2004 HONDA ELEMENT Owners Manual

Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position.Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch so you can’t
move a mirror out of position by
accidentally bumping the switch.
Move the selector switch to L
(driver’s side) or R (passenger’s
side).
1. 2. 3.
If equipped
Mirrors
Inst rument s and Cont rols
Adjusting the Power Mirrors
82
TAB
SELECTOR SWITCH
ADJUSTMENT SWITCH
—
—y
y
(+
yy

To apply the parking brake, pull the
lever up f ully. To release it, pull up
slightly, push the button, and lower
the lever. The parking brake light on
the instrument panel should go out
when the parking brake is f ully
released (see page ).
To open a rear window, pull the lever
towards you, then push it out until it
locks. To close the rear window pull
the lever towards you, then push it
back. Make sure the window is f ully
closed and locked.
Toliftuptherearoftheskylightfor
ventilation, pull down the lever to
unlock the skylight, then push it up
until the skylight is locked in the tilt-
up position.
To close the skylight, pull down the
lever to unlock the skylight, then
push it back in place. Make sure the
skylight is f ully closed and locked.
54
CONT INUED
On 4WD models only
Inst rument s and Cont rols
Rear Windows, Parking Brake, Skylight
Parking Brake
Rear Windows Skylight
83
PARKING BRAKE LEVER
Driving the vehicle with the parking
brake applied can damage the rear
brakes and axles.
—
—y
y
(+
yy

Turn of f the engine, and set the
parkingbrake.Thenpulldownthe
lever, squeeze both sides of the pivot
while pushing up the red tab in the
lever, and pull the lever assembly
away from the ceiling.Push up the rear of the skylight.
Standing on the tailgate with the
hatch down, hold both sides of the
skylight and pull it toward you to
remove it f rom the vehicle roof .
To remove the skylight:
Skylight
Inst rument s and Cont rols84
Bef ore lif ting the skylight, make sure
the roof of the vehicle is dry. Rain or
remaining water af ter car-washing may
get into the f rame of the skylight. In
winter, remove the buildup of snow on
the roof .
If you try to tilt up the skylight in
below-f reezing temperatures, or when
it is covered with snow or ice, you can
damage it.
The maximum weight on the tailgate is
440 lbs (200 kg).
—
—y
y
(+
yy

With the rear seats in their upright
position, store the skylight, f ace
down in its bag in the cargo area.
Secure the bag with four hooks on
the cargo area f loor. Do not store
anything on top of the skylight.To reinstall the skylight, make sure
the air deflector is pushed down.
When reinstalling the lever assembly,
push in both red pivots, and align
with the receptacle holes. Let the
pivots move out until they rest in the
holes securely. Make sure the
skylight is f ully closed and latched.
Inst rument s and Cont rols
Skylight
85
An unsecured skylight can be
thrown about and cause serious
injury in a sudden stop or crash.
Make sure to store the skylight
in its bag, and secure the bag to
the hooks on the cargo areafloor.
—
—y
y
(+
yy

ÎÎ
Î
Î
Î Î
Î
Interior Convenience Items
Inst rument s and Cont rols86
CARGO AREA COIN TRAY
CARGO AREA
SIDE POCKET
DOOR POCKETS VANITY MIRROR
RADIO POCKET
ACCESSORY
POWER
SOCKET
GLOVE BOX
CENTER LOWER POCKET
BEVERAGE HOLDERS CEILING POCKET
: If equipped BUNGEE CORDSSEAT-BACK POCKET
—
—y
y
(+
y
y

These sockets are intended to supply
power f or 12 volt DC accessories
that are rated 120 watts or less (10
amps).
To power an accessory, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position.
When both sockets are begin used,
the combined power rating of each
accessory should be 120 watts or less
(10 amps).
These sockets will not power an
automotive type cigarette lighter
element.Open the glove box by pulling the
bottom of the handle. Close it with a
f irm push. Lock or unlock the glove
box with the master key.
Be caref ul when you are using the
beverage holders. A spilled liquid
that is very hot can scald you or your
passengers. Spilled liquids can also
damage the upholstery, and
electrical components in the interior.
Your vehicle has one or two
accessory power sockets, depending
on the model. All models have a
f ront accessory power socket on the
dashboard above the glove box.
The EX model has another
accessory power socket in the cargo
area on the passenger’s side.
On EX models
Interior Convenience Items
Inst rument s and Cont rols
Beverage Holders
Glove Box
A ccessory Power Sockets
87
An open glove box can cause
serious injury to your passenger
inacrash,evenifthe
passenger is wearing the seatbelt.
Always keep the glove box
closed while driving.
—
—y


y
(+
yy

The ceiling light has a three-position
switch: ON, Door Activated, and
OFF.
In the Door Activated (center)
position, the light comes on when
you:Open any door.
Remove the key from the ignition.
If you do not open a door, the light
f ades out in about 30 seconds.
Unlock the doors with the key or
remote transmitter. The cargo area light has a three-
position switch. In the center
position, the light comes on when
you open the hatch.
Turn on the spotlight by pushing the
lens. Push the lens again to turn it
of f . You can use the spotlights at all
times.
The ignition switch light comes on
when you unlock the driver’s door,
and f ades out about 30 seconds af ter
you close the door.
On EX models
Interior Lights
Ceiling L ight
Spotlights
Cargo Area Light
Ignition Switch L ight
Inst rument s and Cont rols88
ON
OFF DOOR ACTIVATED
—
—y
y
(+
yy

The heating and air conditioning
systems in your Honda provide a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section de-
scribes those f eatures and how to
use them. (If you selected an
optional audio system, ref er to the
operating instructions that came
with it.)
Your Honda has an anti-thef t audio
system that requires a code number
to enable it................
Vents, Heating, and A/C . 90
.........................
Air Flow Buttons . 91
............................
Playing the Radio . 94
..............................
Radio Reception . 97
....................................
Playing a CD . 99
....................
Protecting Your CDs . 101
.........
CD Player Error Messages . 102
.....
CD Changer Error Messages . 103
.................
Radio Thef t Protection . 104
..........................
Setting the Clock . 105
......................
Auxiliary Input Jack . 106
...............................
Cruise Control . 107
Comf ort and Convenience Features
Comf ort and Convenience Feat ures89
—
