driver door is closed (door switch OFF).
Step lamp turns ON at time when driver door or passenger door is opened (door switch ON). Lamp turns OFF
when driver, passenger doors are closed (all door switches OFF).
POWER SUPPLY AND GROUND
Power is supplied at all times (without intelligent key system)

through 15A fuse [No. 22, located in fuse block (J/B)]

to key switch terminal 2 and

to BCM (body control module) terminal 42

through 50A fusible link [letter M, located in fuse and fusible link block]

to BCM (body control module) terminal 55.
Power is supplied at all times (with intelligent key system)

through 10A fuse [No.38, located in fuse and fusible link block]

to key switch and ignition knob switch terminals 1

through 15A fuse [No.22, located in fuse block (J/B)]

to BCM (body control module) terminal 42

to key switch and ignition knob switch terminal 3, and

to key switch terminal 2

through 50A fusible link [letter M, located in fuse and fusible link block]

to BCM (body control module) terminal 55.
When the key plate inserted to key switch, power is supplied (without intelligent key system)

through the key switch terminal 1

to BCM (body control module) terminal 37.
PKIA2923E

LT-158
INTERIOR ROOM LAMP
Revision: 2004 November 2004 FX35/FX45
When inserted the key plate to key switch, power is supplied (with intelligent key system)

through the key switch and ignition knob switch terminal 4

to BCM (body control module) terminal 37.
When moved the ignition knob switch, power is supplied (with intelligent key system)

through the ignition knob switch terminal 2

to intelligent key unit terminal 27.
With the ignition switch in the ON or START position, power is supplied

through 15A fuse [No. 1, located in fuse block (J/B)]

to BCM (body control module) terminal 38.
Ground is supplied

to BCM (body control module) terminals 49 and 52

through grounds terminals M35, M45 and M85.
When the driver side door is opened, ground is supplied

through case ground of door switch driver side

to BCM (body control module) terminal 62.
When the passenger side door is opened, ground is supplied

through case ground of door switch passenger side

to BCM (body control module) terminal 12.
When the rear door LH is opened, ground is supplied

through case ground of door switch rear door LH

to BCM (body control module) terminal 63, and

to personal lamp LH terminal 1.
When the rear door RH is opened, ground is supplied

through case ground of door switch rear door RH

to BCM (body control module) terminal 13, and

to personal lamp RH terminal 1.
When the driver side door is unlocked by the door lock and unlock switch, BCM (body control module)
receives a ground signal

through grounds terminals M35, M45 and M85

to power window main switch terminal 17 (door lock and unlock switch) or front power window (passenger
side) terminal 11 (door lock and unlock switch)

from power window main switch terminal 14 (door lock and unlock switch) or front power window (passen-
ger side) terminal 16 (door lock and unlock switch)

to BCM (body control module) terminal 22.
When the front driver side door is unlocked by the driver side door lock assembly (door key cylinder switch),
BCM (body control module) receives a ground signal

through grounds M35, M45 and M85

to front door lock assembly (driver side) (door key cylinder switch) terminal 5

from front door lock assembly (driver side) (door key cylinder switch) terminal 6

to power window main switch terminal 6 (door lock and unlock switch)

from power window main switch terminal 14 (door lock and unlock switch)

to BCM (body control module) terminal 22.
When a signal, or combination of signals is received by BCM (body control module), ground is supplied

through BCM (body control module) terminal 48

to interior room lamp terminal 1(without DVD player),

to map lamp terminal 2 and

to front door inside handle illumination (driver side and passenger side) terminal 2
With power and supplied, the interior lamp illuminates.

INTERIOR ROOM LAMP
LT-159
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
SWITCH OPERATION
When driver door switch is ON (door is opened), ground is supplied

through BCM terminal 1

to ignition keyhole illumination terminal 2.
And power is supplied

from BCM terminal 41

to ignition keyhole illumination terminal 1.
When any door switch is ON (door is opened), ground is supplied

through BCM terminal 47

to front step lamp driver side and passenger side, rear step lamp (LH and RH)

through rear door switch terminal 1

to personal lamp (LH and RH) terminal 1.
And power is supplied

from BCM terminal 41

to every step lamp terminal 1, and personal lamp (LH and RH) terminal 2.
When map lamp switch is ON, ground is supplied

through grounds M35, M45 and M85

to map lamp terminal 1.
And power is supplied

from BCM terminal 41

to map lamp terminal 3.
When vanity mirror lamp (driver side and passenger side) is ON, ground is supplied

