Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.With the trunk lid open, air f low can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
trunk lid open, open all the windows
and set the heating and cooling
system as shown below.
If you must sit in your parked vehicle,
even in an unconf ined area, with the
engine running, adjust the heating
and cooling system as f ollows:
Select the Fresh Air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
Have the exhaust system inspected
f or leaks whenever:
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the under-
side. 1.
2.
3.
4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety46
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury. Read these labels caref ully. If
a label comes of f or becomes hard to
read, contact your Honda dealer f or
a replacement.
CONT INUED
U.S. modelsCanadian models
U.S. models only
Saf ety L abels
Driver and Passenger Saf ety47
RADIATOR CAP SUN VISOR
DASHBOARD

On models without side airbagsOn models with side airbags
Saf ety L abels
Driver and Passenger Saf ety48
HOOD

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your Honda. All the essential
controls are within easy reach............................
Control Locations .50
............................
Instrument Panel .51
.............................................
Gauges .59
.....................................
Odometer .60
...................................
Trip Meter .60
.................
Current Fuel Mileage . 60
................................
Trip Mileage .60
Turning Of f the Mileage .....................................
Display .61
..................................
Fuel Gauge .61
.........
IMA Battery Level Gauge . 62
................
Charge/Assist Gauge . 63
...................
Temperature Gauge . 63
Controls Near the Steering ...........................................
Wheel .64
.
Windshield Wipers and Washers . 65
...........
Turn Signal and Headlights . 66
........
Instrument Panel Brightness . 67
.................
Hazard Warning Button . 67
.................
Rear Window Def ogger . 68
..........
Steering Wheel Adjustment . 69
...............................
Keys and Locks .70
........................
Immobilizer System .71
................................
Ignition Switch .72 ......................................
Door Locks .73
..................................
Door Locks .73
......................
Power Door Locks .73
..............
Childproof Door Locks . 73
...........................................
Trunk .74
........
Emergency Trunk Opener . 74
.......................
Remote Transmitter .75
.................................................
Seats .77
..............................
Power Windows .79
.............................................
Mirrors .81
.................................
Parking Brake .82
.................................
Interior Lights .83
...........
Interior Convenience Items . 84
.......................
Beverage Holders .85
..........
Accessory Power Sockets . 85
....................................
Glove Box .85
...............
Console Compartment . 85
Instruments and Controls
Inst rument s and Cont rols49

AT model is shown.
Control L ocations
Inst rument s and Cont rols50
HEATING/COOLING CONTROLS
FUEL FILL DOOR RELEASE
TRUNK RELEASE CRUISE CONTROL SWITCHES
CRUISE CONTROL
MASTER SWITCH
POWER DOOR LOCK
SWITCH
MIRROR
CONTROLS
HOOD RELEASE
HANDLE
POWER WINDOW
SWITCHES AUDIO SYSTEM
DIGIT
AL CLOCK
(P.
88)
ACCESSORY POWER
SOCKET
(P. 109)
(P. 117)
(P. 74)
(P.
115)
(P.
109)
(P.
73)
(P.94)
(P. 108 )
(P.
81)
(P. 79)
(P.85)

Î
ÎThe U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
Automatic Transmission(CVT)
51
CRUISE CONTROL INDICATOR
SIDE AIRBAG OFF INDICATOR
CHARGING SYSTEM
INDICATOR
AUTO IDLE STOP
INDICATOR
MALFUNCTION INDICATOR LAMP ELECTRIC POWER STEERING(EPS)
INDICATOR SHIFT LEVER POSITION
INDICATOR LOW FUEL INDICATOR
MAINTENANCE REQUIRED INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATOR
SUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR
IMMOBILIZER SYSTEM INDICATOR HIGH BEAM INDICATOR
TRUNK-OPEN INDICATORIMA SYSTEM
INDICATOR
LOW OIL PRESSURE INDICATOR (P.
56)
(P. 56)
(P. 53)
(P. 53)
(P. 53)
(P. 54, 191)
(P. 137)
(P. 55)
(P.54, 190)
(P.55)(P.
133) (P.
56) (P.
55)
(P.
56)
(P.
54)
(P.
58)
(P.
54)
SEAT BELT INDICATOR
ANTI-LOCK BRAKE
SYSTEM INDICATOR
(P. 192)

Instrument Panel
Inst rument s and Cont rols
Manual Transmission
52
CRUISE CONTROL INDICATOR
SIDE AIRBAG OFF INDICATOR
CHARGING SYSTEM
INDICATOR
AUTO IDLE STOP
INDICATOR
MALFUNCTION INDICATOR LAMP LOW OIL PRESSURE INDICATOR ELECTRIC POWER STEER ING(EPS)
INDICATOR LOW FUEL INDICATOR
MAINTENANCE REQUIRED INDICATOR
SUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR
IMMOBILIZER SYSTEM INDICATOR HIGH BEAM INDICATOR
TRUNK-OPEN INDICATOR
SHIFT UP/SHIFT DOWN
INDICATORS IMA SYSTEM
INDICATOR
(P.
56)
(P. 56)
(P. 53)
(P. 53)
(P. 53)
(P. 54, 191)
(P. 132)
(P. 55)
(P.55)(P.
132) (P.
56) (P.
55)
(P.
56)
(P.
54)
(P.
58)
(P.
54)
(P. 54, 190)
SEAT BELT INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATOR
ANTI-LOCK BRAKE
SYSTEM INDICATOR
(P. 192)

Only on models equipped with sideairbags
The instrument panel has many
indicators to give you important
inf ormation about your vehicle. This indicator comes on when you turn the ignition switch to ON (II). If
it comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
or automatic seat belt tensioners.
For more inf ormation, see page .This indicator comes on when you
turn the ignition switch to ON (II). If
it comes on at any other time, it
indicates that the passenger’s side
airbag has automatically shut off.
For more inf ormation, see page .
The seat belt system includes an
indicator on the instrument panel
and a beeper to remind you and your
passengers to f asten your seat belts.
If you turn the ignition switch to ON
(II) bef ore f astening your belt, the
beeper sounds and the indicator
f lashes. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator stops f lashing but remains
on.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals. 26
27
Supplemental Restraint
System Indicator
Side Airbag Of f Indicator
Seat Belt Indicator
Inst rument s and Cont rols
Instrument Panel
53
