2004 DODGE SPRINTER ESP

WHAT TO DO IN EMERGENCIES 201
6
If the Engine is DamagedFor towing distances up to 30 miles (about 50 km)
 Shift selector lever to "N" position.
 Do not exceed a towing speed of 30 mph (50 km / h).
For towing distances greater than 30 miles (about
50 km)
 Remove the propeller shafts leading to the drive
axles.
The vehicle can be towed without restriction.If the Transmission is Damaged Remove the propeller shafts leading to the drive
axles.
WARNING!
Do not tow the vehicle if the key cannot be turned
in the ignition lock.
If the key cannot be turned, the ignition lock re-
mains locked and the vehicle cannot be steered.
With the engine not running there is no power
assistance for the braking and steering systems.
In this case, it is important to keep in mind that a
considerably higher degree of effort is necessary
to brake and steer the vehicle.
The vehicle must not be towed with the front axle
raised and the key in position 2 in the ignition
lock as the drive wheels could then lock due to the
acceleration skid control (ASR) or the optional
Electronic Stability Program (ESP).
Freightliner-all.book Pag e 201 Monday, December 1, 2003 2:54 PM

208 MAINTAINING YOUR VEHICLEDisposal of Service ProductsDispose of service products and of parts which come
into contact with them (e.g. filters) in an
environmentally responsible manner. Comply with
applicable bars and regulations.EMISSION RELA TED COMPONENT WA RRA NTY
STATEMENTThe Manufacturer warrants to the original and each
subsequent owner of a MERCEDES-BENZ heavy-duty
on highway diesel engine that:
(1) the engine was designed, built and equipped so as
to conform at the time of sale with the applicable
regulations adopted by the Federal Environmental
Protection Agency
(2) the emission control system of such engine is free
from defects in materials and workmanship which
would cause it not to conform with those regulations
for a period of use of five years or 100 000 miles or
3 000 hours of engine operation, whichever occurs
first.
REGULA R CHECKSThe following checks should be performed at regular
intervals (for example once a week or each time the
vehicle is refueled):
 Windshield cleaner system – fluid reservoir.
 Air strainer, in vehicles with an air strainer element
maintenance indicator (optional equipment).
 Engine oil level.
 Checking ribbed V-belt.
 Hydraulic brake system, clutch mechanism fluid
level.
 Coolant level.
 Tire and spare wheel condition and pressures of the
same. For more information, refer to "Wheels and
Tires".
 Vehicle lighting.
Freightliner-all.book Pag e 208 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 213
7
Have the coolant renewed at least every five years or
after 100,000 miles.
When the coolant is renewed, the new coolant should
contain 50% antifreeze/corrosion inhibitor by volume.
This corresponds to antifreeze protection down to -
37 °C/-35°F.
Do not exceed a proportion of about 55 % by volume
(antifreeze protection down to about -45 °C/-49 °F) as
the heat dissipation properties then deteriorate.
In the event of coolant loss, do not add water only, but
sufficient antifreeze/corrosion inhibitor to maintain
the correct concentration.
The water in the coolant must satisfy certain
requirements. These are often met by tap supply
drinking water.
The water must be specially prepared if the water
quality does not come up to the required standards.
Have the corrosion inhibitor/antifreeze concentration
in the coolant checked at the outset of winter,
respectively once a year in countries with high
prevailing temperatures.A regular check is included in the maintenance service.
Checking Coolant LevelCoolant reservoir (1)
The cooling system is pressurized. Only check the
coolant level with the vehicle parking on a level surface
and with the engine switched off.
– Wait until the coolant temperature has dropped
below 194 °F (+90 °C).
Freightliner-all.book Pag e 213 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 217
7
Reconnecting the Battery1. Vent tube
2. Fitting
All electrical consumers must be switched off. First
connect and tighten the positive terminal clamp, then
the negative terminal. Make sure that the terminal
clamps are not switched.
NOTE: If batteries have to be replaced, only use
batteries with a central vent cap as this will prevent
corrosion damage.
Connect the battery vent tube (1) to the fitting (2).
Charging the BatteryDisconnect the battery before charging it with a battery
charger.
Comply with the operating instructions for the battery
charger.
To ensure that the battery is disposed of in an
environmentally responsible manner, it should only be
replaced by an authorized Sprinter Dealer.
Batteries contain material that can harm the
environment with improper disposal.
Large 12 volt storage batteries contain lead.
Recycling of batteries is the preferred method of
disposal.
Many states require sellers of batteries to accept old
batteries for recycling.
Freightliner-all.book Pag e 217 Monday, December 1, 2003 2:54 PM

248 MAINTENANCE SCHEDULES
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S8
INTRODUCTIONThis is intended as a guide to the service requirements
of your vehicle.
It contains all necessary instructions concerning
service intervals and operations which have to be
carried out.
Scope and frequency of maintenance work primarily
depend on the vehicle's operating conditions.
In the interest of maintaining the vehicle's operating
safety, the specified work should be performed
regularly and in good time.
Our vehicles are subject to ongoing development.
Technical progress may also affect the scope of service
work performed.
"Daily vehicle checks" before starting a journey are the
responsibility of the driver.
WA RRA NTYThe Sprinter Dealer network is at your disposal for
maintenance work. Each of these workshops has the
equipment and tools, the specially trained, skilled and
experienced personnel and receives regular technical
instruction from DaimlerChrysler Corporation to
ensure that your vehicle is inspected and maintained
thoroughly and in accordance with the latest
procedures.
Please follow the instructions given in this Owner’s
Manual and ensure that they are observed, even if you
hand the vehicle over to a third party for use or care. By
not observing these instructions you may void your
warranty rights.
If the specified oil and maintenance services are not
carried out regularly or at the time intervals specified,
a decision as to the validity of a warranty claim can
only be made after DaimlerChrysler Corporation has
investigated your claim.
Freightliner-all.book Pag e 248 Monday, December 1, 2003 2:54 PM

258 IF YOU NEED CONSUMER ASSISTANCEService Contract
You may have purchased a service contract for your
vehicle to help protect you from the high cost of
unexpected repairs after your manufacturer’s new
vehicle limited warranty expires. The manufacturer
stands behind only the manufacturer’s Service
Contracts. If you purchased a manufacturer’s Service
Contract, you will receive Plan Provisions and an
Owner Identification Card in the mail within three
weeks of your vehicle delivery date. If you have any
questions about your service contract, call the
manufacturer’s Service Contract National Customer
Hotline at 1-800-521-9922.
The manufacturer will not stand behind any service
contract that is not the manufacturer’s Service
Contract. It is not responsible for any service contract
other than the manufacturer’s Service Contract. If you
purchased a service contract that is not a
manufacturer’s Service Contract, and you require
service after your manufacturer’s new vehicle limited
warranty expires, please refer to your contract
documents and contact the person listed in those
documents.We appreciate that you have made a major investment
when you purchased your new vehicle. Your dealer
has also made a major investment in facilities, tools,
and training to assure that you are absolutely
delighted with your ownership experience. You’ll be
pleased with their sincere efforts to resolve any
warranty issues or related concerns.Freightliner-all.book Pag e 258 Monday, December 1, 2003 2:54 PM