through grounds M35, M45 and M85

to vanity mirror lamp (driver side and passenger side) terminal 2.
And power is supplied

from BCM terminal 41

to vanity mirror lamp (driver side and passenger side) terminal 1.
When luggage room lamp (back door side) is ON, ground is supplied

through grounds B15 and B45

to luggage room lamp (back door side) terminal 3.
And power is supplied

from BCM terminal 41

to luggage room lamp (body side and back door side) terminal 2.
ROOM LAMP TIMER OPERATION
Without Intelligent Key System
When interior room lamp and map lamp switch is in DOOR position, and when all conditions below are met,
BCM performs timer control (maximum 30 seconds) for interior room lamp and map lamp ON/OFF.
In addition, when spot turns ON or OFF there is gradual brightening or dimming over 1 second.
Power is supplied

to 15A fuse [No. 22, located in fuse block (J/B)]

through key switch terminal 2.
Key is removed from ignition key cylinder (key switch OFF), power will not be supplied to BCM terminal 37.
Ground is supplied

from BCM terminal 22

to power window main switch (door lock and unlock switch) terminal 14.
At the time that driver door are opened, BCM detects that driver door is unlocked. It determines that interior
room lamp and map lamp timer operation conditions are met, and turns the interior room lamp and map lamp
ON for 30 seconds.
Key is in ignition key cylinder (key switch ON),
Power is supplied

LT-160
INTERIOR ROOM LAMP
Revision: 2004 November 2004 FX35/FX45

through key switch terminal 1

to BCM terminal 37.
When key is removed from key switch (key switch OFF), power supply to BCM terminal 37 is terminated. BCM
detects that key has been removed, determines that interior room lamp and map lamp timer conditions are
met, and turns the interior room lamp and map lamp ON for 30 seconds.
When driver door opens → closes, and the key is not inserted in the key switch (key switch OFF), BCM termi-
nal 62 changes between 0V (door open) → 12V (door closed). The BCM determines that conditions for inte-
rior room lamp and map lamp operation are met and turns the interior room lamp ON for 30 seconds.
Timer control is canceled under the following conditions.

Driver door is locked [when locked keyfob or power window main switch (door lock and unlock switch),
door key cylinder switch].

Driver door is opened (driver door switch turns ON).

Ignition switch ON.
With Intelligent Key System
When interior room lamp and map lamp switch is in DOOR position, and when all conditions below are met,
BCM performs timer control (maximum 30 second) for interior room lamp and map lamp ON/OFF.
In addition, when spot turns ON or OFF there is gradual brightening or dimming over 1 second.
Power is supplied

to 15A fuse [No. 22, located in fuse and fuse block (J/B)]

through key switch and ignition knob switch terminal 3.
Key is removed from ignition key cylinder (key switch OFF), power will not be supplied to BCM terminal 37.
And not turned ignition knob switch, power will not be supplied to Intelligent Key unit.
Ground is supplied

from BCM terminal 22

to power window main switch (door lock and unlock switch) terminal 14.
At the time that driver door are opened, BCM detects that driver door is unlocked. It determines that interior
room lamp and map lamp timer operation conditions are met, and turns the interior room lamp and map lamp
ON for 30 seconds.
Key is in ignition key cylinder (key switch ON), or turned ignition knob switch,
Power is supplied

through key switch and ignition knob switch terminal 4

to BCM terminal 37

through key switch and ignition knob switch terminal 2

to Intelligent Key unit terminal 27.
When key is removed from key switch (key switch OFF), power supply to BCM terminal 37 is terminated. And
turned ignition knob switch, power supply to intelligent key unit is terminated. BCM detects that key has been
removed, determines that interior room lamp and map lamp timer conditions are met, and turns the interior
room lamp and map lamp ON for 30 seconds.
When driver door opens → closes, and the key is not inserted in the key switch (or not turned ignition knob
switch), BCM terminal 62 changes between 0V (door open) → 12V (door closed). The determines that condi-
tions for interior room lamp and map lamp operation are met and turns the interior room lamp ON for 30 sec-
onds.
Timer control is canceled under the following conditions.

Driver door is locked [when locked keyfob or power window main switch (door lock and unlock switch).
door key cylinder switch].

Driver door is opened (driver door switch terns ON).

Ignition switch ON.
INTERIOR LAMP BATTERY SAVER CONTROL
If interior lamp is left “ON”, it will not be turned out even when door is closed.
BCM turns off interior lamp automatically to save battery 30 minutes after ignition switch is turned off.
BCM controls interior lamps listed below:

Luggage room lamp

Vanity mirror lamp

Map lamp
